Nautilus F3AHE User manual

Model: F3AHE
P/N: 001-4089 Rev A (03/20/07)
Assembly Manual
Commercial Free Weights
Adjustable Hip Extension
Be Strong.™

2
PREFACE/TABLE OF CONTENTS
Thank you for purchasing the Nautilus
®
Commercial Free Weights Adjustable Hip Extension. For more
than 30 years Nautilus
®
has been producing the world’s finest fitness equipment used in health clubs and
homes around the globe. We hope this product exceeds your expectations and is a valuable tool for your
facility.
Please carefully read through this manual to familiarize yourself with the operation of your new Nautilus
®
Commercial Free Weights Adjustable Hip Extension. Doing so will help to insure that your users get the
most out of your Adjustable Hip Extension, enjoying safe and effective workouts ahead.
Nautilus, Inc.
World Headquarters
16400 SE Nautilus Drive
Vancouver, Washington, USA 98683
1-800-NAUTILUS
www.nautilus.com
TABLE OF CONTENTS
Safety Precautions/
Product Specifications ..............................3
Before You Assemble.................................4
Hardware and Tools ...................................5
Box Contents ...............................................6
Assembly Guide ..........................................8
Assembly Complete....................................14
Companion Exercise Equipment...............15
Limited Warranty.........................................16
Important Contact Numbers .....................17

3
Nautilus® Commercial Free Weights Adjustable Hip Extension Assembly Manual
SAFETY PRECAUTIONS/PRODUCT SPECIFICATIONS
IMPORTANT SAFETY INSTRUCTIONS
The following definition applies to the word “WARNING” when used in this manual:
Used to call attention to POTENTIAL hazards that could result in personal
injury or loss of life.
READ ALL INSTRUCTIONS BEFORE USING THE MACHINE.
PRODUCT SPECIFICATIONS
User Weight Capacity: 350 lbs / 158.7 kg
Dimensions (assembled): 37”w x 62.2”l x 33”h / 93.9 cm x 157.9 cm x 83.8 cm
Shipping Weight: 183.6 lbs / 83.3 kg
Net Weight: 159 lbs / 72.1 kg
Power Requirements: Self Generating
7!2.).'
!44%.4)/.
$!.'%2
)--%$)!4%!#4)/.2%15)2%$
#!54)/.
7!2.).'
!44%.4)/.
$!.'%2
)--%$)!4%!#4)/.2%15)2%$
#!54)/.
7!2.).'
!44%.4)/.
$!.'%2
)--%$)!4%!#4)/.2%15)2%$
#!54)/.
For your safety, perform
all assembly steps in the
sequence given. Improper
assembly can lead to injury.
Some components can
be heavy or awkward
to handle. Get help if
necessary.

4
BEFORE YOU ASSEMBLE
Note: Throughout this manual, all references to the left or right
side and to the front or back are made as if you were standing on
a level surface and facing the Adjustable Hip Extension.
Basic Assembly Principals
Here are few basic assembly tips that can make assembly of your
Nautilus®Commercial Free Weights Adjustable Hip Extension
quick and easy.
1. You can make the assembly process go faster by gathering the
pieces you need for each step prior to starting the step.
2. As a general rule, and for all fasteners on your Nautilus®
Commercial Free Weights Adjustable Hip Extension , turning
toward the right will tighten, turning towards the left will
loosen. An easy way to remember this is by remembering the
expression, “Lefty loosey, righty tighty.”
3. Not all of the tools needed to assemble your Nautilus®
Commercial Free Weights Adjustable Hip Extension are
provided. Refer to the Tool List. You may find the use of a utility
knife or scissors beneficial during the unpacking and assembly
process.
4. It is recommended that you use two people to assemble
your Nautilus® Commercial Free Weights Adjustable Hip
Extension .
Positioning Your Nautilus® Commercial Free Weights
Adjustable Hip Extension
Take great care when moving your Commercial Free Weights
Adjustable Hip Extension into place prior to assembly.
The Adjustable Hip Extension is heavy and requires two people
to safely move from one location to another. To move, use only the
handle to roll the unit. Never pick up the unit by any moving parts.

5
Nautilus® Commercial Free Weights Adjustable Hip Extension Assembly Manual
REF # DESCRIPTION QTY
1 WRENCH, ALLEN HEX 7/32 BLK 1
2 WRENCH, ALLEN HEX 5/32 BLK 1
3 WRENCH, ALLEN HEX 5/16 BLK 1
4 SCW-BHCS 0500x3.25 G5-BLKZ 2
5 SCW-FHSCS 0250x1 G5-BLKZ 2
6 WSH-FLAT O500 REGULAR BLKZ 17
7 WSH-FLAT O375 REGULAR BLKZ 4
8 SCW-FHSCS 0500x5.5 G5-BLKZ 2
9 NUT-NL 0500 G5-BLKZ 9
10 SCW-BHCS 0500x4.25 G5-BLKZ 2
11 SCW-BHCS 0500x1.25 G5-BLKZ 1
12 SCW-BHCS 0500x3.75 G5-BLKZ 2
13 SCW-BHCS 0500x5.0 G5-BLKZ 1
14 SCW-BHCS 0375x1.25 G5-BLKZ 4
HARDWARE CARD
HARDWARE NOT TO SCALE
HARDWARE AND TOOLS
TOOLS NOT PROVIDED
3/4” Wrench or Adjustable Wrench
4
13
5
14
11
3
1
2
97
6
8
10
12

