MJ LED LIGHTNING WIRELESS BATTERY PAR 910 User manual

WIRELESS BATTERY PAR 910
MJ-3119A
(RGBA)
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED wireless battery par light. For the sake of
your safety, Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.

81
Before open the LED wireless battery par can light and if you want to do the
repair work, please make sure the power source is at the separation
condition.
Unceasingly carries on the product improvement about our company the
policy, in this instruction booklet carries the data will have the possibility to be
able to change in the future, when no longer separate notice change matters
concerned. Our company retains when the product improvement changes the
related specification the authority. This instruction booklet publisher cannot be
responsible regarding this instruction booklet in information accuracy, also
cannot the related consequence which causes regarding these information be
responsible
Most important: FIRST CHARGE THE FIXTURES FOR 6-8 Hours on the First
Charge before use. Plug in Power cord. Turn off Power Switch and wireless
Switch and Turn ON charger switch to charge.
Introduction
Unpacking: Thank you for purchasing this product, all products has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the shipping carton for damage
that may have occurred during shipping. If the carton appears to be damaged, carefully inspect
your fixture for any damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are missing, please contact the
manufacturer or your dealer for further instructions. Do not return this unit to your dealer without
first contacting.
Introduction: The Light is a DMX intelligent and battery powered LED par light. This par light is
light weight and compact which makes it a great piece for mobile DJ‟s and clubs.
Warning! To prevent or reduce the risk of electrical shock or fire, do not expose this unit to rain
or moisture.
Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs
yourself; doing so will void your manufactures warranty. In the unlikely event your unit may
require service please contact the manufacturer or your dealer.
PLEASE recycle the shipping carton whenever possible.
General Instructions
To optimize the performance of this product, please read these operating instructions carefully
to familiarize you with the basic operations of this unit. These instructions contain important
safety information regarding the use and maintenance of this unit. Please keep this manual with
the unit, for future reference.
Notice :please pay attention to ventilation, to prevent the
battery overheat cause burning When charging.

27
Features
●Power supply: AC100V-250V
●Frequency: 50-60Hz
●Power consumption: 90W
●Light source: 9pcs 10W RGBA high brightness 4in1 led
●Lamp life: 6-10 ten thousand hrs
●LED angle: 30(±5) degree
●Color: 16.7 million kinds of color change
●Control channels: 4/8 CH
●Battery power & wireless DMX
●Wireless DMX-512 protocol
●Built in 2.4G receiver/ transmitter for wireless DMX operations
●Control mode: DMX512, master/slave, auto, sound active ,wireless DMX512
●Automatic model(by function button) : color change, color strobe, color dimmer,
color gradual change/color jump change
●Operation menu: 4 digit digital LED display
●Packing size: 265*165*275mm
●N.W: 3.5kg
●G.W: 4.2kg
Safety Precautions
●To reduce the risk of electrical shock or fire, do not expose this unit to rain or
moisture.
●Do not spill water or other liquids into or on to your unit.
●Be sure that the local power outlet match that of the required voltage for your
unit.
●Do not attempt to operate this unit if the power cord has been frayed or broken.
Do not attempt to remove or break off the ground prong from the electrical cord.
This prong is used to reduce the risk of electrical shock and fire in case of an
internal short.
●Disconnect from main power before making any type of connection.
●Do not remove the cover under any conditions. There are no user serviceable
parts inside.
●Never operate this unit when it‟s cover is removed.
●Never plug this unit in to a dimmer pack.
●Always be sure to mount this unit in an area that will allow proper ventilation.
Allow about 6” (15cm) between this device and a wall.
●Do not attempt to operate this unit, if it becomes damaged.
●This unit is intended for indoor use only; use of this product outdoors voids all
warranties.
●During long periods of non-use, disconnect the unit‟s main power.
●Always mount this unit in safe and stable matter.
There are three buttons on the rear panel of the lighting. One is for power, one is
wireless signal and the other is for charger.
●When use the fixture with DMX, not wireless, please switch the signal button
for “off”
●When use the wireless DMX, please switch the button for “on”
●When charge the light, please switch both of the button for “of”. At the same
time, if the switch for power is “on”, the light will be at work during the process of
charge, but will consume some power from the charge; if the switch for power is
“off”, the light will be blackout and not be at work.
Tip for the battery and charge:
●The battery can last for 3-4 hours when all LEDs on after full charge , and can
last for more than 6-8 hours on auto running mode. Up to 10 Hours with one color
diode on. Results will vary based on brightness of LEDs
●It is suggested to charge the battery for at least 4 hours, which will extend the
life span of the battery.
Charge Warning:
1.For carton box:
Please do NOT put in carton box while charging.
2.For Flight case:
Please do NOT close the case while charging.
3.For charge time:
Please do NOT charge over 10 hours.

