MTS Sensors Temposonics R Series User manual

Model RH Rod-style position sensor
Model RP Prole-style position sensor
Temposonics
®
Magnetostrictive, Absolute, Non-contact
Linear-Position Sensors
R-Series Models RP and RH
EtherCAT®Industrial Ethernet Interface
Data Sheet
SENS
O
RS
®
Document Part Number
551074 Revision B
All specifications are subject to change. Contact MTS for specifications and
engineering drawings that are critical to your application. Drawings contained
in this document are for reference only. Go to http://www.mtssensors.com for
the latest support documentation and related media.
Time-based Magnetostrictive position sensing principle
Movable position magnet
Magnetic field from
position magnet
Interaction of magnetic
fields causes waveguide to
generate a strain pulse
Magnetic field encompasses
entire waveguide - generated
by the interrogation pulse
Bias magnet
Strain-Pulse detector
Interrogation
Return wire
Waveguide
Benefits of Magnetostriction
Temposonics linear-position sensors use the time-based magneto-
strictive position sensing principle developed by MTS. Within the
sensing element, a sonic-strain pulse is induced in a specially designed
magnetostrictive waveguide by the momentary interaction of two
magnetic fields. One field comes from a movable permanent magnet
that passes along the outside of the sensor. The other field comes
from an “interrogation” current pulse applied along the waveguide.
The resulting strain pulse travels at sonic speed along the waveguide
and is detected at the head of the sensing element.
The position of the magnet is determined with high precision and
speed by accurately measuring the elapsed time between the applica-
tion of the interrogation pulse and the arrival of the resulting strain
pulse with a high-speed counter. The elapsed time measurement is
directly proportional to the position of the permanent magnet and is
an absolute value. Therefore, the sensor's output signal corresponds
to absolute position, instead of incremental, and never requires
recalibration or re-homing after a power loss. Absolute, non-contact
sensing eliminates wear, and guarantees the best durability and output
repeatability.
FEATURES
Linear, Absolute Measurement
LEDs For Sensor Diagnostics
Superior Accuracy, Resolution down to 1 µm
Non-Contact Sensing Technology
Linearity Deviation Less Than 0.01%
Repeatability Within 0.001%
Direct EtherCAT Interface, Position + Velocity
100 µs Position / Velocity Update Time, Regardless of
Overall Stroke Length
BENEFITS
Rugged Industrial Sensor
Position + Velocity Measurements For Up to 20 Magnets
APPLICATIONS
Continuous Operation In Harsh Industrial Conditions
High Pressure Conditions
For Accurate, High-Speed, Simultaneous Multi-Position
and Velocity Measurements
TYPICAL INDUSTRIES
Factory Automation
Fluid Power
Plastic Injection and Blow Molding
Material Handling and Packaging
EtherCAT® is a registered trademark and patented technology licenced by
Beckhoff Automation GmbH, Germany

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT®Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/2014 2
Product specifications
Product overview
Parameters Specifications
OUTPUT
Measured output
variables: Simultaneous multi-position and velocity
measurements up to 20 magnets or up to
5 magnets when using high-speed update
(for EtherCAT distributed clock mode).
Option for acceleration measurements up to
2 magnets.
Resolution: 1 to 1000 µm selectable
Update time: 100 µs min. (high speed update feature
is active when the controller’s loop time is
less than the sensor’s measurement cycle
time)
Linearity
deviation: < ± 0.01% full stroke (minimum ± 50 µm)
(Linearity Correction Option (LCO)
available)
Repeatability: < ± 0.001% full stroke
(minimum ± 2.5 µm)
Hysteresis: < 4 µm
Outputs: Interface:
EtherCAT
Data format: EtherCAT 100 Base-Tx,
fast Ethernet
Data transmission rate: 100 Mbit/s max.
Stroke length: Range (Profile style):
25 mm to 5080 mm (1 in. to 200 in.)
Range (Rod style):
25 mm to 7620 mm (1 in. to 300 in.)
