Midea MK-17DC-GN User manual

MK-17DC-GN
MK-17DC-PK
MK-15D
CLEANING
HOW TO USE
PRODUCT SPECIFICATION
PRODUCT PARTS NAME
BRIEF INTRODUCTION
IMPORTANT SAFETY
INSTRUCTION 1
4
5
6
3
4

1
Read carefully and keep this instructions manual.
For additional protection, we recommend using power outlet with
a rated current of 13A. To avoid circuit overload, do not operate another
high wattage appliance on the same circuit.
Do not fill kettle when positioned on base. Dry the water on the bottom of
the body before placing it onto power base.
Never leave the appliance unattended when in use.
Close supervision is necessary when your appliance is being used near
children or infant persons.
Electric kettle must be operated on a flat surface. Do not place this appliance
on or near a hot gas or electric burner or on the top of other electric
appliances.
Do not touch the hot surfaces, use the handle. Beware of steam being emitted
from spout or lid especially during erfilling. Do not remove lid during boiling
cycle.
Do not use kettle to heat anything other than water. Do not fill above the
“max ”. Do not operate kettle if water is below minimum.
Do not let the power cord hang over the edge of the table or hot over
surfaces. Always store excess portion of the power cord in the compartment
of the base unit.
Do not immerse any part of the appliance in water or other liquid. Do not use
your appliance with an extension cord unless this cord has been checked
and tested by a qualified technician or service person. Always use your
appliance from a power outlet of the voltage (A.C.only)marked on the
appliance.
If the power cord is damaged,it must be replaced by manufacturer or authorized
persons.
If the kettle is overfilled, boiling water may overflow.
The kettle is only to be used with the base provided.
Do not switch on if there is a possibility that the
water in the heater is frozen.
NOTE:
WARNING:
●
●
●
●
●
●
●
●
●
●

2
Always unplug from the socket in the following conditions:
No water in kettle Filling water Not in use Before cleaning or
moving kette.
Call our free customer service number for information or return to Midea
Customer Sevice Department for examination and repair. Never repair the
appliance yourself.
WARNING: To reduce the risk of fire or electric shock,do not remove
the bottom cover of the body or the power base by yourself.
Do not use a base unit other than the one supplied. The use of accessory
attachments not recommended by the manufucturer may result in firek,
electrical shock or personal injury.
Do not insert any object into slots or holes of the kettle.
This appliance is for household use only. Do not use outdoors.
This appliance can be used by children aged 8 years and above
if they have been given supervision or instruction concerning use of
the appliance in a safe way and if they understand the hazards invol-
ved. Cleaning and maintenance shall not be made by children
unless they are older than 8 and supervised. Keep the appliance and
its cord out of reach of children aged less than 8 years.
This appliance is intended to be used in household and similar applications
as:
- Staff kitchen areas in shops,offices and other working environments;
- Farm houses;
- By clients in hotels, motels and other residential environments;
- Breakfast type environments.
WARNING:Do not remove the lid while the water is boiling.
CAUTION:Position the lid so that steam is directed away from the
handle.
CAUTION:Ensure that the appliance is switched off before removing it
from its base.
CAUTION:Becareful and avoid water spillage on connector.
Incorrect use of appliance may cause serious burns, therefore, attention
shall be given.
Do not try to access into kettle’s container, heating element surface
is subject to residual heat after use.
●
●
●
●
●
●
●
●
●
●
●
●
●
●

Do not dispose of electrical appliances as unsorted municipal waste,
use separate collection facilities.
Contact your local government for information regarding the collection
systemsavailable.
If electrical appliances are disposed of in landfills or dumps, hazardous
substancescan leak into the groundwater and get into the food chain,
damaging your health andwell-being.
When replacing old appliances with new once, the retailer is legally obligated
to take back your old appliance for disposal at least for free of charge.
Appliances can be used by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
3
●
●
Rapid boiling time and energy saving
Steam control to automatically switch off the kettle after boiling.
Automatically cuts off for boil-dry protection
Anti scald porbocly
High quality thermostat
360 rotational power base
double layer
Rational design,
bring convenience and enjoyment to your life

Product Specification
Product Parts Name
MK-17DC-GN
4
1. Lid 2. Spout Lid release button
4. Handle 5. Double wall 6.Switch/Light
7. Power base
3.
1800-2150W
MK-17DC-PK 1800-2150W
21.4 ×15.3×25.2cm
21.4 ×15.3×25.2cm
1.03Kg

MK-15D 1800-215 5 1.08 kg0W
How To Use
Press the lid release button on th handle and open the lid
Remove the kettle from the base . Fill the kettle (no less than the minimum and
no more than the maximum.)close lid; place the kettle back on the base unit.
Connect the plug into a power outlet (220-240V, AC), switch the kettle on by
pressing the switch.The neon light will illuminate to indicate the kettle is heating.
The kettle will automatically switch off once the water has boiled and the
neon light goes off.
Lift the kettle from the base, and you can pour out the water into container.
5
For first time use or if you have not used it for a long period; it is
recommended that you fill the kettle to the maximum level mark with fresh tap
water, boil and empty the kettle at least 2 times to clear the kettle of any tiny
particles. Do not drink the water.

