Mitel Networks 5303 User manual

Installation and User Guide
Guide d’installation et d’utilisation

NOTICE
The information contained in this document is believed to be accurate in all
respects but is not warranted by Mitel Networks™ Corporation. The
information is subject to change without notice and should not be construed
in any way as a commitment by Mitel or any of its affiliates or subsidiaries.
Mitel and its affiliates and subsidiaries assume no responsibility for any
errors or omissions in this document. Revisions of this document or new
editions of it may be issued to incorporate such changes.
No part of this document can be reproduced or transmitted in any form or by
any means - electronic or mechanical - for any purpose without written
permission from Mitel Networks Corporation.
Mitel Networks is a trademark of Mitel Networks Corporation.
Other product names mentioned in this document may be trademarks of
their respective companies and are hereby acknowledged.
AVIS
Bien que les informations contenues dans ce document soient considérées
comme exactes à tous égards, Mitel Networks™ Corporation ne peut en
garantir l’exactitude. Ces informations sont susceptibles d’être modifiées
sans préavis et ne doivent être en aucun cas considérées comme un
engagement de Mitel Networks, de l’un de ses partenaires ou de l’une de ses
filiales. Mitel Networks, ses partenaires et ses filiales déclinent toute
responsabilité quant aux éventuelles erreurs ou omissions présentes dans ce
document. Des révisions du présent document ou de nouvelles versions
peuvent être publiées pour incorporer de tels changements.
Aucune partie de ce document ne peut être reproduite de quelque façon que
ce soit, en tout ou partie, pour quelque usage que ce soit, sans autorisation
écrite de Mitel Networks Corporation.
Mitel Networks est une marque de commerce de Mitel Networks Corporation.
Tous les autres noms de produits mentionnés dans ce document peuvent
être des marques de commerce de leurs sociétés respectives et sont, par la
présente, reconnues.
Mitel Networks 5303 Conference Phone
Installation and User Guide/Guide d’installation et d’utilisation
56005581, Rev A
April/Avril 2003
, Trademark of MITEL Networks Corporation
©Copyright 2003, MITEL Networks Corporation
All rights reserved
, Marque de commerce de Mitel Networks Corporation
© Copyright 2003, Mitel Networks Corporation
Tous droits réservés

1
Mitel Networks™ 5303 Conference Phone
Installation and User Guide
Welcome
Congratulations on your purchase of the Mitel Networks
5303 Conference Phone, a state of the art conference unit. The
5303 Conference Phone provides the following features to
ensure outstanding quality and ease of use:
• Full duplex audio with echo cancellation and noise reduction
for high quality audio;
• Acoustic beam forming technology that ensures that every-
one in a conference room can be clearly heard regardless of
where they are in the room;
• A Presentation Mode feature which allows the microphone
of the Speaker Unit to lock onto a specific sector where the
speaker is located, to facilitate audio presentations;
• Compatibility with business telephone systems and the
public switched telephone network;
• An intuitive, friendly interface;
• Nine programmable Speedcalls for storing names and
numbers, and a special Conference Softkey to make
conference calls easy to setup;
• Support for Calling Line Identification provided by your
IS (Information Service) department or telephone com-
pany. To subscribe to a Calling Line Identification service,
contact your IS department or local telephone company.
Disclaimer
DUE TO THE DYNAMIC NATURE OF THE PRODUCT
DESIGN, THE INFORMATION CONTAINED IN THIS
DOCUMENT IS SUBJECT TO CHANGE WITHOUT
NOTICE. MITEL NETWORKS CORPORATION, ITS
AFFILIATES, AND/ OR ITS SUBSIDIARIES ASSUME
NO RESPONSIBILITY FOR ERRORS AND/OR
OMISSIONS CONTAINED IN THIS INFORMATION.
!

2
Important Safety Instructions and Precautions
When using the Mitel Networks 5303 Conference Phone and
related equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury to
persons. These include the following:
• Only Mitel Networks-approved power adapters shall be
used to power the 5303 Conference Phone.
• Do not use this product near water (for example near a
bathtub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool).
• Avoid using a telephone during an electrical storm. There
may be a remote risk of electric shock from lightning.
• Do not use the telephone to report a gas leak in the vicinity
of a leak.

