NAMCO CYBERSLED User manual

CYBERSLED’”
Operators Manual

CONTENTS
,, SPEClFlCATlONS .........................................................................................................................
1
2. PRECAUTIONS
2-t Caution When Installing .........................................................................................................
1
2-2 Caution When Handling .........................................................................................................
2
3. tNSPECTlON .................................................................................................................................
2
4. INSTALLATION
4-t tnstalling Seat Assemblies .....................................................................................................
3
42 installing Control A.s.sen-bties
................................................................................................ 4
5. ADJUSTMENTS
5-I Power On ..............................................................................................................................
.5
5-2 Adjustment Switches on the Service Panel ...........................................................................
5
5-3 Test Mode and Play Options .................................................................................................
6
5-3-l
Se&Test
.................................................................................................................. .6
5-3-2 Test Mode .................................................................................................................
6
53-3
Changing Game Settings (Game Option Screen) .................................................... 7
53-t
Changing Coin Settings (Coin Option Screen) ......................................................... 8
53-5 Switch Test Screen ...................................................................................................
9
5-4 tnkializing Controls - Adjustment After Replacing Pans .....................................................
10
5-4-l
Adjusting Joystick Assembly .................................................................................. IO
5-4-2
Minor Joystick Adjustments .................................................................................... 1 1
5-3
Initializing Communication Numbers ...................................................................... 11
6. HOWTO PLAY .............................................................................................................................
12
7. MAINTENANCE
7-l Power Switches ...................................................................................................................
.13
7-2 Replacing the Fluorescent Lamp (Marquee) ........................................................................
13
73 Replacing Revotving Attract Light Bulb ...............................................................................
13
7-4 Replacing Game PC Board
................................................................................................
.13
7-5 Joystick Assembly:
7-5-l Removing the Joystick Assembly ...........................................................................
14
7-5-2 Replacing the UP and DOWN Potentiometer.........................................................
15
7-5-3 Replacing the RIGHT and LEFT Potentiometer .....................................................
15
76 Removing the Control Panel ................................................................................................
15
7-7 Removing the Monkor Bezel ...............................................................................................
15
8. TROUBLESHOOTING -GENERAL
..... I ..................................................................................... 16
9. PARTS LIST.. .........................................................................................................................
20-23
16. GAME HARNESS WIRING DIAGRAM ..................................................................................
26-28
11, LIST OF ILLUSTRATIONS (See over)

7. LIST OF ILLUSTRATIONS
4-l 314 Front and Back View of Game ___.._____________....................................................................... 3
4-2 3/4 Back View of Game .._....___..______...................,...,.,,,...................................................,,.. 4
5-l Service Panel __..__.....___.,,,...,,.................................................................................................5
52 Menu Screen .,_.,.,..__.....__._................................................,.,....,,................,........................... 6
5-3 Game Option Screen ,,..__....____...._............................................,.,...,...,...................................7
5-4 Table of Game Option Settings _.......__.._______...__.,........,,,.,..,.................................................. 7
5-5 Coin Option Screen . . .._...._.________..............................................,......,.,.................................,.. 6
s Table of Coin Option Settings _____________..............,.................................................................... 8
5-7 Switch Test Screen _...__...,,,,,....................,..............,..............,,.............................................. 9
H Switch Test Description Table .,.._.,.,,..________................................................................~ 9
59 Volume Adjustment Screen - (Initialization) ____.._....................___.......................................... 10
5-10 Joystick Adjustment Screen _______________..___...............,,,..,,,,.................................................. 11
7-1 Joystick Assembly .___....__........._............,..............................................................................14

