Mocka Aspen Four Drawer User manual

Phillips & Flathead screwdrivers and hammer required
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
1
X
Z
Y
W
safety
strap
x1
screw
x1
long
screw
x1
wall
anchor
x1
washer
x1
mocka.co.nz | mocka.com.au
B
ACDEF
GH
12 mm
Hardware Supplied
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
WARNING: Any furniture that is not anchored to a wall has the potential
to tip over in certain circumstances, i.e. if a child attempts to climb up on
the furniture or in the event of an earthquake. Accordingly, we
recommend that all furniture is anchored to a wall. We supply a free
safety wall anchor with all furniture sold and we recommend these are
used to prevent your product tipping. The fixing device provided should
fit most wall types, but please note that different wall materials
may require different fixing devices from those supplied.
bolt
x32
locking
nut x 32
dowel
x12
small
screw x32
I
L + R
slide rail
x8
L + R
slide rail
x8
screw x 20
Aspen Four Drawer
40 mm
long
screw x 10
handle
x 4
30 mm
medium
JKL
nut
x4
long
screw x4
cover
x 16
M
wedge
x8

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
2
mocka.co.nz | mocka.com.au
Aspen Four Drawer
12
A
1
Insert 4 x bolts (A) into panel [1]. Tighten with a screwdriver.
Attach 1 x wall strap (W) to panel [1] using 1x screw (Y).
G
Attach 4 x left slide rails (G) to panel [3] and secure with 8 x small screws (E).
Attach 4 x right slide rails (G) to panel [4] and secure with 8 x small screws (E).
E
4
Tighten with a screwdriver.Insert 8 x bolts (A) into panels [3] and [4].
10
9
10
9L
L
KK
KK
L
L
K
Insert 4 x nuts (K) into panels [10]. Attach panels [9] to panels [10] and secure
with 4 x screws (L).
YW
A
A
A
A
E
EE
EE
EE
A
A
GGGG
A
3A
EE
EE
EE
EE
A
A
A
A
GG
G
G

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
3
mocka.co.nz | mocka.com.au
Aspen Four Drawer
34
5
4
6
Insert 2 x dowels(C) into panels [6]. Attach panels [3] to panels [5] and [6]
and secure with 4 x locking nuts (B). Tighten with a screwdriver.
B
6
B
B
B
B
C
B
C
6
6
5
B
B
BC
B
C3
Insert 2 x dowels (C) into panels [6]. Attach panels [4] to panels [5] and [6]
and secure with 4 x locking nuts (B). Tighten with a screwdriver.

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
4
mocka.co.nz | mocka.com.au
Aspen Four Drawer
56
Insert 4 x dowels (C) into panels [3] and [4]. Attach panel [2]
to panels [3] and [4] and secure with 4 x long screws (D).
Slide panels [7] and [8] between the grooves on panels [3] and [4]
to form theback of the unit as shown.
7
8
3
4
2
D
D
D
D
C
C
C
3
4

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
5
mocka.co.nz | mocka.com.au
Aspen Four Drawer
78
3
4
1
C
3
DD
D
D
D
D
2
7
C
B
B
B
B
CC
Attach panels [9] and [10] to panel [2] and secure with 6 x long
screws (D). Tighten with a screwdriver. Tighten with a screwdriver.
Insert 4 x dowels (C) into panels [3] and [4]. Attach panel [1] to panels [3] and
[4] and secure with 4 x locing nuts (B).
9
10

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
6
mocka.co.nz | mocka.com.au
Aspen Four Drawer
910
Drawers (x4)
BB
B
B
A
AA
A
11
12
13
Tighten with a screwdriver.
Insert 16 xbolts (A) into panel [11] .Attach panels [12] and [13] to panel
[11] secure with 16 x locking nuts (B).
B
A12
13
14
15
11
I
II
M
Cover locking nuts (B) with 16 x covers (M).
Drawers (x4)
Insert 4 x bolts (A) into panels [11]. Slide panels [15] between the
Attach panels [14] to panels [11] and secure with 4 x locking nuts (B).
grooves on panels [12] and [13] to form the base of the drawer as shown.

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
7
mocka.co.nz | mocka.com.au
Aspen Four Drawer
11 12
Drawers (x4)
I
E
I
13
E
H
H
E
F
F
F
F
F
12
15 14
16
13
Tighten with a screwdriver.
Attach panels [16] to panels [12], [13] and [14] secure with 20 x medium
screws (F).
Attach 8 x slide rails (H) to panels [12] and [13] and secure with 16 x small
screws (E). Insert 4 x handles (I) into panels [11] .
Drawers (x4)
11
12

Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
8
mocka.co.nz | mocka.com.au
Aspen Four Drawer
13 14
Once assembled lift furniture into place, do not drag. Use a drill to create
a small hole lining up with the top of the safety strap (W). Fasten to wall
using wall anchor (X), washer (Z) and screw. Ensure the unit is balaced
and steady before use. You’re done, enjoy!
X
Z
x1
wall
screw
wall
anchor
wall
screw
Washer
Strap
Attach 8 x wedges (J) to panels [7] and
[8].
Tighten with a screwdriver.
J
J
J
8
J
J
J
J
7
J
J
