Mocka Kennedy User manual

Kennedy Console Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hardware Supplied
dowl
x12
bolt
x10
long screw
x6
locking nut
x10
small screw
x13
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
1
A B C D E
P
O
KJIH
G
wedge
x4
scerw
x4
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
CL runner tracks
x1
CR runner tracks
x1
DL runners
x1
DR runners
x1
M
L
bracket
x1
cover
x1
Q
F
allen key
x1
plug
x1
bolt
x8
RS
sticker
x2
N
screw
x4
felt pad
x4
Phillips & Flathead screwdrivers required.

Kennedy Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au
2
1
C
C
C
C
C
C
EE
L
EE
M
LL
2
1
Attach 1x bracket (L) to panel [2] and secure with 2x screws (E). Tighten
with a screwdriver and attach 1x cover (M) as shown. Insert 6x bolts (C)
into panel [1].
1
2
3
4
5
6
7
7
810
9
11
12
Panel Layout

Kennedy Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
3
23
E
H
CR
E
G
CL
E
E
E
E
E
E
4
5
3
4
5
1
A
A
A
A
A
A
D
D
D
D
D
G
H
Attach 1xCL runner tracks (G) to panel [4] using 3x small screws (E).
Attach 1xCR runner tracks (H) to panel [5] using 3x small screws (E).
Tighten with a screwdriver.
Insert 6x dowels (A) into panel [1]. Attach panels [3] , [4] and panel [5] to
panel [1] using 6x locking nuts (D). Tighten with a screwdriver. Cover the
holes of panel [3] using 2x sticker(R) as shown.
R
R
D

Kennedy Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
4
4 5
6
1
3
4
5
2
A
A
A
A
B
B
B
B
B
B
5
3
Attach panel [2] to panel [3] , [4] and [5] using 6x dowels (A) and secure
with 6x long screw (B). Tighten with a screwdriver.
Slide panel [6] down along the grooves between the side panels to form
the back of the unit.
4
B

Kennedy Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
5
67
Q
Q
Q
Q
Q
Q
2
7
7
S
S
S
S
C
C
C
C
K
E
8
Q
F
Insert 4x bolts (C) into panels [8]. Attach 1x plug (K) to panels [8]
and secure with 1x screw (E). Tighten with a screwdriver.
Attach leg panels [7] to panel [2] using 8x bolts (Q) as shown. Tighten with the
allen key (F). Attach 4x felt pads (S) to the ends of the legs.

Kennedy Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
6
8 9
Attach panel [9] and [10] to front panel [8] using 4x locking nuts (D). Tighten
with a screwdriver.
D
D
DD
8
9
10
Slide panel [11] along the grooves between the side panels [9] and [10]
to form the base of the drawer.
9
10
11

Kennedy Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
7
10 11
12
9
10
N
N
N
N
E
E
E
E
I
J
Attach slide rail (I) and slide rail (J) to the underside of the side panels[9] and
[10] as shown. Secure with 4x screws (E) and tighten with a screwdriver.
Attach panels [9], [10] and [12] as shown using 4x screws (N). Tighten
with a screwdriver.
10
9

Kennedy Console Table
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
8
12 13
O
O
P
O
O
P
V
Z
W
X
Y
Z
If the drawer is not catching or sitting flush, twist the end of the cover
(M) until it catches on the stopper (K). Once assembled lift furniture into
place, do not drag. Use a drill to create a small hole lining up with the
top of the safety strap (V). Fasten to wall using 1x washer (Z), 1x wall
plug (X) and 1x screw (Y). Ensure unit is balanced and steady before
use.You’re done, enjoy!
Attach 4x wedges (O) into the corners of the back of the unit and secure
with 4x screws (P). Tighten with a screwdriver.Attach 1x safety strap (V)
to the top of the back side of the unit as shown using 1x washer (Z) and
1x screw (W). Tighten with a screwdriver.
V
Z
W
O
P
M