1. SPECIFICATIONS
POWER SUPPLY: Two PC XT Type Switching Power Supplies,150 Watts
POWER CONSUMPTION:
12OVAC, 5.0 AMP
DIMENSIONS: Width
Depth
Height
Cabinet Assembly
57” 64” 75”
Seat Assembly
19”
4.0 112,
56”
Assembled Game
62” 64”
75”
SHIPPING WEIGHT:
Seat Assembly
196 lbs.
Control Panel Assembly 71 Ibs.
Monitor Cabinet Assembly
680 lbs.
Total Product Weight 947 lbs.
MONITOR: Two (2) 25” standard resolution Color Monitors
ACCESSORIES: (in Coin Box) Keys:
Coin box/Coin Door/Rear Door
.................................................. 2 czeh
Monitor Cabinet Kit:
Seat “U Bra&et .................................................................................
4
Token Button Label..
.......................................................................... .2
Machine Screw, Y8 x 5/8” .................................................................
18
Machine Screw, 5/16” 1 l/2’ HX TAP BO
.................................... 16
Fla, Washer, 5/16” BO ......................................................................
16
Lock Washer, 5/16’ BO ....................................................................
16
“a, Washer, 916” ZN ........................................................................
6
Lock Washer, 5116” ZN ......................................................................
6
Wrench, Hex Key S/32” ......................................................................
I
Wrench, Metric 3MM .........................................................................
1
Beacon Light Bulb ..............................................................................
2
CYBERSLED ~ton Manual
....................................................... 1
Control Panel Kit:
Machine Screw, 3/S’-16 x 2 HX ZN
.................................................. 8
Star Washer, 3/8” EXT.. ......................................................................
8
Flat Washer, 318” ZN ..........................................................................
8
Note: Specifications may change without prior notice. Moditication and/or alteration of the
CYBERSLED- game with kits or parts not supplied by NAMCO may void the warranty.
2. PRECAUTIONS
2-1 Cautions When Installing
This game is designed for indoor use only. The game must not be installed out-
doors or under the following conditions:
a. In areas directly exposed to sunlight, high humidity, direct water contact, dust,
high heat or extreme cold.
b. In locations that would present an obstacle in case of emergency, i.e. near fire
equipment or emergency exits.
c. On an unstable surface or subject to floor or other vibration.
1

2-2 Caution When Handling
a.
b.
C.
d.
e.
f.
g.
h.
i.
AC power must always be turned OFF, and the game unplugged, before replac-
ing any parts or connecting/disconnecting connectors.
When unplugging the game from an electrical outlet, always grasp the plug, not
the cord.
Do not subject game to physical shock when transporting or moving it.
The power supply range is between 1 IO-120VAC, (switchable to 220 VAC).
The cabinet must bc grounded with a securely connected ground plug.
Care must be taken at all times to avoid electrical shock whenever inspecting or
adjusting the game, particularly around the monitors.
Always return the levelers to the extreme “up” position before moving the game,
and separate the game into its two assemblies - cabinet and seat.
Adjustment is required whenever the game PC board, ROM, joystick or potenti-
ometers are changed. (Ref. Section 5-5)
DO NOT attempt to repair the Printed Circuit Board (PCB). It contains sensitive
chips that could easily be damaged by even the small internal voltage of a multi-
meter. Always return the PCB to your distributor for any repairs.
3. INSPECTION
NOTE: The Seat Assemblies and Control Panels are shipped separately (to allows
the Monitor Cabinet to tit through a standard 36” wide door) and must be installed
on the Monitor Cabinet by the operator as described in Sections 4-1 and 4-2.
The three (3) CYBERSLEDTM Game cartons should be carefully inspected upon receipt
to insure that the game is complete and was delivered in good condition.
Inspect the game cabinet by doing the following:
1. Examine the cabinet exterior for dents, chips, or broken parts.
2. Unlock and open the rear service door and the front coin door.
Inspect the interior of the cabinet as follows:
a.
b.
C.
d.
Verify that all plug-in connectors (on the cabinet harnesses) are firmly plugged
in. DO NOT force connectors together. The connectors are keyed so they fit
only in the proper orientation. A reversed edge connector can damage a PCB
and will void your warranty.
Inspect the power cord to insure that there are no cuts or dents in the insulation.
Inspect the power supply connectors.
Inspect other major sub-assemblies, such as the video display monitors, PCB,
and speakers. Make sure that they are mounted securely and that all ground
wires are firmly connected.
2

