User Guide
Single-Unit Charger

1
English
IMPORTANT
SAFETY INSTRUCTIONS
This document contains important safety
and operating instructions. Please read
these instructions carefully and save them
for future reference.
Before using the battery charger, read all the
instructions and cautionary markings on (1) the
charger, (2) the battery, and (3) on the radio using
the battery.
1. To reduce risk of injury, charge only
the rechargeable Motorola Solutions
authorized batteries listed in Table 1.
Other batteries may explode,
causing personal injury and damage.
WARNING
WARNINGS

2
English
WARNINGS (continued)
2. Use of accessories not recommended
by Motorola Solutions may result in risk
of fire, electric shock, or injury.
3. To reduce risk of damage to the
electric plug and cord, pull by the plug
rather than the cord when disconnecting the
charger.
4. An extension cord should not be used unless
absolutely necessary. Use of an improper extension
cord could result in risk of fire and electric shock. If
an extension cord must be used, make sure that the
cord size is 18 AWG for lengths up to 100 feet
(30.48 m), and 16 AWG for lengths up to 150 feet
(45.72 m).
5. To reduce risk of fire, electric shock, or injury, do not
operate the charger if it has been broken or
damaged in any way. Take it to a qualified Motorola
Solutions service representative.
WARNING

3
English
WARNINGS (continued)
6. Do not disassemble the charger; it
is not repairable and replacement
parts are not available. Disassembly
of the charger may result in risk of
electrical shock or fire.
7. To reduce risk of electric shock, unplug the
charger from the ac outlet before attempting any
maintenance or cleaning.
8. This is a Class A product. In a domestic
environment, this product may cause radio
interference in which case the user may be
required to take adequate measures.
WARNING

4
English
OPERATIONAL SAFETY GUIDELINES
• Turn the radio off when charging the battery.
• This equipment is not suitable for outdoor use. Use
only in dry locations/conditions.
• Connect equipment only to an appropriately fused
and wired supply of the correct voltage (as
specified on the product). Disconnect from line
voltage by removing main plug.
•The socket outlet to which this equipment is
connected should be close by and easily
accessible.
• In equipment using fuses, replacements must
comply with the type and rating specified in the
equipment instructions.
• Maximum ambient temperature around the power
supply equipment must not exceed 40°C (104°F).
• Output power from the power supply unit must not
exceed the ratings stated on the product label
located on the bottom of the charger.
• Make sure the cord is located where it will not be
stepped on, tripped over, or subjected to water,
damage, or stress.

5
English
CHARGER SPECIFICATION
Input: 14 V , 1 A
Output: 8.4 V , 1.25 A
MOTOROLA SOLUTIONS AUTHORIZED
BATTERIES
The batteries listed in Table 1 are approved for use with the
Single-Unit Chargers in Table 2.
Table 1. Motorola Solutions
Authorized Batteries
Kit (part)
Number Battery Chemistry/Description
HNN9008_R NiMH/High-Capacity
HNN9009 NiMH/Ultra-High-Capacity
HNN9010_R NiMH/Ultra-High-Capacity, Factory Mutual
HNN9011 NiCd/High-Capacity, Factory Mutual
HNN9012 NiCd/High-Capacity
HNN9013_R Lithium Ion/High-Capacity
JMNN4023_R Lithium Ion
JMNN4024_R Lithium Ion/High-Capacity

6
English
Note: In Taiwan, only battery HNN9013D is available.
POWER SOURCES AND MOTOROLA
SOLUTIONS AUTHORIZED TRANSFORMERS
These Class 2 battery chargers should be used with the direct
plug-in, Motorola Solutions authorized transformers listed below:
JMNN4025_R NiMH, Factory Mutual
NNTN5510_R ATEX Lithium Ion, 1480 mAh
PMNN4073_R Lithium Ion, Factory Mutual, IP67
PMNN4074_R Lithium Ion, Non-Factory Mutual, IP67
PMNN4094 Lithium Ion, Non-Factory Mutual, IP67
PMNN4097 NiMH/High-Capacity
PMNN4440 Lithium Ion, Non-Factory Mutual, IP68
PMNN4502 IMPRES Lithium Ion 3000T, IP68
PMNN4511 IMPRES Lithium Ion 2900T, IP68
Table 1. Motorola Solutions
Authorized Batteries (Continued)
Kit (part)
Number Battery Chemistry/Description

