MINOLTA-QMS 4060 Building instructions

4060 Service and Parts Manual
1750040-001A

General Information
SERVICE MANUAL
1-1
CHAPTER 1 GENERAL INFORMATION
Chapter 1 contents include:
Section
1-1 Introduction...................................................................................................... 1-3
1-2 Printer Specifications ....................................................................................... 1-4
1-2.1 Printer General Specifications ...................................................... 1-4
1-2.2 Printer Print Speed Specifications ................................................ 1-5
1-2.3 Printer Physical Specifications ..................................................... 1-6
1-2.4 Printer Electrical Specifications.................................................... 1-6
1-2.5 Environmental Specifications For All Equipment........................ 1-8
1-3 Summary of Printer Optional Features and Feature Specifications................. 1-9
1-4 Large-Capacity Hopper (LCH) ........................................................................ 1-9
1-4.1 LCH Overview.............................................................................. 1-9
1-4.2 LCH Paper Handling Specifications............................................. 1-10
1-4.3 LCH Physical Specifications ........................................................ 1-11
1-4.4 LCH Electrical Specifications....................................................... 1-12
1-4.5 LCH Environmental Specifications .............................................. 1-12
1-5 Large-Capacity Stacker (LCS)......................................................................... 1-12
1-5.1 LCS Overview .............................................................................. 1-12
1-5.2 LCS Paper Handling Specifications.............................................. 1-13
1-5.3 LCS Physical Specifications ......................................................... 1-14
1-5.4 LCS Electrical Specifications ....................................................... 1-14
1-5.5 LCS Environmental Specifications............................................... 1-14
1-6 Printer Custom Paper Tray............................................................................... 1-15
1-7 Printer Consumable Specifications .................................................................. 1-15
1-8 Best Printing Area Specifications .................................................................... 1-17
1-9 System Configuration Component Locations and Descriptions...................... 1-20
1-9.1 Front and Right Side of the Printer ............................................... 1-20
1-9.2 Behind the Front Door .................................................................. 1-22
1-9.3 Behind the Upper Right Cover ..................................................... 1-24
1-9.4 Behind the Lower Right Cover ..................................................... 1-25
1-9.5 Rear and Left Side of the Printer .................................................. 1-26
1-9.6 Rear-Inside of the Printer.............................................................. 1-28
1-9.7 Large-Capacity Hopper (LCH) Accessory ................................... 1-30
1-9.8 Large-Capacity Stacker (LCS) Accessory .................................... 1-31
1-10 Printer Component Block Diagram ................................................................. 1-32
1-11 Safety and Regulatory Information.................................................................. 1-36
1-12 Servicing Approach ......................................................................................... 1-36

General Information
SERVICE MANUAL
-2
NOTE
This page intentionally left blank.

General Information
SERVICE MANUAL
1-3
1-1. Introduction
This chapter provides specifications, safety compliance, options, available supplies, printing paper
and design, system configuration, related manuals, and servicing approach for the 4060 cut sheet
printer and supporting optional Large-Capacity Hopper (LCH) and Large-Capacity Stacker (LCS)
paper handlers.
The 4060 non-impact printer combines semiconductor laser optical technology and two-
component dry development process technology to print on cut-sheet plain paper. Figure 1-1
illustrates an installed printer and the external large capacity paper handling options.
Figure 1-1. 4060 Printer With Optional LCH and LCS Paper Handlers
LTR
LTR
LTR
LCS M3894SA LCH

General Information
SERVICE MANUAL
-4
1-2. Printer Specifications
This section provides general, print speed, physical, electrical, environmental specifications as
well as safety standards applicable to all equipment and an illustration of the printer laser
equipment warning label.
1-2.1. Printer General Specifications
Table 1-1 lists general specifications for the 4060 printer.
Table 1-1. 4060 Printer General Specifications
1-2.2. Printer Print Speed Specifications
Table 1-2 lists the specifications for the 4060 printer print speeds.
Table 1-2. 4060 Printer Print Speed Specifications
Item Specifications
Printing technology Laser diode, Electro-photography
Printing speed 40 ppm (Letter and A4 landscape)
Paper Size Letter, Legal, Ledger. Executive, A3, A4, A5, B4 (JIS), B5 (JIS)
Type Plain Paper, Label paper, Recycle paper, Transparency paper, Bond paper, Pre-punched paper
Resolution 600 ×600 dpi
Paper capacity • 3 trays ×500 sheets (64 g/m2) standard
• 1 tray ×500 sheets (64 g/m2) optional custom tray
• 3,000 sheets (A4, Letter size only) optional Large-Capacity Hopper (LCH)
Stacker capacity • 500 sheets (64 g/m2) face down tray
• 2,000 sheets optional Large-Capacity Stacker (LCS)
Paper Size (direction) Simplex *2 Duplex *2
Letter (landscape) 40 40
Legal (portrait) 25 25
Ledger (portrait) 21 15
Executive (portrait) 40 40
A3 (portrait) 21 15
A4 (landscape) 40 40
A5 (portrait) 40 40
B4 (JIS) (portrait) 24 24
B5 (JIS) (portrait) 30 30
B4 (ISO) (portrait) *1 21 15