4-I Installing the Seat Assemblies (Ref. Illustration 4-l)
NOTE: Installing the seats before the control panels eases the process of inslalling
the control panels.
I.
2.
3.
Unpack and inspect the red and blue seat assemblies.
Wheel the seat assemblies up to the monitor cabinet. Connect the wire har-
ness connectors to the speaker harness.
Bolt the seat ‘I” brackets to the monitor using the fasteners provided.
3

1-2 Installing the Control Assemblies (Ref. Illustration 3-l)
1.
7
-.
3
.
4.
5.
6.
linpack and inspect the control assemblies.
IMPORTANT: FIRST REMOVE THE PLASTIC COVER FROM EACH
CONTROL PANEL.
Notice the two (2) hook brackets on the hack of each contwl panel. Thcsc
hooks allow you to place the control panels in position while installing the
controls.
Connect the control panel harness connectors to the monitor cabinet connec-
tors.
Using the hooks on the control panel. hang the control panel in place on the
cabinet slots. Be sure to press down firmly on the control panel to seat it all
the way down. Reinstall the plastic cover on the control panel.
Go around to the back of the Same and bolt the control panel in place from the
back using the four (4) bolts provided.
Initialize each joystick as described in Section 5S3-1

5. ADJUSTMENTS
5-l Power on
When installation is complete, connect the power cord to an AC outlet and turn
the power on. The Power on/off Switch is located on the bottom right hand side
of the game. NOTE: Each P/S is also equipped with a pushbutton power switch
which must also be turned on.
5-2 Adjustment Switches on the Service Panel
The Service Panel is located behind the coin door. It has controls for adjustment
of the speaker volume, and switches for accessing the test modes.
Illustration S-l, SERVICE PANEL
1. Test Switch
Turning this switch “ON” enters the Test Mode, and activates the Game
Option Screen on the monitor. This is where the self-tests ate performed, and
game variables (pricing, level of difficulty, potentiometer adjustment etc.) are
set/changed (Ref. 5-S-3). Turn the test switch to the “OFF” position at any
time to return to the Game Mode.
2. Audio Volume Controls
Volume adjustments are made separately for the speakers located in the
control panels and seats.
3. Service Switch
By pressing this switch, credits can be issued without advancing the coin
counter.
5

5-3 Test Mode
1. Self-test
The self test is performed automatically when power is turned on. If no errors
are encountered, the Game Screen is displayed on the monitor.
2. Test Mode
Open the coin door and set the test switch to ON. The Menu Screen appears
on the monitor displaying the various tests available. (See Illustration 5-2)
MENU
SWITCH TEST
SOUND TEST
COIN OPTIONS
GAME OPTIONS
A.D.S.
COLOR TEST
CONVERGENGE TEST
LIGHT TEST
JOYSTICK ADJUST
@ For testing each switch/potentiometer
g
For test the various sounds
For changing the game ptfcfng etc.
@ For setting the game optfons
@ For displaying game data
@ For adjusting the color of the monitor display
@ For adjusting various monitor items
@ For lighting the red rotary lamp and the ‘Viewpoint Change” button
@ For making adjustments of the joystick operation
Illustration 5-2, MENU SCREEN
To select the item to be tested - move. the joystick backward or forward.
To enter the test item selected (highlighted) - squeeze the joystick trigger.
At the end of testing, turn the test switch “OFF”, and the display will return to
the Attract Mode.
6