3
Installation
Parts Included
The 5303 Conference Phone comprises the parts shown below.
If any parts are missing, contact your authorized
Mitel Networks dealer.
Figure 1: Parts of the 5303 Conference Phone
For best performance
It is recommended that the Mitel Networks 5303 Conference
Phone be used in a 15’x25’ maximum size room. Be sure to
install the unit on a flat surface away from obstacles, including
windows and walls. The 5303 Conference Phone works best in a
quiet environment (background noise should be less than
48 dBA; for example, no more than a typical workplace noise
such as a ventilator or overhead projector fan).
To Install the 5303 Conference Phone:
1 Connect the long phone cord to the jack labeled with the
speaker unit icon on the 48 V DC Power Adapter.

4
2 The short phone cord has a different connector on each
end. Connect the end with the larger connector (RJ45) to
the remaining jack (labeled with a phone jack icon )
on the 48 V DC Power Adapter. Refer to Figure 2.
3 Connect the other end of the short phone cord to a modular
wall jack.
4 Plug the supplied power cord into the 48 V DC Power Adapter
and into an electrical outlet. Refer to Figure 3 for the over-
view of the 5303 Conference Phone setup.
5 Using a felt-tip marker, write the unit’s phone number on one
of the Phone Number Tags, and attach it to the phone cord.
Refer to Figure 3.
Note : If you experience difficulty setting up a three-way
conference call (or activating other service provider features),
change the hook flash time. For more information, see the
section on the ‘Installation Menu’.
Figure 2: 48 V DC Power Adapter
Caution: Mitel Networks-supplied 48 V DC Power Adapters are
the only adapters accepted by Mitel Networks Corporation for
connection to the 5303 Conference Phone.

5
Figure 3: Overall Setup
Quick Reference
The 5303 Conference Phone is comprised of a Speaker Unit and
a Tablet. The Speaker Unit houses the speaker and microphone.
The Tablet, shown in Figure 4 below, allows you to dial numbers
and access the unit’s many features.
Figure 4: 5303 Conference Phone Features

6
1Mute Button: Mutes the microphone so your callers cannot
hear you. The Direction Light Indicator Ring on the Speaker
Unit turns orange when Mute is on. Mute is automatically
turned off when a call is ended.
2Levels Control Button: Adjusts the display screen con-
trast when no call is active, speaker volume when you are
on a call, and ringer volume when the phone is ringing.
3On/Off Button: Lets you turn the phone on to answer an
incoming call or make an outgoing call, and turn the phone
off at the end of the call.
4Call Indicator Lamp: Flashes when you have an incoming
call and stays on when the phone is in use.
5Presentation Mode Button: Allows the microphone to
lock onto the voice of only one person in that sector of the
room. Useful for presentations or when one person is
addressing a group of callers.
6Softkeys: Lets you navigate and use the features accessi-
ble via the display screen. Refer to the Softkeys section for
more information.
7Keypad: Lets you dial numbers or enter names and num-
bers in Speedcalls. When entering names, use the ‘1’ key
for spaces and the ‘#’ key for special characters (?, /, -). To
enter a half-second dialing pause in a speedcall, use the ‘*’
key.
Softkeys
Softkeys allow you to access a variety of features using the LCD
Display.
SpdCall – Lets you select from up to 9 programmable
SpeedCall telephone numbers. You can scroll through the list,
or press a number from 1 to 9 to jump directly to the
associated SpeedCall. To program a Speed Call, select the Menu
softkey and follow the prompts.
Redial – Lets you redial the last dialed telephone number.
Flash – Lets you put the second party on Hold (you will then
hear dialtone), and allows you to call the third party. Once
you’ve contacted the third party, press Flash again to begin the
all-party conference. Contact your IS department or local
telephone company for more information.

