Middle Atlantic Products ASR Series User manual

I-00140 Rev G
ASR SERIES
Slide-Out Rotating Shelf System
Instruction Sheet
THANK YOU
Thank you for purchasing the ASR Slide-Out Rotating Shelf System. Please read
these instructions thoroughly before installing / assembling this product.
PRODUCT FEATURES
- Adjustable shelving
- Cable management included
- Easy access to rear connections

Page 2
PARTS LIST
A
B
C
D
E
F
G
H
J
K

Page 3
PARTS LIST (CONTINUED)
PART
NAME
TOP
PANEL
BOTTOM
PANEL/SHELF
SHELF
BASE
(2 SLIDES)
BASE
(4 SLIDES)
SIDE
LOCKING
BRACKET
MOUNTING
TEMPLATE
LOCKING
PANEL
LACER
BAR
LETTER
DESIGNATION
A
B
C
D
E
F
G
H
J
K
ASR-30
1
1
3
1
2
1
1
1
1
ASR-36
1
1
4
1
2
1
1
1
1
ASR-42
1
1
5
1
2
1
1
1
2
ASR-48
1
1
6
1
2
1
1
1
2
QUANTITY
MODEL NUMBER

Page 4
HARDWARE LIST
L
M
N
O
P
S
R
T
Q
U
V
15" Velcro hook adhesive
15" Velcro loop non-adhesive
5/8" Dia.
Velcro Loop
7/8" Dia.
Velcro Hook
(Actual size)
(Actual size)
(Actual size)
(Actual size)
(Actual size)
(Actual size)
middleatlantic.com
W
X
®
®
®
®

Page 5
HARDWARE LIST CONTINUED
* 5/8"X15.5" VELCRO LOOP
** 5/8"X15.5" VELCRO HOOK
PART
NAME
SWIVEL
DISC
1" SHOULDER
BOLT
1-1/4"
WOODSCREW
5/8"
WOODSCREW
3/4" MACHINE
SCREW
5/8" DIAMETER
VELCRO LOOP
7/8" DIAMETER
VELCRO HOOK
15-1/2"
VELCRO LOOP
15-1/2"
VELCRO HOOK
HEX KEY
DRIVER
NAIL
CABLE
STRAP
HEX DRIVER BIT
PART
REQUIRED
L
M
N
O
P
Q
R
*S
**T
U
V
W
X
ASR-30
4
1
25
14
2
16
16
4
4
1
1
12
1
ASR-36
4
1
29
14
2
20
20
5
5
1
1
12
1
ASR-42
4
1
33
24
2
24
24
6
6
1
1
24
1
ASR-48
4
1
37
24
2
28
28
7
7
1
1
24
1
QUANTITY
®
®
®
®
®
®

Page 6
TOOLS REQUIRED (User supplied)
- Hammer
- # 2 Phillips screwdriver
- Screwgun or drill: # 2 Phillips bit and low torque setting
- 1/8" Drill bit
- Clear or masking tape
DIMENSIONS
WEIGHT CAPACITIES
TIPPING HAZARD: Host enclosure (cabinet) MUST be adequately secured to the floor it
rests on to prevent cabinet from falling forward when shelving system
is extended for servicing. Shelving system must be secured to the host
enclosure as detailed in these instructions. Overloading equipment may
increase chances of tipping.
!
YOU ARE RESPONSIBLE: It is the responsibility of the installer to ensure millwork is
rated for the "Required Millwork Weight Capacity" and can
support the shelving system in the service (extended) position.
Failure to do so can result in serious damage to equipment and
or risk of injury. Installation must be performed in strict
adherence to the specifications within this instructions sheet.
!
*19.00" [483mm] Minimum width required leaves approximately 0.25" clearance per side
*Weight capacity of shelving system not to be exceeded by the total weight of equipment being installed in it. This is NOT
the required weight capacity of the host enclosure
Required Millwork Weight Capacity =Weight of ASR system without equipment + total weight
of equipment
Weight Distribution Warning: 1/2 of total equipment weight must be mounted in the lower 1/3
of the ASR shelving system
Part # Overall Height *Minimum Width Minimum Depth-No Setback Min. Depth-3/4" max. Setback Useable Inside height
ASR-30 30.00 [762] 19.00 [483] 20.00 [508] 20.75 [527] 25.40 [645]
ASR-36 36.00 [762] 19.00 [483] 20.00 [508] 20.75 [527] 31.40 [645]
ASR-42 42.00 [762] 19.00 [483] 20.00 [508] 20.75 [527] 37.40 [645]
ASR-48 48.00 [762] 19.00 [483] 20.00 [508] 20.75 [527] 43.40 [645]
Part # ASR Weight Capacity
Weight of ASR System
without Equipment
Single Shelf
Weight Capacity
Required Millwork
Weight Capacity
ASR-30 100 Lbs [46kg] 60 Lbs [27kg] 65 Lbs [30kg] see below
ASR-36 100 Lbs [46kg] 68 Lbs [31kg] 65 Lbs [30kg] see below
ASR-42 200 Lbs [91kg] 76 Lbs [35kg] 65 Lbs [30kg] see below
ASR-48 200 Lbs [91kg] 86 Lbs [39kg] 65 Lbs [30kg] see below

