NAMCO PAC-MAN BATTLE ROYALE User manual

PAC-MAN BATTLE ROYALE
OPERATION MANUAL

To ensure safe operation of the game machine, be sure to read this Operation Manual before use.

Keep this Operation Manual in a safe place for quick access whenever needed.
The actual product may differ slightly from the illustrations in this manual.
Specications of the machine and contents of this operation manual are subject to change without prior notice due to product improvements.
WARNING
PAC-MAN BATTLE ROYALE
Operation Manual
Part No. PG45-13396-00
First Edition Published in January 2011
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

INTRODUCTION
Thank you for purchasing the “PAC-MAN BATTLE ROYALE” game machine (hereinafter referred to as the
“machine”).
This operation manual describes:
●Howtoinstall,operate,relocate,transport,service,anddiscardthemachinesafely
and properly
●Howtooperatethemachinecorrectlyandmakefulluseofitsfeatures
●Howtoensurethesafetyofplayersandbystanders
Inquiries regarding this machine and its repair
●Forfurtherinformationaboutthemachineanditsrepair,contactyourdistributor.
Thesoftwareincludedinthemachineisprotectedbycopyrightlaws.Thesoftwaremaynot
becopied,modied,distributedpublicly,orusedforpurposesotherthantheoperationofthis
gamemachine.Violatorsofcopyrightlawsmaybesubjecttocriminalpenalties.Donotuse
thestoragemediacontainingsoftwareinanyothergamemachine;doingsomaycausethat
machine to malfunction.
Thismachineusesthefollowinglicenses.
Fontsusedin-gameareprovidedbyBitstreamInc.Allrightsreserved.
Copyright©1997-2002,MakotoMatsumotoandTakujiNishimura,Allrightsreserved.
Redistributionanduseinsourceandbinaryforms,withorwithoutmodication,arepermitted
providedthatthefollowingconditionsaremet:
1.Redistributionsofsourcecodemustretaintheabovecopyrightnotice,thislistofconditions
andthefollowingdisclaimer.
2.Redistributionsinbinaryformmustreproducetheabovecopyrightnotice,thislistof
conditionsandthefollowingdisclaimerinthedocumentationand/orothermaterialsprovided
withthedistribution.
3.Thenamesofitscontributorsmaynotbeusedtoendorseorpromoteproductsderivedfrom
thissoftwarewithoutspecicpriorwrittenpermission.
THISSOFTWAREISPROVIDEDBYTHECOPYRIGHTHOLDERSANDCONTRIBUTORS
“ASIS”ANDANYEXPRESSORIMPLIEDWARRANTIES,INCLUDING,BUTNOT
LIMITEDTO,THEIMPLIEDWARRANTIESOFMERCHANTABILITYANDFITNESSFOR
APARTICULARPURPOSEAREDISCLAIMED.INNOEVENTSHALLTHECOPYRIGHT
OWNERORCONTRIBUTORSBELIABLEFORANYDIRECT,INDIRECT,INCIDENTAL,
SPECIAL,EXEMPLARY,ORCONSEQUENTIALDAMAGES(INCLUDING,BUTNOT
LIMITEDTO,PROCUREMENTOFSUBSTITUTEGOODSORSERVICES;LOSSOFUSE,
DATA,ORPROFITS;ORBUSINESSINTERRUPTION)HOWEVERCAUSEDANDON
ANYTHEORYOFLIABILITY,WHETHERINCONTRACT,STRICTLIABILITY,ORTORT
(INCLUDINGNEGLIGENCEOROTHERWISE)ARISINGINANYWAYOUTOFTHEUSE
OFTHISSOFTWARE,EVENIFADVISEDOFTHEPOSSIBILITYOFSUCHDAMAGE.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Test mode Troubleshooting
Magnitudes of risk/Denition of “technician”
1
1. SAFETY PRECAUTIONS
– Be sure to read this section before installing or operating the machine. –
Instructions to the owner
If you entrust another party to perform installation, operation, relocation,
ztransportation, service, or discarding of the machine, instruct the concerned party
to read and observe all the instructions and precautions in this operation manual
regarding the particular action to be taken.
1-1 Magnitudes of risk
On the labels attached to the machine and in this operation manual, precautions
regarding safety and property damage are classied as shown below in accordance
with the magnitude of the particular risk.
WARNING
: Failure to avoid the indicated risk may result in
death or serious injury.
CAUTION
: Failure to avoid the indicated risk may result in
minor injury or property damage.
Notes related to machine functions but not to safety are marked with the following
indication.
● Note related to product function or protection.
1-2 Denition of “technician”
This operation manual is written for arcade personnel. However, the sections marked “To
be conducted by a technician only” in the table of contents are written for technicians.
These tasks should be conducted by technicians only.
Technician:A person engaged in machine design, manufacture, inspection or
service for a manufacturer of amusement equipment, or a person who
has technical knowledge related to electricity, electronics or mechanical
engineering at a level equal to or higher than that of a technical high
school graduate and who is engaged routinely in the service and
management (including repair) of amusement machines.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