General Information
SERVICE MANUAL
1-5
1-2.3. Printer Physical Specifications
Table 1-3 lists the printer physical specifications.
Figure 1-2 illustrates the physical specifications and Figure 1-3 illustrates the required printer
service area dimensions.
Table 1-3. 4060 Printer Physical Specifications
1-2.4. Printer Electrical Specifications
Table 1-4 lists the printer electrical specifications.
Table 1-4. 4060 Printer Electrical Specifications
B5 (ISO) (portrait) *1 40 40
Custom (paper width = 120mm to 297mm,
paper length = 182mm to 215.9mm) *1
24 24
Custom (paper width = 120mm to 297mm,
paper length = 215.9mm to 431.8mm) *1
34 34
Notes:
*1: Can be fed from optional custom paper tray only.
*2: Unit of measure: Images Per Minute (IPM). All the speeds have ±5% tolerance.
Item Specification
Dimensions Width Depth Height
585 mm (23.0 in) 640 mm (25.2 in) 1,030 mm (40.6 in)
Weight Approximately 135 kg
Service area Front Back Left Right
650 mm (25.6 in) 850 mm (33.5 in) 850 mm (33.5 in) 850 mm (33.5 in)
Item Specifications
Input power Voltage 120 to 127 VAC ±10%, 12A
200 to 240 VAC ±10% 7A
Phase Single-phase
Frequency 50/60Hz ±5%
Power consumption 1,300 VA or less than during operating
Heat capacity 894 kcal per hour

General Information
SERVICE MANUAL
-6
Figure 1-2. 4060 Printer Physical Dimensions
23.0 in.
(585 mm) 25.2 in. (640 mm)
1.38 in
(35 mm)
40.5 in.
(1030 mm)
LTR
LTR
LTR

General Information
SERVICE MANUAL
1-7
Figure 1-3. 4060 Printer Required Service Area Dimensions
1-2.5. Environmental Specifications For All Equipment
Table 1-5 lists environmental specifications applicable to the printer, LCH, and LCS units.
Table 1-5. 4060 Printer, LCH Option, and LCS Option Environmental Specifications
1-3. Summary of Printer Optional Features and Feature Specifications
Table 1-6 lists the options available with the 4060 printer along with their associated
specifications.
Item Specification
Ambient
Condition
Device condition Operating Non-operating
Temperature 10 to 35 °C 0 to 35 °C
Humidity 20 to 80% RH
(no condensation)
20 to 80% RH
(no condensation)
Temperature and
humidity gradients
15 °C per hour or less and 30% RH per day or
less (no condensation)
Acoustic noise 55 dBA or less (printer only)
Dust 0.15 mg./m3(stearic acid)
Ozone emission 0.1 PPM or less
Printer
Operating
Side
23.0 in.
(585 mm)
33.5 in.
(850 mm) 33.5 in. (850 mm)
25.6 in.
(650 mm)
33.5 in.
(850 mm)
25.2 in.
(640 mm)
84.3 in.
(2140 mm)
90.0 in.
(2285 mm)

General Information
SERVICE MANUAL
-8
Table 1-6. 4060 Printer Available Options and Specifications Summary
Item Specification Model Number
Large-Capacity Hopper
(LCH)
3,000 sheets (75 g/m2)4060 (Letter)
4060 (A4)
Large-Capacity Stacker
(LCS)
2,000 sheets (75 g/m2)4060 (120 VAC)
4060 (240 VAC)
Custom paper tray 500 sheets (75 g/m2)

General Information
SERVICE MANUAL
1-9
1-4. Large-Capacity Hopper (LCH)
1-4.1. LCH Overview
Models 4060 and 4060 are the user-installable optional Large-Capacity Hoppers (LCH) units for
the 4060 printer, connecting to the right side of the printer. The 4060 can feed Letter size paper
only, and the 4060 can feed A4 size paper. Both LCHs can be installed up to 3000 sheets of paper
(75g/m2).
Figure 1-4 illustrates the Large-Capacity Hopper unit.
Figure 1-4. Large-Capacity Hopper Physical Dimensions
1-4.2. LCH Paper Handling Specifications
Table 1-7 lists the LCH paper related specifications.
Table 1-7. LCH Paper Handling Specifications
Item Specifications
PRINTER
11.3 in.
(287 mm)
22.2 in.
(562 mm)
17.6 in.
(446 mm)

