NAMCO FLAMING FINGER User manual

OPERATOR’S MANUAL

Important
Read PRECAUTIONS and INSTALLATION
Sections before operating game
FCC Notice
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operating in a
commercial environment. This equipment uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Copyright 2003 NAMCO AMERICA INC. - All rights reserved
No part of this publication may be reproduced by any mechanical photographic, or
electronic process, or in the form of a phonographic recording, nor may it be stored in a
retrieval system, transmitted, or otherwise copied for public or private use, without
permission from NAMCO AMERICA INC.

FLAMIN’ FINGER™Operator’s Manual
TABLE OF CONTENTS
1.0 SPECIFICATIONS 1
2.0 INTRODUCTION 2
3.0 PRECAUTIONS 2
3.1 Installation 2
3.2 Handling 2
4.0 INSTALLATION 3
4.1 Linking 3
5.0 SCREEN DESCRIPTIONS 4
6.0 GAME PLAY 8
7.0 TROUBLESHOOTING 9
APPENDIX A: PARTS LIST 10
APPENDIX B: WIRING DIAGRAM 12
APPENDIX C: LINKING WIRING DIAGRAMS 13

FLAMIN’ FINGER™Operator’s Manual
1
1.0 SPECIFICATIONS
Logic Power Supply: 200 Watt ATX style, NAI # VG88-08776-00
Input Power: 120 VAC, 60 Hz, 3 Amps max.
Overall Height: 68”
Crated Dimensions: 74” H x 29” W x 38” D
Installed Dimensions: 68” H x 22.25” W x 32” D
Shipping Weight: 227 lbs
Controls: Touch screen
Convenience Kit: Operator’s Manual (1)
(in coin box)
Note: Specifications subject to change without prior notice. Modifications and/or
alterations of the FLAMIN’ FINGER
™ game with kits or parts not supplied by NAMCO may
void the warranty. WARNING
REMOVAL OF SERIAL NUMBERS AND/OR BAR-CODES FROM PRODUCT OR
COMPONENTS WILL VOID THE WARRANTY

FLAMIN’ FINGER™Operator’s Manual
2
2.0 INTRODUCTION
Namco’s FLAMIN’ FINGER
™ is a 1-player (linkable up to 64 players) redemption game
featuring randomly generated mazes on a touch-screen.
Complete the maze within the time allowed and win the JACKPOT!
3.0 PRECAUTIONS
3.1 Installation
This game is designed for indoor use only. It must not be installed outdoors. The
following conditions must be avoided:
1. Direct exposure to sunlight, extreme high humidity, direct water contact, dust,
high heat or extreme cold.
2. Vibration. The game must be installed on a level surface with levelers
properly adjusted.
Do not install in an area such that the game would present an obstacle in case of an
emergency (i.e., near fire equipment or emergency exists).
3.2 Handling
1. Before operating the game, make sure that the main AC power hookup
includes a safety ground. This will ensure safe operation as well as
compliance with the applicable FCC and UL regulations. Measure the AC
power line voltage. Verify that the voltage source is between 110 and 125
VAC.
2. Before replacing any parts, turn the AC power OFF and unplug the game.
3. The game includes areas where 120 VAC is present. Take care at all times
to avoid electrical shock whenever inspecting or adjusting the game.
4. Do not attempt to repair the Printed Circuit Board (PCB) on-site. It contains
sensitive integrated circuit chips that could be easily damaged, even by the
small internal voltage of a multi-meter. Always return the PCB to your
distributor for any repairs. PCB assemblies must be returned as complete
sets.

FLAMIN’ FINGER™Operator’s Manual
3
4.0 INSTALLATION
Note: Shipping damage may void the warranty. In case of shipping damage, contact your
distributor and the transportation carrier immediately.
1. Unpack the game.
2. With the game in its installation position, lower the leveler pads as required
to eliminate any tilting of the game.
3. Plug in the main AC power cord, and turn the game ON.
4.1 LINKING
Games are shipped with 2 link cables. One is plugged into the output jack on the main pcb,
and runs to one side of a female-to-female (f-f) connector mounted on top of the coin box,
accessible through the coin door. A second cable is plugged into the other side of the
female-to-female connector and runs to the input jack on the main pcb. The link cables
must be installed for proper game function.
Linking can be done using one of two methods.
SEE APPENDIX C FOR LINKING DIAGRAMS
1. SEQUENTIAL. Recommended for 2 or 3 games, where the link cable can reach
from the last game to the first game in the line of linked games.
To link 2 or 3 games, unplug the link cable from the output side of the f-f connector of
game 1. Route it through the small round hole in the back of the cabinet, into the hole in
the back of the cabinet of game 2. Unplug the link cable plugged into the output side of
the f-f connector in game 2 and plug in its place the link cable just routed from game 1.
Route the cable just unplugged from game 2 out of the cabinet and into the game 1
cabinet, and plug it into the output side of the f-f plug in game 1.
THE LAST LINKED GAME IN THE CHAIN OF GAMES MUST CONNECT BACK TO THE
FIRST GAME IN THE CHAIN.
2. STAGGERED. Recommended for 4 or more games.
This method utilizes staggered routing, or every other game is linked. After the initial
input-to-output linking of games 1 and 2, the odd number games are linked together,
and the even number games are linked together.
SEE APPENDIX C FOR LINKING DIAGRAMS

