Mitsubishi Electric MELSEC iQ-RX40NC6B User manual

MELSEC iQ-R I/O Module (With Diagnostic
Functions) User's Manual (Startup)
-RX40NC6B
-RY40PT5B

1
SAFETY PRECAUTIONS
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle
the product correctly.
The precautions given in this manual are concerned with this product only. For the safety precautions of the programmable
controller system, refer to the MELSEC iQ-R Module Configuration Manual.
In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".
Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to serious
consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future reference.
WARNING Indicates that incorrect handling may cause hazardous conditions, resulting in
death or severe injury.
CAUTION Indicates that incorrect handling may cause hazardous conditions, resulting in
minor or moderate injury or property damage.

2
[Design Precautions]
WARNING
●Configure safety circuits external to the programmable controller to ensure that the entire system
operates safely even when a fault occurs in the external power supply or the programmable controller.
Failure to do so may result in an accident due to an incorrect output or malfunction.
(1) Emergency stop circuits, protection circuits, and protective interlock circuits for conflicting
operations (such as forward/reverse rotations or upper/lower limit positioning) must be configured
external to the programmable controller.
(2) When the programmable controller detects an abnormal condition, it stops the operation and all
outputs are:
• Turned off if the overcurrent or overvoltage protection of the power supply module is activated.
• Held or turned off according to the parameter setting if the self-diagnostic function of the CPU
module detects an error such as a watchdog timer error.
(3) All outputs may be turned on if an error occurs in a part, such as an I/O control part, where the
CPU module cannot detect any error. To ensure safety operation in such a case, provide a safety
mechanism or a fail-safe circuit external to the programmable controller. For a fail-safe circuit
example, refer to "General Safety Requirements" in the MELSEC iQ-R Module Configuration
Manual.
(4) Outputs may remain on or off due to a failure of a component such as a relay and transistor in an
output circuit. Configure an external circuit for monitoring output signals that could cause a
serious accident.
●In an output circuit, when a load current exceeding the rated current or an overcurrent caused by a
load short-circuit flows for a long time, it may cause smoke and fire. To prevent this, configure an
external safety circuit, such as a fuse.
●For the operating status of each station after a communication failure, refer to manuals relevant to the
network. Incorrect output or malfunction due to a communication failure may result in an accident.
●When connecting an external device with a CPU module or intelligent function module to modify data
of a running programmable controller, configure an interlock circuit in the program to ensure that the
entire system will always operate safely. For other forms of control (such as program modification,
parameter change, forced output, or operating status change) of a running programmable controller,
read the relevant manuals carefully and ensure that the operation is safe before proceeding. Improper
operation may damage machines or cause accidents.
●Especially, when a remote programmable controller is controlled by an external device, immediate
action cannot be taken if a problem occurs in the programmable controller due to a communication
failure. To prevent this, configure an interlock circuit in the program, and determine corrective actions
to be taken between the external device and CPU module in case of a communication failure.

3
[Design Precautions]
WARNING
●Do not write any data to the "system area" and "write-protect area" of the buffer memory in the
module. Also, do not use any "use prohibited" signals as an output signal from the CPU module to
each module. Doing so may cause malfunction of the programmable controller system. For the
"system area", "write-protect area", and the "use prohibited" signals, refer to the user's manual for the
module used.
●If a communication cable is disconnected, the network may be unstable, resulting in a communication
failure of multiple stations. Configure an interlock circuit in the program to ensure that the entire
system will always operate safely even if communications fail. Failure to do so may result in an
accident due to an incorrect output or malfunction.
●To maintain the safety of the programmable controller system against unauthorized access from
external devices via the network, take appropriate measures. To maintain the safety against
unauthorized access via the Internet, take measures such as installing a firewall.
[Precautions for using the I/O module with diagnostic functions in normal mode]
●Configure a circuit so that the programmable controller is turned on first and then the external power
supply. If the external power supply is turned on first, an accident may occur due to an incorrect output
or malfunction.
[Precautions for using the I/O module with diagnostic functions in SIL2 mode]
●When the I/O module with diagnostic functions detects a fault in the external power supply or
programmable controller, it turns off outputs. Configure an external circuit to ensure that the power
source of a hazard is shut off by turning off the outputs. Failure to do so may result in an accident.
●When a load current exceeding the rated current or an overcurrent caused by a load short-circuit
flows, the output module with diagnostic functions detects an error and turns off all outputs. Note that
if the overcurrent state continues for a long time, it may cause smoke and fire. To prevent this,
configure an external safety circuit, such as a fuse.
●Configure protection circuits, such as a fuse and breaker, external to the output module with
diagnostic functions.
●When a communication failure (data link) occurs in CC-Link IE Field Network, the I/O module with
diagnostic functions turns off outputs. However, the program does not automatically turn off outputs.
Create a program that turns off outputs when a communication failure (data link) is detected in CC-
Link IE Field Network. If data link is restored with outputs on, connected machines may suddenly
operate, resulting in an accident.
●Create an interlock program which uses reset buttons so that the system does not restart
automatically after executing safety functions and turning off outputs.

