NAMCO BALL SPECTACULAR User manual

BALL SPECTACULAR MANUAL

．1．
This indicates risk that can lead to personal injury and/or property damage
1.
1.1.
1. SAFETY PRECAUTIONS
SAFETY PRECAUTIONSSAFETY PRECAUTIONS
SAFETY PRECAUTIONS
Before using this game,read the following safety precautions thoroughly and use the game
correctly.
Be sure to observe the safety instructions as they are important for ensuring safe operation
of the game.
This appliance is not intended for use by persons(including children)with reduced
physical,sensory or mental capabilities, or lack of experience and knowledge,unless they
have been given supervision or instruction regarding the use of theappliance by a person
responsible for their safety.
Children should be supervised while playing this game.
When opening or closing the glass door, support the glass with one hand and avoid
applying impact to the door during opening or closing. Careless handling of the glass
door can result in the pinching of your hand or the breakage of the glass causing
possible injury.
When moving the machine, exercise caution and do not push the glass section.
The glass us
ed on the game is tempered safety glass, but it can break if excessive
forceis applied, thus causing possible danger to yourself and people around the
machine.
Do not allow players to tilt, lift or drop the machine, or conduct any other improper
action. S
uch action may cause the machine to tip over or the glass to break,thus causing
danger to people around the machine.
When installing the machine, use the leg levelers to ensure that machine does not move
easily. lf the leg levelers are not adjusted proper
ly, the machine can move if a light
push is applied, thus causing possible danger to people around the machine.
Be careful not to pinch your fingers when adjusting the leg levelers.
The machine is very heavy. Do not place your hand under the machine.
Thi
s machine is for indoor use only. Never use the machine outdoors as rain or dust
can cause a short circuit or electric shock.
To prevent possible electric shock due to failure, this equipment MUST be fitted with
a securely connected GROUNDED plug.
Instal
l the power cord so that people cannot step on it or in such a way that could
present a trip hazard. Route it under other machines or where it could be crushed.
Do not unplug the power cord by pulling the cord, as could break internal wires and
cause electric shock.
Do not use power cord if it becomes damaged.
If internal wires are exposed, replace the cord immediately; otherwise, a short circuit
or electric shock can occur.
●
if you have to leave the machine unattended during maintenance or service, be sure
to close and lock the the glass door, coin door, and rear compartment door to prevent

．2．
people from getting injured by touching the inside of the machine.
● Never touch th
e slide unit or other drive system during operation. Moving parts
can pinch or injure your fingers.
●
When removing the rear compartment door, hold it carefully with both hands as it
is large and heavy. Be careful not to drop it on your feet.
2.
2.2.
2. SPECIFICA
SPECIFICASPECIFICA
SPECIFICATIONS
TIONSTIONS
TIONS
POWER SUPPLY: Rated voltage: AC 120/240 V
Rated frequency: 50/60 Hz
Rated power consumption: 400W (for indoor use only)
AMBIENT OPERATING +5゜C to +35゜C(41F -95F)
TEMPERATURE
DIMENSIONS: 915mm(w) x 1165mm(d) x 2555mm(h)
WEIGHT: 260kg
ACCESSORIES: Operation Manual;
Ball: (pink ball; white ball;
yellow;orange ball;);
power cord;
Keys: (Front Door)
(Coin compartment Door) Common Key (Redemption
Door)
(Cashbox)
Number acrylic;

．3．
3.
3.3.
3. TEARDOWN FOR TRANSPORTATION
TEARDOWN FOR TRANSPORTATIONTEARDOWN FOR TRANSPORTATION
TEARDOWN FOR TRANSPORTATION
3.1
3.13.1
3.1 ・・・
・・・・・・
・・・Jackpot Cascading Unit
Jackpot Cascading UnitJackpot Cascading Unit
Jackpot Cascading Unit
3.2
3.23.2
3.2 ・・・
・・・・・・
・・・Starting Gate
Starting GateStarting Gate
Starting Gate Unit
UnitUnit
Unit
3.3
3.33.3
3.3 ・・・
・・・・・・
・・・5Ball Gate Unit
5Ball Gate Unit5Ball Gate Unit
5Ball Gate Unit
Teardown this foam
Teardown here:
ironwork、preservative film
Teardown here:
ironwork、preservative film

