After penetrating the cranium with
the pins, fixate in order to prevent
slippage/movement.
Stopper Sleeve
Adoption of a ratchet slider on all 6
pin holes. There is no need to rotate
the pin countless times, simply push
the pin in with a quick sliding motion.
Positioned at the back of each pin is a
locking mechanism, this allows the
final pin fixation to be done safely by
rotating pins with one’s finger.
Ratchet Slider
Change in the shape of the fixation
screw on the center of the box joint.
This increases the fixing force of the
head frame. Additionally, added new
rollers to allow the smooth sliding
motion of the overall frame.
Box Joint
The table attachment and basal frame
from the original version of the
Sugita Multi-Purpose Head Frame
System are interchangeable and can
be used in conjunction with the
upgraded Smart Fix Head Holder
System.
Table attachment and Basal Frame
Insert the pin through the smart fix
ratchet holes. Due to the mechanism of
the ratchet slider, simply press the pin
forward to smoothly position the pin in
place. Upon the pin reaching the patient’s
skull, manually rotate the pin for final
fixation. Always rotate two pins at the
same time for fixation. By rotating two
opposed pins at a time, minute
adjustments can be implemented.
After the skull has been fixated, please fix
the stopper sleeve so there is no risk that
the pin will slip or move.
Simply push
the pin in!
a
m
e
the
a
me
c
an
t
h
e
der
t
and Basal Fram
e
Method / Technical of
mounting the pin

New Smart Fix Head Holder Set
0504 215.9mm 215.9mm
Ⓙ
07-951-11
Ⓚ
07-951-12
Ⓞ
07-952-00
Ⓛ
07-951-15
The adoption of a new Ratchet Slider mechanism.
This allows the Sugita Multi-Purpose Head
Holder to retain the reliability and standard of
performance that the current system has, while
making it possible to implement a quickly agile
skull fixation.
Ⓐ
07-981-02
Ⓔ
07-981-06
Ⓕ
07-981-07
Ⓗ
07-954-00MM
Ⓑ
07-981-03
Ⓒ
07-981-04
Ⓓ
07-981-09
Ⓘ
07-955-01
Ⓖ
07-981-10
Product DescriptionP. No.
07-981-02
07-981-03
07-981-04
07-981-06
07-981-07
07-981-09
07-981-10
07-954-00MM
07-955-01
07-951-11
07-951-12
07-951-15
07-951-33
07-951-34
07-952-00
Set Qty
1
1
1
1
1
1
1
6
2
1
1
4
4
4
1
Basal Frame/Semi-Circular Frame
Hand Rest
Adjustable Hand Rest With Dome Screw
Instrument Receptacle
Cotton Plate
Adjustable Hand Rest With Slide
Quarter Frame
Spring Hook Retractors, SUS
Slede Adjustor For Retractor
Smart Fix C Holder
Smart Fix Joint Box (Including 2 Fixing Screws)
Smart Fix Stopper Sleeve
Smart Fix Head Pin Standard
Smart Fix Head Pin Long
Table Attachment
Ⓐ
Ⓑ
Ⓒ
Ⓔ
Ⓕ
Ⓓ
Ⓖ
Ⓗ
Ⓘ
Ⓙ
Ⓚ
Ⓛ
Ⓝ
Ⓜ
Ⓞ
Smart Fix Head Frame Set
Smart Fix Head Frame Set
Basal Frame and Accessories
Table Attachment
Product DescriptionP. No.
07-952-05
07-952-06
08-075-10
08-075-11
Table Attachment For 2080
Table Attachment For 3080
Mayfield Adaptor
Attachment For Mayfield Head Support
Table attachment Option
Ⓜ
07-951-33
Ⓝ
07-951-34
Long
Standard

0706 215.9mm 215.9mm
Horseshoe Head Rest
Navigation Adaptor
Head Holder (Original model)
Simple and Cost effective 4 pins
fixation model.
Product DescriptionP. No.
07-970-50
07-970-51
NV Adaptor, Stainless
NV Adaptor, MRI/CT
07-951-01MM
07-951-02MM
07-951-03MM
07-951-00MM
07-175-00
07-157-01
07-952-00
07-970-50
07-970-51
Product DescriptionP. No.
07-951-00MM
07-951-01MM
07-951-02MM
07-951-03MM
Head Holder
Head Pin, Standard, Sus
Head Pin, Short Tip, For Adult, SUS
Head Pin, Short Tip, For Pediatric, SUS
Product DescriptionP. No.
07-175-00
07-157-01
07-952-00
Self-Retaining Retractor Attachment F-1
Tapered Self-Retaining Retractor 42cm
Table Attachment
Product DescriptionP. No.
08-073-03
08-073-04
U-Shaped Head Rest L
U-Shaped Head Rest S
L:200
S:170
L:110
S:65
L:130
S:110
（mm）