3.
a.
b.
Changing the game settings (Game Option Screen)
Select item 4 “Game Options” on tbe Menu Screen (Ref. Section 5-3-2) to
display the Game Options Screen. Game time settings and levels of difficulty
can be adjusted with this screen.
I
>
GAME OPTIONS
TIME 1T
C
120
(a)
TIME 1C C
50 +22
(W
TME 28
C
120
(C)
TIME 2”A
C
70
(d)
1 PLAY LEVEL
C(e)
2 PLAY LEVEL
C
(fl
WAtTTlME
C
20
(g)
WIN S TIME C
15
(4
POSITtON
1
LEFT
0)
EXIT OK
ti)
LINK
\ /
Illustration 5-3, GAME OPTION SCREEN
To select an item to he changed-move. the joystick up or down.
To change the content of the seleckd item according to the TABLE OF
GAME OPTION SETHNGS (below) - squeeze the joystick trigger.
After all desired changes have been made, you may exit the Test Mode by selecting
“EXIT”, or press the Service Switch.
ITEM
(a) lime of one-playw training
(b) Time of one-player vs. computer
(c) Fme of Iwo-player Beginnw’s
(d) Xime of trvo-player Inkrmediate/Mvanced
(e) One~player game difficulty
(1) Two-player game diRicully
(g) Waiting time for an opponent player
(h) Waiting time for an opponent pfarer
playing me bonus game
CONTENT
A (b-t) to E (shortest) (original setting is
C)
A (longest) to E (shortest) (original setting is
C)
A (longest) lo E (shortest)
(ckgiit setting is C)
A (longest) to E (stmrtast)
(wiginal setttrg is C)
A (easiest) to E (most difficult)
(original setting is C)
This settfrg identiks me pawer level
of each “hit” on an opponent.
A (tow power) to E (high power) (@inat Setting is C)
A (kmgest) to E (nhortest)
(wiginal setting is E)
A (bngest) to E (shortest) (original setting is
C)
(i) Communication number semng
1 (Left seat)
2 (Right seat)
(I) Communication conditions OK (Communication functions properly)
* You cannot select this item
ERROR (Communication error)
Illustration 54, TABLE OF GAME OFITON SETTINGS

4.
a.
b.
Changing the coin settings (Coin Option Screen)
Select item 3 “Coin Options” on the Menu Screen (Ref. Section 5-3-2) to
display the Coin Options Screen. This allows game pricing and other settings to
be changed.
COIN OPTIONS
COIN, MECH
1 COUNT 1 COIN -
COfN 2 MECH
GAME COST
BONVS COIN
FREE PLAY
WIN actw.5
ATTRACT SOUND
ATTRACT LlGKl
EXIT
Illustration 5-5, COIN OlWON SCREEN
To select an item to be changed - move the joystick up or down.
To change the content of the selected item according to the TABLE OF
COIN OPTION SETTINGS (below) - squeeze the joystick trigger.
After all desired changes have been made, you may exit the Test Mode by selecting
“EXIT”, or press the Service Switch.
ITEM
CONTENT
(a) COIN MECH 1
1 Coin counts as ‘x’credit(s)
(4 standard setting)
l-9 (original sening is 14 )
(b) COfN MECH 2
(C) GAME FEE
(d) BONUS COIN
(e) FREE PLAY
1 Coin counts as ‘x” credit(s)
Number of cm& lo play Uw game 14 (oviginal seting is 3. )
A bonus coin is added when the none (original seting is none 4
specified number of coins is entered
l-9
NO 4
YES
(0 BONUS FOR WINNER
(3) ATTRACT SOUND YES
4
NO
:h) ATTRACT LIGHT YES.
NO
Illustration 54, TABLE OF COIN OFIION SEITINGS
8

5. Switch Test Screen
Select item I “Switch Test” on the Menu Screen (Ref. Section 5-3-2) to
display the Switch Test Screen.
Illustration 5-7, SWITCH TEST SCREEN
J”llbrl DCIRU IE=ICY
IL.., Y_,,.r II_. -I.” ..LU. L” I” n.1..
(a) DIPSW
This test displays Ihe status 01 the option switches on me game PC boarc
(Cpu~PCS). Any number displayed in RED, indicates it is turned “ON”~
(b) TEST SW It
‘y3N^ is displayed in RED, the rendition is normal.
_
(c) CDtN 1 SW
T)w is displayed in RED when the coin 1 switch is turned “ON’, and the
numbers win advamz. (me coin meter will not advance)
(d) COtN 2 SW
Not used.
(e, SERVlCE BUTTON
_
When !31is label is illuminated RED white pressing me service switch imkl
me coin &aq ti condition is nwmal. Press the sr?wiQ switi to return 1
me Men” sc?een.
(0 YtSStLE BUllON
When this label is illuminated RED while pressing the missile button, the
condtion is n-l.
_
(g) GUN TRlGGER When this
label is iltumi~t& REDwhile passing the machine gun buttor
me cocdllon is nwmal.
(h) VtEWPDtNT
CHANGE BUTTON
(i) LEFT JOVSTtCK
(‘oruard,backward)
When this label is illuminated RED whilt, pressing the ViewpOint change
button. the cord*on is normal.
mis tests the Left Joysrick forward and backward +wtenSometer and
switch action. It w appears when the joystick is moved fully toward or
hilly b&ward, and -CENTER’ appears when the joystick is in the middle
position, me mndition is normal.
(i) LEFT JOYSTtCK This tests
tte L&t Joystick right and lett potentiometer and switch action.
(rightnctt)
‘RIGHT or ‘LEFT appears when tie pystick is moved kAy right or fully
I&, and -CENTER’appears when the joystick is in the middle pOsition, th
condition is normal.
_
(k) RIGHT JOYSTtCK This
tests the Right Joystick toward and backward potcntiomcter and
(forward/backward)
switch. and it is operating normally if the same indications appear as those
for the left joys6ck described in (i) above.
(t) RtGHT JOYSTICK
(rightiH)
This tesh the Right .kysti& right and left wtentiometer and switch, and it
is operating normally if tie same indications appear a6 those for the tett
joystick described in(j) abow
Illustration S-8, TEST TABLE
9