．4．
4.
4.4.
4. Installation
InstallationInstallation
Installation of
of of
of LCD Box Unit
LCD Box UnitLCD Box Unit
LCD Box Unit
Top Tray 1pcs
Screw M4X12 8pcs
Top Tray 1pcs
Screw M4X12 8pcs
Pipe
OK
OKOK
OK

．5．
5.
5.5.
5. INSTALLATION
INSTALLATION INSTALLATION
INSTALLATION
Install the machine according to the instructions and procedures specified in this operation
manual. Failure to follow the specified procedures may result in a fire, electric shock, injury,
or machine malfunction.
Insert the power cord plug firmly into the
power outlet. Poor contact may cause overheating that
can lead to fire or burns.
Install the machine securely by using the level adjusters. Unstable machine installation can result
in accident or injury (See“Adjusting the Level Adjusters”)
Installation Conditions
Installation ConditionsInstallation Conditions
Installation Conditions
Locations to avoid
Locations to avoidLocations to avoid
Locations to avoid
 The machine is designed for indoor use. Never install the machine outdoors or
at any of the following locations:
● Place in direct sunlight
● Place exposed to rain or water leaks.
● Place where a water jet could be used.
● Damp place.
● Dusty place.
● Close to heating devices.
● Hot place.
● Extremely cold place.
● Place where moisture condensation may occur due to temperature differences.
● Place where the machine may become an obstruction in emergencies (such as
close to emergency exits ) and place where a fire extinguisher or similar
equipment is installed.
● Unstable place or location where vibrations are produced.

The quality of prizes may deteriorate, depending on installation conditions and prize
types.
＊
The temperature inside the upper doors can be much higher than the temperature of
the surrounding
area since the upper doors block ventilation and fluorescent lamps are
used to illuminate the prizes. If the machine is installed where it is exposed to direct
sunlight, the temperature inside the glass doors may become extremely high

．6．
6.
6.6.
6. Play Zone of Installed Machine
Play Zone of Installed MachinePlay Zone of Installed Machine
Play Zone of Installed Machine
● Set a play zone as shown below so that players can move away from the machine
without bumping into observers or passersby.
● Provide a space of at least 500mm(2 feet) between the machine and wall
or other machines. This space is necessary for maintenance and service.
Maintenance Zone
Play Zone

．7．
7.
7.7.
7. ACCESSORIES
ACCESSORIESACCESSORIES
ACCESSORIES LIST
LIST LIST
LIST
ITEM DESCRIPTION QY． PART No.
１ Key（9895） 2 310-680
２ Key （9888） 2 310-681
３ White Ball (25 pieces) 25 310-564
４ Pink Ball (25 pieces) 25 310-565
５ Yellow Ball (25 pieces) 25 310-566
６ Orange Ball (25 pieces) 25 310-567
７ Number acrylic (“1”) 4 310-621
8 Number acrylic (“3”) 6 310-617
9 Number acrylic (“10”) 8 310-618
10 Number acrylic (“20”) 2 310-622
11 Power cord 1 310-553
12 Operation Manual 1 310-682
13 Pipe 1
14 Top Tray 2
15 Screw M4x12 16
（※ Number acrylic (“2”) PART No.310-620 ）
（※ Number acrylic (“5”) PART No.310-619 ）
8.
8.8.
8. Adjusting the Level Adjusters
Adjusting the Level Adjusters Adjusting the Level Adjusters
Adjusting the Level Adjusters
Set the machine in the desired location and lower the Level Adjusters(two positions)so
that the casters are raised from the floor by approximately 5mm(1/4”)..Make sure that the
machine is level and does not shake.