7
Conf - Transmits a pre-programmed feature access code which
may be required to set up a third-party call. For more informa-
tion, see PROGRAM CONF KEY? in the table below.
LocalNum - Displays the telephone number (manually dialed)
of the 5303 Conference Phone. For more information, see PRO-
GRAM LOCAL NUM? in the table below.
Menu – Leads you through an intuitive, step by step procedure
for programming a variety of features as described.
Presentation Mode
The Presentation Mode feature allows the microphone to lock
onto a specific area of a room and minimizes any extraneous
noise coming from other areas. This feature is particularly use-
ful for audio presentations to conference callers when other
people are in the room with the presenter.
PROGRAM LOCAL
NUM? Stores the telephone number of the conference unit you are using so that
you can easily retrieve it.
PROGRAM
SPEEDCALLS? Stores names and numbers that can be easily retrieved for dialing. You can edit,
empty or program new Speed Calls.
SET TIME/DATE? Sets the date and time.
If your phone displays the number of
the person calling, it is not necessary to
set the time and date on the 5303
Conference Phone. It will be set
automatically when you receive a call.
CHANGE
LANGUAGE? Default setting for display prompts is English.
Note: Choice of French available in
North America only.
PROGRAM CONF
KEY? Stores the feature access code of the conference service provided by your
business telephone system or local
telephone company. For example, to
initiate a three way call, you may need
to enter a code such as *73. Once this
softkey has been programmed, it
appears on the LCD display once you
have initiated a call.

8
If a person other than the presenter wishes to address the con-
ference callers, Presentation Mode must be turned off. The pre-
senter must remain in the focus area in order to be heard.
To Turn Presentation Mode On:
1 Begin speaking.
2 When the Direction Light Indicator (green light) appears on
the Speaker Unit in your direction, press the Presentation
button. The 5303 Conference Phone will pick up sound
coming from your direction, at the point where you turned
Presentation Mode on. The associated light on the Direction
Light Indicator Ring flashes to indicate that the unit is
receiving your voice.
To Turn Presentation Mode Off:
• Press the Presentation button to allow other speakers to be
heard during the teleconference. The associated Direction
Light Indicator stops flashing.
Installation Menu
The Installation Menu provides the following functionality:
• Displays the current software versions of the 5305 Confer-
ence Phone.
• Allows all programmable parameters to be set to default.
• Allows you to change the duration of the hook flash single
when the Flash softkey is pressed during a call. The 5303
Conference Phone is pre-programmed with a default flash
time of 300 milliseconds. Contact your IS department or
local telephone company for the recommended hook flash
time.
• Allows the automatic hook flash to be enabled (default) or
disabled through the Conf softkey. If the automatic hook
flash is enabled, an F character appears as the first entry
when programming the conference key string in the PRO-
GRAM CONF KEY? section of the menu. When the Conf soft-
key is pressed during a call, a hook flash will occur before
sending the programmed dial characters.
To access the Installation Menu and change the hook flash
time:
1 Power up the phone, and then press the Menu button. PRO-
GRAM LOCAL NUM? appears.

9
2 Press the Mute and Presentation buttons at the same time,
and then release. The software version number displays.
3 To change the hook flash time, follow the on-screen instruc-
tions.
To exit the Installation Menu and return to normal operation:
• Press the Exit button.
Maintenance and Repair
The 5303 Conference Phone is a single field-replaceable
product. There are no user serviceable parts inside either unit.
For repairs, return the entire 5303 Conference Phone to an
authorized Mitel Networks dealer.
Regulatory Notices
Notice to Canadian Customers
This Class B digital apparatus complies with Canadian Standard
ICES 003.
NOTICE: The Industry Canada label identifies certified equip-
ment in accordance with Industry Canada CS03. This certifica-
tion means that the equipment meets telecommunications
network protective, operational and safety requirements as
prescribed in the appropriate Terminal Equipment Require-
ments document(s). The department does not guarantee the
equipment will operate to the user's satisfaction.
Before installing this equipment, users should ensure that it is
permissible to be connected to the facilities of the local tele-
communications company. The equipment must also be
installed using an acceptable method of connection. The cus-
tomer should be aware that compliance with the above condi-
tions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be coordinated by a rep-
resentative designated by the supplier. Any repairs or alter-
ations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company cause
to request the user to disconnect the equipment.

10
Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines and
internal metallic water pipe system, if present, are connected
together. This precaution may be particularly important in rural
areas.
CAUTION: Users should not attempt to make such connections
themselves, but should contact the appropriate electric inspec-
tion authority, or electrician, as appropriate.
NOTICE: The Ringer Equivalence Number (REN) assigned
to each terminal device provides an indication of the maximum
number of terminals allowed to be connected to a telephone
interface. The termination on an interface may consist of any
combination of devices subject only to the requirement that
the sum of the Ringer Equivalence Numbers of all the devices
does not exceed 5. The REN value for the Mitel Networks
5303 Conference Phone is 0.1.
Notice to US Customers
Complies with Part 68 FCC Rules. US:BN2TF01BMN5303.
This equipment has been tested and found to comply with the
limits for Class B digital device pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instruction manual may cause harmful interference to
radio communications. However there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception which can be determined by turning the
equipment off and on the user is encouraged to try one by one
the following measures:
• Reorient or relocate the receiving antenna
• Increase separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different
from that which the receiver is connected
• Consult the dealer or an experienced radio/TV technician
for help.

