NAMCO ACE DRIVER DELUXE Guide

Part No. 90500031
ACE DRIVER
DELUXE
Installation and Commissioning
Manual
ITIS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN
CUSTOMER SAFETY AT ALL TIMES, AND IT IS IMPERATIVE THAT
THE DETAILS SET OUT IN THIS MANUAL ARE FOLLOWED PRECISELY.

© 1994 Ltd - all rights reserved.
Published by:
BRENT LEISURE Ltd.
Unit 1 Brent Crescent,
London. NW10 0QT
Phone:- 0181-965-0550
Fax:- 0181-961-0574
No part of this publication may be reproduced by any mechanical, photographic or electronic
process, or in the form of phonographic recording, nor may it be stored in a retrieval system,
transmitted or otherwise copied for public or private use, without permission from Ltd.
While the information contained in this manual is given in good faith and was accurate at the
time of publication, BRENT LEISURE LIMITED reserve the right to make changes and
alterations without notice.
This machine has been manufactured in accordance with European Community directives (1st.
January 1995), and as such bears the marking. Any changes or modifications to this
machine must be in accordance with European Community directives (1st. January 1995).
If you make any unauthorised changes to this product, you may contravene European
Community directives (1st. January 1995)

This machine is designed for indoor use only. Do not install the machine in the following places.

SAFETY WARNING
In Order to Use This Machine Safely
In order to use this machine safely, be sure to read this Installation and
Commissioning manual and the Operators Manual carefully before installation and use
of the machine.
Whenever the owner of this machine entrusts disassembly, installation, adjustment,
routine maintenance or trouble shooting to another person, the owner should ensure
that they read the appropriate precautions and relevant sections of this manual before
starting work.
In order that no accidents occur when the machine is in operation, strictly
follow the notes on safety described below.
Do not turn the machine ON until it has been correctly installed.
Warnings for Operation
NOTE: Only operate this machine after checking that it has been installed correctly
in accordance with this Installation and Commissioning manual.
NOTE: Parts of this machine move during game play, so there are places where the
distance between the stationary section and moveable section changes.
There are warning stickers to keep hands and feet clear of moving parts,
however if the operator feels that a customer playing the game is in any
danger, he should warn the customer accordingly.
NOTE: The warning stickers must always be kept in good condition and replaced if
worn so that the customer can read them clearly.
NOTE: If there is an error or problem with this machine, operation must be
stopped immediately.
Warnings for Disassembly, Installation, Routine Maintenance and Troubleshooting
DANGER: Namco Ltd. bears absolutely no responsibility for accidents or injuries
resulting from unauthorized changes to the machine.
DANGER: Ensure that the machine has been turned OFF before making adjustments
or carrying out maintenance. Also ensure only qualified personnel carry out
maintenance or turn the power ON to this machine.
DANGER: The power supply and inside the monitor will remain hot and have areas of
high voltage even though the machine has been turned OFF, and there is a
possibility of burns or electric shock. Be careful not to touch these areas.
DANGER: In order to avoid injuries due to mis-operation, be sure that the voltage of the
power supply is within the prescribed limits. Also to prevent possible electric
shocks due to failure, this machine MUST be fitted with a securely
connected earthed plug.
NOTE: Do not turn the main power switch ON until the machine has been installed
correctly.

Contents
1. INSTALLATION........................................................................................... 7
1-1 Installing the SignAssembly .................................................................................. 8
1-2 Installing the Sign Boards (L), (R) .........................................................................9
1-3 Connecting the Seat Assemblies to the Tower Assembly ................................... 10
1-4 Removing the Shipping Brackets ........................................................................12
1-5 Installing the Guard Fence................................................................................... 14
1-6 Applying the Number Stickers.............................................................................. 15
1-7 Linking Two or More Machines. ........................................................................... 16
1-7-1 Setting the Link Switches ...................................................................... 17
2 ADJUSTMENTS ....................................................................................... 18
2-1 Turning on the Power .......................................................................................... 18
2-2 Adjustment Switches...........................................................................................18
2-3 TestMode ............................................................................................................ 19
2-3-1 Coin Options.......................................................................................... 20
2-3-2 Game Options...................................................................................... 21
2-3-3 I/O Test .................................................................................................. 23
2-3-4 Switch Test ............................................................................................ 24
2-3-5 MotorTest .............................................................................................. 25
2-3-6 Motion StopTest .................................................................................... 25
2-3-7 Lamp Test..............................................................................................26
2-3-8 LED Test................................................................................................26
2-3-9 Sound Test ............................................................................................ 27
2-4 Adjustments When Replacing Parts (Initialization) ............................................. 28
3. DISASSEMBLY ......................................................................................... 29
3-1. Removing the MonitorAssy (L), (R)..................................................................... 30
3-2 Disassembling the Upper Seat Assy from the Seat Base Assy ..........................31

