MSI MP54G5 User manual

i
MSIMP54G5(MS-6833B)
Wireless 11g MiniPCICard
QuickUser sGuide

ii
Hiermit erkl rt MicroStarInternationalCO.,LTD dass sichdiesesProduktin
Übereinstimmung mit dengrundlegendenAnforderungenunddenanderen
relevantenVorschriftenderRichtlinie1999/5/EGbefindet. Die
Konformit tserkl rung kann auffolgenderwebsiteeingesehenwerden:
http://www.msi-computer.de/support/dl_man.php
Hereby, MicroStarInternationalCO.,LTD declaresthatthisdevice isin
compliancewiththeessentialrequirementsand otherrelevantprovisionsof
Directive1999/5/EC.TherespectiveDeclarationofconformitycanbefound
online:
http://www.msi-computer.de/support/dl_man.php
IEEE802.11b/gandBluetooth®2.4GHzoperation
Europe: Frequencies:2.400 –2.4835 GHz
France: Frequencies:2.4465–2.4835GHz,
Outdooruseislimitedto10mWe.i.r.p.withintheband 2454-2483.5MHz
IEEE 802.11b/gund Bluetooth®2.4GHzBetrieb
Europa: Frequenzen:2.400 –2.4835GHz
Frankreich: Frequenzen:2.4465–2.4835 GHz,
Außerhalbvon geschlossenenGeb udenistdiegenehmigteSendeleistung im
Frequenzband2454-2483.5MHzaufmaximal10mWbeschr nkt.
Italy:
Ifusedoutsideofownpremises,generalauthorisation isrequired.
Luxembourg:
Generalauthorisation requiredforpublicservice.
NotifiedCountries:
Germany,UK,Netherlands,Belgium,Sweden,Denmark,Finland,France,Italy,
Spain,Austria,Ireland,Portugal, Greece,Luxembourg,Estonia,Letvia,Lithuania,
CzechRepublic,Slovakia,Slovenia,Hungary,Poland undMalta.
Bestimmungsgem ßeVerwendung:
DiesesProduktintegriertalsTeilderProduktausstattung eineWLAN-
Komponenteund/odereineBluetooth®-Komponente.
DieentsprechendeKomponenteverbindetComputer übereineFunkverbindung.
Eskann aucheineFunkverbindung zuanderengeeignetenWLAN-oder
Bluetooth®Ger tenhergestelltwerden.

iii
Prescribeduse:
ThisproductintegratesaWLAN-and/orBluetooth®device.
Thedevice setsuparadiolinkbetweentocomputer.Inadditionit ispossibleto
linktheWLAN-orBluetooth®devicetoanyotherWLAN-orBluetooth®device
whichsticktotheIEEE 802.11b/gorBluetooth®requirements.
HinweisezurReichweite:
DerAbstand zwischenSenderundEmpfδnger(von einem WLAN-oderBluetooth®
-GerδtzueinementsprechendenanderenGerδt)hδngtstarkvon der
Einsatzumgebungab.Wδnde,Betonboden(Eisen),beschichteteFensterscheiben,
Fahrzeug-Karosserie,etc..
WeitereBeeinflussungen:
-HochfrequenzaussendungenjederArt
-Gebδude,Bδume,etc.
-Heizkφrper,Stahlbeton,etc.
-offenbetriebeneComputer,etc.
-Mikrowellenherde,etc,
DieKommunikation zwischenunterschiedlichenWLAN-oderBluetooth®-
Gerδtenistvon derjeweiligenSoftwareunddem entsprechendenVersionsstand
abhδngig
Operatingrange:
Thetransmission rangebetweendifferentWLAN-orBluetooth®devicesvaries
dependingthespecificenvironment.Walls,concretefloor(iron),laminated
windows,vehicle-body,etc..
Moreelectromagneticinterferences:
-high frequencyemission ofanykind,
-Buildings,trees,etc.
-Heaters,ferroconcrete,etc.
-opencomputersystems,etc.
-Microwaveoven,etc,
Communication(exchangedata)isdependenton thesoftwareoftheWLAN or
Bluetooth®devices.
MSITechnologyGmbH
HanauerLandstraίe306
60314Frankfurt
Telefon:[phone]
Telefax:[phone]