6
BOX #1
REF # DESCRIPTION QTY
3 FRONT LEG ASSEMBLY 1
4 FOOT PLATE ASSEMBLY 1
5 FRONT AND REAR TELESCOPING ASSEMBLY 1
6 PLATE, WEIGHT HOLDER 1
7 HANDLE ASSEMBLY 1
8 ROLLER SHAFT ASSEMBLY 1
9 PAD FLANGE 2
10 WASHER, BUMPER END 2
11 CAP, WEIGHT HORN 2
12 HARDWARE CARD - F3AHE 1
13 BACK FRAME ASSEMBLY 1
14 F3AHE ASSEMBLY INSTRUCTION 1
BOX CONTENTS
11
10
9
6
8
7
5
4
3
13
12
14

7
Nautilus® Commercial Free Weights Adjustable Hip Extension Assembly Manual
UPHOLSTERY
REF # DESCRIPTION QTY
3 HIP PAD ASSEMBLY, RIGHT 1
4 HIP PAD ASSEMBLY, LEFT 1
5 FOAM, THIGH ROLLER 2
BOX CONTENTS
5
3
4

8
Step 1: Attach Front Leg Assembly and Weight Holder
Plate to Back Frame
Locate the following for this step:
Parts:
• Ref 3, Front Leg Assembly Qty. 1
• Ref 13, Back Frame Assembly Qty. 1
• Ref 6, Plate, Weight Holder Qty. 1
Hardware:
• Ref 13, 1/2” x 5” Button Head Bolt Qty. 1
• Ref 6, 1/2” Washers Qty. 4
• Ref 8, 1/2” x 5 1/2” Flat Head Bolt Qty. 2
• Ref 9, 1/2” Nylock Nuts Qty. 3
Tools:
• Ref 3, 5/16” Allen Wrench
• 3/4” Wrench
Refer to Figure 1:
1-1 Place the c-channel of the Back Frame Assembly
around the front tube of the Front Leg Assembly
with the hole pattern aligned.
1-2 Place the Weight Holder Plate on top of the two
assemblies and secure using the hardware
listed. The flat head bolts are used in fastening
the Plate to the Legs and Back Frame.
The following instructions provide direction in assembling the Frame, Leg, Plate, and Telescoping Assemblies, Footplate, Handle, Hip
Pads, Roller Pads, Upholstery Roller, and Weighthorn Cap for the Nautilus® Commercial Free Weights Adjustable Hip Extension. All
instructions in the manual are given with the orientation of standing on a level surface and facing the machine.
Figure 1:
ASSEMBLY GUIDE

9
Nautilus® Commercial Free Weights Adjustable Hip Extension Assembly Manual
Step 2: Attach Telescoping Assembly to Back Frame
Locate the following for this step:
Parts:
• Ref 13, Back Frame Assembly Qty. 1
• Ref 5, Front and Rear Telescoping Assembly
Qty. 1
Hardware:
• Ref 10, 1/2” x 4 1/4” Button Head Bolt Qty. 2
• Ref 6, 1/2” Washers Qty. 4
• Ref 9, 1/2” Nylock Nuts Qty. 2
Tools:
• Ref 3, 5/16” Allen Wrench
• 3/4” Wrench
Refer to Figure 2:
2-1 Place the Front and Rear Telescoping Assembly
tubes in the c-channels on the Back Frame
Assembly.
2-2 Using the hardware above, fasten the
Telescoping Assembly to the Frame. Be sure that
the hardware is tight and the Telescoping
Assembly adjusts freely.
Figure 2:
ASSEMBLY GUIDE

10
Step 3: Attach Foot Plate to Telescoping Assembly
Locate the following for this step:
Parts:
• Ref 5, Front and Rear Telescoping Assembly Qty. 1
• Ref 4, Foot Plate Assembly Qty. 1
Hardware:
• Ref 12, 1/2” x 3 3/4” Button Head Bolt Qty. 2
• Ref 6, 1/2” Washers Qty. 4
• Ref 9, 1/2” Nylock Nuts Qty. 2
Tools:
• Ref 3, 5/16” Allen Wrench
• 3/4” Wrench
Refer to Figure 3:
3-1 Place the c-channel of the Foot Plate Assembly on
the Telescoping Assembly.
3-2 With the holes aligned, securely fasten with
the hardware.
Figure 3:
ASSEMBLY GUIDE