4
[Design Precautions]
CAUTION
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction
due to noise.
●During control of an inductive load such as a lamp, heater, or solenoid valve, a large current
(approximately ten times greater than normal) may flow when the output is turned from off to on.
Therefore, use a module that has a sufficient current rating.
●After the CPU module is powered on or is reset, the time taken to enter the RUN status varies
depending on the system configuration, parameter settings, and/or program size. Design circuits so
that the entire system will always operate safely, regardless of the time.
●Do not power off the programmable controller or reset the CPU module while the settings are being
written. Doing so will make the data in the flash ROM and SD memory card undefined. The values
need to be set in the buffer memory and written to the flash ROM and SD memory card again. Doing
so also may cause malfunction or failure of the module.
●When changing the operating status of the CPU module from external devices (such as the remote
RUN/STOP functions), select "Do Not OPEN in Program" for "Open Method Setting" in the module
parameters. If "OPEN in Program" is selected, an execution of the remote STOP function causes the
communication line to close. Consequently, the CPU module cannot reopen the line, and external
devices cannot execute the remote RUN function.

5
[Installation Precautions]
[Installation Precautions]
WARNING
●Shut off the external power supply (all phases) used in the system before mounting or removing the
module. Failure to do so may result in electric shock or cause the module to fail or malfunction.
CAUTION
●Use the programmable controller in an environment that meets the general specifications in the Safety
Guidelines included with the base unit. Failure to do so may result in electric shock, fire, malfunction,
or damage to or deterioration of the product.
●To mount a module, place the concave part(s) located at the bottom onto the guide(s) of the base unit,
and push in the module until the hook(s) located at the top snaps into place. Incorrect interconnection
may cause malfunction, failure, or drop of the module.
●When using the programmable controller in an environment of frequent vibrations, fix the module with
a screw.
●Tighten the screws within the specified torque range. Undertightening can cause drop of the screw,
short circuit, or malfunction. Overtightening can damage the screw and/or module, resulting in drop,
short circuit, or malfunction.
●When using an extension cable, connect it to the extension cable connector of the base unit securely.
Check the connection for looseness. Poor contact may cause malfunction.
●When using an SD memory card, fully insert it into the SD memory card slot. Check that it is inserted
completely. Poor contact may cause malfunction.
●Securely insert an extended SRAM cassette into the cassette connector of the CPU module. After
insertion, close the cassette cover and check that the cassette is inserted completely. Poor contact
may cause malfunction.
●Do not directly touch any conductive parts and electronic components of the module, SD memory
card, extended SRAM cassette, or connector. Doing so can cause malfunction or failure of the
module.

6
[Wiring Precautions]
WARNING
●Shut off the external power supply (all phases) used in the system before installation and wiring.
Failure to do so may result in electric shock or cause the module to fail or malfunction.
●After installation and wiring, attach the included terminal cover to the module before turning it on for
operation. Failure to do so may result in electric shock.

