Thank you for choosing the MS-9A79, an excellent industrial data
machine from MSI.
The MS-9A79’s wide heatsink fanless solution eliminates the noise
and the risk of fan’s failure. Furthermore, it supports VESA wall-mount
interface for various scenarios like digital signage, kiosk, industrial
control and POS with affordable expenditure, which not only meets the
demand of Industrial applications but also fullls the needs of companies,
governments and institutes for general applications.
1Overview

1-2
Overview MS-9A79
Package Contents
1. MS-9A79 Industrial Data Machine
2. Power Adapter & Power Cord
3. Wall Mount Set
4. DIN Rail Mount Set
5. VESA Mount Set (Optional)
6. SATA Power & Signal Cable
7. Phoenix Plug-in Terminal Block
8. Jumper Caps
9. Driver/Utility Disc
* Contact your place of purchase or local distributor if any of the items is damaged
or missing.
* Package contents may vary by country.

1-3
Overview MS-9A79
System Overview
hSystem I/O & Controls
1
7
8
1
23
4
5
14
9
10 11 12
13
16
6
1
1
15

1-4
Overview MS-9A79
1WLAN Antenna Connector (Optional)
This connector allows you to connect an external antenna for wireless LAN.
2Power Button
Press the button to turn the system on or o󰘯.
3Extend Switch Connector
This connector is provided for remote power button control.
4DIO Port
This port is provided for the Digital Input/Output (DIO) peripheral module.
PIN SIGNAL PIN SIGNAL
1
2
3
4
5
6
7
8
9
10
11
12
13
GND
GPI0
GPI1
GPI2
GPI3
GPI4
GPI5
GPI6
GPI7
VCC5
NC
NC
NC
14
15
16
17
18
19
20
21
22
23
24
25
GND
GPO0
GPO1
GPO2
GPO3
GPO4
GPO5
GPO6
GPO7
VCC5
NC
NC

1-5
Overview MS-9A79
5RS232/422/485 Serial Port
The serial port is a 16550A high speed communications port that sends/
receives 16 bytes FIFOs. It supports barcode scanners, barcode printers, bill
printers, credit card machine, etc.
15
69
RS232
PIN SIGNAL DESCRIPTION
1
2
3
4
5
6
7
8
9
NDCD
NSIN
NSOUT
NDTR
GND
NDSR
NRTS
NCTS
0V/5V/12V
Data Carrier Detect
Signal In
Signal Out
Data Terminal Ready
Signal Ground
Data Set Ready
Request To Send
Clear To Send
Power Pin
RS422
PIN SIGNAL DESCRIPTION
1
2
3
4
5
6
7
8
9
422 TXD-
422 RXD+
422 TXD+
422 RXD-
GND
NC
NC
NC
0V/5V/12V
Transmit Data, Negative
Receive Data, Positive
Transmit Data, Positive
Receive Data, Negative
Signal Ground
No Connection
No Connection
No Connection
Power Pin
RS485
PIN SIGNAL DESCRIPTION
1
2
3
4
5
6
7
8
9
485 TXD-
NC
485 TXD+
NC
GND
NC
NC
NC
0V/5V/12V
Transmit Data, Negative
No Connection
Transmit Data, Positive
No Connection
Signal Ground
No Connection
No Connection
No Connection
Power Pin
6USB 2.0 Port
The USB (Universal Serial Bus) port is for attaching USB devices such as
keyboard, mouse, or other USB-compatible devices.
7Line-Out Jack
This connector is provided for headphones or speakers.
8Microphone Jack
This connector is provided for microphones.

1-6
Overview MS-9A79
9LVDS Port (Optional)
The LVDS (Low Voltage Di󰘯erential Signal) connector provides a digital
interface typically used with 󰘱at panels.
DVI Port (Optional)
Digital Visual Interface (DVI) is a video display interface developed by the
Digital Display Working Group (DDWG). The digital interface is used to connect
a video source, such as a video display controller, to a display device, such as
a computer monitor.
10 Mini DisplayPort
Mini DisplayPort is a digital display interface standard. This connector is used
to connect a monitor with Mini DisplayPort inputs.
11 HDMI Port
The High-De󰘰nition Multimedia Interface (HDMI) is an all-digital audio/video
interface capable of transmitting uncompressed streams. HDMI supports all
TV format, including standard, enhanced, or high-de󰘰nition video, plus multi-
channel digital audio on a single cable.
12 GbE RJ45 Port
The standard RJ45 LAN jack is provided for connection to the Local Area
Network (LAN). You can connect a network cable to it.
Speed LED Active
LED
LED LED Status Description
Active
LED
Off No link
Yellow Linked
Blinking Data activity
Speed
LED
Off 10 Mbps connection
Green 100 Mbps connection
Orange 1 Gbps connection
13 Phoenix DC Power Connector
The system is designed with a Phoenix connector that carries DC input.
Important
Your power source can either be connected to the Power Jack or the Phoenix
DC Power Connector. Avoid connecting to both simultaneously.
14 Power Jack
Power supplied through this jack supplies power to the system.
Important
Your power source can either be connected to the Power Jack or the Phoenix
DC Power Connector. Avoid connecting to both simultaneously.