ELECTRONICS
Operating
voltage: +24 Vdc nominal: -15% or +20%*
Polarity protection: up to -30 Vdc
Over voltage protection: up to 36 Vdc
Current drain: 80 mA typical
Dielectric withstand voltage: 500 Vdc
(DC ground to machine ground)
Product Overview and Specifications
Parameters Specifications
ENVIRONMENTAL
Operating
conditions: Operating temperature:
0 °C (32 °F) to +75 °C (+167 °F)
Relative humidity:
90% no condensation
Temperature coefficient: < 15 ppm/ °C
EMC test: Electromagnetic emission:
IEC/EN 50081-1
Electromagnetic susceptibility:
IEC/EN 50082-2, IEC/EN 61000-4-2/3/4/6,
level 3/4 criterium A, CE qualified
Shock rating: 100 g (single hit)/IEC standard 68-2-27
(survivability)
Vibration rating: 15 g / 10 to 2000 Hz / IEC standard 68-2-6
WIRING
Connection type: D56 option: Two female 4-pin (M12-D) plus
one 4-pin male (M8) connector
PROFILE STYLE SENSOR (MODEL RP)
Electronic head: Aluminum housing with diagnostic LED
display (LEDs located beside connectors)
Sealing: IP 65**
Sensor extrusion: Aluminum (Temposonics profile style)
Mounting: Any orientation. Adjustable mounting feet or
T-slot nut (M5 threads) in bottom groove
Magnet types: Captive-sliding magnet or open-ring magnet
ROD STYLE SENSOR (MODEL RH)
Electronic head: Aluminum housing with diagnostic LED
display (LEDs located beside connectors)
Sealing: IP 67**
Sensor rod: 304L stainless steel
Operating
pressure: 350 bar static, 690 bar peak
(5000 psi static, 10,000 psi peak)
Mounting: Any orientation. Threaded flange M18 x 1.5
or 3/4 - 16 UNF-3A
Typical
mounting torque: 45 N-m (33 ft. - lbs.)
Magnet tyes: Ring magnet, open-ring magnet, or magnet
float
Temposonics R-Series EtherCAT sensors represent MTS Sensors’
development and product offering in high-speed networked position
feedback. EtherCAT (Ethernet for Control Automation Technology) is a
unique interface developed by Beckhoff Automation and is supported
by the EtherCAT Technology Group (ETG).
This interface is used for industrial Ethernet, providing the fastest,
most deterministic industrial networking solution possible using
the base Ethernet physical layer. By using this format, coupled with
our high speed networked sensing capability, machine builders and
automation engineers will be able to overcome bandwidth and node
limitation issues found with other commercially available industrial
networks.
* UL Recognition requires an approved power supply with energy limitation UL 61010-
1), or Class 2 rating according to the National Electrical Code (USA) / Canadian
Electrical Code.
** The IP rating is not part of the UL Recognition.

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT® Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/2014
3
EtherCAT Output Options, Programmability
Enhanced Monitoring and Diagnostics
Enhanced monitoring and diagnostics
SENSOR STATUS AND DIAGNOSTIC DISPLAY
Integrated diagnostic LEDs (green/red), located
beside sensor connectors (see ‘Figure 1’), pro-
vide basic visual monitoring for normal sensor
operation and troubleshooting. Diagnostic display
LEDs indicate four modes described in ‘Table 1.
Diagnostic display indicator modes'
Figure 1. R-Series sensor Integrated diagnostic LEDs
Status LED
(Green)
Off:
On:
Flashing:
Initializing
Normal function
Various flashing codes show
different operational status
Error LED
(Red)
Off:
On:
Flashing:
Normal function
missing magnet
Supply voltage beyond limits
(high or low)
IN Port
LED
(Green)
Off:
On:
Flashing:
No link
Link detected
Traffic
OUT
Port LED
(Green)
Off:
On:
Flashing:
No link
Link detected
Traffic
Table 1. Diagnostic display indicator modes
EtherCAT interface
EtherCAT is an open field bus system which is based on Ethernet
technology, (IEEE 802.3), with a high data rate and short response
time, resulting in very good real-time performance. It is standardized
in the IEC/PAS 62407 and is part of the ISO 15745-4 standard. The
EtherCAT protocol is also being integrated into the IEC 61158, IEC
61784, and IEC 61800-7 standards.
The Temposonics EtherCAT sensor is connected as a slave device,
and as such, fulfils all the requirements of the EtherCAT field bus
system. Adding the sensor to an EtherCAT bus system is very easy.
The system manager (e.g. TwinCAT from Beckoff Automation) gets
all the parameters of the sensor from the XML file, available from
the MTS website at http://www.mtssensors.com. There are no
adjustments necessary on the sensor itself. For some applications,
optimum system performance is obtained using the sensor’s high
speed updates, up to 10 kHz, by synchronizing to the EtherCAT’s
'distributed clock mode' (available on the “E101” sensor output
option).