Page 7
Installation Opening Preparation
1) Install Lacer Bar(s) (K) onto rear wall of host enclosure
as shown. (FIGURE A) Your installation may require
Lacer Bars to be placed in a different position. Lacer Bar
placement should be arranged so that signal wires can be
separated from power/speaker cables upon finishing .
3) Ensure that installation opening is clean and clear of debris.
4) Plumb and level installation opening and mounting surface.
WARNING: Do not attempt installation unless base has
been proven to be level in 2 directions. Failure to do so may
result in the ASR Shelving System to slide out freely, causing
personal injury or damage to equipment installed in it.
REAR
WALL
(K)
FIGURE A
REAR
WALL
FIGURE B
2) Pull existing cables into host enclosure
and secure to Lacer Bar(s) so cables are
cleared from the installation opening.
(FIGURE B)
NOTE: Models ASR-30 and ASR-36 include 1
Lacer Bar which may be mounted horizontally if
better suited to your installation. Models ASR-42
and ASR-48 include 2 Lacer Bars.

Page 8
FIGURE A
LOCKING PANEL (J)
TOP VIEW
ROLLER
CENTER
HOLE
(D/E)
Line up rollers as shown
BASE
UNPACK AND INSTALL SYSTEM BASE / SLIDER ASSEMBLY
NOTE: If any parts are damaged or missing, call 1-800-266-7225. Do not return
to the place of purchase.
1) Unpack all parts carefully on a flat, clean surface. Inspect all packaging and
remove hardware kits before discarding.
2) Firmly press rollers into holes on base (D/E), using the locking panel (J) as a
straight edge guide (FIGURE A). Ensure all rollers are seated fully into holes
on base. If needed, gently tap around edges with a hammer, taking care not to
damage the plastic.

Page 9
TEMPLATE (H)
INSTALLATION
OPENING
FIGURE B
Template shown
in setback mounting
position
Template shown
in flush mounting
position
3) Use tape to attach the paper mounting template (H) to the base of the installation
opening. (FIGURE B)
NOTE: The template is marked with a dotted fold-line to help position for flush or setback
mounting. 3/4" setback is suggested when customer supplied doors are used.
4) Use the paper mounting template (H) to mark base installation holes and locking
bracket (G) installation holes with the supplied nail. Gently tap the nail with a hammer
to mark each hole location.
NOTE: ASR-30, ASR-36: 100 LB Capacity; uses 2 outer slides
ASR-42, ASR-48: 200 LB Capacity; uses all 4 slides
You may also choose to drill pilot holes in the marked mounting hole locations.
A 1/8" drill bit is required. Do not over-size the pilot holes, as over-sized holes will
compromise the strength of your mounting.

