NAMCO TEKKEN 4 Instruction manual

TEKKEN 4
Game PCB Kit
Connections
and
Adjustments
Issue 2Part No 90500133

Page 2

Page 3
is a term to describe a copyright protection technology created by
Sony Group. This mark does not necessarily guarantee compatibily
with other products bearing the “MagicGate” trademark.
is a trademark of Sony Corporation.
est une terme décrivant une technique de protection de copyright
crééé par Sony Group. ne garantit pas nécessairement de
cpmpatabilté avec d’autres produits portant la marque de commerce “MagicGate”
est une marque de commerce de Sony Corporation.
The DVD-ROM DISC supplied with the product must not be copied, modified,
distributed, or used for the purposes other than the operation of the product.
Copyright laws protect the contents of the DVD-ROM DISC. Infringement of
copyright laws may be subject to criminal penalties.
Do not use the supplied DVD-ROM DISC with other product models or other
media formats. Doing so may result in equipment failure.
NOTICE

Page 4
Contents
KIT CONTENTS .............................................................................................................. 5
1. SPECIFICATIONS.................................................................................................... 7
2. CABINET CONNECTIONS (Standard Jamma) ........................................................ 7
3. CABINET CONNECTIONS (JVS Standard) ........................................................... 11
4. FITTIN THE DON LE ......................................................................................... 12
5. FITTIN THE CD-ROM DISC ................................................................................ 13
6. ADJUSTMENTS AND SETTIN S ......................................................................... 15
6-1 Option Switches ............................................................................................. 15
6-2 Test Mode ...................................................................................................... 16
6-2-1 Display Test .............................................................................................. 16
6-2-2 Colour Edit ............................................................................................... 18
6-2-3 Convergence ............................................................................................ 18
6-2-4 Interlace ................................................................................................... 19
6-2-5 Input Test ................................................................................................. 20
6-2-6 ame Options .......................................................................................... 21
6-2-7 Coin Options ............................................................................................ 22
6-2-8 Sound Test ............................................................................................... 23
6-2-9 JVS Status ............................................................................................... 23
6-2-10 A. D. S - (Book Keeping) .......................................................................... 24
6-2-11 Data Clear ................................................................................................ 25

Page 5
KIT CONTENTS
noitpircseDoNtraPytitnauQ
yssAkcaRBCP4nekkeT BCP-4KETX1
csiDDCmoRDVD ORDC-4KETX1
BCP)B(ammaJ AAJ-4KETX1
selbac
gnitcennocBCP)B(ammaJotyssAkcaR
mooLylppuSrewoP1
mooLoediVBGR1
mooLoiduA)onohP(ACR1
mooLataD1
mooLrotpadAegdEy
aw84otsrotcennocIEpmA 760002961
mooLsdaeLgniylFhtiwsrotcennocIEpmA 660002961
slaceDnottuB tes1
draCnoitcurtsn
I 1
draCtsiLevo 1
draoBeltiT 1
retsoPlanoitomorP4nekkeT 1
hsalFpoT 307000041
SHR/SHL-laceDediStenibaClasrevinU 4
07000042
laceDredaeH 507000041
launatnemtsujdAdnanoitcennoC 331005091

Page 6
1. SPECIFICATIONS
COMPATIBILITY: JAMMA STANDARD (with JAMMA (B) P B)
JAMMA VIDEO STANDARD (JVS)
PCB INPUT POWER: +5v (±5%) @ 7A (Min), +12v (±5%) @ 2A (Min)
OPERATING
ENVIRONMENT:
MONITOR ORIENTATION Horizontal Orientation
AND SIGNAL: Horizontal Frequency 15kHz / 31kHz (selectable)
RGB output level 0.7V p-p / 3.0V p-p (selectable)
when set to 15kHz
0.7V p-p when set to 31kHz
omposite Sync / Separate Sync (selectable)
Temperature +5º to +45º
Humidity 10% to 85% (no condensation)

Page 7
NO
OFF
ON
2341
Option Switches
PCB Rack Assy
CD-ROM Drive
Audio Cable
Data Cable
Jamma (B) PCB
Power Cable
Video Cable
Volume Control
2. CABINET CONNECTIONS (Standard Jamma)

