Middle Atlantic Products Lever Lock VWM Series User manual

I-00802 Rev A
VWM SERIES
Lever Lock™ Front Door Option
Instruction Sheet
Thank you for purchasing a VWM Lever Lock™ Front Door option. Please read these instructions
thoroughly before installing or assembling this product.
For more information, refer to the VWM Series
Vertical Wall Mount Rack Instruction Sheet (I-00796).
THANK YOU
• Allows mounting of select Lever Lock accessories from inside the front door
• Includes 10” Lever Lock™ plate with universal mounting pattern
• Allows for the horizontal mounting of other 17” vertical Lever Lock options
(LL-XX-17)
• Patented, tool-free Lever Lock™ system facilitates cable management and
device mounting
PRODUCT FEATURES

REQUIRED TOOLS
Page 2
SUPPLIED COMPONENTS AND HARDWARE
• No. 2 Phillips Driver
(6x) 6-32 x 5/16 Phil.
Bonding Screws
A
INSTALLING THE LEVER LOCK FRONT DOOR OPTION
1. Use (4x) 6-32 x 5/16 bonding screws (A, 2 per bracket) to install the brackets (B) to the door as
shown. (FIGURE A)
Lever Lock Plate
(VP-1710)
C
Lever Lock Brackets
B
!
!
CAUTION! The bonding screws must be used as explained to ensure proper bonding.
ATTENTION! Les vis doivent être utilisées comme expliqué pour assurer approprié électrique de liaison.
(2x) Lever Lock
Securing Rivet
D
(20x) Lever Lock
Plate Washer
E
NOTE:
Position the
brackets so
the 3 depth
patterns are
facing each
other inside
the door.
FIGURE A
A
B

Page 3
INSTALLING THE LEVER LOCK FRONT DOOR OPTION (CONTINUED)
2. Insert the side of the Lever Lock front door plate (C) without the clip into the brackets (B) first. Then
install the side with the clip until it clicks into place. (FIGURE B)
FIGURE B
NOTE:
• The Lever Lock front door plate may be installed on the brackets at different depths. All 4 corners of
the Lever Lock front door plate must be inserted into the brackets at the same depth in order to function
correctly.
• Allows for the horizontal mounting of other 17” vertical Lever Lock options (LL-XX-17).
• (20x) Lever Lock plate washers (E) are provided for equipment mounting convenience.
B
C
Side with
clip
Side without
clip Clip
NOTE: Install plastic securing
rivet (D) into hole to secure
the clip more permanently, if
desired.

Page 4
For warranty information, refer to www.middleatlantic.com/terms.
Corporate Headquarters
Corporate Voice: 973-839-1011 - Fax: [phone] / International Voice: [phone]
Fax: [phone]
www.middleatlantic.com - [email protected]
Middle Atlantic Canada
Voice: 613-836-2501 - Fax: [phone] / ca.middleatlantic.com -
[email protected]
Factory Distribution
USA: NJ - CA - IL Canada: ON - BC
At Middle Atlantic Products we are always listening. Your comments are welcome.
Middle Atlantic Products is an ISO 9001 and ISO 14001 Registered Company.
WARRANTY