7
[Wiring Precautions]
CAUTION
●Individually ground the FG and LG terminals of the programmable controller with a ground resistance
of 100 ohms or less. Failure to do so may result in electric shock or malfunction.
●Use applicable solderless terminals and tighten them within the specified torque range. If any spade
solderless terminal is used, it may be disconnected when the terminal screw comes loose, resulting in
failure.
●Check the rated voltage and signal layout before wiring to the module, and connect the cables
correctly. Connecting a power supply with a different voltage rating or incorrect wiring may cause fire
or failure.
●Connectors for external devices must be crimped or pressed with the tool specified by the
manufacturer, or must be correctly soldered. Incomplete connections may cause short circuit, fire, or
malfunction.
●Securely connect the connector to the module. Poor contact may cause malfunction.
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction
due to noise.
●Place the cables in a duct or clamp them. If not, dangling cable may swing or inadvertently be pulled,
resulting in damage to the module or cables or malfunction due to poor contact. Do not clamp the
extension cables with the jacket stripped. Doing so may change the characteristics of the cables,
resulting in malfunction.
●Check the interface type and correctly connect the cable. Incorrect wiring (connecting the cable to an
incorrect interface) may cause failure of the module and external device.
●Tighten the terminal screws or connector screws within the specified torque range. Undertightening
can cause drop of the screw, short circuit, fire, or malfunction. Overtightening can damage the screw
and/or module, resulting in drop, short circuit, fire, or malfunction.
●When disconnecting the cable from the module, do not pull the cable by the cable part. For the cable
with connector, hold the connector part of the cable. For the cable connected to the terminal block,
loosen the terminal screw. Pulling the cable connected to the module may result in malfunction or
damage to the module or cable.
●Prevent foreign matter such as dust or wire chips from entering the module. Such foreign matter can
cause a fire, failure, or malfunction.
●A protective film is attached to the top of the module to prevent foreign matter, such as wire chips,
from entering the module during wiring. Do not remove the film during wiring. Remove it for heat
dissipation before system operation.
●Programmable controllers must be installed in control panels. Connect the main power supply to the
power supply module in the control panel through a relay terminal block. Wiring and replacement of a
power supply module must be performed by qualified maintenance personnel with knowledge of
protection against electric shock. For wiring, refer to the MELSEC iQ-R Module Configuration Manual.
●For Ethernet cables to be used in the system, select the ones that meet the specifications in the user's
manual for the module used. If not, normal data transmission is not guaranteed.

8
[Startup and Maintenance Precautions]
[Startup and Maintenance Precautions]
WARNING
●Do not touch any terminal while power is on. Doing so will cause electric shock or malfunction.
●Correctly connect the battery connector. Do not charge, disassemble, heat, short-circuit, solder, or
throw the battery into the fire. Also, do not expose it to liquid or strong shock. Doing so will cause the
battery to produce heat, explode, ignite, or leak, resulting in injury and fire.
●Shut off the external power supply (all phases) used in the system before cleaning the module or
retightening the terminal screws, connector screws, or module fixing screws. Failure to do so may
result in electric shock.
CAUTION
●When connecting an external device with a CPU module or intelligent function module to modify data
of a running programmable controller, configure an interlock circuit in the program to ensure that the
entire system will always operate safely. For other forms of control (such as program modification,
parameter change, forced output, or operating status change) of a running programmable controller,
read the relevant manuals carefully and ensure that the operation is safe before proceeding. Improper
operation may damage machines or cause accidents.
●Especially, when a remote programmable controller is controlled by an external device, immediate
action cannot be taken if a problem occurs in the programmable controller due to a communication
failure. To prevent this, configure an interlock circuit in the program, and determine corrective actions
to be taken between the external device and CPU module in case of a communication failure.
●Do not disassemble or modify the modules. Doing so may cause failure, malfunction, injury, or a fire.
●Use any radio communication device such as a cellular phone or PHS (Personal Handy-phone
System) more than 25cm away in all directions from the programmable controller. Failure to do so
may cause malfunction.
●Shut off the external power supply (all phases) used in the system before mounting or removing the
module. Failure to do so may cause the module to fail or malfunction.
●Tighten the screws within the specified torque range. Undertightening can cause drop of the
component or wire, short circuit, or malfunction. Overtightening can damage the screw and/or module,
resulting in drop, short circuit, or malfunction.
●After the first use of the product, do not mount/remove the module to/from the base unit, and the
terminal block to/from the module, and do not insert/remove the extended SRAM cassette to/from the
CPU module more than 50 times (IEC 61131-2 compliant) respectively. Exceeding the limit may cause
malfunction.
●After the first use of the product, do not insert/remove the SD memory card to/from the CPU module
more than 500 times. Exceeding the limit may cause malfunction.
●Do not touch the metal terminals on the back side of the SD memory card. Doing so may cause
malfunction or failure of the module.
●Do not touch the integrated circuits on the circuit board of an extended SRAM cassette. Doing so may
cause malfunction or failure of the module.
●Do not drop or apply shock to the battery to be installed in the module. Doing so may damage the
battery, causing the battery fluid to leak inside the battery. If the battery is dropped or any shock is
applied to it, dispose of it without using.