FLAMIN’ FINGER™Operator’s Manual
4
5.0 SCREEN DESCRIPTIONS
Enter the MAIN MENU options screen by pressing the SERVICE button located on the
service panel inside the coin door. The MAIN MENU screen includes the following
choices:
MAIN MENU
OPTIONS
ACCOUNT
DIAGNOS
Press the red on-screen boxes to choose that item. Use the red on-screen slider to adjust
the selection. The large LED read-out just above the touch panel shows the current
adjustment level.
Upon touching the OPTIONS box, the following items can be selected:
1- SET 1-9 COST PER PLAY The number set is the amount of credits required to
start a game. (Default setting is “1")
2- SET 1-9 COIN #1 VALUE The number set is the amount of credits each coin is
worth from slot #1. (Default setting is “1")
3- SET 0-9 COIN #2 = X TIMES #1 The number set will make the coin in slot #2
worth that multiple of what is set in coin slot #1. For example if you want the coin in
slot #2 to be worth the same as a coin in slot #1, set the number to 1. If you want
the coin in slot #2 to be worth double the coin in slot #1 set the number to 2.
(Default setting is “1")
4- SET 1-10 GAME VOLUME This sets the volume for when a game is being played.
Setting it to “1" is the softest and “10" is the loudest. (Default setting is “6")
5- SET 1-10 ATTRACT VOLUME This sets the volume of the music that plays during
the attract mode. Setting it to “1" is the softest and “10" is the loudest. (Default
setting is “4")
6- SET 0-20 ATTRACT VOL RATE This sets the frequency of the music playing in
attract mode. The number you set will be the amount of times the attract mode
wraps before the music will play. If set to “0" the attract mode music will never play.
The time for attract mode to wrap once is about seven minutes. (Default setting is
“1")

FLAMIN’ FINGER™Operator’s Manual
5
7- SET 0-10 MIN TICK PER TRY This sets the minimum number of tickets a player
will receive regardless of their performance. (Default setting is “3") NOTE: The
player will receive an amount of tickets somewhere between the “min tick per try”
and the “max tick per try” settings, based upon the percentage of completion
through the path.
8- SET 0-20 MAX TICK PER TRY This sets the maximum number of tickets a player
can receive without winning the jackpot. (Default setting is “8") NOTE 1: You can
only set this as low as the “min tick per try” is set. NOTE 2: The player will receive
an amount of tickets between the “min tick per try” and the “max tick per try”
settings, based on the percentage of completion through the path.
9- 0=OFF 1=ON CLIMBING JACKPOT When this is enabled it will allow the jackpot
to randomly climb at the completion of a game. (Default setting is “1") NOTE: If you
have multiple games linked, their jackpots will all climb together.
10- SET 10-500 AVG PLAYS 2 JACKPOT This sets the average amount of games
played between each jackpot. (Default setting is “75") NOTE 1: The game will
automatically maintain this average by adjusting its internal difficulty setting based
upon the players at your location. NOTE 2: If you have multiple games linked, this
setting will apply to all. NOTE 3: Each time this setting is changed the averaging
process is restarted.
11- SET 0-500 JACKPOT MINIMUM This sets the minimum jackpot number. After a
jackpot is won the jackpot number will return to this setting. (Default setting is “100")
NOTE: If you have multiple games linked, their jackpots will all return to this setting
together.
12- SET 0-9000 MAXIMUM This sets the maximum number the jackpot can climb to.
(Default setting is “5000") NOTE: You can only set this as low as the “jackpot
minimum” is set.
13- SET 1-4 MONEY PROMPT This sets which money prompt screen will be
displayed in attract mode. Setting “1" will display INSERT COIN, “2" is INSERT
TOKEN, “3" is INSERT CARD, and “4" is SWIPE CARD. (Default setting is “2")
14- 0=OFF 1=ON TICKET EMULATOR When this is enabled, the game will function
as if it had tickets but not require or dispense them. (Default setting is “0")
15- 0=NO 1=YES RESTORE DEFAULTS When this is set to “1" and you exit the
menu screen, all of the settings in options will be restored to their defaults. (Default
setting is “0")
Press the SERVICE button to return to the MAIN MENU options screen.