Assembly work complete just to put basal frame on head
holder and tighten screws by two handles (P07-980-04).
A key accessory for microscopic operation.
Arm rest secures free space to operate by setting it up
above spatula and self-retaining retractors.
Product DescriptionP. No.
07-981-02
07-981-03
07-981-04
07-981-06
07-981-07
07-981-09
07-981-10
07-954-00MM
07-955-01
Basal Frame/Semi-Circular Frame
Hand Rest
Adjustable Hand Rest With Dome Screw
Instrument Receptacle
Cotton Plate
Adjustable Hand Rest With Slide
Quarter Frame
Spring Hook Retractors, SUS
Slede Adjustor For Retractor
Everything surgeon needs for operation is on this circular
frame. All accessories can attach on. Well organized
frame to support operation.
At each end of the Basal Frame are two
holes to support the Hand Rest
and Instrument Receptacle.
The angle and height of the Hand Rests
are adjustable to suit each surgeon.
Instrument Receptacle is insulated
and used to retain Bipolar Forceps,
Suction Tubes, and other
microsurgery instruments.
The sub frame and semi-circular
is used to attach Scalp Hooks,
Cotton plate and self-retaining
retractor.
All accessories can attach on.
07-981-03
07-981-06
07-981-04
07-981-09
Basal Frame
0908 215.9mm 215.9mm
Arm Rest Example Usage
Instrument Receptacle Example usage
Very easy to assemble

Tapered and Non Tapered Self-Retaining RETRACTORS for Microsurgery
09
08 215.9mm 215.9mm
Safety, security, stability
Mizuho’s self-retaining snake retractors provide
exceptional stability and control throughout the
entire neurosurgical procedure. Once adjusted
and locked down, the arm maximizes balance
and holding power, effectively preventing “drift
and drop” that cause spatulas to shift and
threaten vulnerable neural and vascular structures
Two convenient, compatible designs
Retractors are available in both tapered and
non-tapered designs. Both are fully compatible
with Mizuho’s F-1 (C-clamp) attachment, which
affixes directly to any standard headframe in just
a few seconds. This timesaving feature is
especially beneficial during urgent trauma cases.
Retractors can also be quickly attached right to
the Sugita Basal Frame using the convenient slide
adjustors. Currently, Mizuho offers nine models
to choose from in lightweight, corrosion-resistant
titanium and traditional stainless steel.
Self-retaining retractor advantages
・No-drift design holds spatulas securely in place
・Choice of tapered or non-tapered to match your
preference
・Faster setup and breakdown than traditional
slide-rail systems
Product DescriptionP. No.
07-174-24
07-174-25
07-157-01
07-157-02
Retaining Retractor 42cm Without Clamp
Retaining Retractor 37cm Without Clamp
Tapered Self-Retaining Retractor 42cm
Tapered Self-Retaining Retractor 37cm
P. No.
07-157-11
07-157-12
Tapered Self-Retaining Retractor 5mm 37cm
(Hadeishi Version)
Tapered Self-Retaining Retractor 6mm 37cm
(Hadeishi Version)
P. No.
07-173-00
07-174-21
07-174-22
07-174-23
07-174-26
Self-Retaining Retractor Single
Self-Retaining Retractor Stainless Steel 37cm
Self-Retaining Retractor Stainless Steel 42cm
Self-Retaining Retractor Stainless Steel 24cm
Self-Retaining Retractor Stainless Steel 48cm
P. No.
07-175-00 Self-Retaining Retractor Attachment F-1
Product Description
Product Description
Product Description
Retractors are fuly compatible with F-1
(C-clamp) attachment, which affixes directly to
any standard head frame in just a few second.
Tapered shape body provides maintaining
strong fixing force during surgery.
New Ball Joint top retractor. Easy to remove
and reposition spatula by one hand.
Helping to retract tumor from back and forth.
Tapered Titanium Retractor
F-1 Attachment
Stainless Retractor
Hadeishi Titanium Retractor