．8．
9.
9.9.
9. Power switch and Ball
Power switch and BallPower switch and Ball
Power switch and Ball
・
・・
・Power switch
switch switch
switch
There are two power switches, one is on the
back and the other is inside of the service
door. Both of them need to be ON to operate
the game.
・
・・
・About the balls to use
About the balls to useAbout the balls to use
About the balls to use
* Use only attached balls.
* Operate the game with less than 100 balls. Too many
balls may cause ball jam.

．9．
10.
10.10.
10. How to Play
How to Play How to Play
How to Play
When a ball through number “ CHANNEL JAM”or 7SEG“ CHANNEL JAM”,the
ticket is dispensed directly to the player.
 After inserting the coin, a set of "Starting Gate Unit" will move from left to right
back & forth.Starting Gate Unit running;(If the Mercy Ticket has been set, the ticket
will come out at the set time.)
 When the "Drop Button" is flashing, you may operate "Drop Button".
 Aiming at the moving back-and-forth "5 Ball Gate Unit ", push the "DROP" button
within the time frame of 15 seconds.(5 seconds before the set time, the timer start
to count and the balls will drop when it is 0 second.)
 After the ball passes through "5 Ball Gate Unit", 5 balls will fall altogether
from the top "5 Ball Launcher Unit (5 Balls sticker).
 When the ball passes through the "Number Gate Unit" & "7seg Gate Unit", the number
of tickets shown on top will also be incremented
(When the player completes the current game and before the next game begins, the
ticket obtained from the previous game will be cleared.)
 When the ball passes through "Jackpot Gate Unit", the 50 balls accumulated at
"Jackpot Cascading Unit (jackpot sticker)" will fall down just like water falling
down from the waterfall.( The number of balls at "Jackpot Cascading Unit" can be
reset at the range from 30 balls to 60 balls with the multiple of 10 balls .)
 After most of the balls pass "Number Gate Unit" & "7seg Gate Unit", the number of
tickets shown on the timer will be increased.( When the player succeed the current
game and before the next game begins, the ticket obtained from the previous game
will be cleared; When the ball passes through "Jackpot Gate Unit", and when the
balls accumulated at "Jackpot Cascading Unit" do not reach the preset quantity;
these passed balls will be kept to be dropped with the other balls when the preset
required quantity of balls are collected.)
 After the "Starting Gate Unit" starts moving, the numbers on the left and right
of "7seg Gate Unit" can be confirmed (the settings can be adjusted)
 Coins can be inserted consecutively even it is in operation.
 If the ticket dispenser is out of tickets, the tickets that have been accumulated
previously will be replenished.

．10．
11.
11.11.
11. CHANGE OF SETTINGS & CONFIRMATION OF DATA
CHANGE OF SETTINGS & CONFIRMATION OF DATACHANGE OF SETTINGS & CONFIRMATION OF DATA
CHANGE OF SETTINGS & CONFIRMATION OF DATA
FUNCTION KEYS ILLUSTRATION:
FUNCTION KEYS ILLUSTRATION:FUNCTION KEYS ILLUSTRATION:
FUNCTION KEYS ILLUSTRATION:
①
①①
① ②
②②
② ③
③③
③ ④
④④
④
MAIN M
MAIN MMAIN M
MAIN ME
EE
ENU
NUNU
NU
BOOKKEEPING………………………………GAME RECORD
SETTING……………………………………CHANGE OF SETTING
TICKET PAYOUT SETTING
ERROR LOG…………………………………ERROR RECORDS（THE LATEST 10 RECORDS）
TICKETS PAY OUT LOG……………………TICKETING RECORDS（THE LATEST 30 RECORDS）
I/O TEST……………………………………INPUT/OUTPUT TESTING
Press button ② & ③ to move the cursor.
Press button ① to return to the game.
Press button ④ to enter each menu.