FLAMIN’ FINGER™Operator’s Manual
6
Upon touching the ACCOUNT box, the following items can be selected:
16- COIN COUNTER This screen displays the amount of coins that have been
inserted into the game. NOTE: If you have multiple games linked, this data will
remain independent to each game.
17- TEST CREDITS This screen displays the amount of times that the test credit
button was pressed. NOTE: If you have multiple games linked, this data will remain
independent to each game.
18- TICKET COUNTER This screen displays the amount of tickets that have been
dispensed from the game. NOTE: If you have multiple games linked, this data will
remain independent to each game.
19- JACKPOTS AWARDED This screen displays the amount of jackpots that have
been awarded. NOTE: If you have multiple games linked, this data will remain
independent to each game.
Press the SERVICE button to return to the MAIN MENU options screen.
Upon touching the DIAGNOS box, the following items can be selected:
20- REDS ON YELS ON MEM TEST BURN IN Press inside one of the red boxes to
select between turning all red or yellow led’s on, performing a memory test, or
running burn-in. Press the SERVICE button to exit the test.
21- ALL RED LED’S ON This screen lets you confirm all 1179 red led’s are properly
functioning. Press the SERVICE button to exit the test.
22- ALL YELLOW LED’S ON This screen lets you confirm all 1126 yellow led’s are
properly functioning. Press the SERVICE button to exit the test.
23- MEMORY TESY WAIT 1 MINUTE Wait at this screen while the memory is being
tested.
24- MEMORY TEST PASS This screen confirms that all memory has passed
inspection.
25- MEMORY TEST CPU FAIL This screen informs you that the memory inside of the
microprocessor has been corrupted. NOTE: Contact Namco Customer Service.
26- MEMORY TEST SMC FAIL This screen informs you that the memory inside of the
memory card has been corrupted. NOTE: Contact Namco Customer Service.
27- This animation is intended to burn-in all of the red and yellow led’s and you should
also hear audio playing out of both speakers. NOTE: Upon entering burn-in the two

FLAMIN’ FINGER™Operator’s Manual
7
miniature #259 bulbs located behind the red caps will flash once to confirm their
operation. Press the SERVICE button to exit the test.
Press the SERVICE button to return to the MAIN MENU options screen.
Other screen messages that may appear are as follows:
28- MEMORY CARD NOT SELECTED Check to see if the memory card is fully
inserted in the proper direction. The memory card is located at site “P3" (upper
right corner) on the backside of the circuit board. Remove the back panel of the
game cabinet to gain access to the circuit board.
29- TESTING SENSORS AND LINK OPERATION On power-up while this screen is
displayed the game will confirm the operation of the sensors and the link cable.
30- LINK ERROR VER. NOT LINKABLE The version of software running on each
individual game is not intended to link with each other.
31- SENSOR ERROR BLOCKED OR FAILED During this screen you will see red dots
at the edge informing you where an emitter or receiver has failed to communicate.
32- PRESS MENU TO SYNC ALL GAMES This screen is displayed when data is not
matching across multiple games. Press the service menu button (located inside coin
door on left wall) on any game to automatically synchronize data across all games.
33- LINK ERROR CHECK INPUT There is a break in the communication cable on the
input side of any game with this screen displayed.
34- LINK ERROR There is a break somewhere in the network of games. Refer to the
game(s) displaying “CHECK INPUT”.
35- OFF-LINE PLEASE WAIT While this screen is displayed the game will be in a lock
out mode, waiting to receive information from the game that has entered main
menu. NOTE: This screen will only be displayed if you have multiple games linked.
36- SAVING DATA This screen is displayed after you exit the main menu. When the
saving of data is complete the game will return to power up mode.
37- OUT OF TICKETS, TICKETS OWED This animation will be displayed when the
game has run out of tickets or when the tickets have become jammed. Feeding in
tickets to the ticket mech will automatically return the game to normal operation.
6.0 GAME PLAY

FLAMIN’ FINGER™Operator’s Manual
8
The starting game time ranges in time allowed to complete the maze from 9 to 30
seconds, depending on the length of the maze, as well as an internal difficulty set
by the skill level of the players that have won the jackpot. The game time is not
adjustable by the operator. However, game difficulty can be adjusted indirectly by
the operator by changing the average games to jackpot value (see screen item
#18). Low values make the game easier (win jackpot more often). High values
make the game harder (win jackpot less often).
7.0 TROUBLESHOOTING