Page 10
(O)
LOCKING
PANEL (G)
(O)
FIGURE C FIGURE D
FRONT
FRONT
5) Remove the mounting template and mount the locking bracket (G) to the
base of the opening using (2) #12 wood screws (O) supplied (FIGURE C).
Place the base assembly in the opening with the flat edge facing the front of
the opening and the rounded corners facing the rear. Starting with the rear
most holes, fasten the slides to the mounting surface using the #12 wood
screws (O) provided. Then, install the remaining screws to attach each slide
to the mounting surface securely, 4 screws per slide total. (FIGURE D)

Page 11
FIGURE E
Install these
screws first
(F)
(A)
(B)
1) Assemble bottom panel/shelf (B) to steel side panels (F)
using 6 large screws (N). Start by placing the
rear edge of the base panel/shelf on a sturdy surface
and the flanged edge of the side panel in the outer
position (FIGURE E). Attach the top (A) as shown,
starting with the circular holes, then fasten the oval holes.
ASSEMBLY AND INSTALLATION OF SHELVING SYSTEM NOTE: All holes in top & bottom
panels are arranged in such a way
that it is only possible to assemble
them in one fashion. DO NOT DRILL
NEW HOLES.
(N)
FRONT

Page 12
FIGURE F
FIGURE G
CENTER
HOLE
Shoulder bolt
Line up rear
edges to insert
shoulder bolt
FRONT
FRONT
(M)
2) Carefully lift the assembled shelving system into position on the base/slider assembly.
Use the rear edge of the shelving system for location. The rear of the shelving system
bottom should be flush with the rear of the system base/slider assembly and flush with
the sides of the installation opening (FIGURE F). Now, insert the 1" shoulder bolt (M)
into the hole in the center of the shelving system base. Thread the bolt by hand into the
receptacle in the base/slider assembly. Hand tighten only, do not over tighten. (FIGURE G)
Check the ease of system's rotation and back the shoulder bolt out slightly to ease rotation
if needed.
3) Slide shelving system in and out to check for interference. Install locking panel (J) to ensure
locking bracket (G) does not require adjustment. Adjust if needed.

Page 13
PROTECTIVE
BACKING
(R)
(Q)
1) Remove the locking panel (J) from the front of the shelving system (if installed).
Extend shelving system and rotate to allow for rear access of equipment to be
installed. Turn your first piece of equipment upside-down, taking care not to
damage any of the buttons, switches, other moving parts, or the finish of your
unit. Remove the tape Back from a small Velcro®circle (Q). Stick the Velcro®
circle (Q) to the foot of your unit. Next, mate a large Velcro®circle (R) to the small
Velcro®circle (Q). Repeat this process for all other feet on your piece of equipment
and press down firmly. (FIGURE H)
NOTE: Before proceeding with equipment
mounting, remove all media sources from
all devices. CD's, DVD's, VHS tapes, etc
EQUIPMENT AND SHELVING INSTALLATION:

Page 14
(N)
(C)
FIGURE H
NOTE: Before proceeding with equipment and shelf mounting: a minimum of 1/2" should be
added to the height of each piece of equipment to allow for heat to dissipate from
the top of each unit. However, you may choose to add more than 1/2" to the height
of each piece of equipment to result in evenly spaced shelves upon finishing. (See
Pages 15 & 16)
2) Mount the first adjustable shelf (C) above the unit already installed leaving at least
1/2" of room between the top of your component and the shelf, or enough space to
evenly distribute the rest of the adjustable shelves to be installed (FIGURE H).
Repeat for rest of shelves to be installed.
3) Attach the locking panel to the locking bracket/front of shelving unit using 2 black
machine screws. Check that the shelving unit stays closed securely.

Page 15
Height
NOT SUGGESTED
SUGGESTED
(ASR-36 SHOWN)
Measure equipment height including feet
This process will help you to place your components in the system beginning at the bottom,
evenly spaced, without trial and error.
PART #
ASR-30
23.125"
ASR-36
28.375"
ASR-42
33.625"
ASR-48
38.875"
AVAILABLE MOUNTING SPACE
ENTER TOTAL COMPONENT HEIGHT
Add up the heights of all components, measuring
as shown above. Record the overall height
dimension on Line A, in the appropriate column.
Subtract Line A from AVAILABLE MOUNTING SPACE
DIVIDE UNUSED SPACE
Divide Line B by the number indicated.
INDIVIDUAL COMPONENT GAP
This is the amount of space that goes above
each component. If there isn't a hole at this
dimension, use the hole below
AAA A
BBB B
C
4
C
5
C
6
C
7
Weight Distribution Warning: 60% of total equipment weight must be mounted
in the lower 30% of the ASR shelving system.
"
"
"
"
"
"
"
"
"
"
"
"