Page 8
JAMMA
56way
Connector
4way
AMP EI
Connector
10way
AMP EI
Connector
JAMMA (B) PCB
The JAMMA (B) P B is connected to the game cabinet with a 56way Edge onnector
(standard JAMMA) and 4 and 10way AMP EI onnectors.
Note: Supplied in the Kit is an Amp EI connectors to 48way extender card adaptor
loom, for ca inets with an existing 48way connector, and an AMP EI connectors
with flying leads loom for ca inets without a 48way connection.
4 and 10way AMP EI onnector with 48way Extender ard
Part No. 69200067
4 and 10way AMP EI onnector with flying leads
Part No.69200066

Page 9
4NEKKET
rotcennoCegdEyaw65AMMAJ
ediSredloSoNlanimreTediStnenopmoC
DNGA1 DNG
DNGB2 DNG
tlo5+C3 tlo5+
tlo5+D4 tlo5+
E5
tlo21+F6 tlo21+
y
eKgniziraloPG7 yeKgniziraloP
2retnuoCnioCH81retnuoCnioC
J9
)-(rekaepSLK01)+(rekaepSL
)onom()-(oiduAL11)onom()+(oiduA
NEE
RGoediVM21DERoediV
CNYSoediVN31EULBoediV
ECIVRESP41DNGoediV
R51TSET
2hctiwSnioCS611hctiwSnioC
TRATS2PT71TRATS1P
PUreeL2PU81PUr
eeL1P
NWODreeL2PV91NWODreeL1P
TFELreeL2PW02TFELreeL1P
THGIRreeL2PY12THGIRreeL1P
1wS)tfeL(HCNUP2PZ221wS)tfeL(HC
NUP1P
2wS)thgiR(HCNUP2Pa322wS)thgiR(HCNUP1P
desutoN3wS2Pb42desUtoN3wS1P
c52
d62
DNGe72DNG
DNGf82DNG
4NEKKET
rotcennoCIEPMAyaw01
oNniPnoitpircseD
1DNG
2
35wS)thgiR(KCIK2P
44wS)tfeL(KCIK2P
5
75wS)thgiR(KCIK1P
84wS)tfeL(KCIK1P
9
01DNG
4NEKKET
rotcennoCIEPMAyaw4
oNniPnoitpircseD
1
2
3)+(rekaepSR
4)-(rekaepSR
Connections or Standard JAMMA Cabinet
Connector Loom
(Part no 69200066)

Page 10
SEMAGNEKKETSUOIVERP
rotcennoCnoisnetxEyaw84
ediSredloSoNlanimreTediStnenopmoC
4nipIEPMAw4)-(rekaepSR42A42B)+(rekaepSR3nipIEPMAw4
32
A32B
22A22B
12A12B
yeKgniziraloP02A02ByeKgniziraloP
91A91B
81A81B
4nipIEPMAw014wS)tfeL(KCIK2P71A71B5wS)thgiR(KCIK2P3nipI
EPMAw01
61A61B
51A51BDNG01nipIEPMAw01
41A41BDNG01nipIEPMAw01
31A31B
21A21B
11A11B
01A01B
9A9B
8A8BDNG1nipIEPMAw01
7A7BDNG1nipIEPM
Aw01
6A6B5wS)thgiR(KCIK1P7nipIEPMAw01
8nipIEPMAw014wS)tfeL(KCIK1P5A5B
4A4B
3A3B
2A2B
1A1B
Adaptor or Earlier Tekken Series Cabinets
with 48way Edge Connector
(Part No 69200067)

Page 11
3. CABINET CONNECTIONS (JVS Standard)
JVS Power Supply Adaptor
Video Connector
Audio Connectors
Data I/O Connector

Page 12
4. FITTING THE DONGLE
The dongle incl ded in this kit is limited to this game only. DO NOT insert this
Dongle in other games. Inserting the Dongle in other games may ca se damage.
Ensure that the power is switched OFF before inserting the Dongle.
1. Remove 1off pozi head screw (M3x10) and remove the Dongle over.
2. Fit the Dongle to the left hand connector.
3. Refit the Dongle cover and pozi head screw (M3x10)
Dongle cover
Pozi head screw
(M3x10)
Left connector
Dongle