FLAMIN’ FINGER™Operator’s Manual
9
Problem Probable Cause Solution
No motion sound. 1) No AC power. 1) Check AC input plug on switching
power supply. Verify PS switch is
ON. Check DC output voltage at 9-
pin connector. RED to BLK should be
5+/-.15VDC. ORG to BLK should be
12VDC -0/+1.8VDC. If 12VDC is bad,
check for output shorts by removing
load connectors one at a time (ref.
overall wiring diagram in Appendix).
If loads are OK, or if 5VDC is out of
adjustment, (4.95 to 5.05), adjust
power supply.
2) No DC power. 2) Check AC input plug on switching
power supply. Verify PS switch is
ON. Check DC output voltage at 9-
pin connector. RED to BLK should be
5+/-.15VDC. ORG to BLK should be
12VDC -0/+1.8VDC. If 12VDC is bad,
check for output shorts by removing
load connectors one at a time (ref.
overall wiring diagram in Appendix).
If loads are OK, or if 5VDC is out of
adjustment, (4.95 to 5.05), adjust
power supply.
3) Main PCB problem. 3) If main PCB rack is suspected bad,
verify by swapping with known good
unit. If service is req’d, contact your
Distributor.
No audio. 1) Cables bad, or incorrectly
connected. 1) Check connectors on MAIN PCB.
2) Sound output set too low. 2)
A
djust audio volume in OPTIONS
under MAIN MENU. Ref. GAME
VOLUME or ATTRACT VOLUME.
Distorted audio. 1) Volume set too high. 1) Adjust in OPTIONS under MAIN
MENU. Ref. GAME VOLUME or
ATTRACT VOLUME.
2) Main PCB problem. 2) Main PCB rack requires service.
3) Incorrect speaker impedance. 3) Verify 4 ohm speakers.
APPENDIX A: PARTS LIST

FLAMIN’ FINGER™Operator’s Manual
10
CABINET ASSEMBLY
Part Number Description
FI63-10974-00 CABINET, FLAMIN’ FINGER
FI40-10911-00 MARQUEE
VG57-10972-00 SOCKET, LAMP, COMPACT FLUORESCENT
FI57-10922-00 STROBE LENS, RED
FI95-10973-00 PLEX, PLAYFIELD
FI40-10914-00 DECAL, GAME INSTRUCTIONS
FI05-10918-00 CPU, MAIN LOGIC
VG88-08776-00 POWER SUPPLY, 200W, ATX STYLE
FI45-10919-00 MANUAL, FLAMIN’ FINGER
VG57-10994-00 BULB, G-3v, WEDGE, # 259
VG57-10993-00 COMPACT FLOURESCENT LIGHT BULB (Marquee Light)

FLAMIN’ FINGER™Operator’s Manual
11

FLAMIN’ FINGER™Operator’s Manual
12
APPENDIX B: WIRING DIAGRAM

FLAMIN’ FINGER™Operator’s Manual
13
APPENDIX C: LINK DIAGRAMS

WARRANTY
Seller warrants that its printed circuit boards and parts thereon are free from defects in materials
and workmanship under normal use and service for a period of ninety (90) days from the date of
shipment. Seller warrants that its video displays (in games supplied with video displays) are free
from defects in material and workmanship under normal use and service for a period of thirty
(30) days from the date of shipment. None of the Seller’s other products or parts thereof are
warranted. Seller’s sole liability shall be, at its option, to repair, replace, or credit Buyer’s
account for such products which are returned to Seller during said warranty period, provided:
a) Seller is promptly notified in writing upon discovery by Buyer that said products are
defective.
b) Such products are returned prepaid to Seller's plant; and
c) Seller's examination of said products discloses to Seller's satisfaction that such alleged
defects existed and were not caused by accident, misuse, neglect, alteration, improper
repair, improper installation, or improper testing.
In no event shall Seller be liable for loss of profits. loss of use, incidental or consequential
damages.
Except for any express warranty set forth in a written contract between Seller and Buyer which
contract supersedes the terms herein, this warranty is in lieu of all other warranties expressed or
implied, including the implied warranties of merchantability and fitness for a particular purpose,
and all other obligations or liabilities on the Seller's part, and it neither assumes nor authorizes
any other person to assume for the Seller any other liabilities in connection with the sale of
products by Seller.
Namco America Inc. distributors are independent, being privately owned and operated. In their
judgment they may sell parts or accessories other than Namco America Inc. parts or
accessories. Namco America Inc. cannot be responsible for the quality, suitability or safety of
any non-Namco America Inc. part or any modification including labor that is performed by such
distributor.
SERVICE
If you have questions regarding any Namco America Inc. product or require technical support:
Contact Namco America Inc. Customer Service at:
[phone] or FAX [phone]
Hours: 8:00 am - 4:00 pm PST
Parts and repair services for Namco America Inc.
products are available through your distributor.

NAMCO AMERICA INC.
890 Service St. # C
San Jose, CA 95112
[phone]
FAX: [phone]
Technical Assistance (USA)
[phone] Fax: [phone]
Reorder Number FI45-10919-00
REV. A NOVEMBER 2003
The specifications of this machine and the instructions in this Operation Manual are subject to change
without notice for enhancement.