Operation modes and output
There are two operation modes available:
E101 - Fast update position and velocity:
• Designed for high-speed motion control
• Up to 5 simultaneous magnet measurements
• 100 µs update rate, (independent of stroke length)
E102 Multi-magnet position and velocity:
• Designed for gauging systems having many magnet positions
• Up to 20 simultaneous magnet measurements
• Standard update rates, (stroke length dependent)
When using multiple magnets, the minimum allowed distance
between magnets is 75 mm (3 in.) to maintain proper sensor output
(see ‘Figure 2’).
Figure 2.
1 to 5 magnet
Measurement
1 to 20 magnet
Measurement
M1
Active stroke length
Position / Velocity
M1 M2 M19
M20
75 mm
(3 in.) min.
M3
Position / Velocity
M2 M4
M5
M3
75 mm
(3 in.) min.
Temposonics®
R-Series
R
®
Temposonics®
R-Series
R
®
Single to multi-magnet output diagram
LINEARITY CORRECTION OPTION (LCO)
The Linearity Correction Option (LCO) provides improved sensor
output accuracy. For most stroke lengths linearity accuracy is
improved up to a factor of 5 resulting in deviations from actual
position of less than ± 20 µm (0.0008 in.). For stroke lengths
over 5000 mm (197 in.), the linearity accuracy is improved
up to factor of 10. Selecting the sensor style and magnet is important
(both must be matched together). Contact the factory for assistance
when designing for the LCO in your application.

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT®Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/2014 4
Model RP profile-style sensor dimension references
MODEL RP, PROFILE-STYLE SENSOR WITH CAPTIVE-SLIDING MAGNET Drawing is for reference only, contact applications engineering for
tolerance specific information.
49 mm
(1.92 in.)
9 mm
(0.36 in.)
50 mm (1.97 in.)
68 mm (2.68 in.)
5.5 mm
(0.21 in.) dia.
M5 or #10 screw
2 mm
(0.07 in.)
45 mm
(1.77 in.)
12 mm (0.47 in.)
100 mm
(3.9 in.)
Stroke length
82 mm (3.2 in.)
Dead zone
End of stroke
‘Span’ position
Beginning of stroke ‘Null’ position
Mounting foot, moveable
(part no.: 400802)
Electronics
housing
Captive-sliding magnet
D56
integral connector option
19 mm (0.75 in.)
Figure 3. R-Series Model RP Profile-style sensor dimension reference (Shown with the D56 connector option)
MODEL RP, PROFILE-STYLE SENSOR WITH OPEN-RING MAGNET Drawing is for reference only, contact applications engineering for toler-
ance specific information.
28 mm
(1.10 in.)
Null
zone Open-ring magnet Style M
(part no. 251416-2)
Dead Zone
66 mm (2.6 in.)
Stroke length
Non-ferrous mounting
support and screws
100 mm
(3.9 in.)
19 mm
(0.75 in.)
28 mm
(1.10 in.)
D56
integral connector option
Electronics
Housing
End of stroke ‘Span’ position
Beginning of stroke ‘Null’ position
Figure 4. R-Series Model RP Profile-style sensor dimension reference (Shown with the D56 connector option)
Model RP Profile-Style Sensor
Sensor Dimension References

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT® Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/20145
Model RP Profile-Style Sensor
Standard Magnet Selections
Standard magnet selections (Model RP)
SELECTION OF POSITION MAGNETS (ONE MAGNET INCLUDED WITH MODEL RP SENSOR)
A choice of two magnet mounting configurations are available with the profile-style sensor; A ‘captive-sliding’ magnet, Styles Sor Vor an
‘open-ring’ magnet, Style M. Captive-sliding magnets utilize slide bearings of special material that reduce friction, and if required, help mitigate
dirt build up. The slide bearings are designed to operate dry, requiring no external lubrication or maintenance.
The Style M ‘open-ring’ magnet mounts on the moving machine part and travels just above the sensor’s profile extrusion. The open-ring
magnet requires a minimum distance away from ferrous metals to allow proper sensor output. It must be mounted using non-ferrous screws
and a non-ferrous support bracket, or utilize a non-ferrous spacer of at least 5 mm (0.2 in.) thickness.
POSITION MAGNET SELECTIONS (Drawing dimensions are for reference only)
Magnet dimensions and mounted magnet dimensions Description Part number
40 mm
(1.58 in.)
