Midea NY2009-20M User manual

OIL FILLED HEATER
OWNER’S MANUAL
OIL FILLED HEATER
MODEL: NY2009-20M / NY2311-20M
READ AND SAVE THESE INSTRUCTIONS
Attention: Pictures in the IM are for reference only.

SAFETY INSTRUCTION
1. Warning: In order to avoid overheating, do not cover the
heater.
2. If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a
hazard.
3. This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
4. The heater must not be located immediately below a socket-outlet.
5. Do not use this heater in the immediate surroundings of a bath, a
shower or a swimming pool.
6. Children of less than 3 years should be kept away unless continuously
supervised.
Children aged from 3 years and less than 8 years shall only switch
on/off the appliance provided that it has been placed or installed in its
intended normal operating position and they have been given supervi-
sion or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children aged from 3 years and
less than 8 years shall not plug in, regulate and clean the appliance or
perform user maintenance.

7. CAUTION — Some parts of this product can
become very hot and cause burns. Particular atten-
tion has to be given where children and vulnerable
people are present.
8. This heater is filled with a precise quantity of special oil. Repairs
requiring opening of oil-container are only to be made by the manu-
facturer or his service agent who should be contacted if there is an oil
leak. When scrapping the heater, follow the regulations concerning
the disposal of oil.
9. Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and collec-
tion systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
10. This heater cannot achieve accurate temperature control of the enviroment,
and thus cannot be used as insulation device for storage environment,
items, animals and plants.

PART FIGURE
Caster assembly
Thermostat Knob
Power Switch Knob
Cord wrap
Fin
Use of oil filled radiator
butterfly nuts
control box
figure 1 figure 2
1,Turn the heater upside down.
2. As shown in figure 1, align the mounting hole of a set of caster assembly and install
it on the screw of the caster pad plate at the end of the radiator fin, and The other
caster assembly is aligned to the screws mounted at the bottom of the control box.
3,As shown in figure 2, two sets of caster components are tightened with four butterfly
nuts. Install solid and then put the heater in place-just put the wheels on the ground.

OPERATING INSTRUCTION
[Inspection before start]
1.The power cord shall not be damaged or fractured.
2.Please verify the rated current of the power socket is in line with the requirements
in the table above and is equipped with a safety grounding device before use;
otherwise, replace the socket.
[Start and power selection]
1.Start
Plug in the power, clockwise turn the thermostat knob to the "+" mark position, then
turn on the power switch, the heater starts to work.
2.Power selection
Under normal circumstances, please use the maximum power "III" gear for rapid
heating. If the room temperature reaches a suitable temperature, please choose a
lower power "II" or "I" gear to reduce energy consumption so as to prevent the
room becoming overheated.
[Note]
To use the machine for the first time or to re-insert the socket, please pay attention
to check whether the plug and the socket are fitted well.
<Inspection method>
Insert the power plug into the socket and start for use; after about half an hour, turn
off and pull out the plug. Check whether the plug pins are hot; replace the socket if
so (more than about 50 °C) to avoid burning the plug or even causing a fire caused
by overheating of the socket due to poor contact.
[Temperature adjustment]
During use, if you feel it is necessary to lower the room temperature since it is too
high, you can use the following adjustment modes:
1.Turn the power switch to gear "II" or "I".
2.Counterclockwise turn the thermostat knob back by a certain angle, for which it
indicates that the set temperature is lower when the temperature indication is
closer to the " -" position.
[Stop]
Turn the power switch to indication point "0", and then pull out the power plug.
[Movement of the heater]
To move the heater, turn it off first, and pull out the power plug; then push the body
to make the four casters below the body to roll.

1. The electric heater should be cleaned regularly to wipe out the dust on
the surface of flanges. As this may influence the radiating efficiency.
2. Disconnect electricity supply and allow radiator to cool, wipe out dust
with a soft damp cloth. Do not use detergent or abrasives.
3. Do not scrap the surfaces of flanges with sharp hard tools, to avoid
surfaces getting rusty, because of damage of the paint coat.
CLEANING AND MAINTENANCE INSTRUCTION