1. SAFETY PRECAUTIONS
2
1-3 Critical safety precautions
WARNING
Should any abnormality occur, turn off the power switch immediately to stop

operating the machine. Then, unplug the power cord plug from the AC outlet.
Operating the machine without correcting abnormalities can result in a fire or
accident.
Some monitor sections remain hot or charged with high voltage even after the power

switch is turned off. Do not touch the monitor unnecessarily in order to avoid electric
shock and burns.
Dust accumulated on the power cord plug may cause a re. Check the power cord

plug regularly and remove dust.
Insert the power cord plug firmly into the AC outlet. Poor contact may cause

overheating that can lead to a re or burns.
A damaged power cord can cause a re, electric shock or electrical leakage. Observe

the following cautions.
Keep the power cord away from heating devices.•
Do not twist the power cord.•
Do not bend the power cord forcibly.•
Do not alter the power cord.•
Do not bundle the power cord.•
Do not pull the power cord. (Always unplug by holding the power cord plug, and •
avoid pulling the power cord.)
Do not place anything on the power cord.•
Do not allow the power cord to be caught under or between the machine, other •
equipment or the wall.
Do not do anything else that might damage the power cord.•
Do not wet the power cord or power cord plug with water. Water can cause an electric

shock or electrical leakage.
Do not touch the power cord plug with a wet hand. Doing so can result in an electric

shock.
The machine’s rated power supply voltage and maximum consumption current are

120 V AC, 2 A, respectively. To prevent re and electric shock, be sure to use interior
wiring that conforms to these power supply specications.
Operate the machine with a power supply voltage in the range of 104 to 127 V AC.

Operating the machine with a supply voltage outside the specied range may cause
a re or electric shock. To ensure that the machine operates in optimum condition,
maintain the power supply at 120 V AC.
To ensure safe operation of the machine, be sure to conduct the pre-service check

(See P. 15 “7-1 Pre-service check”) and service (See P. 44 “8B. SERVICES”) described
in this manual. Failure to conduct the pre-service check or service can result in an
accident.
Use consumables and service parts (including fasteners) specied by our company.

To order parts, contact your distributor.
Do not convert the machine without permission. Do not perform any work that is not

described in this operation manual. Unauthorized conversion of the machine may
create unforeseen hazards.
When transferring ownership of the machine, be sure to provide this operation

manual with the game machine.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

1. SAFETY PRECAUTIONS
Test mode Troubleshooting
Critical safety precautions/ Description of warning labels attached to the machine
3
1-4 Description of warning labels attached to the machine
WARNING
The warning labels describe important safety precautions. Be sure to observe the

following:
To ensure that the warning labels attached to the machine are easily legible, install •
the machine at an appropriate location with ample illumination and keep the labels
clean at all times. Also, make sure that the labels are not hidden behind another
game machine or other objects.
Do not remove or alter the warning labels.•
If the warning labels become excessively dirty or damaged, replace them with new •
labels. To order warning labels, contact your distributor.
Warning labels
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