25 mm
(1 in.)
20 mm
(0.79 in.)
43 mm
(1.69 in.)
14 mm
(0.55 in.)
Rotation:
Vertical: 18°
Horizontal: 360°
Ball-jointed arm
(M5 thread)
Captive-sliding magnet, Style S
For Model RP profile-style sensor 252182
40 mm
(1.58 in.)
25 mm
(1 in.)
9 mm
(0.35 in.)
57 mm
(2.24 in.)
14 mm
(0.55 in.)
Rotation:
Vertical: 18°
Ball-jointed arm
(M5 thread)
Captive-sliding magnet, Style V
For Model RP profile-style sensor 252184
Magnet dimensions and mounted magnet dimensions Description Part number
21 mm
(0.81 in.)
25 mm
(0.97 in.)
14 mm
(0.55 in.)
2 Holes
Each 4.3 mm
(0.17 in.) dia. on
24 mm (0.94 in.) dia.
60°
Open-ring magnet, Style M
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.31 in.)
Operating temperature:
- 40 °C to 100 °C
This magnet may influence the
sensor performance specifications
for some applications.
251416-2
45 mm
(1.77 in.)
52 mm
(2.05 in.)
36 mm
(1.41 in.)
21 mm
(0.81 in.)
29 mm
(1.14 in.)
Max gap
3 mm ± 1 mm
(0.12 in. ± 0.04 in.)
Non-ferrous mounting support
and screws
Open-ring magnet Style ‘M’

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT®Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/2014 6
Model RP Sensor mounting
Model RP profile-style sensor mounting flexible installation in any position!
Temposonics Model RP profile-style sensors offer two basic mounting methods; side grooves for use with mounting feet or a bottom groove
that accepts special T-Slot nuts. Both the mounting feet and T-Slot nuts can be positioned along the sensor extrusion to best secure the sensor
for each particular application.
Notes:
1. Model RP sensors include two mounting feet (part no. 400802) for sensors stroke lengths up to 1250 mm (50 in.)
2. One additional mounting foot is included for stroke lengths over 1250 mm (50 in.) and for each additional 500 mm (20 in.),
thereafter.
3. MTS recommends using 10-32 cap screws (customer supplied) at a maximum torque of 44 in. lbs. when fastening mounting feet.
Profile-Style sensor mounting and installation reference Mounting method Part number
(Width = 14.5 mm (0.57 in.)
Mounting feet, standard (304 SS)
Profile-style sensor mounting for sen-
sor model RP
400802
10 - 32 Cap screws
Recommended
(Customer supplied)
Mounting feet and screws
Profile-style sensor foot installation
See Mounting
Feet
part number:
400802
T-Slot nut
Nut for mounting model RP sensor
M5 thread
(Optional, ordered separately)
401602
4 Holes
5.3 mm
(0.21 in.) dia.
28 mm
(1.1 in.) 9 mm
(0.36 in.)
50 mm
(1.97 in.)
2 mm
(0.08 in.) 68 mm
(2.68 in.)
9 mm
(0.36 in.)
Mounting foot and screws
5 mm (0.20 in.)
T-Slot nut, M5 thread
Detail
M5 Threaded
stud and nut
Model RP Profile-Style Sensor
Sensor Mounting Reference

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT® Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/20147
Model RH Rod-Style Sensor
Dimension References
Model RH rod-style sensor dimension reference
The Temposonics R-Series rod-style sensor (Model RH) offers modular construction, flexible mounting configurations, and easy installation.
The Model RH sensor is designed for mounting in applications where high pressure conditions exist (5000 psi continuous, 10,000 psi spike)
such as inside hydraulic cylinders. The Model RH sensor (see 'Figure 5') may also be mounted externally in many applications.
Stroke-dependent Dead Zones:
Stroke length:
25 mm (1 in.) - 5000 mm (197 in.)
5005 mm (197 in.) - 7620 mm (300 in.)
Dead zone:
63.5 mm (2.5 in.)
66 mm (2.6 in.)
MODEL RH, ROD-STYLE SENSOR WITH RING MAGNET (MAGNET ORDERED SEPARATELY) Drawing is for reference only, contact
applications engineering for tolerance specific information.
Figure 5. Model RH Rod-style sensor dimension reference (shown with D56 integral connector options
19 mm (0.75 in.)
105 mm (4.1 in.) 51 mm (2 in.)