9
[Startup and Maintenance Precautions]
[Operating Precautions]
[Disposal Precautions]
[Transportation Precautions]
CAUTION
●Startup and maintenance of a control panel must be performed by qualified maintenance personnel
with knowledge of protection against electric shock. Lock the control panel so that only qualified
maintenance personnel can operate it.
●Before handling the module, touch a conducting object such as a grounded metal to discharge the
static electricity from the human body. Failure to do so may cause the module to fail or malfunction.
CAUTION
●When changing data and operating status, and modifying program of the running programmable
controller from an external device such as a personal computer connected to an intelligent function
module, read relevant manuals carefully and ensure the safety before operation. Incorrect change or
modification may cause system malfunction, damage to the machines, or accidents.
●Do not power off the programmable controller or reset the CPU module while the setting values in the
buffer memory are being written to the flash ROM in the module. Doing so will make the data in the
flash ROM undefined. The values need to be set in the buffer memory and written to the flash ROM
again. Doing so can cause malfunction or failure of the module.
CAUTION
●When disposing of this product, treat it as industrial waste.
●When disposing of batteries, separate them from other wastes according to the local regulations. For
details on battery regulations in EU member states, refer to the MELSEC iQ-R Module Configuration
Manual.
CAUTION
●When transporting lithium batteries, follow the transportation regulations. For details on the regulated
models, refer to the MELSEC iQ-R Module Configuration Manual.
●The halogens (such as fluorine, chlorine, bromine, and iodine), which are contained in a fumigant
used for disinfection and pest control of wood packaging materials, may cause failure of the product.
Prevent the entry of fumigant residues into the product or consider other methods (such as heat
treatment) instead of fumigation. The disinfection and pest control measures must be applied to
unprocessed raw wood.

10
CONDITIONS OF USE FOR THE PRODUCT
• When SIL2 mode is set
(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident;
and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the
case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED TO ANY AND ALL
RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY
INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE
OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR
WARNING CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL
BULLETINS AND GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the
public could be affected if any problem or fault occurs in the PRODUCT.
• Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality
assurance system is required by the Purchaser or End User.
• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator,
Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for Recreation and Amusement, and
Safety devices, handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling, and/or other
applications where there is a significant risk of injury to the public or property.
Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the PRODUCT in one or
more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific
applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or
other safety features which exceed the general specifications of the PRODUCTs are required. For details, please
contact the Mitsubishi representative in your region.
(1) Although Mitsubishi Electric has declared Product's compliance with the international safety standards IEC61508,
IEC61511, this fact does not guarantee that Product will be free from any malfunction or failure. The user of this Product
shall comply with any and all applicable safety standard, regulation or law and take appropriate safety measures for the
system in which the Product is installed or used and shall take the second or third safety measures other than the
Product. Mitsubishi Electric is not liable for damages that could have been prevented by compliance with any applicable
safety standard, regulation or law.
(2) Mitsubishi Electric prohibits the use of Products with or in any application involving, and Mitsubishi Electric shall not be
liable for a default, a liability for defect warranty, a quality assurance, negligence or other tort and a product liability in
these applications.
(a) power plants,
(b) trains, railway systems, airplanes, airline operations, other transportation systems,
(c) hospitals, medical care, dialysis and life support facilities or equipment,
(d) amusement equipments,
(e) incineration and fuel devices,
(f) handling of nuclear or hazardous materials or chemicals,
(g) mining and drilling,
(h) and other applications where the level of risk to human life, health or property are elevated.
(3) Mitsubishi Electric shall have no responsibility or liability for any problems involving programmable controller trouble and
system trouble caused by DoS attacks, unauthorized access, computer viruses, and other cyberattacks.

11
INTRODUCTION
Thank you for purchasing the Mitsubishi Electric MELSEC iQ-R series programmable controllers.
This manual describes the specifications, procedures before operation, installation, and wiring to use the relevant products
listed below in normal mode.
Before using this product, please read this manual and the relevant manuals carefully and develop familiarity with the
functions and performance of the MELSEC iQ-R series programmable controller to handle the product correctly.
Please make sure that the end users read this manual.
Relevant products
RX40NC6B, RY40PT5B
To use the relevant products in SIL2 mode, refer to the following.
MELSEC iQ-R I/O Module (With Diagnostic Functions) User's Manual (Application)
COMPLIANCE WITH EMC AND LOW VOLTAGE
DIRECTIVES
Method of ensuring compliance
To ensure that Mitsubishi Electric programmable controllers maintain EMC and Low Voltage Directives when incorporated into
other machinery or equipment, certain measures may be necessary. Please refer to one of the following manuals.
• MELSEC iQ-R Module Configuration Manual
• Safety Guidelines (This manual is included with the base unit.)
The CE mark on the side of the programmable controller indicates compliance with EMC and Low Voltage Directives.
Additional measures
No additional measures are necessary for the compliance of this product with EMC and Low Voltage Directives.