54 Initialization - Adjustments After Replacing Parts
Initialization is required whenever the game PCB, the joystick assembly and/or the
potentiometers are replaced.
541
1.
2.
3.
4.
Adjusting the Joystick Assembly (Initialization)
With the joystick centered, hold the Service Switch and turn the Test
Switch “ON”. The “VOLUME ADJUST” screen (below) will appear.
The joystick assembly is automatically initialized with this action.
Set the test switch to “OFF” to return to the Menu Screen again.
I
VOLUME ADJUST
LEFT JOYSTICK 00 CENTER
00 CENTER
RIGHT JOYSTICK
00 CENTER
00 CENTER
Illustration 5-9, VOLUME ADJUST SCREEN
Select 1 “SWITCH TEST” to test the joysticks.
If:
a) “CENTER” appears when the joystick is set in the neutral position
and
b) “OK” appears when the joystick is pushed all the way down,
then
the joystick assembly is adjusted correctly.
If operation does not appear normal, minor adjustments can be made to the
joysticks by selecting “JOYSTICK ADJUST” on the Menu Screen (Ref.
Section S-3-2).
10

542 Minor Joystick Adjustments (JOYSTICK ADJUST)
1. Select 9 “JOYSTICK ADJUST’ on the Menu Screen. The following
screen will appear:
JOYSTICK ADJUST
(LEFT) (RIGHT)
UP
UP
DOWN DOWN
LEFT LEFT
RIGHT RIGHT
(LEFT) (RIGHT)
g
/
E
DOWN DOWN
a
a
LEFT LEFT
a a
RIGHT RIGHT
Adjustments are
conducted in this order
Illustration 5-10, JOYSTICK ADJUST SCREENS
NOTE: Make the following adjustments ONLY AmER adjustments
described in Section -1 Adjusting Joystick Assembly (Initiali-lation).
2.
3.
4.
543
Push the left joystick forward until it stops, then press the View Point
change button located between the bases of the two joysticks.
“OK” appears next to the “UP” label.
Pull the left joystick back toward you until it stops, then press the View
Point change button located between the bases of the two joysticks.
“OK” appears next to the “DOWN” label.
In the same manner as in steps 2 and 3 (above), adjust both joysticks for
operation in all directions
Initializing the Communication Numbers
When the communication numbers of the right and left game PCB are not set
correctly, communication does not function normally.
1.
2.
3.
4.
Select “POSITION” on the GAME OPTIONS Screen.
Set “1” for the left side (blue) seat.
Set “2” for the right side (red) seal.
When the correct numbers are set for both the right and left side seats,
“OK” appears under the “LINK” label display.
11

