MJ LED LIGHTNING MJ-2010 3W5DRGBW User manual

LED Outdoor Par-354
MJ-2010
(3W5DRGBW)
User Manual
=======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED Par light. For the sake of your safety, Please read
and follow these instructions carefully and keep this manual in a safe place for
future reference

5
Important notice:
Before open the LED outdoor par light and if you want to do the repair work,
please make sure the power source is at the separation condition.
Unceasingly carries on the product improvement about our company the
policy, in this instruction booklet carries the data will have the possibility to
be able to change in the future, when no longer separate notice change
matters concerned. Our company retains when the product improvement
changes the related specification the authority. This instruction booklet
publisher cannot be responsible regarding this instruction booklet in
information accuracy, also cannot the related consequence which causes
regarding these information be responsible.
Warning:
Please do NOT connect the power supply before open the light.
Please do NOT use any object to cover the lamp.
Please do NOT use the lamp under the close environment.
Please do NOT use the lamp under the water.
Please do NOT connect the power cable hand by hand over 10pcs.

4 1
Waterproof manage:
Signal joint(at most 30pcs)XL-3R,at first, use the high voltage and waterproof
adhesive tape with mucosity to enlace the joint one circle. After stretch the
adhesive tape, then you can enlace it, please reference the operation
describe.), then cover a 20mm cannula with pyrocondensation.
At last, envelop the joint to reach a waterproof effect.
Warning: If this joint can’t do the waterproof manage, then the lamp waterproof
effect will be invalid, then destroy the product.
Channel List:
4CH Mode
Channel Value Function
CH1 0-255 Red dimming, Linear dimming, from dark to bright
CH2 0-255 Green dimming, Linear dimming, from dark to bright
CH3 0-255 Blue dimming, Linear dimming, from dark to bright
CH4 0-255 White/Amber dimming, Linear dimming, from dark to bright
8CH Mode
Channel Value Function
CH1 0-255 Main dimming from dark to bright
CH2 0-255 Red dimming, Linear dimming, from dark to bright
CH3 0-255 Green dimming, Linear dimming, from dark to bright
CH4 0-255 Blue dimming, Linear dimming, from dark to bright
CH5 0-255 White/Amber dimming, Linear dimming, from dark to bright
CH6 0-255 Control strobe from slowly to quickly
CH7 0-255 The speed of function from slowly to quickly
CH8 0-50 No function
51-100 Choose the color
101-200 Color change by pulse
201-240 Color change byFade
241-250 Color change by Snapping
251-255 Sound control
Installation:
1.This light can work normally between the Voltage of AC90~~240V/50Hz/60Hz.
2. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
3. Always keep this light with a safe distance from any flammable materials.
4. Never install, dismantle and maintain this light when it is powered; and all
work aforesaid must be conducted by professionals.
5. The packing list of this light is as follows:
1) Light----------------------------------------------1pcs
2) Power Cable-----------------------------------1pcs
3) User Manual-----------------------------------1pcs
Modes of Operation
There are four modes of operation: DMX control (Slave), Sound, Automatic, and
Manual. In the Sound, Automatic, and Manual settings, the unit will perform
independently and will send DMX signal, so that other fixtures may be linked.
This is useful if you want every fixture doing the same thing and do not wish to
use an external DMX controller. All menu settings will be retained even after
the lights have been powered off.
1. DMX Control – Fixture is remotely controlled via a DMX controller (sold
separately).
2. Sound Control – Fixture changes color in response to noise.
3. Manual Control – Color are manually set via the control pad.
4. Automatic Color Cycle – Unit cycles through colors automatically. User
sets whether fade is instant or slow, whether 3 or 7 colors are used, and
the length of time between fades.
No. Display Function
1 d001 d001—d512 (4 channel) press “UP” and “Down” button
change the DMX address

2 3
2 A001 A001—A512 (8 channel) press “UP” and “Down” button
change the DMX address
3 FF00 FF01—FF
99 (Color change by Fade), press “UP” and
“Down” button change the Fade speed
4 CC00 CC01—CC99 (Color change by Snapping), press “UP” and
“Down” button change the snapping speed
5 R(GBW) 000—255 (RGBW dimming by hand)
, Press ENTER to
chose the RGBW to balance
6 DE00 DE01--DE99
(Color change by RG,RB,RW,BG,BW,RGB…..)
press “UP” and “Down” button change the speed
7 Soud Sound mode
8 SLAu Slave mode
NOTE：When operating the color balance function, please press ENTER to
choose the colors, then use UP or DOWN to select the brightness.
1. DMX Control
1. If you wish to control the unit remotely via DMX, you will need a DMX
controller. Connect an XLR cable to the controller's DMX output
and the fixture's input.
2. Set the fixture to receive DMX signal
a) Press and hold 'MENU' button until display says d001 or A001.
(Note:d001 is 4CH,A001 is 8CH,you can choose it.)
b) Press 'ENTER', then the fixture will receive the DMX 512 signal.
c) Press UP or DOWN to select the desired address.
d) Press ENTER button to activate the selection..
2. Sound Activation (color changes in response to loud noises)
1. Press and hold 'MENU' button until the display panel says SoUd
(short for sound).
2. Press 'ENTER'
3. Manual Control(RGBW dimming by hand):
1. Press and hold 'MENU' button until display panel says R255 ,Press Enter
button to chose G,B,W
2. Press UP or DOWN to select the address
3. Press 'ENTER'
RED (0-255) BLUE (0-255)
GREEN (0-255) WHITE (0-255)
4. Automatic Color Cycle
1．Press MENU, the display panel says CC01 – CC99,this way is color
jumping and speed changing.
2. Press MENU, the display panel says FF01 – FF99,this way is color
changes by Fading.
Technical Parameters:
Construction: Aluminum
Voltage: AC 100-240V, 50Hz/60Hz
LED: 3W*54 LED (Red:14pcs, Green:14pcs, Blue:14pcs, White: 12)
Power Consumption: 170 Watts
LED Current: 750mA / 1 pc
LED Beam Angle: 5°
LED Lifetime: 80,000-100,000 hours
Color: RGBW color mixing
DMX Control: 4/8 Channels
Operation Modes: DMX512, Internal Program, Master/slave,Sound
Control Panel: Digital 4 Character Alphanumeric
Maximum Ambient Temperature: 60° C
Waterproof Rating: IP65
Gross Weight: 10.2 kg
Package Size: 31×31×35.5CM