12
MEMO

13
CONTENTS
CONTENTS
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
CONDITIONS OF USE FOR THE PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
RELEVANT MANUALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
CHAPTER 1 PART NAMES 15
CHAPTER 2 SPECIFICATIONS 17
2.1 Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Input module with diagnostic functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Output module with diagnostic functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
CHAPTER 3 FUNCTION LIST 21
CHAPTER 4 PROCEDURES BEFORE OPERATION 23
CHAPTER 5 INSTALLATION AND WIRING 25
5.1 Before Using the I/O Modules with Diagnostic Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Input module with diagnostic functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Output module with diagnostic functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.2 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.3 Input Wiring Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
APPENDICES 30
Appendix 1 External Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
INDEX 34
REVISIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

14
RELEVANT MANUALS
User's manuals relevant to the module
This manual does not include detailed information on the following:
• General specifications
• Applicable combinations of CPU modules and the other modules, and the number of mountable modules
• Installation
For details, refer to the following.
MELSEC iQ-R Module Configuration Manual
This manual does not include information on the module function blocks.
For details, refer to the Function Block Reference for the module used.
e-Manual refers to the Mitsubishi Electric FA electronic book manuals that can be browsed using a dedicated
tool.
e-Manual has the following features:
• Required information can be cross-searched in multiple manuals.
• Other manuals can be accessed from the links in the manual.
• The hardware specifications of each part can be found from the product figures.
• Pages that users often browse can be bookmarked.
• Sample programs can be copied to an engineering tool.
TERMS
Unless otherwise specified, this manual uses the following terms.
Manual name [manual number] Description Available
form
MELSEC iQ-R I/O Module (With Diagnostic Functions) User's Manual
(Startup)
[SH-081619ENG] (this manual)
Specifications, procedures before operation, installation, and
wiring of the I/O module with diagnostic functions
Print book
e-Manual
PDF
MELSEC iQ-R I/O Module (With Diagnostic Functions) User's Manual
(Application)
[SH-081621ENG]
Functions, parameter settings, troubleshooting, I/O signals, and
buffer memory of the I/O module with diagnostic functions
Print book
e-Manual
PDF
Before Using the Product
[BCN-P5999-0209]
Compatible models, specifications, and installation procedure of
the Q6TE-18SN spring clamp terminal block
Print book
PDF
Term Description
CPU module A generic term for the MELSEC iQ-R series CPU modules
Engineering tool Another term for GX Works3
GX Works3 The product name of the software package for the MELSEC programmable controllers
I/O module with diagnostic functions The abbreviation for the MELSEC iQ-R series I/O module with diagnostic functions
Normal mode A mode to be set for performing normal I/O operation
Power supply module A generic term for the MELSEC iQ-R series power supply modules
Remote head module The abbreviation for the RJ72GF15-T2 CC-Link IE Field Network remote head module
SIL2 mode A mode to be set for using the I/O module with diagnostic functions in the system where a SIL2 Process
CPU is used