6. HOW TO PLAY
- CYBERSLEDTN is a game that allows one or two players to engage in a battle, firing
missiles and machine guns while driving futuristic tanks with joysticks.
* A single player can compete against the computer, while two players can compete
against each other.
l The tank and weapons controls operate as follows:
.
By pushing forward or pulling backward on botb joysticks at the same time, the player’s tank moves
in that direction.
.
By pulling ooe joystick in one direction, and the odw in the opposite direction, the player turns the
tank.
-
Depressing the thumb button on the joystick launches a missile. The number of missiles are limited
-
Squeezing the trigger fms the machine gun. Continuous round5 are fired as long as the bigger is
held closed, but if fued too long, the gun will overheat and stop firing. The gun will cool if the
uigger is releawd.
.
Three items can be picked up: “Missile supply
“, “Shield repair”, and “Special”. Tluee effects are
hidden in the “Special” item “Jam opponents radar’
‘, ‘Jam opponents missile tracking”, and
“Special shield”.
lThe Game is played as follows:
.
A player inserts a coin(s), and waits for an opponent. The waiting time for an opponent can be
shortened by pxssing/pulling tbe missile button/joystick trigger repeatedly as quickly as possible
while depressing the viewpoint change button.
.
If a second player inserts a coin(s) within the allowed time, a twwplayer game starts.
If not the one-
player game mode is activated
.
In the one-player mode, the player can select two kinds of courses, i.e. “training & practice
course” and “vs. the computer.” This is a timed match.
.
The goal of “vs. the computer” is to clear all stages of tbe game within the given time limit. The
player can tight for unlimited rounds within the given time limit
-
The “training course” consists of three stages, and it is provided for the beginner tin practice.
-
“Vs. Computer” consists of six stages. Every time the player defeats the enemy, extra time is
awarded..
-
In the two-player mode, the players can select Beginner, Intermediate, or Advanced levels of play.
.
Tbe Beginner level is a training course. The player(s) can fight for unlimited rounds within the
given time period. In the Beginner level, the special items do not appear.
.
Both the Intermediate and Advanced level of games provide full-scale fighting stages. The players
can select the battlefield.
.
The Advanced level of a game allows the players to select the fighting environmental factors, i.e.
Night or Fog, by pressing the viewpoint change button when selecting the battlefield.
As these
environmental factors limit the functions of the radar, the game becomes more difficult to play.
.
A game consists of a match with three games. The frst player to win two games wins the match.
.
If the “Win Bonus” option is selected the winning player can continue his/her game
12

7. MAINTENANCE
r
__II____________________
CAUTION
1
B E SURE TO UNPLUG THE AC POWER BEFORE
:
:__________________.___.___~
CONDUCTING ANY MAINTENANCE PROCEDURES.
7-1 The Power Switches
CYBERSLED is equipped with two (2) Power Switches located at the rear
base of the Monitor Cabinet, one on each side. They are equipped with circuit
breakers that automatically turn the power off with excess current flow.
7-2 Replacing the Fluorescent Lamp (Marquee)
1. Remove the four (4) bolts securing the upper marquee bracket to the top of the
game cabinet.
2. Remove the upper bracket, and remove the marquee acrylic panel by sliding
up and out, exposing the two (2) 20W fluorescent lamps.
3. Remove the defective fluorescent lamp(s) from its holders by rotating the tube
and pulling outward.
4. Replace with a new 20 watt fluorescent lamp.
5. Replace marquee acrylic panel and marquee bracket.
7-3 Replacing the Revolving Attract Lamp Light Bulb
1. Remove the four (4) bolts (one on each comer) of the top pane1 cover, and
remove the panel.
2. Remove the two (2) screws securing the revolving light assembly bracket, and
remove the bracket.
3. Remove the screw securing the lamp case, and turn the case to remove it
4. Replace the defective light bulb with a new 12V, 1OW bulb.
7-4 Replacing the Game PC Board
CYBERSLED is equipped with two (2) Game PCB assemblies. This section
describes the procedure for removing the game PCBs on the left (BLUE SEAT)
side of the cabinet. The game PCBs for the right (RED SEAT) side are removed
in the same manner.
1. Remove the rear door.
2. Remove the two connectors. (One on the rear of the PCB Cage)
3. Remove the two (2) mounting screws securing the PCB cage to the cabinet,
and slide the cage out to remove.
13