Beginning of stroke ‘Null’ position End of stroke ‘Span’ position
Electronics
housing
Null zone
Stroke length
Flat-faced hex flange type ‘S ’
Sensor Rod
10 mm (0.39 in.) dia.
25 mm
(0.98 in.)
O-Ring
Ring magnet
Dead zone
(refer to Notes
‘Stroke dependent
dead zones’)
Refer to ‘Table 2’ for
(A) Flange threads
D56
Integral connector option
)
MODEL RH, ROD-STYLE SENSOR WITH RING MAGNET (MAGNET ORDERED SEPARATELY)
Drawing is for reference only, contact applications engineering for tolerance specific information.
Figure 6.
25.4 mm
(1 in.)
O-Ring
Beginning of stroke ‘Null’ position
Null
51 mm (2 in.)
Electronics
housing
2.5 mm (0.10 in.)
Raised-faced flange, Type ‘T’
Refer to ‘Table 2’
25 mm
(0.98 in.)
Ring Magnet
part no.: 201542-2
Refer to ‘Table 2’
(A) Flange Threads
B
C
Refer to ‘Table 2’
(B) dimensions and (C) dimension
s
D56
Integral connector option
Model RH Rod-style sensor dimension reference (Shown with the D56 Integral cable connection type option)
Housing style
Flange type Description (A) Flange threads (B) Dimensions (C) Dimensions
TUS customary threads with raised-face flange 3/4" - 16 UNF-3A 1.75 in. 2 in.
SUS customary threads with flat-faced flange 3/4" - 16 UNF-3A 1.75 in. 2 in.
MMetric threads with flat-faced flange M18 x 1.5 46 mm 53 mm
Table 2. Model RH Rod-style sensor housing style and flange type references

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT®Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/2014 8
Model RH Rod-Style Sensor
Standard Magnet Selections
Standard magnet options (Model RH)
Magnets must be ordered separately with Model RH position sensors. The standard ring magnet (part number 201542-2) is suitable for most
applications.
POSITION MAGNET SELECTIONS (MAGNET MUST BE ORDERED SEPARATELY) (Drawing dimensions are for reference only)
Magnet and magnet dimensions Description Part number
Standard ring magnet
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
201542-2
Magnet spacer
(Non-ferrous, use with ring magnet
Part number: 201542-2)
I.D.: 14 mm (0.56 in.)
O.D.: 32 mm (1.25 in.)
Thickness: 3.2 mm (0.125 in.)
400633
Ring magnet
I.D.: 13.5 mm (0.53 in.)
O.D.: 25.4 mm (1 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
400533
Open-ring magnet, Style M
I.D.: 13.5 mm (0.53 in.)
O.D.: 33 mm (1.3 in.)
Thickness: 8 mm (0.3 in.)
Operating temperature:
- 40 °C to 100 °C
This magnet may influence the sensor perfor-
mance specifications for some applications.
251416-2
MAGNET FLOAT SELECTION (Drawing dimensions are for reference only)
Magnet float
(Level sensing applications)
Specific gravity: 0.70 maximum
Pressure: 870 psi maximum
(This float is used with Model RH rod-style
sensors for hydraulic fluid or fresh water
applications only). Collar (part no.: 560777)
is recommended for end of stroke stops.
251447
4 Holes
Each 4.3 mm (0.17 in.) dia.
90° apart on
24 mm (0.94 in.) dia.
4 Holes
Each 4.3 mm (0.17 in.) dia.
90° apart on
24 mm (0.94 in.) dia.
21 mm
(0.81 in.)
25 mm
(0.97 in.)
14 mm
(0.55 in.)
2 Holes
Each 4.3 mm
(0.17 in.) dia. on
24 mm (0.94 in.) dia.
60°
14 mm (0.55 in.) Min. I.D.
51 mm (2 in.)
Spherical O.D.
3.4 mm (0.13 in.)
C
L
53 mm
(2.1 in.)

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT® Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/20149
Model RH Rod-Style Sensor Mounting
Cylinder Installation and Connections
Model RH rod-style sensor mounting
The position magnet requires minimum distances away from ferrous
metals to allow proper sensor output. The minimum distance from
the front of the magnet to the cylinder end cap is 15 mm (0.6 in.).
The minimum distance from the back of the magnet to the piston
head is 3.2 mm (0.125 in.). However, a minimum distance of at
least 5 mm (0.197 in.) is preferred for added performance margin.