1 PART NAMES
15
1
1PART NAMES
This chapter describes the part names of the I/O module with diagnostic functions.
*1 The LED and terminal block are added to the module with production information (first four digits) of "0202" or later.
No. Name Description
(1) RUN LED Indicates the operating status.
On: In operation
Flashing (400ms cycles): Selected as a module for the online module change
Off: 5V power supply interrupted, watchdog timer error occurred, or module replacement allowed in the
process of the online module change
(2) ERR LED Indicates the error status of each I/O terminal in combination with the I/O status indicator LED. (
MELSEC iQ-R I/O Module (With Diagnostic Functions) User's Manual (Application))
On: Error occurred
Off: Normal operation
(3) ALM LED Indicates the alarm status of each I/O terminal in combination with the I/O status indicator LED. Or indicates
the wait-for-restart state after the safety module is disabled. (MELSEC iQ-R I/O Module (With
Diagnostic Functions) User's Manual (Application))
On: Alarm occurred
Flashing (400ms cycles): Wait-for-restart
Off: Normal operation
(4) S MODE LED*1 Always off in normal mode. Used in SIL2 mode. (MELSEC iQ-R I/O Module (With Diagnostic Functions)
User's Manual (Application))
(5) I/O status indicator LED Indicates the I/O status of each I/O terminal, error status, or alarm status according to the setting of "LED
display setting when error occurred".
• When "Hide abnormal occurrence points" is set
On: I/O signals on
Off: I/O signals off
• When "Always display abnormal occurrence points" or "Switching display of input status and alarm (1
second intervals)" is set
The I/O where an error has occurred can be specified. For details on the LED indication, refer to the
following.
MELSEC iQ-R I/O Module (With Diagnostic Functions) User's Manual (Application)
(6) Module identification lamp Light gray: Input
Dark orange: Output
(7) Rate indication Indicates the rated voltage, and input current or output current.
(8) Terminal block 18-point screw terminal block. For the terminal layout, refer to the following.
Page 17 Performance Specifications
(9) Terminal block cover Covers for preventing electric shock while the power is on
(10) Terminal block for test pulse output*1 Not used in normal mode. Used in SIL2 mode. (MELSEC iQ-R I/O Module (With Diagnostic Functions)
User's Manual (Application))
(11) Production information marking Shows the production information (16 digits) of the module.
(1)
(2) (3)
(5)
(4)
(6)
(7)
(8)
(11)
(9)
(1)
(2) (3)
(5)
(4)
(6)
(7)
(8)
(11)
(10)
(9)

16 1 PART NAMES
MEMO

2 SPECIFICATIONS
2.1 Performance Specifications 17
2
2SPECIFICATIONS
This chapter describes the performance specifications.
2.1 Performance Specifications
This section describes the performance specifications of the I/O module with diagnostic functions.
Input module with diagnostic functions
RX40NC6B DC input module
*1 When the input current is 0.3mA/point or lower, a disconnection (no connection) is detected. When the leakage current of the input
device is 0.3mA/point or lower, connect a bleeder resistance (resistance value as a guide: approx. 56k) in parallel near the device
connected.
Immediately after power-off of the power supply module, if the input power source is applied to the power
supply module again, the input module with diagnostic functions may not start up. When applying the input
power source to the power supply module again, do so five seconds or more after the shut-off of the power.
Item Specifications
Number of input points 16 points
Rated input voltage 24VDC (ripple ratio: within 5%) (allowable voltage range: 20.4 to 28.8VDC)
Rated input current 6.0mA TYP. (at 24VDC)
ON voltage/ON current 14V or higher/3.5mA or higher
OFF voltage/OFF current 6V or lower/1mA or lower
Input resistance Approx. 4.0k
Response time Page 18 Input response time
Disconnection (no connection)
detection current
0.3mA or lower/point*1
External power
supply
Voltage 24VDC (ripple ratio: within 5%) (allowable voltage range: 20.4 to 28.8VDC)
Current 130mA (at 24VDC)
Withstand voltage 510VACrms, 1 minute
Isolation resistance 10Mor higher by isolation resistance tester
Noise immunity Simulator noise 500Vp-p, noise width 1s,
noise frequency 25 to 60Hz (noise simulator condition)
Protection degree IP2X
Wiring method for common 16 points/common (common terminal: TB18)
Number of occupied I/O points 32 points (I/O assignment: Input 32 points)
Interrupt function Available (can be set in the parameters of the CPU module)
External interface 18-point screw terminal block (M36 screw)
Page 28 Wiring
Internal current consumption (5VDC) 450mA (TYP. all points ON)
Weight 0.25kg

18 2 SPECIFICATIONS
2.1 Performance Specifications
■Circuit configuration
■Terminal connection
Connection diagram viewed from the front of the module
■Input response time
*1 The default value of input response time is 10ms.
X00 to X0F are signal names.
The number of 1 to 18 indicates the terminal number.
Timing Setting value
1ms 5ms 10ms*1 20ms 70ms
OFFON (MAX) 1ms 5ms 10ms 20ms 70ms
ONOFF (MAX) 1ms 5ms 10ms 20ms 70ms
TB17
TB18
TB1
TB16
24VDC
Internal
circuit
Constant-voltage
circuit
X01
X03
X05
X07
X09
X0B
X0D
X0F
X00
X02
X04
X06
X0A
X0C
X0E
1
3
5
7
9
11
13
15
17
2
4
6
8
10
12
14
16
18
COM
X08
24VDC
