Micromax A92 User manual

A92

Model A92 2
WELCOME
Welcome to the Micromax family. Congratulations on becoming a proud
owner of the Micromax A92 Android phone. Your A92 device offers you
the following exciting features and much more:
Android 4.1.2 Platform: Your A92 comes packaged with Android 4.1.2
OS meaning that your Mobile phone is based on a versatile operating
system.
5.0 Megapixel Camera: The 5.0 Megapixel camera allows you to take
crisp and sharp high quality pictures and videos any time.
1 GHz Dual Core Processor: To give you speed in handling your
applications
5 Inch Capacitive Touch screen: Gives you an intuitive and friendly
Interface allowing you to operate your phone with finesse.
Pinch Zoom Feature: You can use the pinch zoom command to magnify
images and web pages displayed on your interface.
Intelligent User Interface: The Intelligent and highly intuitive User
interface makes your access to the features a smooth ride.
Memory Card Support: Expandable up to 32 GB, it lets you store and
back up audio and video files.
Wi-Fi: The Wi-Fi features lets you connect wirelessly and seamlessly
with your Wi-Fi network.
Bluetooth: Lets you exchange files and information with Bluetooth
enabled devices.

Model A92 3
THE ANDROID ADVANTAGE
An Android TM Phone can perform many of the same functions as a
computer and you can customize it to your own needs. For example, you
can add and remove applications or upgrade existing applications to
improve the functions. At Android market, you can download a range of
applications and games from an ever growing collection. You can also
integrate applications on your android phone with other applications and
with online services that you use.
READ ME FIRST
Please read all safety precautions and this manual carefully before
using your device to ensure safe and proper use.
The descriptions in this manual are based on the default settings of
your device.
Available features and additional services may vary by device,
software, or service provider.
Applications and their functions may vary by country, region, software
or hardware specifications. Micromax is not liable for performance
issues caused by third-party applications.
D
DI IS SC CL LA AI IM ME ER RS S: :
Talk and Standby time are affected by Network preferences, type of
SIM card, and individual usage patterns.
Specifications are subject to change without prior notice. Services and
some features may be dependent on the network, or service content

Model A92 4
provider.
Images shown in this User Guide are for representation only. Other
product logos and company names mentioned/used herein may be
trademarks or trade names of their respective owners.
The functions explained or listed in this manual may differ from the
actual functions appearing in the device. In such a case, the latter shall
govern.
Content in this user manual may differ based on software provided by
service providers or carriers, and is subject to change without prior
notice.
Micromax reserves the right to make modifications to the content in
this user guide without any prior notice.
I
IN NS ST TR RU UC CT TI IO ON NA AL L I IC CO ON NS S
Before you start, please familiarize yourself with the icons you will see in
this manual:
Information: Provides useful information
Warning: Situations that could cause injury to yourself or others
Caution: Situations that could cause damage to your device or other
equipment
Tips to help you with the features.

Model A92 5
CONTENTS
WELCOME 2
THE ANDROID ADVANTAGE 3
READ ME FIRST 3
DISCLAIMERS: .........................................................................3
INSTRUCTIONAL ICONS..............................................................4
CONTENTS 5
PHONE LAYOUT 8
ICONS AND INDICATORS 9
INSERT SIM CARD....................................................................9
INSERT MEMORY CARD 10
TURN THE PHONE ON AND OFF 11
CHARGE THE BATTERY ...........................................................12
LOCK/UNLOCK YOUR PHONE ...................................................12
USING THE TOUCH SCREEN 13
TOUCH AND HOLD..................................................................13
DRAG AN ITEM .......................................................................14
SCROLL ................................................................................15
SWIPE…...............................................................................15
USING THE PINCH ZOOM.........................................................16
DOUBLE-TAP..........................................................................16
CHANGE THE ORIENTATION .....................................................17
TOUCH THE LAUNCHER ICON TO OPEN THE MAIN MENU...............17