The non-ferrous spacer (part no. 400633), provides this minimum
distance when used along with the standard ring magnet (part no.:
201542-2) as shown in Figure 7.
Figure 7.
Non ferrous
spacer
Min. 3.2 mm
(0.125 in.)
Ring magnet
on fe
pace
(0.125 in.)
g magnet
Ring
No
sp
Min. 3.2 mm
(0 125 in )
g magnet
Ring
Cylinder end cap
Piston head
Temposonics®
R-Series
R
®
> 15 mm
(0.6 in.)
Model RH rod-style mounting
Cylinder installation
When used for direct-stroke measurement in fluid cylinders, the
sensor's high pressure, stainless steel rod installs into a bore in
the piston head/rod assembly as shown in Figure 8. This method
guarantees a long-life and trouble-free operation.
The sensor cartridge can be removed from the flange and rod hous-
ing while still installed in the cylinder.This procedure allows quick
and easy sensor cartridge replacement, without the loss of hydraulic
pressure.
The sensor’s rod housing and flange can remain
permanently installed in the cylinder
Ring magnet
The sensor cartridge, consisting of the electronics housing
and sensing element, is easy to replace by removing
(2) M4 thread 2.5 mm hex socket head screws
Figure 8. Fluid cylinder installation
(D56) BUS CONNECTOR OPTION
D56 connector option for 'daisy chain' topologies. A separate cable
is used for the supply voltage. Unused connectors should be covered
by a protective cap (part no.: 370537).
D56
Female
4-pin Bus In
D56
Female
4-pin Bus Out
D56
Male, 4-pin
Input voltage
Connections and wiring
BUS CONNECTIONS IN/OUT
4
3
2
1
Female, 4-pin (M12-D) Integral connector
pin-out as viewed from the end of the sensor
Pin number Cable color Function
1 Yellow Tx+
2 White Rx+
3 Orange Tx-
4 Blue Rx-
INPUT VOLTAGE
3
4
2
1
Input voltage, male, 4-pin (M8) integral
connector pin-out as viewed from the end of
the sensor
Pin number Cable color Supply voltage
1 Brown +24 Vdc (-15/+20%)
2 White No connection
3 Blue DC ground (for supply)
4 Black No connection

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT®Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/2014 10
Models RP and RH Sensors
Ordering Information, Connector and Cable Assembly Options
(D56) CABLE CONNECTOR OPTIONS (Drawing dimensions are for reference only)
Connector and connector dimensions Description Part number
Bus Cable Connector, Male 4-pin
(M12), D-coded with insulation
displacement technology
370523
Connector, Female 4-pin
(M8) and cable with pigtail
termination
For 24 Vdc input.
Wire gage 4x0.25 mm2 shielded,
PUR cable jacket
5 m length =
530066
10 m length =
530096
15 m length =
530093
Connector end cap
(Unused connectors should be
covered by this protective cap)
370537
BUS CABLE WITH CONNECTORS (Drawing dimensions are for reference only)
Bus cable and connector assemblies Description Part number
Ethernet cable
2 - Male, (M12)
4-pin connectors
47 mm
(1.85 in.)
16 mm
(0.63 in.) dia.
1
2
3
4
Industrial Ethernet Bus Cable,
5 m length (Cat 5e ES)
Assembly Includes two 4-pin
(M12) connectors (D-coded) and
PUR cable jacket (green)
530064
Ethernet cable
Male, (M12)
4-pin connector
47 mm
(1.85 in.)
16 mm
(0.63 in.) dia.
1
2
3
4M12 x 1
RJ45 Connector
55 mm
(2.17 in.)
Industrial Ethernet Bus Cable,
5 m length (Cat 5e ES)
Assembly Includes one RJ45
connector and one 4-pin (M12)
connector (D-coded) with PUR
cable jacket (green) Cables using
the RJ45 connector provide con-
venient sensor connection to a PC
for setup and programming but
are not recommended for factory
floor installations.
530065
SW17/ width across flats 17
M12x1
Ø19.5 mm
(0.77 in.)
52 mm (2.05 in.)
SW13/ width across flats 13
10 mm
(0.39 in.)
dia.
M8 x 1
32.5 mm
(1.28 in.)