Page 16
C
ASR-36
28.375"
AVAILABLE MOUNTING SPACE
ENTER TOTAL COMPONENT HEIGHT
Add up the heights of all components.
Record the overall height dimension
on Line A, in the appropriate column.
Then subtract Line A from
AVAILABLE MOUNTING SPACE
A
B
2.30" [58mm]
2.30" [58mm]
2.30" [58mm]
2.30" [58mm]
COMPONENT 1
COMPONENT 2
COMPONENT 3
COMPONENT 4
FRONT VIEW
2.30" [58mm]
3.50" [89mm]
3.25" [83mm]
3.50" [89mm]
3.25" [83mm]
3.25" [83mm]
16.75" [425mm]
*EXAMPLE *
+
5
DIVIDE UNUSED SPACE
Divide Line B by the number indicated
INDIVIDUAL COMPONENT GAP
This is the amount of space that goes above
each component. If there isn't a hole at this
dimension, use the hole below
"
"
"
COMPONENT 5
Example showing 5 components being installed in an ASR-36

Page 17
REAR
WALL
Double Sided
Cable Straps
CABLE MANAGEMENT
1) Pull out and rotate shelving system in the direction you prefer.
HINT: Once cables are connected to equipment installed in the shelving
system and laced to Lacer Bar(s), the shelving system will be restricted
and should only be turned in the direction chosen.
2) Select one side of shelving system for signal cables, and the opposite side
for power and speaker cables. Lace cables as shown, ensuring cables are fairly taut.
This ensures that the service loop will be the correct length and not be pinched
when closing the rack.
3) Cable Management Tip:
Tie your cable bundles at least every 6" - 8". This allows cable bundles to lay neatly
together when shelving system is in the closed position.
WARNING: To reduce to risk of electrical shock, complete the following
steps before supplying power to equipment.
NOTE: CABLE STRAPS ARE
PROVIDED AND SHOULD
BE USED ON THE LACER BARS
TO HOLD WIRES IN PLACE

WARRANTY
Middle Atlantic Products, Inc. (the "Company") warrants the ASR Series Slide-out Rotating
Shelf System to be free from defects in material or workmanship under normal use and conditions
for a period of (3) three years from date of shipment by the Company.
The Company's entire liability to the purchaser, and the purchaser's (or any other parties) sole and
exclusive remedy, under this warranty shall be limited, at the Company's option, to either (a) return
of and refund of the price paid for, or (b) repair or replacement at the Company's factory of the
products purchased, or any part or parts thereof, which the Company has determined to be
defective after inspection thereof at the Company's factory.
This warranty does not cover damage due to acts of God, accident, misuse, abuse or negligence by
parties other than the Company, or any modification or alteration of the products. In addition, this
warranty does not cover damage due to improper handling, assembly, installation or maintenance.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND, EITHER EXPRESSED OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL THE COMPANY
BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE OF THE
PRODUCTS PURCHASED, EVEN IF THE COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. THE COMPANY'S LIABILITY TO THE PURCHASER (OR ANY OTHER PARTY)
HEREUNDER, IF ANY, SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCTS
PAID TO THE COMPANY.
Corporate Headquarters
Corporate Voice 973-839-1011 - Fax [phone]
International Voice [phone] - Fax [phone]
middleatlantic.com - [email protected]
Middle Atlantic Canada
Voice 613-836-2501 - Fax [phone]
middleatlantic.ca - [email protected]
Factory Distribution
USA: NJ - CA - IL Canada: ON - BC
At Middle Atlantic Products we are always listening. Your comments are welcome.
Page 18
Middle Atlantic Products is an ISO 9001 Registered Company.
30% Recycled Paper

Page 19
INSTALLATION NOTES