6
To prolong the kettle’s life, please clean the mineral deposits in the
kettle regularly.
Always unplug from the socket and allow to cool down before
cleaning.
Do not use chemical, steel wool, or abrasive cleaners to clean the
outside of the kettle, as these will scratch the surface and fade the
outside color.
Fill the kettle with 0.5L white vinegar and with water and allow to stand for over
1 hours;
Empty the solution from the kettle. Wipe off the deposits with damp cloth
Fill the kettle with clean water, boil and then discard the water. Repeat
and the kettle will be ready to use;
If necessary, repeat the operations above for several times;
Do not immerse into water. The surface of the kettle may be wiped over
with a damp cloth and polished with a soft dry cloth.

MK-17DC-GN
MK-17DC-PK
MK-15D
Pembersihan
Cara-cara Penggunaan
Spesifikasi Produk
Nama Bahagian
Pengenalan Ringkas
Peringatan Keselamatan
Penting
C erek J ag E lektrik
KANDUNGAN
Terima kasih kerana telah membeli Cerek Jag Elektrik Midea. Sila baca buku panduan ini dengan teliti sebelum
menggunakan unit ini. Simpan buku panduan ini untuk rujukan kelak.

Peringatan Keselamatan Penting
Baca buku panduan ini dengan teliti dan disimpan untuk rujukan kelak.
Sebagai langkah perlindungan tambahan, gunakan soket kuasa dengan arus
kadaran 13A. Jangan berkongsi litar dengan perkakas elektrik lain yang
menggunakan kuasa watt yang tinggi bagi mengelakkan beban berlebihan.
Untuk mengisi air, alihkan cerek dari tapaknya. Lap bahagian bawah cerek
sehingga kering sebelum diletakkan semula pada tapak kuasa.
Jangan biarkan cerek yang sedang beroperasi tanpa pengawasan.
Pengawasan yang rapi adalah wajar jika perkakas ini digunakan berdekatan
dengan kanak-kanak atau orang-orang yang belum dewasa.
Cerek elektrik ini mesti dikendalikan di atas permukaan yang rata. Jangan
letakkan cerek ini di atas atau berhampiran dengan pembakar gas atau elektrik
yang panas atau di atas perkakas elektrik yang lain.
Jangan sentuh permukaan yang panas, pegang gagangnya. Berhati-hati
terhadap wap air yang dibebaskan dari muncung atau penutup khususnya ketika
mengisi semula air. Jangan sesekali buka penutupnya ketika proses pendidihan.
Jangan gunakan unit ini untuk memanaskan benda-benda lain yang selain
daripada air. Air yang diisi jangan melebihi paras “max”. Jangan panaskan cerek
ini jika air di dalamnya lebih rendah daripada paras minimum.
Pastikan kord kuasa tidak terjuntai di tepi meja atau bersentuhan dengan
permukaan yang panas. Simpan kord kuasa yang berlebihan di dalam ruang
penyimpan kord pada bahagian bawah tapak unit ini.
Jangan rendamkan mana-mana bahagian daripada perkakas ini di dalam air atau
cecair lain. Jangan gunakan kord kuasa yang dipanjangkan melainkan telah
diperiksa oleh juruteknik bertauliah atau ejen perkhidmatan. Guna soket kuasa
yang mempunyai voltan (arus ulang alih sahaja) yang sama seperti ditandakan
pada perkakas ini.
Jika kord kuasa sudah rosak, ia mesti ditukar ganti oleh pengilang atau orang
yang diberikuasa.
●
●
●
●
●
●
●
●
●
●
NOTA: Jika cerek ini terlebih diisi, air yang mendidih mungkin terpancut
keluar. Cerek ini hanya boleh digunakan bersama tapak yang
disediakan.
AMARAN: Jangan dipasang suisnya jika air di dalam cerek kemungkinan
sudah membeku.
1

Peringatan Keselamatan Penting
●
●
●
●
●
●
●
●
●
2