1. INSTALLATION
Notes on installation
DANGER: NEVER turn the power to the machine ON until installation has been
completed.
DANGER: In order to avoid injury or damage to the machine due to mis-operation,
ensure that the voltage of the mains in supply is 220-240volt AC. Also,
in order to prevent possible electric shocks, be sure that the machine is
connected to the mains in supply with a securely connected earthed
plug.
NOTE: When installing the machine, in order to maintain customer safety, be
sure to attach the supplied rear fence and safety warning mats.
NOTE: In order to prevent customer injury when the machine is being played,
make sure that the space between the side of the machine and a wall
or other machine is at least 30cm.
NOTE: In order that the PCB rack or power supply can be removed for service,
make sure that the rear of the machine is separated from a wall or other
machine by a distance of at least 50cm.
[NOTE]
The shipping brackets that are removed during installation will be required
to be refitted for moving, shipping, and for maintenance when the drive
castor is worn. They should be stored safely and not lost or thrown away.
Page 1

Page
1-1 Installing the Sign Assembly
For your convenience, the sign assembly has already been fitted to the tower unit.
NOTE: The weight of the Sign Assembly (not including the sign board) is 32kg. The
centre of gravity of the Sign Assembly is to the front , making it unstable, and
as assembly involves lifting the Sign Assembly above head height, at least
two people should be used to install the Sign Assembly.
1) Remove the two security screws (M5x12), and remove the harness cover.
2) Make sure that there are no wires or connectors on top of the main tower assy. If
there is, drop them in to the tower.
3) NOTE: The Sign Assembly is unstable. Ensure that one person maintains the
balance of the sign assembly during installation.
4) Place the Sign Assembly on top of the tower, making sure that the Sign
Assembly is forward of the tab at the top rear of the tower. Centre the Sign
Assembly left to right and push the assembly back until the base board engages
in to the tab.
5) Using the four hex head bolts (M10x30) and washers supplied, secure the Sign
Assembly to the main tower assembly.
6) Feed the harness through from the tower assembly and connect the connectors.
Refit the harness cover using the two security screws (M5x12) removed in step 1.
2

Page
1-2 Installing the Sign Boards (L), (R)
The overall height of the machine can be adjusted by altering the position at which the
sign boards are fitted.
Normal Height (Total height: 2,200mm)
1) Bring the Sign Boards (L), (R) close to the fixing position, and connect the
connectors.
2) Hang the Sign Boards (L) (R) on the side joints (L) (R).
3) Slide the Sign Boards (L) (R) to the back, and fasten to the cabinet using two
security screws (M6x20).
Lower Height (Total height: 2,140mm)
1) Remove the two hex head screws (M6x20), and remove the side joints (L) (R).
2) Turn the side joint top to bottom, and refit the side joint using the lower two of the
three fixing holes.
3

Page
1-3 Connecting the Seat Assemblies to the Tower Assembly
1) Insert the seat assembly from the side of the tower unit so that the front legs of
the tower unit are underneath the seat assembly.
2) Remove the four security screws (M5x12) from the bottom front of the tower unit,
and remove the lower front cover (F). Temporarily fasten the seat unit with two
hex head bolts (M10x25), flat washers and safety washers. (Do not tighten)
3) Remove the four security screws (M5x12) from the bottom rear of the tower unit,
and remove the lower rear cover (S). Temporarily fasten the ride unit with four
hex head bolts (M10x25), flat washers and security washers.
4) Tighten all of the hex head bolts (M10x25).
5) Connect the connectors between the seat assembly and tower unit.
6) Connect the other seat assembly in the same way.
7) Replace the front and rear covers (F), (S) taking care not to trap or pinch any
wiring.
[NOTE]: When connecting the seat asseblies to the tower unit take care not to
trap any wires.
4

