Mocka Watson Buffet User manual

WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
C
dowel
x14
D
long
screw x16
A
bolt
x18
B
locking
nut x18
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
X
Z
Y
W
safety
strap x1
screw
x1
long
screw x1
wall
anchor
x1
washer
x1
Phillips & Flathead screwdrivers and Hammer
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
E
small
screw x8
G
L + R slide
rail x2
F
medium
screw x6
H
L + R slide
rail x2
I
nut
x4
J
long bolt
x4
K
plastic
guide
x4
L
small screw
x24
M
hinge x4
Watson Buffet
1
mocka.co.nz |mocka.com.au |PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.

12
Attach 1 x L slide rail (G) to panel [3] and secure with 2 x small screw
(E). Attach 1 x R slide rail (G) to panel [4] and secure with 2 x small
screw (E). Insert 4 x bolt (A) into panels [3] and [4]. Tighten with a
screwdriver.
Insert 6 x dowel (C) into panels [6] and [19]. Attach panels [3], [4], [6] and
[19] and secure with 6 x locking nuts (B). Tighten with a screwdriver.
Watson Buffet
2
mocka.co.nz |mocka.com.au |PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions

34
Insert 4 x dowel (C) into panel [2]. Attach panel [2] to panels [3], [4] and
[5] and secure with 6 x long screw (D). Attach 1 x safety strap (W) to
panel [5] and secure with 1 x screw (Y). Tighten with a screwdriver.
Insert 4 x nut (I) into panel [9]. Attach panel [8] to panel [9] and secure
with 4 x long bolt (J). Tighten with a screwdriver.
Watson Buffet
3
mocka.co.nz |mocka.com.au |PO BOX 6171, Maroochydore BC, QLD, 4558
Assembly Instructions

56
Insert 6 x bolt (A) into panel [1]. Attach panel [7] to panel [1] and secure
with 4 x long screw (D). Tighten with a screwdriver.
Attach panels [8] and [9] to panel [2] and secure with 6 x long screw (D).
Tighten with a screwdriver. Insert 4 x plastic guide (K) into panel [8] with
a hammer.
8
8
9
9
Watson Buffet
Assembly Instructions
4
mocka.co.nz |mocka.com.au |PO BOX 6171, Maroochydore BC, QLD, 4558

Jolt Wardrobe
ASSEMBLY INSTRUCTIONS
5
mocka.co.nz |mocka.com.au
78
Slide panel [16] between the grooves on panels [2], [3] and [5] to form
the back of the unit as shown.
Attach 2 x hinge (M) to panel [17] and secure with 4 x small screw (L).
Tighten with a screwdriver.
Watson Buffet
Assembly Instructions
5
mocka.co.nz |mocka.com.au |PO BOX 6171, Maroochydore BC, QLD, 4558

910
Attach 2 x hinge (M) to panel [18] and secure with 4 x small screw (L).
Tighten with a screwdriver.
Insert 4 x dowel (C) into panels [3] and [4]. Attach panel [1] to panels [3],
[4] and [5] and secure with 6 x locking nuts (B). Tighten with a
screwdriver.
A
A
Watson Buffet
Assembly Instructions
6
mocka.co.nz |mocka.com.au |PO BOX 6171, Maroochydore BC, QLD, 4558

11 12
Insert 6 x bolt (A) into panel [10]. Attach panels [12] and [11] to panel
[10] and secure with 4 x locking nut (B). Slide panel [13] between the
grooves on panels [12] and [11] to form the base of the unit as shown.
Attach panel [14] to panel [10] and secure with 2x locking nuts (B).
Tighten with a screwdriver.
Attach panel [15] as shown and secure with 6 x medium screw (F).
Attach 1 x L slide rail (H) to panel [12] and secure with 2 x small screw
(E). Attach 1 x R slide rail (H) to panel [11] and secure with 2 x small
screw (E). Tighten with a screwdriver.
Watson Buffet
Assembly Instructions
7
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558

13 14
Attach 4 x hinge (M) to panels [17] and [18] and secure with 16 x small
screw (L). Tighten with a screwdriver.
Insert drawer into the unit as shown, ensuring it slides smoothly and
easily along the rails. Once assembled, lift furniture into place, do not
drag.
NOTE: If the doors are
uneven or there is a gap in
the middle, loosen or tighten
the screw on the hinge until
they are sitting ush.
Watson Buffet
Assembly Instructions
8
mocka.co.nz |mocka.com.au |PO BOX 6171, Maroochydore BC, QLD, 4558

15
Move the unit into the desired location up against a wall. Use a drill to
create a small hole lining up with the top of the safety strap (W). Fasten
to the wall using 1x wall anchor (X), 1x washer (Z) and 1x long screw.
Ensure the unit is balanced and steady before use. You’re done, enjoy!