Model A92 6
PLACING AND RECEIVING CALLS 18
MAKE A CALL.........................................................................18
CONFERENCE CALL................................................................19
MAKE AN INTERNATIONAL CALL................................................20
END ACALL ..........................................................................20
DISABLE PHONE CALLS ..........................................................20
SCREEN LOCK 21
USING THE HANDSET’S KEYS ..................................................21
THE HOME SCREEN 22
SWITCH BETWEEN HOME SCREENS.........................................22
REARRANGE ITEMS ON THE HOME SCREEN ..............................22
CUSTOMIZE HOME SCREEN ....................................................23
WORKING WITH MENUS 24
MENU ICONS .........................................................................24
CONTEXT MENU ....................................................................24
OPTIONS MENUS ...................................................................25
MANAGING NOTIFICATIONS 26
OPEN THE NOTIFICATIONS PANEL ............................................26
TOOLKITS..............................................................................27
MESSAGING 28
CREATE AND SEND MULTIMEDIA MESSAGE ...............................29
FORWARD A MESSAGE ............................................................29
LOCK A MESSAGE ..................................................................30
USING THE ONSCREEN KEYBOARD ..........................................30
USE VOICE COMMAND............................................................31

Model A92 7
MULTIMEDIA 31
CAMERA ...............................................................................31
GALLERY...............................................................................32
MUSIC…………………………………………………………….33
COPY SONGS FROM YOUR PC.................................................34
FM RADIO.............................................................................34
RECORD SOUND....................................................................34
CONNECT TO NETWORKS AND DEVICES 34
CONNECT TO THE INTERNET....................................................34
PAIR WITH BLUETOOTH DEVICES.............................................36
MANAGE ACCOUNTS 37
WHY USEA GOOGLE ACCOUNT...............................................37
START GMAIL.........................................................................38
GOOGLE SEARCH ..................................................................38
SYNCHRONIZE CONTACT LIST..................................................39
APPLICATIONS 39
MAPS……………………………………………………………..39
SAFETY PRECAUTIONS 40
TAKING CARE OF YOUR DEVICE 42
COPYRIGHT...........................................................................44
INDEX 45

Model A92 8
PHONE LAYOUT

Model A92 9
ICONS AND INDICATORS
I
IN NS SE ER RT T S SI IM M C CA AR RD D
When you subscribe to a cellular service, you will receive a Subscriber
Identity Module (SIM) card, with subscription details, such as your
personal identification number (PIN) and optional services.
To insert SIM card(s):
1. Switch off the mobile phone and remove the rear cover and battery.
2. Insert the SIM card correctly in the card slot(s) (See figure below).
Icons
Indicators
Icons
Indicators
Signal strength indicator
Alarm has been
set
New missed calls
Wi-Fi networks
available
USB is connected
Bluetooth is on
The headphone is being
used
Battery level
New message
Airplane mode is
activated

Model A92 10
3. Finally insert the battery and replace the rear cover of the mobile
phone.
Please keep the SIM Card out of the reach of small children.
The card and the contacts are vulnerable to damage due to
scratching or bending. Therefore, be careful when using, inserting
or removing the cards
INSERT MEMORY CARD
To store additional multimedia files, you must insert a memory card.
1. Power off the mobile phone, and then remove the rear cover and
battery.
2. Insert the memory card into the slot.

Model A92 11
3. Finally insert the battery and the rear cover of the mobile phone.
Use only compatible memory cards approved by Micromax
with this device. Incompatible memory cards may damage
the card or the device and corrupt the data stored in the
card.
TURN THE PHONE ON AND OFF
Switch On: Press and hold the Power key for a few seconds.
Switch Off: Press and hold the power key and select switch off.
If the phone lock has been activated, you need to enter the
password to unlock.
If the SIM card has been inserted in the phone, and the
related PIN code protection is activated, you need to enter
the required password to unlock.
Warning: If you enter three wrong PIN codes in a row, the
SIM card will be locked and you need to enter the PUK code
to unlock. Both the PIN code and PUK code are provided by
the network operator.

Model A92 12
C
CH HA AR RG GE E T TH HE E B BA AT TT TE ER RY Y
Before using the device for the first time, you must charge the battery.
You can charge the device with a travel adapter or connecting the device
to a PC with a USB cable.
.
.
Tip: You can also use a compatible USB charger to charge your
battery.
Use only Micromax approved chargers and cables. Unapproved
chargers or cables can cause batteries to explode or damage your
device.
We suggest you charge the battery for 4 hours continuously for the
first time.
L
LO OC CK K/ /U UN NL LO OC CK K Y YO OU UR R P PH HO ON NE E
You can lock the phone using Pattern lock, PIN, Password or Face Unlock.
Go to Settings>Security>Screen lock to set your preference.
To unlock the phone, do one of the following:
Press and hold the Power key. The LCD shows up a with a lock
icon.
Slide the lock icon towards the unlock icon to unlock the phone.
If the phone lock has been activated, you need to enter the unlock
code.