．11．
BOOKKEEPING
BOOKKEEPINGBOOKKEEPING
BOOKKEEPING MENU
MENU MENU
MENU
GAME COUNT …Number of games played. It will be updated when it is game over.
COIN COUNT …Number of coins inserted. It will be updated when a coin is inserted.
(Key in is not counted)
TICKETS PAYOUT …Number of tickets paid out.
TICKETS/COINS …Average number of ticket out per coin.
TICKET/GAMES …Average number of ticket out per game.
AVE. GAME TIME …Average amount of game time. It will be updated when the game is over.
5Balls GATE COUNT…Total count of ball passing through 5Balls GATE.
Jackpot GATE COUNT…Total count of ball passing through Jackpot GATE.
GATE PAY OUT Value ….Display of set value of gates.
GATE COUNT Value …Number of passing through of all gates.
Press button ① to return to the main menu

．12．
SETTING MENU
SETTING MENUSETTING MENU
SETTING MENU
Jackpot
JackpotJackpot
Jackpot…Number of JPs
Mercy Tickets
Mercy TicketsMercy Tickets
Mercy Tickets…Number of mercy tickets
Mode Switching
Mode SwitchingMode Switching
Mode Switching…Change of mode（Normal or Debug）
Coin Set Mode
Coin Set ModeCoin Set Mode
Coin Set Mode…Setup of coin in.
№
№№
№Gate PAY OUT Mode
Gate PAY OUT ModeGate PAY OUT Mode
Gate PAY OUT Mode…Setup of number gate payout.
When the ball enters the number gate, the player will get the scores displayed on the number
gate.
7
77
7-
--
-segment display PAY OUT Mode
segment display PAY OUT Modesegment display PAY OUT Mode
segment display PAY OUT Mode…Setup of 7-segment displayed number payout.
When the ball enters the 7-segment displayed number, which are right next to the Jackpot,
the player will get the payout which is exactly the number displayed on the 7-segment gate.
BGM
BGMBGM
BGM…On/off of background music.
Jackpot/7
Jackpot/7Jackpot/7
Jackpot/7-
--
-segment display
segment displaysegment display
segment display…When the ball enters the Jackpot/7-segment gates, the player
will get the payout exactly the same as the number shown on the Jackpot/7-setment display.
BOOKKEEPING(Data Initialization)
BOOKKEEPING(Data Initialization)BOOKKEEPING(Data Initialization)
BOOKKEEPING(Data Initialization)…Input password (1342) to reset to factory default.
Select “YES” to clear bookkeeping .
GATE COUNT(Data Initialization)
GATE COUNT(Data Initialization)GATE COUNT(Data Initialization)
GATE COUNT(Data Initialization)…Select “YES” to clear the number of passing through.
Coin Acceptor Type
Coin Acceptor TypeCoin Acceptor Type
Coin Acceptor Type…Select the mechanical type of coin acceptor or the electrical coin
acceptor.
Ticket Output
Ticket OutputTicket Output
Ticket Output… Normal（Ticket out based on the scores obtained）
Half
HalfHalf
Half …. Number of ticket out is the half of the total scores obtained, if it is an odd
number, it will be carried over.
Press button ② & ③ to move the cursor.
Press button ① to return to the main menu.
Press button ④ to change the set value.

．13．
TICKET PAY OUT SETTING
TICKET PAY OUT SETTINGTICKET PAY OUT SETTING
TICKET PAY OUT SETTING
●№Gate PA OUT Mode
A SETTING
10 5 10
10 5 5 10
10 5 10
10 5 5 10
20 20
B SETTING
10 3 10
10 3 3 10
10 3 10
10 5 5 10
10 10
C SETTING 【Default】
5 2 5
5 2 2 5
5 2 5
5 3 3 5
10 10
D SETTING
3 2 3
3 1 1 3
3 2 3
3 1 1 3
10 10
●Jackpot/7-segment display
90 SETTING
90 90 Max（Jackpot）
5 85 norma l（Jackpot）：Totai 90
70 SETTING
70 70 Max（Jackpot）
5 65 normal（Jackpot）：Totai 70
50 SETTING【Default】
50 50 Max（Jackpot）【Default】
5 45 normal（Jackpot）：Totai 50
30 SETTING
30 30 Max（Jackpot）
5 25 normal（Jackpot）：Totai 30
※normal(Jackpot)：at random Nu mber
●JACKPOT
SETTING
Number of JP
30
40
50
【Default】
60