General Information
SERVICE MANUAL
-10
1-4.3. LCH Physical Specifications
Table 1-8 lists the LCH physical dimensions, unit weight, and required service area dimensions
and Figure 1-4 illustrates these dimensions. Figure 1-5 illustrates the LCH service area
requirements.
Table 1-8. LCH Physical Specifications
Processing speed 40 ppm (4060: Letter landscape and 4060: A4 landscape)
Paper Size 4060: Letter and 4060: A4
Type Plain paper, Label paper, Transparency, Bond paper, Pre-punched paper 64 to 90g/m2
Paper capacity 3,000 sheets (75g/ m2)
Item Specification
Dimensions Width Depth Height
287 mm (11.3 in) 446 mm (17.6 in) 562 mm (22.2 in)
Weight About 17 kg (38 lbs)
Service area Front Back Right
650 mm (25.6 in) 850 mm (33.5 in) 850 mm (33.5 in)
Printer LCHLCS
Operating
Side
23.0 in.
(585 mm)
33.5 in.
(850 mm) 21.25 in.
(540 mm)
33.5 in.
(850 mm)
11.38 in.
(289 mm)
25.6 in.
(650 mm)
33.5 in.
(850 mm)
25.2 in.
(640 mm)
84.3 in.
(2140 mm)
122.6 in.
(3114 mm)

General Information
SERVICE MANUAL
1-11
Figure 1-5. LCH, Printer, and LCS Required Service Area Dimensions
1-4.4. LCH Electrical Specifications
Table 1-9 lists the LCH electrical specifications.
Table 1-9. LCH Electrical Specifications
1-4.5. LCH Environmental Specifications
Refer to Table 1-5 for LCH environmental specifications.
Item Specification
Input power 24VDC, supplied from 4060 printer
Power consumption 30VA or less during operation

General Information
SERVICE MANUAL
-12
1-5. Large-Capacity Stacker (LCS)
1-5.1. LCS Overview
Figure 1-6 shows the user-installable optional Large-Capacity Stacker (LCS) paper handler that
connects to the left side of the printer. Model 4060 is for 120V, and model 4060 is for 240V. The
LCS can stack up to 2000 sheets of paper (75g/m2).
Figure 1-6. Large-Capacity Stacker Physical Dimensions
1-5.2. LCS Paper Handling Specifications
Table 1-10 lists the LCS paper handling specifications.
Table 1-10. LCS Paper Handling Specifications
Item Specifications
Processing speed 40 ppm
Paper Size Letter, Legal, Ledger, Executive, A3, A4, A5, B4(JIS) (ISO), and B5 (JIS) (ISO)
Type Plain paper, Label paper, Transparency, Bond paper, Pre-punched paper 64 to 90g/m2
PRINTER
21 in.
(533 mm)
36.0 in.
(913 mm)
17.4 in.
(442 mm)

General Information
SERVICE MANUAL
1-13
1-5.3. LCS Physical Specifications
Table 1-11 lists the LCS physical dimensions, unit weight, and also provides the required service
access area dimensions.
Figure 1-6 illustrates these specifications.
Table 1-11. LCS Physical Specifications
1-5.4. LCS Electrical Specifications
Table 1-12 lists the LCS electrical specifications.
Table 1-12. LCS Electrical Specifications
1-5.5. LCS Environmental Specifications
Table 1-5 lists the LCS environmental specifications.
Paper capacity 2,000 sheets (75g/ m2)
Item Specification
Dimensions Width Depth Height
533 mm (21 in) 442 mm (17.4 in) 913 mm (36.0 in)
Weight About 32 kg (70 lbs)
Service area Front Back Left
650 mm (25.6 in) 850 mm (33.5 in) 850 mm (33.5 in)
Item
Specification
4060 4060
Input Power Voltage 100 to 120 VAC
±10%
200 to 240 VAC
±10%
Phase Single-phase
Frequency 50/60 Hz 5%
Power consumption 120 VA or less during operation
Heat capacity 83 kcal per hour