iv
FCCCaution
1. ThedevicecomplieswithPart 15ofthe FCCrules. Operationissubjectto
thefollowingtwoconditions:
(1)Thisdevicemaynot causeharmful interference,and
(2) Thisdevice mustacceptanyinterferencereceived,including interference
that may causeundesiredoperation.
2. FCCRFRadiationExposureStatement: The equipment complieswithFCC
RFradiation exposurelimitsset forthfor anuncontrolledenvironment.
Thisequipmentshouldbe installed andoperated withaminimum
distanceof 20centimetersbetween theradiator and yourbody.
3. ThisTransmitter mustnot beco-locatedoroperating inconjunction with
anyother antenna or transmitter.
4. Changesormodificationstothisunit not expresslyapprovedbythe
partyresponsiblefor compliancecouldvoidtheuserauthoritytooperate
theequipment.
CopyrightNotice
Thematerialinthisdocument istheintellectualpropertyof MICRO-STARINTERNA-
TIONAL.Wetakeeverycareinthe preparationofthisdocument,but noguaranteeis
givenastothe correctnessofitscontents. Ourproductsareunder continualimprove-
ment andwereserve therighttomakechangeswithout notice.
Trademarks
MicrosoftWindowsandInternetExplorerareregistered trademarksortrademarksof
Microsoft Corporation.
All brandnames,icons,andtrademarksusedinthisQuick User’sGuide arethesole
propertyoftheir respectiveowners.
RevisionHistory
Revision History Date
V1.0 FirstRelease April 2006

v
ImportantSafetyPrecautions
Alwaysread andfollowthese basicsafetyprecautionscarefullywhenhandlingany
pieceofelectroniccomponent.
1. Keep this QuickUser sGuide forfuturereference.
2. Keep thisequipmentawayfromhumidity.
3. Laythisequipmentonareliableflatsurface beforesetting it up.
4. Theopeningson the enclosurearefor air convectionhenceprotectsthe
equipment fromoverheating.
5. Allcautionsand warningsontheequipmentshouldbenoted.
6. Neverpouranyliquidintotheopening thatcoulddamage or causeelectrical
shock.
7. If anyof the following situationsarises, get theequipmentcheckedbya
servicepersonnel:
Liquidhaspenetratedintothe equipment
Theequipmenthasbeen exposed tomoisture
Theequipmenthas notworkwell or youcannotget it work
accordingtoQuick User’sGuide
Theequipment hasdroppedanddamaged
Ifthe equipmenthasobvioussignofbreakage
8. DONOTLEAVETHISEQUIPMENTINANENVIRONMENT
UNCONDITIONED,STORAGETEMPERATURE ABOVE70O COR
BELOW-20OC,ITMAYDAMAGETHEEQUIPMENT.

vi
TableofContents
CE Compliance..........................................................................................................ii
FCCCaution..............................................................................................................iv
CopyrightNotice.......................................................................................................iv
Trademarks.................................................................................................................iv
RevisionHistory........................................................................................................iv
ImportantSafetyPrecautions...................................................................................v
Chapter1.Introduction..............................................................................................1
1.1MSIMP54G5Wireless11g MiniPCICard.....................................................1
1.2HowMSIMP54G5Wireless11gMiniPCICardWorks................................2
1.2.1InWLANEnvironment.............................................................................2
1.3Specifications......................................................................................................4
1.4SystemRequirements.........................................................................................6
1.5Package Contents................................................................................................6
1.6ProductView.......................................................................................................7
Chapter 2.HardwareInstallation.............................................................................8
Chapter3. SoftwareInstallation..............................................................................9
3.1SoftwareSetup...................................................................................................10
Chapter4.NetworkingSetup...................................................................................12
4.1InfrastructureMode...........................................................................................12
4.2Ad-hocMode......................................................................................................18