Page 13
5. FITTING THE CD-ROM DISC
nThe CD-ROM Disc m st be inserted with the power switched on. To prevent
an electric shock, accident or inj ry, do not to ch any parts other than
those specified below.
nThe s pplied CD-ROM Disc is designed excl sively for this prod ct. Never
se the CD-ROM Disc in any other prod ct. Do not insert other CD-ROM
Discs in the CD-ROM drive of this game.
nThe CD-ROM tray retracts a tomatically after 10 seconds.
1. Press the eject button of the D-ROM drive to open the tray.
Access Lamp
Eject Button
CD-ROM Drive

Page 14
2. Place the D-ROM Disc on to the tray, ensuring that the label side (printed
surface) is facing away from the Tray.
3. Press the Eject button to retract the Tray in to the unit.
4. Switch the power OFF, wait approx 10 seconds then switch the game back ON.
CD-ROM DISC
Ensure that the CD-ROM
Disc is securely placed on
the tray, with the label side
facing away from the tray
Tray

Page 15
6. ADJUSTMENTS AND SETTINGS
The Game P Board Assy is fitted with 4 Option Switches.
The JAMMA (B) P B has the Volume ontrol fitted.
6-1 Option Switches
NO
OFF
ON
2341
Option Switches
Volume Control
JAMMA (B) PCB
Switch 1 is used to change between Test Mode and Game Mode.
ON: Test Mode OFF: Game Mode
Switch 2 is used to set the output level of the video signal.
31kHz ON: 0.7V p-p OFF: 0.7V p-p
15kHz ON: 3.0V p-p OFF: 0.7v P-P
Switch 3 is used to change the monitor Sync Frequency
ON: 31kHz OFF: 15kHz
Note: When using a 31kHz monitor, set the RGB input of the monitor to 0.7v. If the
monitor does not have a setting adjustment, refer to page 17 section 6-2-1
Display Test, and change the Contrast and RGB Brightness levels to adjust
the rightness.
Switch 4 is used to set the Video Sync Signal
ON: omposite Sync OFF: Seperate Sync

Page 16
6-2 Test Mode
To enter Test Mode set the Test switch in the cabinet (if fitted) to ON, or if no Test
switch is fitted to the cabinet, set Option switch 1 ON
Note: The test mode is activated only when the ca inet Test switch or Option switch
1 is moved from OFF to ON. If the game is switched on with either switch in
the ON position the Test Mode will not e activated. The switch must e
switched OFF and then ON to enter the test mode.
When the Test Mode is entered, the following screen is displayed.
Use the Joystick Up or Down to step through the tests. (The selected test will be
displayed in red)
Press the 1 Player Button 1 to enter the selected test.
After making adjustments select EXIT and press the 1 Player Button 1 to return to the
above screen. Select another test or select EXIT & SAVE and press the 1 Player
Button 1 to save the changes and return to the Game Mode.
Note: If EXIT &SAVE is not selected and activated, any changes made may not e
stored properly. Switching the ca inet Test switch or Option 1 switch OFF does
not exit the Test Mode.
Switch the cabinet Test switch or Option 1 switch OFF.
NO
2341
DISPLAY TEST
INPUT TEST
GAME OPTIONS
COIN OPTIONS
SOUND TEST
JVS STATUS
A.D.S.
DATA CLEAR
EXIT & SAVE
Monitor Adjustments
Tests all switches
Set Game options
Set Price of Play
Sound test
Not used
Bookkeeping
Data clear
Exit from test mode

Page 17
DISPLAY TEST
Color bar
Overall contrast
Brightness (red)
Brightness (green)
Brightness (blue)
Reset Colour Edit values to factory defaults
Colour Edit ON /OFF
Select next test pattern
Return to test menu screen
Color bar (white)
Color bar (red)
Color bar (green)
Color bar (blue)
Previous Color
EXIT color edit
NEXT
EXIT
: P1-Button4
: P1-Button3
: P1-Button1
: P1-Start
Contrast
Bright R
Bright G
Bright B
: OO
: OO
: OO
: OO
Colour Edit ON /OFF
Select to next test pattern
Return test menu screen
Color bar (white)
Color bar (red)
Color bar (green)
Color bar (blue)
DISPLAY TEST
Color bar
ENTER color edit
NEXT
EXIT
: P1-Button3
: P1-Button1
: P1-Start
6-2-1 Display Test
This test allows the following checks and adjustments to be made.
nolour Edit
Adjust contrast and brightness of each colour to match video output from the
P B to the Monitor.
Note: This adjustment should only e made if the correct picture quality cannot
e achieved y using the normal monitor adjustments.
nonvergence
heck and adjust the size, position and distortion of the screen image.
nInterlace heck
Switches between interlaced and non-interlaced display. (Only with 15kHz video
signal).
1. Select display Test from the Test Menu Screen, the following screen is displayed.
2. Each time the 1P Button 3 is pressed the olour Edit adjustment box is turned
ON or OFF.
3. Press the 1P Button 1 to step to the next test function
OLOUR BAR ONVERGEN E INTERLA E