General Information
SERVICE MANUAL
-14
1-6. Printer Custom Paper Tray
Model 4060 printer custom paper tray is user-installable, optional custom paper tray for the 4060
printer that is compatible and switchable with the standard printer paper tray. The custom paper
tray can hold up to 500 sheets (75g/m2) of free sized paper as listed in Table 1-13 specifications.
Table 1-13. Custom Paper Tray Physical Specifications
Paper size information for the custom tray is selectable. The custom tray also supports the
following standard media sizes: Letter, Legal, Ledger, Executive, A3, A4, A5, B4 and B5.
The printing speed from the custom tray is listed in Table 1-2 (measured on and after the second
page in continuous printing mode).
1-7. Printer Consumable Specifications
This section explains how the replacement rate is established for the printer consumables. The
4060 User Manual provides details about consumables kit contents, ordering, and replacement
procedures.
Table 1-14 lists the consumables and their respective replacement cycle specifications. Ensure that
consumables are replaced at the recommended intervals by monitoring the usage of the printer.
Table 1-14. Consumables and Replacement Cycle
Notes supporting Table 1-14:
(1) All the values for replacement cycle shown above are based upon printing on A4 size
paper.
Paper Size Inches Millimeters
Minimum 4.7 x 7.2 120 x 182
Maximum 11.7 x 17 297 x 431.8
Consumable Item Replacement cycle
Toner 20,000 images for continuous printing, with 4% coverage for each bottle (average 18,000 images)
Developer 1,600 drum count for each bottle (160,000 images for continuous printing, average 114,000 images)
Drum 2,500 drum count (250,000 images for continuous printing, average 178,500 images)
Transfer Charger 2,500 drum count (250,000 images for continuous printing, average 178,500 images)
Fuser 3,000 page length count (approx. 300,000 images)
Cleaning Roller 40,000 images for continuous printing with 4% coverage (average 36,000 images)
Ozone Filter 3,200 drum count (320,000 images for continuous printing, average 228,000 images)
Collector Bottle 20,000 images for continuous printing with 4% coverage (average 18,000 images)
Printer Pick Roller Kit 5,000 page length count each (approx. 500,000 images)
LCH Pick Roller Kit 5,000 page length count each (approx. 500,000 images)

General Information
SERVICE MANUAL
1-15
(2) All the listed values are theoretical. The damage due to improper handling, maintenance,
papers, environments, and other uncontrollable occasions are not considered in these
values.
(3) All the values for replacement cycle/life shown above depends on printing usage’s and
conditions:
• Drum Counts: The drum counter will increment every 150 seconds (equals 100
images of A4 paper at continuous printing). This counter increments during
Warming-up, Intermittent printing and Auto-patrol sequence.
Calculation of the average printed images is based on 1/1.4 of continuous printing;
the combination of intermitted printing mode and continuous printing mode.
• Page Length count: The page length counter will increase after 100 simplex A4
images are stacked. On duplex printing the page length counter is incremented by
two.
For the Printer Pick Roller Kit and the LCH Pick Roller Kit, this counter always
increments as simplex printing. When another size paper is used, the counter
increments according to the Table 1-15 listed values.
Table 1-15. Page Length Count
Paper size
Increment by 100
sheets at simplex
printing
Increment by 100
sheets at duplex
printing
Letter 1 2
Legal 2 4
Ledger 2 4
Executive 1 2
A5 1 2
A4 1 2
A3 2 4
B4 (JIS) 2 4
B5 (JIS) 1.5 3

General Information
SERVICE MANUAL
-16
1-8. Best Printing Area Specifications
The printed images must be in an area within a 0.5 inch (12 mm) border. Printing outside of this
boundary may be of lower quality.
Figure 1-7 shows the best printing area.
Figure 1-7. Best Printing Area
If data is printed outside the best printing area, you may obtain poor print quality
Figure 1-8 shows the print area of the 4060 printer.
Figure 1-8. Print Area Specifications
If data is printed outside the printing-assured area as listed in Table 1-16 it will cause poor print
quality such as:
• Paper feed skew (up to ±2mm) that may cause missing characters.
• Bad paper transport that may cause a paper jam.
Margin
Best area
| D-E | 1.5 mm
| F-G | 1.5 mm
Feed direction
Paper
F
G
ED

General Information
SERVICE MANUAL
1-17
Table 1-16. Print Area Specifications
Figure 1-9 shows the printing position precision.
A (mm) B (mm) A (mm) B (mm)
A5 139.6 201.6 LEDGER 271.0 423.4
A4 288.6 201.6 EXECUTIVE 175.75 258.3
A3 288.6 411.6 B5(JIS) 248.6 355.6
LETTER 271.0 207.5 B4 (JIS 173.6 248.6
LEGAL 207.5 347.2

General Information
SERVICE MANUAL
-18
Figure 1-9. Print Positions
H
I
J
K
Ideal print area
– MAGNIFICATION
– SKEW
– OFFSET
Print area
Paper
| H-I | 2.5 mm
| J-K | 1.5 mm
| D-E | 1.5 mm
| F-G | 1.5 mm
Feed direction
Print section
Paper
| A-B | 2mm/432mm
B
A
Feed direction
Paper
F
G
ED