1-7
Overview MS-9A79
15 USB 3.0 Port
The USB 3.0 port is backward-compatible with USB 2.0 devices and supports
data transfer rate up to 5 Gbit/s (SuperSpeed).
16 Grounding Point
The Grounding Point is provided to connect a grounding wire.

1-8
Overview MS-9A79
System Specications
Processor
■Intel® Atom™ x5 E3940 Processor for WT SKU
■Intel® Celeron® N3350 Processor for Non-WT SKU
Memory
■Onboard 4GB Single-Channel LPDDR4 Memory
■2133 MHz for E3940 SKU
■2400 MHz for N3350 SKU
Network
■2 * Intel® I210-IT GbE LAN for E3940 SKU
■2 * Intel® I211-AT GbE LAN for N3350 SKU
Audio
■Realtek®ALC887-VD2-CG HDA Codec
■Compliant with Azalia 1.0 specs
■1 * Line-Out jack
■1 * Mic-In jack
Graphics
■Integrated Intel® HD Graphics
■1 * HDMI
-Max resolution 3840 x 2160 @30Hz
■1 * LVDS 18/24bit Dual Channel (Optional)
-Max resolution 1920 x 1200 @60 Hz
■1 * DVI-I by MS-99C0 from LVDS (Optional)
-Supported resolution: 1400 x 1050 & 24bit, 1600 x 900 & 24bit, 1600 x
1200 & 24bit, 1680 x 1050 & 24bit, 1920 x 1080 & 24bit, 1920 x 1200 &
24bit
Important
For their monitors to work properly, users need to select a resolution
supported by their monitors through the Chipset menu‘s LCD Panel
Type setting in BIOS.
■1 * Mini-DP
-Max resolution 4096 x 2160 @60Hz
■3 * independent displays
-Mini-DP + HDMI + LVDS
Storage
■1 * SATA 2.5” Drive Bay for HDD/SSD
■1 * mSATA (Half-size)

1-9
Overview MS-9A79
Expansion Slot
■1 * Mini-PCIe1 (Full-size, with Nano SIM-Holder)
■1 * Mini-PCIe2 (Half-size, with mSATA)
Front Panel Input/Output
■2* WLAN Antenna Connectors (Optional)
■1* Power Button
■1* Extend Switch Connector
■1* DIO Port
■2* RS232/422/485 Serial Ports
■2* USB 2.0 Ports
■1* Line-Out Jack
■1* Microphone Jack
Rear Panel Input/Output
■2* WLAN Antenna Connectors (Optional)
■1* LVDS Port/ DVI Port (Optional)
■1* Mini DisplayPort
■1* HDMI Port
■2* GbE RJ45 Ports
■1* Phoenix DC Power Connector
■1* Power Jack
■2* USB 3.0 Ports
■1* Grounding Point
Power Supply
■1* 4-pin DC-in 12V Connector
■36 Watt Power Adapter
fInput: 100~240Vac, 1.8A, 50~60Hz
fOutput: 12Vdc, 3.0A
fNo power consumption for COM1~2
■48 Watt Power Adapter (Optional)
fInput: 100~240Vac, 1.5A, 50~60Hz
fOutput: 12Vdc, 4.0A
fFull power consumption for COM1~2
fEach COM port 5V/1A Max or 12V/0.5A Max
Dimension & Weight
■155mm x 110mm x 55mm
■0.95kg
Regulatory Compliance
■EMC: FCC Class A, CE, RCM, BSMI, VCCI
■Safety: BSMI
■IEC61373, EN60068-2-1, EN60068-2-2, EN60068-2-30
■RoHS Compliant

1-10
Overview MS-9A79
Environment
SKU
Environment E3940 SKU N3350 SKU
Operating
Temperature
■-20 ~ 70°C (with WT SSD/
mSATA)
■-10 ~ 60°C (with MS-99C0
LVDS to DVI-I converter
board)
■-10 ~ 60°C (with SSD/
mSATA, MS-99C0 LVDS to
DVI-I converter board)
Storage
Temperature
-40 ~ 80oC -20 ~ 80°C
Humidity 10 ~ 90% RH, non-condensing

1-11
Overview MS-9A79
Motherboard Jumpers
Important
Avoid adjusting jumpers when the system is on; it will damage the motherboard.
JVDD1
JDNX1 JTXE1
JCMOS1
JINVDD1
JCOMP1
JAT1
JNVM1
JNVM2

1-12
Overview MS-9A79
Clear CMOS Jumper: JCMOS1
Normal
(Default)
Clear CMOS
11
AT/ATX Select Jumper: JAT1
ATX (Default) AT
11
Serial Port Power Jumper: JCOMP1
1
+5V +12V
11
0V
(Default)
LVDS Power Jumper: JVDD1
3V
(Default)
5V
11
LVDS Inverter Power Jumper: JINVDD1
5V 12V
(Default)
11