．14．
★
★★
★RECOMMEND SETTING
A SETTING＋70 SETTING(Max）＋JACKPOT SETTING 50
⇒Average Tickets/GAME ：40
10 5 10
10 5 5 10
10 5 10
10 5 5 10
70 20 20 70 Max（Jackpot）
B SETTING＋50 SETTING(Max）＋JACKPOT SETTING 50
⇒Average Tickets/GAME ：30
10 3 10
10 3 3 10
10 3 10
10 5 5 10
50 10 10 50 Max（Jackpot）
C SETTING＋50 SETTING(Max）＋JACKPOT SETTING 50
⇒Average Tickets/GAME ：20【Default】
5 2 5
5 2 2 5
5 2 5
5 3 3 5
50 10 10 50 Max（Jackpot）
D SETTING＋30 SETTING(Max）＋JACKPOT SETTING 40
⇒Average Tickets/GAME ：10
3 2 3
3 1 1 3
3 2 3
3 1 1 3
30 10 10 30 Max（Jackpot）

．15．
Display of error log
Display of error logDisplay of error log
Display of error log
显示最新10笔故障记録
按键①回到主画面
按键④进入清除画面
选择 ES再按下 按键④清除 记録
TICKET PAYOUT LOG
TICKET PAYOUT LOGTICKET PAYOUT LOG
TICKET PAYOUT LOG
Display the latest 30 records of ticket out.
Press button ① to return to the main menu.
Move cursor to “CLEAR”and press button ④ to clear.
Select “YES” and to press button ④ to clear records.

．16．
INPUT/OUTPUT TESTING
INPUT/OUTPUT TESTINGINPUT/OUTPUT TESTING
INPUT/OUTPUT TESTING
TESTING DISPLAY：
IN RED… Starting up (ON)
IN YELLOW…No startup (OFF)
UP Sensor signal
MIDDLE On/off of allmotors and solenoid valve.
DOWN On/off of all LED lamps.
Press button ② & button ③ to move cursor.
Press button ① to return to the game.
Press button ④ to begin or end.