7-5 Joystick Assembly
c
NOTE: CYBERSLEDm uses a HAPP CONTROLS joystick mechanism.
7-S-I
1.
2.
3.
4.
5.
NOTE: Numbers shown are Happ Controls Parl Numbers
Illustration 7-1, HAPP JOYSUCK ASSEMBLY
Removing the Joystick Assembly
Remove the rear cover located at the back of the Monitor Cabinet.
Disconnect the four (two 12-position, one 6-position and one 4-position)
connectors which attach to the control panel box.
Remove the eight bolts securing the plastic panel cover and remove it.
Remove the seven (7) screws securing the control panel cover and remove
the control panel cover together with the lever assembly.
Remove the four (4) screws securing the joystick assembly to the control
panel cover and remove it.
14

7-5-2 Replacing the UP and DOWN Joystick Potentiometer
1. Remove the cord clip securing the joystick harness.
2. Turn the joystick assembly upside down, remove the four (4) flange sockets
and remove the under case.
3. Insert a phillips screwdriver into the hole located at the side of the joystick
assembly and remove the two (2) screws securing the potentiometer
mounting bracket and remove.
4. Replace the defective potentiometer with a new one.
5. Reassemble by reversing the above steps.
7-S-3 Replacing the RIGHT and LEFT Joystick Potentiometer
I. Remove the cord clip securing the joystick harness.
2. Turn the joystick assembly upside down, remove the four (4) flange sockets
and remove the under case.
3. Remove the two (2) screws securing the potentiometer bracket and remove it
4. Replace the defective potentiometer with a new one.
5. Reassemble by reversing the above steps.
6. When reassemblying, be sure to:
a) Connect the harness to the potentiometer so that no gap exists between
the potentiometer and the harness.
b) Fix the set screw of the spur gear to the direction of the potentiometer
connector on the potentiometer gear.
7-6 Removing the Control Panel Assembly
1. Remove the mar cover of the Monitor Cabinet.
2. Disconnect all connectors to the control panel.
3. Remove the four (4) assembling bolts.
4. Lift the control panel assembly, unhook it and pull it forward to remove
7-7 Removing the Monitor Bezel
1. Remove the rear cover of the Monitor Cabinet.
2. Loosen the four (4) assembling bolts securing the control panel to the cabinet,
but DO NOT REMOVE THEM.
3. Remove the four (4) assembling bolts securing the monitor bezel to the cabinet.
4. Lift the monitor bezel diagonally towards you to remove.
15

8. TROUBLESHOOTING -GENERAL
If you suspect the game may be malfunctioning, the following steps should be taken
before you make a service request.
(1) Inspect the fuses.
(2) The power supply should be set to either 110 or 220 Volts AC. However, when some
other equipment (air conditioner, multiple pinball games, air compressors, et.c.) are
connected to the same power supply, the voltage may change beyond this range and
cause game trouble or improper operation.
(3) When the game does not work with the power turned on, turn the power off, wait ten
seconds, then turn the power back on. This may restart the game. If it still does not
work, inspect the fuses.
(4) When the game PCB, the Joysticks, or the Potentiometers are replaced, it is necessary
to make initialization adjustments to play normal games. Make appropriate adjust-
ments referring to section 5-4.
(5) Check all wiring connections as malfunctions can be caused by loose connections
(6) Foreign substances or dust on the game PCB or on the monitor PCB may cause
malfunctions or improper operation. Check that the PCB enclosure is clean.
(7) When you make electrical checks, use the wiring diagrams for reference.
* If the above suggestions are not applicable, or no improvement is observed, con-
tact your distributor or the service office printed on the back cover of this manual.
* DO NOT ATTEMPT TO REPAIR THE GAME PCB YOURSELF. Instead,
please return the board to your distributor for any repairs. The PCB contains
sensitive chips that could be destroyed even by the internal voltage of a multi-
meter.
* When sending parts to be repaired, make sure to pack them firmly with a complete
explanation of the problem. When sending PCBs, package them in anti-static
foam or bubble wrap, and pack them in cardboard boxes to protect against impact
damage during shipment. To ship monitors, pack them in wooden frames so that
CRTs and PCBs are protected against excess load.
16

COIN CONTROLS COIN DOOR ASSEMBLY
17