1
Introduction
The MSIMP54G5Wireless 11gMiniPCICard,isa Type
IIIB card,which can beusedtointegratewithsuch systemsas
notebook, mini-bareboneandportablePC. With MSIMP54G5
Wireless11gMiniPCICard embedded inside,asystemcould
provide users withtheabilityandflexibilitytoconnectupto
Internetwirelesslyvia 802.11g withspeed upto54Mbps.
MSIMP54G5Wireless11gMiniPCICard istakingadvan-
tage ofleading technologies fromRalink.ItaddressesWLAN
(WirelessLocalAreaNetwork) marketsbyprovidingtruesimul-
taneousconnectivitywhiledeployingIEEE 802.11g. Alongwith
thissolution, asysteminstalledinasinglecardisabletooffer
capabilityofWiFimode. It willbenefit systemvendorsinmin-
iaturizationofsystemdimension andBOMcostreduction,as
wellasalsomakeusershappy withthe all-in-one functionality.
>>>1.1MSIMP54G5Wireless11gMiniPCICard

2
Ad-hocMode : AnAd-hocnetworkisalocalareanetworkor
other smallnetwork,especiallyonewithwirelessortemporary
plug-inconnections, inwhich someof the networkdevicesare
partofthenetworkonlyfor thedurationofacommunications
session.Usersinthenetworkcansharefiles,print toashared
printer,andaccess the Internetwithasharedmodem.Inthis
kindofnetwork,newdevices canbe quicklyadded;however,
userscanonlycommunicatewithotherwirelessLAN comput-
ersthatareinthiswireless LAN workgroup,andarewithin
range.
InWLAN Environment1.2.1
MSIMP54G5Wireless 11g
MiniPCI Card MSIMP54G5Wireless 11g
MiniPCI Card
>>> 1.2How MSIMP54G5Wireless 11g MiniPCICard
Works

3
InfrastructureMode: The differencebetween Infrastructure
networkand Ad-hocnetworkisthat theformeroneincludesan
Access Point. InanInfrastructurenetwork, theAccessPointcan
manage thebandwidthtomaximizebandwidthutilization.Addi-
tionally,the AccessPointenablesusers onawireless LANto
access anexistingwirednetwork, allowing wireless users totake
advantage ofthewired networksresources,suchasInternet,
email, filetransfer, andprinter sharing. Thescaleandrange of the
Infrastructurenetworkingarelarger andwiderthanthatofthe
Ad-hocnetworking.
MSIMP54G5Wireless 11g
MiniPCI Card
MSIMP54G5Wireless 11g
MiniPCI Card

4
>>>1.3Specifications
Network Standard IEEE802.11b/g
Frequency Band 2.400-2.4835GHz
FormFactor Compliantwiththe32-bitMiniPCIType IIIB
AntennaConnector Twoantenna connectors
DataRate IEEE802.11g(auto-fallback):
-OFDM:54,48, 36,24, 18,12, 9and 6Mbps
IEEE802.11b(auto-Fallback):
-CCK:11,5.5Mbps
-DQPSK:2Mbps
-DBPSK:1Mbps
MediaAccessProtocol CSMA/CAwithaACK
Channel IEEE 802.11g IEEE 802.11b
Ch. 1-11--N. America Ch.1-11--N.America
Ch. 1-13--Japan Ch.1-14--Japan
Ch.1-13--Europe ETSI Ch.1-13--EuropeETSI
Ch.10-11--Spain Ch.10-11--Spain
Ch.10-13--France Ch.10-13--France
Transmission IEEE802.11b (DSSS), IEEE 802.11g(OFDM)
Modulation IEEE 802.11b(DSSS)IEEE 802.11g(OFDM)
CCK@11,5.5Mbps BPSK@6,9Mbps
DQPSK@2Mbps QPSK@12,18Mbps
DBPSK@1Mbps 16-QAM@24,36 Mbps
64-QAM@48,54 Mbps
NetworkArchitecture Ad-HocMode(PeertoPeer)
InfrastructureMode