4
CONTENTS
INTRODUCTION
1. SAFETY PRECAUTIONS
– Be sure to read this section before installing or operating the machine. –.....................................................................1
1-1 Magnitudes of risk...........................................................................................................................................1
1-2 Denitionof“technician” .................................................................................................................................1
1-3 Criticalsafetyprecautions...............................................................................................................................2
1-4 Descriptionofwarninglabelsattachedtothemachine ..................................................................................3
2. SPECIFICATIONS...................................................................................................................................... 6
3. PACKAGE CONTENTS............................................................................................................................. 8
4. OVERALL CONSTRUCTION (Names of Parts)....................................................................................... 9
5. INSTALLATION.........................................................................................................................................10
5-1 Installationconditions ...................................................................................................................................10
5-1-1 Locationstoavoidwheninstallingthemachine..................................................................................10
5-1-2 Playzoneforinstalledmachine..........................................................................................................11
5-2 Requireddimensionsforbringingthemachineinside(suchasdoorsandcorridors) ..................................11
6. MOVING AND TRANSPORTING.............................................................................................................12
6-1 Moving(ontheoor).....................................................................................................................................12
6-2 Transportation...............................................................................................................................................13
6-2-1 Manualtransportation(carryingonstairs,etc.) ..................................................................................13
7. OPERATION..............................................................................................................................................14
7-1 Pre-servicecheck .........................................................................................................................................15
7-1-1 Safetycheck(beforepowerON) ........................................................................................................15
7-1-2 Operationcheck(afterpowerON)......................................................................................................16
7-2 Explanationofthepowerswitchandadjustmentswitches...........................................................................17
7-2-1 Turningthepowerswitchon...............................................................................................................17
7-2-2 Adjustmentswitchesandbuttons .......................................................................................................18
7-3 HowtoplayPAC-MANBATTLEROYALE....................................................................................................19
7-3-1 Gamerules.........................................................................................................................................19
7-3-2 HowtocontrolyourPac-Man .............................................................................................................19
7-3-3 Itemsandastrategyinthemaze........................................................................................................19
7-3-4 STARTbutton.....................................................................................................................................20
7-4 Testmode .....................................................................................................................................................21
7-4-1 Descriptionofthemenuscreen(MENU)............................................................................................21
7-4-2 Gamefeesettings(COINOPTIONS).................................................................................................22
7-4-3 Gamedetailsettings(GAMEOPTIONS)............................................................................................24
7-4-4 Switch/sensortest(I/OTEST) ............................................................................................................25
(1) SWITCHTEST..............................................................................................................................26
(2) OUTPUTTEST.............................................................................................................................27
7-4-5 Monitorconditiontest(MONITORTEST)...........................................................................................28
7-4-6 Soundadjustment(SOUNDTEST) ....................................................................................................29
7-4-7 Gamedatadisplay/initialization(BOOKKEEPING).............................................................................30
(1) ERRORLOG ................................................................................................................................31
7-4-8 Initializationandothersettings(OTHERS) .........................................................................................32
(1) CLOCKSETTING.........................................................................................................................33
(2) BACKUPMEMORYINITIALIZE ...................................................................................................34
7-5 Errordisplay(forthearcadeoperator)..........................................................................................................35
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Test mode Troubleshooting
CONTENTS
5
8A. ASSEMBLY AND SETUP – To be conducted by a technician only –.......................................................................36
8A-1Assembly ......................................................................................................................................................36
8A-1-1 Securingthemachineusingleveladjusters .......................................................................................36
8A-1-2 Removingandattachingthesideservicedoor ..................................................................................36
8A-1-3 AttachingtheSignboardassembly.....................................................................................................37
(1) Attachingthesignboardpillar........................................................................................................37
(2) Attachingthesignboard ................................................................................................................39
8A-2Disassemblyforpassingthroughanarrowcorridor .....................................................................................41
8A-2-1 RemovingtheMiddleBoxassemblyfromtheUnderBoxassembly ..................................................41
8B. SERVICES – To be conducted by a technician only –...................................................................................................44
8B-1Inspectionsandservices ..............................................................................................................................44
8B-1-1 Inspectionitems..................................................................................................................................44
8B-2Troubleshooting............................................................................................................................................45
8B-2-1 General...............................................................................................................................................46
8B-2-2 MiddleBoxassembly..........................................................................................................................46
8B-2-3 UnderBoxassembly ..........................................................................................................................46
8B-2-4ControlPanelassembly......................................................................................................................47
8B-2-5Signboardassembly...........................................................................................................................47
8B-3Errordisplay(forthetechnician)...................................................................................................................48
8B-4Assemblyanddisassemblyofthemachine..................................................................................................49
8B-4-1TopBoardassembly...........................................................................................................................49
(1) RemovingandattachingtheTopBoardassembly........................................................................49
(2) Replacingthemonitorglass..........................................................................................................51
8B-4-2MiddleBoxassembly..........................................................................................................................52
(1) ReplacingtheLCDmonitor...........................................................................................................52
8B-4-3UnderBoxassembly ..........................................................................................................................55
(1) ReplacingtheMAINPCB .............................................................................................................55
(2) ReplacingthebackupbatteryontheMAINPCB..........................................................................56
(3)ReplacingtheI/OPCB..................................................................................................................57
(4)ReplacingtheA.I.PCB.................................................................................................................58
(5)ReplacingtheAMPPCB...............................................................................................................59
(6)Replacingthepowersupply..........................................................................................................60
8B-4-4ControlPanelassembly......................................................................................................................61
(1) RemovingandattachingtheControlPanelassembly ..................................................................61
(2) Replacingthejoystick ...................................................................................................................62
(3)ReplacingtheilluminatedswitchanditsLEDlamp.......................................................................63
8B-4-5Signboardassembly...........................................................................................................................64
(1) Replacingtheuorescentlamp.....................................................................................................64
9. DISPOSAL OF THE MACHINE...............................................................................................................65
10. PARTS LISTS......................................................................................................................................... 66
10-1 TopBoardassembly .....................................................................................................................................66
10-2 MiddleBoxassembly....................................................................................................................................67
10-3 UnderBoxassembly.....................................................................................................................................68
10-4 ControlPanelassembly................................................................................................................................70
10-5 Signboardassembly .....................................................................................................................................71
11. WIRING DIAGRAMS.............................................................................................................................. 72
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