7
English
Note: All the transformers listed in Table 2 can also be used with the
HTN9000 charger.
Note: In Taiwan, only kit or power source or transformer PMTN4024BW is
available.
Table 2. Kits/Power Sources/Transformers
Kit Number Power Source Transformer
(part) Number
AAHTN3000 110–120 Vac
50/60 Hz (U.S. Plug) 2571586S13
AAHTN3001 230Vac (Euro. plug) 2571586S07
AAHTN3002 230Vac (U.K. plug) 2571586S06
HTN3032 230Vac (Argentina plug) 2571586S11
RLN4948 120Vac (U.S. plug) 2580410E01
RLN5255 230Vac (U.K. plug) 2580410E01
RLN5256 230Vac (Euro plug) 2580410E01
PMLN5195 90–264Vac (U.K. plug) 2571886T01
PMLN5196 90–264Vac (Euro plug) 2571886T01
PMLN5197 90–264Vac (U.S. plug) 2571886T01
PMLN5205 90–264Vac (Aus/NZ plug) 2571886T01
WPLN4282 90–264Vac (Brazil plug) 2571886T01
PMTN4024 120 VAC (US/Taiwan Plug) 25009297001

8
English
OPERATING INSTRUCTIONS
Single-unit chargers will charge only the Motorola
Solutions authorized batteries listed in Table 1 on
page 5 Other batteries may not charge.
The battery charger’s pocket will accommodate
either a radio with a battery attached or a battery
alone. Prior to charging a battery with radio, turn
the radio off. To charge a battery, use the following
procedure: (Refer to Figure 1, page 8)
1. Plug the round end of the transformer cord into the
socket on the back of the charger.
2. Plug the transformer into the appropriate ac outlet.
The charger LED will blink green once to indicate
a successful power-up.
3. Insert a battery, or a radio with battery (radio
turned off), into the charger's pocket by:
a. aligning the groove on each side of the battery
with the corresponding raised rail on each side
of the charger pocket.
b. pressing the battery toward the rear of the
pocket

9
English
c. sliding the battery into the charger pocket,
ensuring complete contact between the char-
ger and battery contacts
Figure 1. Battery Charger
SOCKET
(located here) RAISED RAIL
CHARGING
CONTACTS
POCKET
WARNING
LABEL
LED

10
English
4. When the battery is properly seated in the pocket,
the charger LED will light red to indicate that the
battery is charging rapidly. When the battery is
90% charged, the LED will begin to blink green to
indicate that the battery is trickle charging. When
the battery is fully charged, the LED will change to
a steady green light to indicate that the battery is
fully charged.
Note: Even though new batteries might prematurely
indicate a full charge (steady green LED), charge
the battery for 14 to 16 hours prior to initial use for
best performance.
Batteries will charge best at room temperature.

11
English
TROUBLESHOOTING
When troubleshooting, always observe the color of
the LED:
Table 3. LED Indications of Battery/Charger Status
LED Color Battery/Charger Status
No LED indication Battery is inserted incorrectly.
Single green blink Successful charger power-up
Blinking red Battery is unchargeable or not
making proper contact.
Steady red Battery is in rapid-charge mode.
Blinking yellow
Battery is in charger, not in rapid-
charge mode, but waiting to be
charged.
Blinking green Battery is charged (to 90% or greater
capacity).
Steady green Battery is fully charged.

12
English
No LED Indication?
1. Check that the radio with battery, or the battery
alone, is inserted correctly (refer to step 3 on
pages 8 and 9).
2. Make sure that the transformer is plugged into an
appropriate ac outlet, and that the transformer
cable is plugged securely into the charger socket.
Blinking Red LED Indicator?
1. Remove the battery from the charger, and:
a. make sure that it is a Motorola Solutions
authorized battery listed in Table 1 on page 5.
Other batteries may not charge.
b. remove power from the battery charger and,
using a clean dry cloth, clean the gold metal,
charging contacts of the battery and charger.
2. Power up the charger and place the battery back
into the charger pocket. If the LED indicator
continues to blink red, replace the battery.