．17．
12.
12.12.
12. Error Messages
Error Messages Error Messages
Error Messages
ERR CODE ERR UNIT HOW TO RELEASE
01. TUBE BOTTOM JAM Long pipe bottom Bottom of ball-dispatching tube
got jammed
02. TUBE COUNT JAM Long pipe MID Middle of ball-dispatching tube
got jammed
03. 5BALL FAIRWAY JAM 5Ball Launcher Unit Insufficient or excessive balls at
5BALL position
04. SOLENOID A ERROR Solenoid error A (Ball jammed or sensor error)
05. SOLENOID B ERROR Solenoid error B (Ball jammed or sensor error)
06. PLAY SOLENOID ERROR Play solenoid error (Ball jammed or sensor error)
07. CHANNEL 01 JAM Channel jam 01 Channel jam 01 got jammed
08. CHANNEL 02 JAM Channel jam 02 Channel jam 02 got jammed
09. CHANNEL 03 JAM Channel jam 03 Channel jam 03 got jammed
10. CHANNEL 04 JAM Channel jam 04 Channel jam 04 got jammed
11. CHANNEL 05 JAM Channel jam 05 Channel jam 05 got jammed
12. CHANNEL 06 JAM Channel jam 06 Channel jam 06 got jammed
13. CHANNEL 07 JAM Channel jam 07 Channel jam 07 got jammed
14. CHANNEL 08 JAM Channel jam 08 Channel jam 08 got jammed
15. CHANNEL 09 JAM Channel jam 09 Channel jam 09 got jammed
16. CHANNEL 10 JAM Channel jam 10 Channel jam 10 got jammed
17. CHANNEL 11 JAM Channel jam 11 Channel jam 11 got jammed
18. CHANNEL 12 JAM Channel jam 12 Channel jam 12 got jammed
19. CHANNEL 13 JAM Channel jam 13 Channel jam 13 got jammed
20. CHANNEL 14 JAM Channel jam 14 Channel jam 14 got jammed
21. CHANNEL 15 JAM Channel jam 15 Channel jam 15 got jammed
22. CHANNEL 16 JAM Channel jam 16 Channel jam 16 got jammed
23. CHANNEL 17 JAM Channel jam 17(JP gate) Channel jam 17(JP gate) got
jammed
24. CHANNEL 18 JAM Channel jam 18 Channel jam 18 got jammed
25. CHANNEL 19 JAM Channel jam 19 Channel jam 19 got jammed
26. 5BALL POSITION JAM Divide Unit (5BALL) Track jam (5BALL)
27. JP POSITION JAM Divide Unit (JP) Track jam (JP)
28. PLAY POSITION JAM Divide Unit (PLAY) Track jam (PLAY)
29. 5BALL CHANNEL JAM 5Ball Gate Unit 5BALL channel jam
30. COIN ACCEPTOR JAM Coin acceptor Coin acceptor jam
31. TICKET EMPTY Coin /Redemption Door
Unit
No ticket out
32. TICKET JAM Coin /Redemption Door
Unit
Ticket jam
33. JP GATE MOTOR ERR. Jackpot Gate Unit Motor not working or sensor error
at JP GATE
34. PLAY STEP MOTOR ERR. Starting Gate Unit Step motor not working or sensor
error at play
35. 5BALL STEP MOTOR ERR. 5Ball Gate Unit Step motor not working or sensor
error at 5BALL GATE
36. JP FALL MOTOR ERR. Jackpot Cascading Unit Motor not working or sensor error

．18．
occurred at dropping balls when
hitting JP.
37. 5BALL FALL MOTOR ERR. 5Ball Launcher Unit Motor not working
38. HOPPER ERROR Hopper Unit Motor for dispatching balls not
working or sensor error occurred
39.Play CHANNEL sensor ERR Play CHANNEL Play CHANNEL JAM
13.
13.13.
13. DISCARDING THE MACHINE
DISCARDING THE MACHINE DISCARDING THE MACHINE
DISCARDING THE MACHINE
●
The machine must be collected, transported and discarded in accordance
with the local laws and regulations.
● When entrusting a third party to collect, transport and discard the
machine, be sure to use specialist companies to perform the task.
● Compliance with WEEE regulations
The machine must be collected, transported and discarded in
accordance with the local laws and regulations.
When entrusting a third party to collect, transport and discard the
machine ensure that they are authorized to do so.
● The software used in this game machine is protected by copyright
laws.
It is forbidden to copy, adapt, distribute publicly, or use the
software for purposes other than the operation of this machine.
Infringement of the copyright laws may subject persons to criminal
penalties.
Do not use the recording media containing the software in a machine
other than the specified game machine. Doing so can result in
equipment malfunction.

．19．
14.
14.14.
14. Assembly description
Assembly description Assembly description
Assembly description
14.1
14.114.1
14.1 ・・
・・・・
・・Cabinet
CabinetCabinet
Cabinet
ITEM DESCRIPTION QY． PART No.
１ LCD Box Unit 1
２ Divide Unit 1
３ Jackpot Cascading Unit 1
４ Starting Gate Unit 1
５ 5Ball Gate Unit 1
６ 5Ball Launcher Unit 1
７ Number Gate Unit 16
８ 7seg Gate Unit 2
９ Jackpot Gate Unit 1
10 Hopper Unit 1
11 Coin /Redemption Door Unit 1
12 Power Supply Unit 1
13 PC Box Unit 1
1
11
1 2
22
2
3
4
5
6
4
5
6
8
7
9
9
12
10
11
13