Page 18
6-2-2 Colo r Edit
1 Ensure that the olour Edit Adjustment Box is showing. (Press P1 Button 3
if the Adjustment box is not displayed.
2. Use the Joystick UP/DOWN to step to the required adjustment.
( ontrast, Brightness (red), Brightness (green), Brightness (blue)).
3. Use the Joystick LEFT/RIGHT to adjust the value.
3. When all adjustments have been made, press P1 Button 1 to step to the
onvergence Test or P1 Start Button to return to the Main Test Menu screen
6-2-3 Convergence
Use this screen to adjust the geometry (height, width , etc.) of the Monitor.
When all adjustments have been made, press P1 Button 1 to step to the Interlace
Test or P1 Start Button to return to the Main Test Menu screen.
DISPLAY TEST
Convergence Interlace
Contrast
Bright R
Bright G
Bright B
: 150
: 100
: 100
: 100
Previous Color
EXIT color edit
NEXT
EXIT
: P1-Button4
: P1-Button3
: P1-Button1
: P1-Start

Page 19
6-2-4 Interlace
Interlace Mode: This mode provides a more detailed and smoother graphics
than the non-interlaced mode. This is achieved by shifting
the picture display a half line in the vertical direction every
other frame scan, so doubling the vertical resolution without
changing the horizontal/vertical frequency.
Non-Interlaced Mode: Use this display if the interlace mode results in flicker over
the entire screen display. In the non-interlaced mode, there is
no shift of the display position, and the display remains
constant every time.
1 Ensure that the olour Edit Adjustment Box is showing. (Press P1 Button 3
if the Adjustment box is not displayed.)
2. Use the Joystick LEFT/RIGHT to change Interlace/Non Interlace.
3. When the adjustment has been made, press P1 Button 1 to step back to the
olour Edit Test or P1 Start Button to return to the Main Test Menu screen.
DISPLAY TEST
Interlace check
Interlace mode
> Interlace
Previous Color
EXIT color edit
NEXT
EXIT
: P1-Button4
: P1-Button3
: P1-Button1
: P1-Start
Contrast
Bright R
Bright G
Bright B
: 150
: 100
: 100
: 100
Reset Colour Edit values to factory defaults
Colour Edit ON /OFF
Select next test pattern
Return to test menu screen

Page 20
6-2-5 Inp t Test
Select Input Test from the Main Test Menu. The following screen is displayed.
Each time a switch is operated, the corresponding item on the display will change
colour to red.
Note: When player utton 1 is pressed Shot 1 is indicated.
When player utton 2 is pressed Shot 2 is indicated
When player utton 3 is pressed Shot 4 is indicated
When player utton 4 is pressed Shot 5 is indicated
When testing is completed, press P1 Buttons 1 and 2 together to return to the
Main Test Menu screen.
INPUT TEST
COIN1: 0 0 0 COIN2: 0 0 0
EXIT : P1-Button1&2
To return to test menu screen
P1 Start switch
P2 Start switch
P1 8-direction lever
P2 8-direction lever
P1 Button switches
Service switch on
the cabinet
Coin signal count
(Default: 0)
1P
Start
Service
Up
Down
Left
Right
2P
Start
Service
Up
Down
Left
Right
P2 Button switches
DIPsw 1 : OFF 2 : OFF 3 : OFF 4 : OFF
DIP switches
Shot 1 Shot 2
Shot 3 Shot 4
Shot 5 Shot 6
Shot 1 Shot 2
Shot 3 Shot 4
Shot 5 Shot 6