5
Temperature Operating 0oCto65oC
Storage -20oCto100oC
Humidty 10%- 90%(non-condensing)
PowerConsumption 802.11g(54Mbps)
310mA@3.3vincontinueTx
260mA@3.3vincontinueRx
160mA@3.3VinStandbymode
802.11b(11Mbps)
350mA@3.3VincontinueTx
240mA@3.3VincontinueRx
160mA@3.3VinStandbymode
Operating Voltage 3.3V+/-5%
Output Power 802.11g
54Mbps,14.0+2/-1dBm
802.11b
11Mbps, 17.5+/-2dBm
Receiver Sensitivity 54MbpsOFDM@10%PER=-65dBm
11MbpsCCK@8%PER=-80dBm
Range Upto400m(outdooroperating range)
Security 64/128-bit WEP,WPA, WPA2,TKIP,AES,
802.1x
OperatingSystem Windows98SE/2000/ME/XP/XP64-bit
Certification FCCPart15, CE,DGT, C-Tick,Wi-Fi
Dimension 59.75(L)x44.6(W)x3.6(H)mm
Weight 11.5g

6
>>>1.4SystemRequirements
Beforeinstalling MSIMP54G5Wireless 11gMiniPCICard,
your PCshouldmeet thefollowing items:
-One desktop/notebook PCwithanavailableMiniPCIslot.
-Windows®98SE/ME/2000/XP/XP64-bitoperating system.
-Minimum5MBfreediskspacefor installing the driver and
utilities.
-OneCD-ROMdrive, doublespeedorhigher.
>>>1.5PackageContents
Unpack thepackage andcheck all theitemscarefully. If anyitem
contained isdamaged or missing,please contact your localdealer
assoon as possible. Also, keepthebox andpacking materialsin
caseyou needtoshipthe unit inthefuture. Thepackageshould
containthe followingitems:
-OneMSIMP54G5Wireless11g MiniPCICard.
-OneInstallation CD-ROMincluding drivers, utilities, and
QuickUser’sGuide
files.

7
>>> 1.6ProductView
GoldenFinger
WLAN 11gantennaconnectors
Connect toexternalantennasfor
enhanceddatatransmission and
reception.The external antennasare
welldesigned on thedesktop or note-
bookcomputers.

8
HardwareInstallation
1. Locatethe MiniPCIslotonthe mainboard.Placeyour
MSIMP54G5Wireless11gMiniPCICard over the
MiniPCIslot(atanangleof30 degrees). Then,gently
insertit intotheslot untilthegoldenfingerofthe card
getsfullyinserted.
2. Press downthecard,andtheretainingclips(ontwo
sidesoftheslot) willlockontothenotchesof the card.
3. Connect theattenna’scabletotheconnector onthecard.
The followingdiagramsprovideyouabasicinstallationfor your
MSIMP54G5Wireless11gMiniPCICard.The instruction
belowissuitableformostcomputers withMiniPCIslot.For
moreinformationabouttheMiniPCImodule,please referto
yourcomputer’smanual.
InstallingMSIMP54G5Wireless11g MiniPCICard:

9
SoftwareInstallation
Thischapterdescribestheprocedures ofinstallingthedriver
andutility. Followtheinstruction stepbysteptofinishthe
installation.IfyouuseWindows®98SE/ME,please prepare
theWindows®Setup CDathandbeforeinstallingthedriver;
becausethe systemwillaskyou toinsert the Setup CDtocopy
filesduringthe installation.
Please NOTE thatthe MSIMP54G5Wireless11gMiniPCI
Card shouldbeinstalledintoyourcomputer beforeinstalling
the driverandutility.Then, theoperatingsystemwilldetecta
newdeviceandstarttoconfigurethenewdevice.Click Cancel
heretostart installation fromthe InstallShieldWizard.
Click
Tip: Thewireless
LANadapter should
beinstalledintoyour
PCbeforeinstalling
thedriverandutility.