11
Note: Changes or modifications not expressly approved by
Mitel Networks Corporation may void the user's right to operate
the equipment.
WHEN PROGRAMMING EMERGENCY NUMBERS AND (OR)
MAKING TEST CALLS TO EMERGENCY NUMBERS:
1. Remain on the line and briefly explain to the dispatcher the
reason for the call.
2. Perform such activities in the off peak hours, such as early
morning or late evening.

12
Declaration of Conformity
Company: Mitel Networks Corporation
Product:
Mitel Networks 5303 Conference Phone
Model Numbers:
5303 Conference Phone
ID#:
BN2TF01BMN5303
Samples of this product have been found to comply with the following standards:
•FCC 47 CFR Part 68 (USA)
This device complies with the applicable technical requirements of Part 68 of the Federal
Communications Commission Rules and any applicable technical requirements referenced by
this document.
The requirements of 68.316 & 68.317 are not applicable to this product, as it does not have a
handset.
Responsible party: Signing Authority:
Mr. Ed Silberhorn
U.S. General Counsel &
Corporate Secretary
Mr. Greg Slingerland
Manager,
Regulatory Approvals
Mitel Networks Inc.
205 Vanburen St.
Suite 400
Herndon Va. 20170
Mitel Networks Corporation
350 Legget Dr. P.O. Box 13089
Ottawa, Ontario, Canada
K2K 2W7
November 28, 2001
Mr. Greg Slingerland Date:
LL0065

13
Notice to Customers in EU countries
DECLARATION OF CONFORMITY
Declare that for the hereinafter mentioned product the
presumption of conformity with the applicable essential
requirements of
DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT (RTTE
DIRECTIVE) AND OF
THE COUNCIL
is given.
MITEL NETWORKS 5303 Conference Phone
Any unauthorized modification of the product voids this
declaration.
For a copy of the original signed Declaration Of Conformity (in
full conformance with EN45014) please contact the Regulatory
Approvals Manager at the above address.
We Mitel Networks LTD,
Of Mitel Business Park,
Portskewett,
Monmouthshire,
NP26 5YR, UK

14
Notices
These notices may appear on the product and in the technical
documentation.
Symbols
This symbol may appear on the product. The exclamation
point within an equilateral triangle indicates that
important operating and maintenance (servicing)
instructions are included in the literature accompanying
the product.
DANGER Danger indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
WARNING Warning indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
CAUTION Caution indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury and/or damage to
the equipment or property.
!

15
Guide d’installation et d’utilisation
du téléphone de conférence Mitel Networks™
5303 Conference Phone
Bienvenue
Félicitations ! Vous venez d'acquérir un téléphone de
conférence Mitel Networks 5303 Conference Phone, un module
de conférence à la pointe du progrès. Le téléphone de
conférence 5303 Conference Phone présente les
caractéristiques suivantes, qui assurent un niveau de qualité
exceptionnel ainsi qu’une facilité d’utilisation du produit.
• De l’audio en duplex intégral avec annulation de l’écho et
atténuation du bruit pour un son de haute qualité ;
• Une technologie de formation de faisceaux acoustiques qui
permet d’assurer que toutes les personnes se trouvant
dans une salle de conférence peuvent se faire entendre
clairement à tout endroit de la pièce ;
• Un mode Présentation qui permet au microphone intégré du
module de haut-parleur de capter uniquement les sons d’une
zone spécifique pour faciliter les présentations audio ;
• Une compatibilité avec les systèmes de téléphonie
d’affaires et le réseau téléphonique commuté ;
• Une interface intuitive et facile à utiliser ;
• Neuf touches de composition abrégée programmables pour
l’enregistrement de noms et de numéros de téléphone,
ainsi qu’une touche d’afficheur Conférence qui permet de
programmer en toute simplicité des appels conférences ;
• La prise en charge de la fonction d’affichage des appels
proposée par votre service SI (Système d’Information) ou
par la compagnie de téléphone. Pour vous abonner à un
service d’affichage des appels, contactez votre service SI
ou votre compagnie de téléphone locale.
Avis de non-responsabilité
DE PAR LA NATURE EVOLUTIVE DE LA CONCEPTION
DU PRODUIT, LES INFORMATIONS CONTENUES
DANS CE DOCUMENT SONT SUJETTES A
CHANGEMENT SANS PREAVIS. MITEL NETWORKS
CORPORATION, SES SOCIETES ASSOCIEES OU SES
FILIALES DECLINENT TOUTE RESPONSABILITE
QUANT AUX ERREURS OU AUX OMISSIONS
CONTENUES DANS CES INFORMATIONS.
!