63
For Battery Function and Charge
The unit has the function of battery powered. The button for battery and
charge is set on the rear panel. It is showed as the following picture,
and the function is described as below.
1. Alpha-numeric display 2. Touch switches 3. DMX-Out socket
4. DMX-In socket 5. Power out 6. Microphone 7. Power in
1. Antenna 2. ID code selector 3. Wireless indicator 4.Power
switch for wireless receiver 5. Power switch for charger 6. Power
switch for light power 7.Battery indicator
●Power-supply cords should be routed so that they are not likely to be walked
on or pinched by items placed upon or against them, paying particular attention to
the point they exit from unit.
●Cleaning -The fixture should be cleaned only as recommended by the
manufacturer. See “Cleaning” for details.
●Heat -The appliance should be situated away from heat sources such as
radiators, heat registers, stoves, or other appliances (including amplifiers) that
produce heat.
●The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a marked
change in performance
●Fuse standard is 2A/250V
●Grounded using yellow/green line
●The ambient temperature must always be under +35° C
Set Up
Power Supply: Before plugging your unit in, be sure the source voltage in your
area matches the required voltage for your light is workable in
100-240V/50~60Hz. Because line voltage may vary from venue to venue, you
should be sure your unit voltage matches the wall outlet voltage before
attempting to operate you fixture.
Operating Instructions
Operating Modes: You can use the light in 5 ways:
●Sound activation – The unit will activated by the sound signal.
●Static display – The unit will display the color in static way.
●Auto Mode -The unit will automatically chase through the different patterns.
●DMX control mode -This function will allow you to control the lighting with a
standard DMX 512 controller.
●Battery powered – This function will allow you to control the lighting
independently without any DMX cable
DMX Mode: Operating through a DMX controller give the user the freedom to
create their own programs tailored to their own individual needs. This function
also allows you to use your fixtures as pattern changing lights.
1. This function will allow you to control each individual fixtures traits with a
standard DMX 512 controller.

45
2. The light use 4/8 DMX channels to operate. Please see “DMX channel and
Functions” for the DMX traits.
3. To run your fixture in DMX mode, plug in the fixture via the XLR connections to
any standard DMX controller. Set your desired DMX address following the setup
specifications that come with your DMX controller.
4. The unit can automatically recognize the DMX signal once the DMX connection
is done.
DMX Linking:
To ensure proper DMX data transmission, when using several DMX fixtures try to
use the shortest cable path possible. The order in which fixtures are connected in
a DMX line does not influence the DMX addressing. For example; a fixture
assigned a DMX address of 1 may be placed anywhere in a DMX line, at the
beginning, at the end, or anywhere in the middle. When a fixture is assigned a
DMX address of 1, the DMX controller knows to send DATA assigned to address
1 to that unit, no matter where it is located in the DMX chain.
Buttons instruction:
There are four touch buttons under the LED Alpha-numerical display: Menu,
Down, Up, Enter. Normally, the LED will display the current DMX address code of
the fixture. At this time, presses Menu to choose the function you want to set up.
Press and hold Up or Down to fast scrolling within the menu options. When an
options flashing the LED display, press Enter to confirm and Menu to exit.
Menu down up Enter
No.
Display
Function
1 A001
A001—A512 (8 channel) press “UP” and “Down”
button change the DMX address
2 d001
d001—d512 (4 channel) press “UP” and “Down”
button change the DMX address
3 CL01
CL01—CL15 (Color Mixing), press “UP” and
“Down” button change the mixing color
4 CC01
CC01—CC99 (Color change by Snapping), press
“UP” and “Down” button change the Snapping speed
5 EE01
EE01—EE99 (Color change by Fade), press “UP”
and “Down” button change the Fade speed
6 FF01
FF01—FF99 (Color change by pulse), press “UP”
and “Down” button change the pulse speed
7 ST99
ST01-ST99(Color Strobe, press “UP” and “Down”
button change the strobe speed
8
SE01
Sound sensitivity adjustment
9
SOU1
Sound mode 1/2/3
10
LED
LED display ON/OFF
11
IRCL
IR control(this model no function)
10
TENP
LED board temperature(this model no function)
11
TEST
Color testing
12
R000
R000—R255 (R dimming by hand)
13
G000
G000—G255 (G dimming by hand)
14
B000
B000—B255 (B dimming by hand)
15
U000
U000—U255 (A dimming by hand)
DMX channel
Channel
Value
4CH
8CH
CH1
0
Off
Off
1-255
R dimmer
Main dimmer
CH2
0
Off
Off
1-255
G dimmer
R dimmer
CH3
0
Off
Off
1-255
B dimmer
G dimmer
CH4
0
Off
Off
1-255
A dimmer
B dimmer
CH5
0
Off
1-255
A dimmer
CH6
0-9
Off
10-255
Strobe function slow-fast
CH7
0-9
Off
10-49
Color mixing
50-89
Color change by Snapping
90-129
Color change by Fade
130-199
Color change by pulse
200-219
Sound mode 1
220-239
Sound mode 2
240-255
Sound mode 3
CH8
0
No action
1-255
Speed control fast -slow