6
2. SPECIFICATIONS
(1) Rated power supply: 120 ± 10% VAC (60 Hz)
(2) Maximum power consumption: 190 W
(3) Maximum current consumption: 1.58A(120 VAC power supply)
(4) Coin box capacity: Approx. $750 in coins (3,000 25-cent coins)
(5) Display device: LCD monitor (32-inch screen)
(6) Dimensions
1
As installed: 35 x 44.5 x 98 in. (890 x 1,130 x 2,490 mm) (W x D x H)
35 in. (890 mm) 44.5 in. (1,130 mm)
98 in. (2,490 mm)
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

2. SPECIFICATIONS
SPECIFICATIONS Test mode Troubleshooting
7
2
When divided
Cabinet: 35 x 44.5 x 38.6 in. (890 x 1,130 x 980 mm) (W x D x H)
35 in. (890 mm) 44.5 in. (1,130 mm)
38.6 in. (980 mm)
41 in. (1,040 mm)
Signboard assembly: 5.1 x 33.1x 87 in. (130 x 840 x 2,210 mm) (W x D x H)
33.1 in. (840 mm)
5.1 in. (130 mm)
87
in. (2,210 mm)
(7) Weight
1
As installed: Approx. 286.6 lb. (130 kg)
2
When divided
Cabinet: Approx. 242.5 lb. (110 kg)
Signboard assembly: Approx. 35.3 lb. (16 kg)
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

8
3. PACKAGE CONTENTS
The product packages shipped from the factory contain the following components and parts.
Make sure that all the items listed below (except the service key)
are contained in the coin box.
If any item is missing, contact your distributor.
Accessory list
No. Name Specication Qty.
1 Operation Manual
Operation Manual
1
2 Service key 2
3 Coin box key 2
4 Power cord 1
5Hex ange bolt M6 x 12 (For signboard) 4
6 Button head bolt M6 x 30 (For signboard pillar) 6
7 Flat washer M6 (For signboard pillar) 6
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

PACKAGE CONTENTS/OVERALL CONSTRUCTION (Names of Parts) Test mode Troubleshooting
9
4. OVERALL CONSTRUCTION (Names of Parts)
Front
Signboard pillar
Signboard Signboard assembly
Fluorescent lamps
(inside)
Control Panel assembly
(3P, Blue)
Top Board assembly
Control Panel assembly
(4P, Red)
Bill acceptor
(option)
Under Box assembly Middle Box assembly
Side service door
Control Panel assembly
(1P, Yellow)
Control Panel assembly
(2P, Pink)
Front service door
Coin box door
Power switch
Fuse(5A 250V)
Cord box
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