Page
8) Insert the front rubber brackets (L), (R) of the tower unit in the side panel of the
seat assembly, and fasten them with two security screws (M5x16) and two
No6X½" pozi flange head screws.
9) Remove the five security screws (M5x16) from the tower side support.
10) Fit the rear safety rubbers to the tower unit with the retaining bracket and the five
security screws (M5x16) previously removed from the tower side support.
11) Place the left, centre, and right safety warning mats in their correct positions.
12) When the machine is in its final location, lower the level adjusters (17 adjusters)
with a spanner so that all castors are raised from the floor.
13) Tighten the lock nuts with a spanner to ensure that the level adjusters not move.
5

Page
1-4 Removing the Shipping Brackets
NOTE: Store the removed shipping brackets in a safe place as they must be refitted
when replacing the drive castor, when shipping, or when moving the machine.
1) Remove two hex head bolts (M8x20) from each rear shipping bracket, and
remove the brackets. Retain the four hex head bolts (M8x20) that were used to fit
the shipping bracket for future use.
2) Slacken two security screws (M10x30), and remove two heax head bolts (M8x20)
from each front shipping bracket, and remove the brackets. Re-tighten the four
security screws (M10x30).
6

Page
After removing the shipping brackets, install the supplied safety rubber skirt (D) and
skirt stay (F) to the upper base assembly as described below.
NOTE: The safety rubber skirt is to prevent hands or feet being trapped by the
moving parts. Be sure to install the safety rubber skirts.
1) The safety rubber is installed on the outside of each seat assembly. i.e.on the left
of the left hand seat and on the right of the right hand seat.
2) Install the safety rubber and skirt stay using three security screws (M5x20).
NOTE: Ensure that the gap between the bottom of the skirt and the cover plate is no
greater than 1.5mm.
7

Page
1-5 Installing the Guard Fence
1) Fasten the guard fence with two retaining plates and security screws (M8x20),
flat washers, and security washers.
2) Fit the extension brackets (R),(L) to the seat base using six security screws
(M8x20), spring washers, and flat washers on each. Ensure that the angles of the
extension bracket match the angles of the extensions fitted to the seat bed.
8

Page
1-6 Applying the Number Stickers
Apply the racing number stickers to the seats and sign boards as shown below.
The team colours and car numbers should match those shown in the following table.
[NOTE]: Ensure that the numbers on the screen match the sticker numbers.
The "TEAM COLOURS" can be checked in the "Test Mode" - "Setting the
Game Options". (page 14)
TEAM COLOUR RED 25 BLUE 3 YELLOW 17 GREEN 11
R
Team Colour Red Blue Yellow Green
Car Number 25 317 11
9

Page
1-7 Linking Two or More Machines.
Up to four machines (8 seats) can be linked together.
The machines should be linked as described below.
NOTE: Each machine can draw up to 8 amps. Make sure that the power supply
is adequate.
1) Ensure that
the power is
“OFF”.
2) Loosen the
two screws
(M4x10) on
the back of
the tower
assy, and
remove the
connector
cover.
3) Set the link switches to “ON” , “EXT”,
and “ON”. (See Diag.)
4) Use the supplied link cable and
connect the machines between “IN”
and “OUT” sockets (See Diag.)
[Examples of Linked Machines]
a) 2 Machines
(4 Seats)
b) 3 Machines
(6 Seats)
c) 4 Machines
(8 Seats)
5) Turn the power to each machine “ON”, and set the PCB ID using the test mode.
(Refer to “Setting the Game Options”).
Note: Settings other than those described will cause the machine to operate
incorrectly.
10

Page
1-7-1 Setting the Link Switches
The link switches are used to set the connection between seats and machines.
1). Setting only one machine (2 seats)
Set the link switches to “ON”, “INT”, and “ON”.
Note: Do not use a link cable.
2) Setting two or more machines.
Setthe link switchesto “ON”,“EXT”, and“ON”.
3) Install the connector cover using
the two screws (M4x10).
The link procedure is now complete.
4) Setting for faulty PCB.
If the game PCB of only one side is faulty, set the link on that side to “OFF”
[Example of setting for faulty left side]
11