10
Click
Thewelcomescreen ofInstallShieldWizardappears. Readand
Accept theLicenseAgreement; thenclick Next.
STEP2
After installingthe MSIMP54G5Wireless 11g MiniPCICard
toyourcomputerand then turning onthe computer, the operat-
ingsystemwill detectanewdevice andstarttheconfiguraton
automatically.Please CANCEL thepop-upwindowfrom
FoundNewHardareWizard toinstallnecessarydriverand
utilityfromthe InstallShieldWizard of yourSoftwareCD.
Insertthe SoftwareCDintoyourCD-ROMdriver,and the
Setupprogramshalllaunchautomatically.
Ifthe Autorunprogramdidn tlaunchautomatically, click Start
atthetaskbarand select Run....Type E:\setup.exe (where Eis
yourCD-drive) inthe Open box andclick OK tolaunch the
Setupprogrammanually.
STEP1
>>> 3.1SoftwareSetup

11
Theprogramwill copythenecessaryfiles tothesystem.The
progressindicatorshallshowtheinstallingstatus.
Click Finish when theinstallationiscompleted.The MSIWire-
lessLAN iconwill appear inthestatusarea.
MSIWireless LANicon
STEP3
STEP4

12
Since the MSIMP54G5Wireless 11g MiniPCICard isin-
stalledinyourcomputer, youhavetoconfigurethe settingsfor
communicationtostartworkinginyournetworkenvironment.
>>>4.1InfrastructureMode
Clickthe MSIWirelessLANicontobring upthe Wireless
NetworkConnection window.
Infrastructuremode allowsyourcomputer tocommunicatewith
theothercomputersinthenetworkthroughanAccess Point.
Thefollowingtasksshouldbe done beforeyouconfigurethe
settings:
- TheAccess Pointmustbeturnedon.
- Your computerwithwireless adapterinstalledand the
AccessPoint mustbe locatedwiththe communication
rangeoftheAccessPoint(see theAccessPoint's
manualfordetails).
Click
STEP1
Connecting totheAccessPoint:
NetworkingSetup

13
Select
STEP2
STEP3
Inthetabof SiteSurvey, select thenetworkyouwant,and
thenclick Connect.
Youalsocanclick Rescan tosearchtheavailableAccessPoint
inthenetworkagain.
If theAccessPointselectedtoconnect hasbeenconnectedand
had set upthe Authentication and Security, youneedtohave
the WPAPre-sharedKeyorWEPKeybeforehand fromthe
AccessPointadministrator toenter inthe blank. Thenclick
OK tocompletethe configuration.
Click
EnterWPA
Pre-shared
Key

14
Advancednetworksettings:
STEP1Clickthe Advanced inthe MSIWirelessUtilitywindowtoset
advancednetworksettings.
1
2
3
Wireless mode:Selectwireless mode.802.11B/Gmix, 802.
11Bonly, and 802.11Gonlymodesaresupported.
B/GProtection: ERPprotection modeof802.11Gdefinition.
Usercan choosefromAuto, On, and Off.
a.Auto: STAwilldynamicallychange as APannouncement.
b.On:Alwayssend framewithprotection.
c.Off:Alwayssendframewithoutprotection.
TxRate:Manuallyforcethe Transmit usingselectedrate.
Default isAuto.
TxBurst:MSIproprietaryframeburst mode.
FastRoamingat:Fast toroaming, setupby transmit power.
SelectYourCountryRegionCode:Sevencountriestochoose.
4
5
6
STEP4Please refertopage 15formoredetail configurationregarding
AddtoProfile selection.