10
5. INSTALLATION
WARNING
Install the machine according to the instructions and procedures specied in this
 operation manual. Failure to follow the specified procedures may result in a fire,
electric shock, injury or machine malfunctions.
Insert the power cord plug firmly into the AC outlet. Poor contact may cause

overheating that can lead to a re or burns.
Install the machine securely by using the level adjusters. Unstable machine
 installation can result in an accident or injury. (See P. 36 “8A-1-1 Securing the
machine using level adjusters.”)
5-1 Installation conditions
5-1-1 Locations to avoid when installing the machine
WARNING
The machine is designed for indoor use. Never install the machine outdoors or in any
 of the following places:
A place subject to direct sunlight•Aplace exposed to rain or water leakage•Damp place•Dusty place•Aplace close to heating devices•Hot place•Extremely cold place•Aplace where dew condensation may occur due to temperature differences•
A place where the machine may become an obstruction in emergencies (such as •
near an emergency exit) or a place where a re extinguisher or similar equipment
is installed
Unstable place or location where vibrations are produced•
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

5. INSTALLATION
Installation conditions/Required dimensions for bringing the machine inside Test mode Troubleshooting
11
5-1-2 Play zone for installed machine
WARNING
Create a play zone around the machine (space as shown below) to prevent players

coming into contact with bystanders or passers-by.
 The distance from the oor to the ceiling must be at least 10.6 in.
(2 m 70 cm).
3.5 in. (90 cm) or more
3.5 in.
(90 cm)
or more
Play zone
5-2 Required dimensions for bringing the machine inside (such
as doors and corridors)
The machine is divided into separate components at the factory before shipping. The
dimensions of main components are as follows:
As installed:
35 x 44.5 x 98 in. (890 x 1,130 x 2,490 mm) (W x D x H)
Weight:Approx. 286.6 lb. (130 kg)
Without Signboard assembly:
35 x 44.5 x 38.6 in. (890 x 1,130 x 980 mm) (W x D x H)
Weight:Approx. 242.5 lb. (110 kg)
Doors and corridors must be sufciently higher and wider than the dimensions indicated
above.
Regarding the method of attaching the signboard assembly to the Under Box assembly,
see “8A-1-3 (1)Attaching the signboard pillar.”
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

12
6. MOVINGAND TRANSPORTING
WARNING
Do not leave the machine on a slope. If the machine is left on a slope, it may tip over
 and cause an accident.
6-1 Moving(ontheoor)
Carefully transport the machine so as not to cause excessive
impacts to it, as the LCD monitor is a precision electronic
component.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

6. MOVING AND TRANSPORTING
Test mode Troubleshooting
Moving(ontheoor)/Transportation
13
6-2 Transportation
6-2-1 Manualtransportation(carryingonstairs,etc.)
WARNING
Thismachineweighsapproximately286.6lb.(130kg).
 When carrying the machine manually, be sure to remove the Signboard assembly
 from the machine, and raise all the level adjusters all the way (See P. 36 “8A-1
Assembly.”)Attemptingtocarrythemachinemanually(overstairs,etc.)without
removing the Signboard assembly as described above can result in an accident.
If a corridor is narrow, separate the machine into parts. (See P. 11 “5-2 Required

dimensionsforbringingthemachineinside(suchasdoorsandcorridors).”)
When carrying the machine manually, the following number of people are needed.
 Attempting to carry the machine with fewer people can result in an accident or injury.
Machine without Signboard assembly:•
 (approx.286.6lb.(130kg)): 5peopleormore
Signboard assembly:•
 (approx.35.3lb.(16kg)): 1personormore
[When divided]
Middle Box and Top Board assemblies:•
 (approx.110.2lb.(50kg)): 4peopleormore
Under Box assembly:•
 (approx.132.3lb.(60kg)): 4peopleormore
Do not drop the machine when lowering it.
 Be sure to transport the machine with great care to avoid damaging it.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

14
7. OPERATION
WARNING
Some monitor sections remain hot or charged with high voltage even after the power
 switch is turned off. Do not touch the monitor unnecessarily in order to avoid electric
shock and burns.
Dust accumulated on the power cord plug may cause a re. Check the power cord
 plug regularly and remove dust.
Insert the power cord plug rmly into the AC outlet. Poor contact may cause

overheating that can lead to a re or burns.
Be sure to check that the machine has been installed according to the instructions

and procedures specied in this operation manual (See P. 10 “5. INSTALLATION.”)
before operating the machine. If the machine is not installed properly, re, electric
shock, injury or equipment malfunction can occur.
The warning labels describe important safety precautions. Be sure to observe the
 following:
To ensure that the warning labels attached to the machine are easily legible,•install the machine at an appropriate location with ample illumination and keep
the labels clean at all times. Also, make sure that the labels are not hidden behind
another game machine or other objects.
Do not remove or alter the warning labels.•If the warning labels become excessively dirty or damaged, replace them with new•labels. To order warning labels, contact your distributor.
To ensure safe operation of the machine, be sure to conduct the pre-service check