Page
2 ADJUSTMENTS
2-1 Turning on the Power
After the machine has been correctley installed, turn ON the power.
The Power switch is located next to the IEC power inlet socket on the rear of the
tower unit
2-2 Adjustment Switches
The adjustment switches are located inside the coin door.
1. Service Switch
Press this switch to obtain game credits without incrementing the play meters.
2. Test Switch
Slide this switch “ON” to enter test mode.
Test mode allows game testing and the changing of game settings. (Refer to
section 2-3 “Test Mode” (page 13).)
12

Page
2-3 Test Mode
1. Open the coin door and slide the test switch “ON”. The “Menu Screen” will be
displayed on the monitor.
2. Select the test required by moving the shift lever up or down. The colour of
the selected test will change.
3. Enter the selected test by stepping on the accelerator. Select “EXIT” to return
to the “Menu Screen” (step on the accelerator when using the monitor test
screen).
4. After testing is completed, ensure that the test switch is returned to the “OFF”
position to return to game mode.
The Test Switch must always be in the “OFF” position for normal game mode.
MENU
COIN OPTIONS-------(1)Sets the price of play. (See2-3-1)
GAME OPTIONS-------(2)Sets the game options.(See 2-3-2)
I/O TEST ------- (3) Used for testing the switches and motor.
-------(See 2-3-3)
MONITOR TEST ------- (4) Used for adjusting the monitor.
SOUND TEST ------- (5) Used for adjusting the speaker volume.
-------(See 2-3-9)
ADS DATA ------- (6) Displays the accumulated game data.
OTHERS ------- (7) Used for testing the PC boards and for
------- initializing all of the settings.
GAS: ENTER SHIFT: CHOOSE
13

Page
2-3-1 Coin Options
a. Select item (1)
“COIN OPTIONS”
on the menu screen,
to set the game cost
and related settings.
b. Use the shift lever to
select the required
item then step on
the accelerator.
c. Use the shift lever to
change the settings
then step on the
accelerator to store
the new values.
d. Select “EXIT” to
return to the menu
screen.
Note:- The price of play on this machine is set within the Cashflow Coin Mech. Ensure that the
Coin Options on the screen are set as shown in the following table.
COIN OPTIONS [DEFAULT IN GREEN]
GAME COST
1 COIN 1 CREDIT ........... (a)
COIN1 MECH VALUE
1 COIN COUNT AS 1 COIN ........... (b)
COIN MECH 2 VALUE
1 COIN COUNT AS 1 COIN ........... (c)
BONUS FOR QUANTITY BUY IN
NONE ........... (d)
FREE PLAY
OFF ........... (e)
EXIT
GAS: ENTER SHIFT: CHOOSE
METISTNETNOCYROTCAF TES
tsoCemaG)a( 9-1elbattes------tiderc1rofderiuqersnioC1
eulaVhceM1nioC)b( 9-1elbattes------niocrepretemnoseslupforebmuN1
eulaVhceM2nioC)c( 9-1elbattes------niocrepretemnoseslupforebmuN1
nioCsunoB)d(nisniocdeificepstaeslupniocartxEENON
yalPeerF)e( oN/seY------rotareleccagnisserpybdetratsemaGON
14

Page
2-3-2 Game Options
a. Select item (2) “GAME
OPTIONS” on the
menu screen to set the
game options.
b. Use the shift lever to
select the required
item then step on the
accelerator.
c. Use the shift lever to
change the settings
then step on the
accelerator to store the
new values.
d. Select “EXIT” to return
to the menu screen.
Note: Race Class (c) must
be set first before
changing items (d),
(e), or (f).
GAME OPTIONS [DEFAULT IN GREEN]
PCB ID NUMBER ................. (a)
TEAM COLOUR BLUE 3 ................. (b)
RACE CLASS BEG EXP PRO ................. (c)
DIFFICULTY B B B ................. (d)
LAPS [LINK] 3 3 4 ................. (e)
LAPS [SOLO] 3 3 4 ................. (f)
SPEED DISPLAY KM/H ................. (g)
SOUND IN ATTRACT ON ................. (h)
EXIT
GAS: ENTER SHIFT: CHOOSE
NOTES
•The rank (level of difficulty) and number of laps must be set the same on all
positions that are linked.
•The PCB number of the seat furthest left (when facing the front of the machine)
should be set to 1, and the other seats set to 2, 3, 4 and so on in order from left to
right. The PCB number of the farthest right position should equal the number of
positions linked.
•Settings other than those described will cause the machine to operate incorrectly.
15