13
English
Blinking Yellow LED Indicator?
• the battery temperature may be below 5°C (41°F)
or above 40°C (104°F).
• the voltage may be lower than the predetermined
threshold level for rapid charging.
Note: Rapid charging outside of the stated
temperature and voltage limits can drastically
reduce the life expectancy of the battery.
Note: When the battery charger detects the proper
battery conditions, rapid charging begins
automatically (steady red LED).
SERVICE
The Single-Unit Chargers are not repairable. Order
replacement chargers as necessary.

14
English

1
Français
(Canada)
INSTRUCTIONS DE
SÉCURITÉ IMPORTANTES
Ce document contient d’importantes directives
relatives à la sécurité et au fonctionnement de
l’appareil. Veuillez lire attentivement cette notice
et la conserver pour vous y référer ultérieurement.
Avant d'utiliser le chargeur de batterie, lisez toutes
les directives et les marquages d'avertissement sur
(1) le chargeur et (2) la batterie et (3) sur la radio qui
utilise la batterie.
1. Afin de réduire les risques de blessure, ne
chargez que les batteries rechargeables
agréées Motorola apparaissant dans le
Tableau 1. Les batteries non approuvées
pourraient exploser et causer des blessures
corporelles et d’autres dommages.
AVERTISSEMENT
AVERTISSEMENTS

2
Français
(Canada)
AVERTISSEMENTS (suite)
2. L’utilisation d’accessoires non recommandés
par Motorola Solutions pourrait occasionner
des risques d’incendie, de décharge électrique
ou de blessure.
3. Afin de réduire la possibilité d'endommager la
fiche et le cordon d'alimentation, débranchez le chargeur en
tirant sur la fiche et non sur le cordon.
4. Il n’est pas recommandé d’utiliser une rallonge, sauf en cas de
nécessité absolue. L’utilisation d’une rallonge inappropriée
pourrait causer un risque d’incendie et de décharge électrique.
Si une rallonge doit être utilisée, assurez-vous que le format du
cordon est de calibre 18 lorsque sa longueur est de 30,48 m
(100 pi) ou moins et de calibre 16 lorsque sa longueur atteint
jusqu'à 45,72 m (150 pi).
5. Pour réduire le risque d’incendie, de décharge électrique ou de
blessure, n’utilisez pas le chargeur s’il est brisé ou endommagé
de quelque manière que ce soit. Portez-le chez un représentant
de service Motorola Solutions.
AVERTISSEMENT

3
Français
(Canada)
AVERTISSEMENTS (suite)
6. Ne désassemblez pas le chargeur. Il ne
peut être réparé et aucune pièce de
rechange n'est disponible. Le
désassemblage du chargeur pourrait
occasionner des risques de choc
électrique ou d'incendie.
7. Pour réduire les risques de décharge électrique, débranchez
le chargeur de la prise c.a. avant de procéder à une
maintenance ou à un nettoyage.
8. Ce produit est de classe A. Ce produit peut entraîner des
interférences radio dans un environnement résidentiel,
auquel cas l’utilisateur peut être tenu de prendre des
mesures adéquates.
AVERTISSEMENT

4
Français
(Canada)
DIRECTIVES D’UTILISATION SÉCURITAIRE
• Éteignez la radio lorsque vous chargez la batterie.
• Cet équipement n’est pas conçu pour une utilisation à
l’extérieur. Ne l'utilisez que dans des emplacements secs
et sous des conditions de nature semblable.
• Ne branchez l'équipement qu'à un bloc d'alimentation à
fusible câblé approprié de tension prescrite (telle que
spécifiée sur le produit). Débranchez le chargeur de la
tension de secteur en retirant la fiche principale.
•La prise de courant à laquelle cet équipement est
branché doit se trouver à proximité et être
facilement accessible.
• Pour les appareils utilisant des fusibles, les pièces de
rechange devront être conformes aux instructions
fournies dans la documentation.
• La température ambiante maximale autour du bloc
d'alimentation ne doit pas dépasser 40 °C (104 °F).
• La puissance de sortie du bloc d'alimentation ne devra
pas dépasser la puissance indiquée sur l'étiquette du
produit apposée sous le chargeur.
• Assurez-vous que le cordon est placé à un endroit où il
ne sera pas écrasé ou endommagé, ne gênera pas le
passage, ne sera pas tendu de façon anormale et ne
sera pas exposé à une source d'humidité.