(see P. 15 “7-1 Pre-service check”) and Service (see P. 44 “8B. SERVICES”) described
in this manual. Failure to conduct the pre-service check or service can result in an
accident.
CAUTION
If a player becomes sick due to light stimulation or game images, have that person
 stop playing the game immediately and let him/her rest.
In rare cases, stimulation by lights or video images can cause convulsions or a loss
 of consciousness. If this happens, advise the player to consult a doctor as soon as
possible. When pre-school children play, request their parents or guardians to keep
an eye on the children.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

7. OPERATION
Test mode Troubleshooting
Pre-service check
15
7-1 Pre-service check
7-1-1 Safety check (before power ON)
WARNING
To prevent accidents and injury, be sure to conduct the pre-service check described
 below before commencing operation.
(1) Are all warning indications in place? (See P. 3 “1-4 Description of warning labels
attached to the machine.”)
(2) Are the warning indications legible? (See P. 3 “1-4 Description of warning labels
attached to the machine.”)
(3) Are all level adjusters adjusted properly? (See P. 36 “8A-1-1 Securing the machine
using level adjusters.”)
(4) Is the specified play zone provided? (See P. 11 “5-1-2 Play zone for installed
machine.”)
(5) Is the power cord routed so that it will not cause players or other customers to trip
over it?
(6) Is the power cord securely connected to the AC outlet and the power input socket
on the machine?
(7) Is the power cord plug free of dust?
(8) Is the signboard pillar securely attached to the Under Box assembly? (See P. 37
“8A-1-3 (1)Attaching the signboard pillar.”)
(9) Is the signboard securely attached to the signboard pillar? (See P. 39 “8A-1-3 (2)
Attaching the signboard.”)
(10)Is the under box side cover securely attached to the Under Box assembly? (See P.
37 “8A-1-3 (1)Attaching the signboard pillar.”)
Check the following items after turning on the power switch. If an abnormality is found,
turn off the power switch immediately to stop operating the machine. Then, unplug the
power cord from theAC outlet and contact your distributor.
(11) Is any part of the power cord or plug abnormally hot?
(12)Does touching the machine give an electric shock?
(13)Is there a burning smell, abnormal noise or vibration?
(14)Is there any other sign of abnormality or malfunction?
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

16
7. OPERATION
7-1-2 Operation check (after power ON)
Check the following items in Test mode. (See P. 18 “7-2-2Adjustment switches and but-
tons.”)
(1) Checkthelampsforproperoperation.(DotheuorescentbulbandStartbuttons
light?)
(See P. 25 “7-4-4 Switch/sensor test (I/O TEST).”)
(2) Check the Start buttons for proper operation.
(See P. 25 “7-4-4 Switch/sensor test (I/O TEST).”)
(3) Check the displayed image. (Does the monitor show images properly?)
(See P. 28 “7-4-5 Monitor condition (MONITOR TEST).”)
(4) Check the sound. (Is sound produced by each loudspeaker?)
(See P. 29 “7-4-6 Sound adjustment (SOUND TEST).”)
(5) Check the clock.
(See P. 33 “7-4-8 (1) CLOCK SETTING.”)
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

7. OPERATION
Test mode Troubleshooting
17
Pre-service check/Explanation of the power switch and adjustment switches
7-2 Explanation of the power switch and adjustment switches
7-2-1 Turning the power switch on
Power switch
zBe sure to complete the installation and setup of the machine
before turning the power switch on.
z When turning the power switch on or off, wait at least 30 seconds
between switch operations. Do not repeat turning the power switch
on and off unnecessarily. Repeated on/off operations can cause
damage to the data in the backup memory.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

18
7. OPERATION
7-2-2 Adjustment switches and buttons
Open the front service door to gain access to the adjustment switches and buttons.
Front service
door
Test switch Select switch
Service button Enter button
Test switch
Set this switch to ON to activate Test mode. Test mode is used to test the monitor and
other parts. (See P. 21 “7-4 Test mode.”)
Service button (red)
Press this button to increase the credit count without activating the coin counter.
Enter button (green)
After selecting an item or setting (a numeric value) using the Select switch, press this
button to enter or execute the selection.
Select switch
InTestmode,ipthisswitchupordowntoselectanitemorsetting(anumericvalue).
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200