Model A92 13
Using Pattern Lock
Pattern Lock is a security feature you can enable on your phone to
prevent it from unauthorized access. You can draw a pattern by
connecting the dots (as shown below).
USING THE TOUCH SCREEN
You can use the touch screen in the following ways:
T
TO OU UC CH H A AN ND D H HO OL LD D
Touch and hold an item. An action occurs depending on the situation.

Model A92 14
D
DR RA AG G A AN N I IT TE EM M
Touch and hold an item and move your finger on the screen until you
reach the target position.
Tap and hold the item, and slide your finger across the screen. The item
follows your finger.

Model A92 15
You can generally drag items on the home screen.
S
SC CR RO OL LL L
Quickly slide your finger across the surface of the screen, (without
dragging an item). For example, slide the screen up or down to scroll a
list.
S
SW WI IP PE E
Place a finger on the screen, and steadily slide your finger in the desired
direction.

Model A92 16
For example, when you are viewing a picture, to view the next picture,
swipe left.
U
US SI IN NG G T TH HE E P PI IN NC CH H Z ZO OO OM M
You can open any image or web page and then use your thumb and index
finger to zoom the display through the pinch gesture as illustrated below.
D
DO OU UB BL LE E- -T TA AP P

Model A92 17
Tap quickly twice on a webpage, map, or other screen to zoom. For
example, double-tap a section of a webpage in Browser to zoom that
section to fit the width of the screen. You can also double-tap to control
the Camera zoom, in Maps, and in other applications.
C
CH HA AN NG GE E T TH HE E O OR RI IE EN NT TA AT TI IO ON N
On most screens, the orientation of the screen changes as you rotate it.
You can turn this feature on and off. You can change the screen
orientation by rotating the handset.
T
TO OU UC CH H T TH HE E L LA AU UN NC CH HE ER R I IC CO ON N T TO O O OP PE EN N T TH HE E M MA AI IN N M ME EN NU U
You can add an application icon to the Home screen by pressing and
holding it until it vibrates and enters Home screen and then release your
finger.

Model A92 18
PLACING AND RECEIVING CALLS
You can dial a phone number or touch a number in your contacts.
You can also place a call from the Call log or messages.
M
MA AK KE E A A C CA AL LL L
1. Tap the icon on main menu or the home screen to dial the desired
number.
2. Tap on any of the Phone, Call Log or Contacts tab to make a call.
3. Tap on the contact to dial the number.
4. Press the Volume Up/ down keys on the left side to adjust the call
volume.
In Call Options
Touch the icon to add another person to the call.
Touch the icon to mute your voice so that the phone’s MIC will
not transmit voice to the other end. You can resume transmitting
your voice by pressing the icon again.
Touch the icon to hold the call. Touch the icon again to resume
the call.
Touch the icon to listen via the speaker.
Touch the icon for DTMF inputs.

Model A92 19
End the call by pressing the icon.
C
CO ON NF FE ER RE EN NC CE E C CA AL LL L
Your device supports conference calls (network service) between select
number of participants, including yourself.
If you dial or accept a new call when you are already on a call, you can or
merge the calls into a conference call.
1. Place a call to the first participant.
2. When you are connected, touch the icon and dial the number.
The first participant is put on hold. You can also place the next call,
using the phone tab, the Call log, or your contacts.
3. When you are connected, touch icon. The participants are added
to the conference call.

Model A92 20
4. You can also swap calls by tapping on icon.
Note: You may need to contact your service provider to activate conference
calling feature on your SIM card.
M
MA AK KE E A AN N I IN NT TE ER RN NA AT TI IO ON NA AL L C CA AL LL L
To dial an international number, touch and hold the ‘0’key from the dial
pad to enter the Plus (+) symbol, and then enter the international country
prefix, followed by the phone number
1. Touch the icon to dial the number.
2. Press the Volume Up/ down keys on the left side to adjust the call
volume.
E
EN ND D A A C CA AL LL L
While during a call, touch the icon.
D
DI IS SA AB BL LE E P PH HO ON NE E C CA AL LL LS S
Some locations may require you to turn off your mobile, Wi-Fi, and
Bluetooth wireless connections.
Press and hold the Power button and then choose Airplane Mode.
Drag notification panel down then touch the icon.