16
Précautions et consignes importantes en matière
de sécurité
Lorsque vous utilisez le téléphone de conférence Mitel Networks
5303 Conference Phone et l’équipement associé, respectez
toujours les consignes de sécurité afin de réduire les risques
d'incendie, d'électrocution ou de blessures corporelles. Ces
consignes sont notamment les suivantes :
• N'utilisez que des adaptateurs d'alimentation approuvés par
Mitel Networks pour alimenter le téléphone de conférence
5303 Conference Phone.
• N’utilisez pas ce produit à proximité de l’eau, par exemple
près d’une baignoire, d’une cuvette, d’un évier ou d’un bac
à laver, ni dans un sous-sol mouillé ou près d’une piscine.
• Evitez d’utiliser un téléphone pendant un orage. Un éclair
pourrait présenter un risque d’électrocution.
• N’utilisez pas le téléphone pour signaler une fuite de gaz si
vous vous trouvez à proximité de celle-ci.

17
Installation
Matériel fourni
Le téléphone de conférence 5303 Conference Phone vous est
livré avec le matériel ci-dessous. Si jamais il manquait une
pièce, contactez votre revendeur Mitel Networks.
Figure 1 : Eléments du téléphone de conférence
5303 Conference Phone
Pour obtenir les meilleurs résultats
Il est recommandé d’utiliser le téléphone de conférence Mitel
Networks 5303 Conference Phone dans une pièce dont les
dimensions n’excèdent pas 4,50 m X 7,50 m (15 X 25 pieds).
Veillez à installer l’appareil sur une surface plane éloignée des
obstacles, y compris des fenêtres et des murs. Le téléphone de
conférence 5303 Conference Phone fonctionne de manière
optimale dans un environnement peu bruyant. Dans l'idéal, les
bruits de fond devraient être inférieurs à 48 dBA, soit environ le
bruit provoqué par un ventilateur de plafond ou un
rétroprojecteur.
Pour installer le téléphone de conférence 5303 Conference Phone :
1 Branchez le cordon téléphonique long dans la prise du haut-parleur
(icône ) de l’adaptateur de courant continu de 48 volts.

18
2 Le cordon téléphonique court ne dispose pas du
même connecteur à chaque extrémité. Branchez
l’extrémité dont le connecteur est le plus large (RJ 45)
dans l’autre prise (icône ) de l’adaptateur de courant
continu de 48 volts. Reportez-vous à la Figure 2.
3 Branchez l’autre extrémité du cordon téléphonique court
dans une prise téléphonique murale.
4 Branchez le cordon d'alimentation (fourni) dans
l’adaptateur de courant continu 48 volts et dans une prise
électrique. Reportez-vous à la Figure 3 pour une vue
d’ensemble de l’installation du téléphone de conférence
5303 Conference Phone.
5 A l’aide d’un marqueur, inscrivez le numéro de téléphone de
l’appareil sur l’une des étiquettes fournies puis fixez-la au
cordon téléphonique. Reportez-vous à la Figure 3.
Remarque : Si vous rencontrez des problèmes lors de la
configuration d’une conférence à trois (ou lors de l’activation
d’autres fonctions offertes par le fournisseur de services),
changez la durée de signal du crochet commutateur. Pour plus
d’informations, consultez la section « Menu d’installation ».
Figure 2 : Adaptateur de courant continu de 48 volts
Mise en garde : Les adaptateurs de courant continu de
48 volts fournis par Mitel Networks sont les seuls adaptateurs
acceptés pour l’alimentation du téléphone de conférence 5303
Conference Phone.