MTS Sensors
R-Series Models RP and RH Temposonics®Linear-Position Sensors - EtherCAT® Output
Product Data Sheet, Document Part No.: 551074 Revision B (EN) 05/201411
Models RP and RH Sensors
Ordering Information
R D 5 6 1 E 1 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
SENSOR MODEL =R1-2
RP =
Profile style
RH
= Hydraulic rod style
HOUSING STYLE =3
Model RP profile-style sensor (includes one magnet):
S=
Captive-sliding magnet with ball joint
at top (part no. 252182)
V
=
Captive-sliding magnet with ball
joint at front (part no. 252184)
M
=
Open-ring magnet (part no. 251416-2)
Model RH rod-style sensor (magnet(s) must be ordered separately):
T=
US customary threads, raised-faced
flange and pressure tube, standard
U
=
Same as option “T”, except uses
fluoroelastomer seals for the
electronics housing
B
=
Sensor cartridge only (no flange or
pressure tube, stroke length
< 1830 mm (72 in.))
S=
US customary threads, flat-faced
flange and pressure tube, standard
H
=
Same as option “S”, except uses
fluoroelastomer seals for the
electronics housing
M=
Metric threads, flat-faced flange and
pressure tube, standard
V
=
Same as option “M”, except uses
fluoroelastomer seals for the
electronics housing
STROKE LENGTH
=
4-8
— — — — M
=
Millimeters
(Encode in 5 mm increments)
Stroke Length Notes:
———.—U
=
Inches and tenths
(Encode in 0.1 in.
increments) 1. Profile-style sensor (model RP) stroke range = 25 mm (1 in.) - 5080 mm. (200 in.)
2. Rod-style sensor (model RH) stroke range = 25 mm (1 in.) - 7620 mm (300 in.)
CONNECTION TYPE =D 5 6 9-11
Integral connector:
D56
=
Two 4-pin female (M12-D), plus one 4-pin male (M8)
INPUT VOLTAGE =112
1=
+24 Vdc (+20% - 15%)
OUTPUT = E 1 0 13-16
E101 =
EtherCAT, position and velocity, high speed updates, maximum 5 magnets
E102 =
EtherCAT, position and velocity, maximum 20 magnets
E103 =
Same as option '
E101' with Linearity Correction Option (LCO)
E104 =
Same as option '
E102' with Linearity Correction Option (LCO)
NUMBER OF MAGNETS =Z
17-19
For multi-position measurement only (Order additional magnets separately).
Z— — =
Number of magnets for output
E101 (range 02 to 05), or for output E102 (range 02 to 20)

Document Part number:
551074 Revision B (EN) 05/2014
MTS, Temposonics and Level Plus are registered trademarks of MTS Systems Corporation. All
other trademarks are the property of their respective owners. Printed in USA. Copyright © 2014
MTS Systems Corporation. All Rights Reserved in all media.
All specifications are subject to change. Contact MTS for specifications and engineering
drawings that are critical to your application. Drawings contained in this document are for
reference only. Go to http://www.mtssensors.com for the latest product information.
LOCATIONS
LEGAL NOTICES
USA
MTS Systems Corporation
Sensors Division
3001 Sheldon Drive
Cary, N.C. 27513, USA
Tel. [phone]
Fax [phone]
[email protected]
www.mtssensors.com
GERMANY
MTS Sensor Technologie
GmbH & Co. KG
Auf dem Schüffel 9
58513 Lüdenscheid, Germany
Tel. + 49 2351 9587-0
Fax + 49 2351 56491
[email protected]
www.mtssensor.de
JAPAN
MTS Sensors Technology Corp.
737 Aihara-machi,
Machida-shi,
Tokyo 194-0211, Japan
Tel. + 81 42 775-3838
Fax + 81 42 775-5512
[email protected]
www.mtssensor.co.jp
FRANCE
MTS Systems SAS
Zone EUROPARC Bâtiment EXA 16
16/18, rue Eugène Dupuis
94046 Creteil, France
Tel. + 33 1 58 4390-28
Fax + 33 1 58 4390-03
[email protected]
www.mtssensor.com
ITALY
MTS Systems Srl.Sensor Division
Via Diaz,4
25050 Provaglio d‘Iseo (BS), Italy
Tel. + 39 030 988 3819
Fax + 39 030 982 3359
[email protected]
www.mtssensor.com
CHINA
MTS Sensors
Room 504, Huajing Commercial Center,
No. 188, North Qinzhou Road
200233 Shanghai, China
Tel. [phone]
Fax [phone]
[email protected]
www.mtssensors.cn
