High ﬂyer

Thank you for buying an NEC phone. You’ve bought a beautifully designed phone with engaging features

from one of the ten largest electronics companies in the world. We have a reputation for innovation and

we’d like to welcome you to a new world of mobile communications.

Your new NEC phone

Your new N400i phone is packed with must-have features and the latest i-mode™ technology. With the

help of this user guide you’ll soon be surﬁng the web with the super-fast i-mode browser and sending your

friends great clips and pictures thanks to your integrated MPEG4 video and digital zoom cameras with

nightlight. Plus, you can keep your phone constantly updated with all the latest games, applications and

polyphonic ring tones. This manual will guide you through all these great features and help you make the

best of your new phone.

39571_NEC_Man_N400i_Item25 24/2/04 2:43 pm Page 5

Emergency Services and Safety Precautions

Emergency Services

To make an emergency call in any country

☛Press 1 1 2 .

Ask the operator for the service which you require: Police, Ambulance, Fire Brigade,

Coastguard or Mountain Rescue Services. Give your position and, if possible, remain

stationary to maintain phone contact.

The 112 emergency number service is available on every digital network service. The

number 999 is an alternative emergency number for the UK only, and can only be used

with a valid SIM card.

2Due to the nature of the cellular system, the success of emergency calls cannot

be guaranteed.

General Care

A cellphone contains delicate electronic circuitry, magnets, and battery systems. You

should treat it with care and give particular attention to the following points.

•Do not allow the phone or its accessories to come into contact with liquid or moisture

at any time.

•Do not place anything in the folded phone.

•Do not expose your phone to extreme high or low temperatures.

•Do not expose your phone to naked flame, cigars or cigarettes.

•Do not paint your phone.

•Do not drop or subject your phone to rough treatment.

•Do not place the phone alongside computer disks, credit cards, travel cards and other

magnetic media. The information contained on disks or cards may be affected by the

phone.

•Do not leave the phone or the battery in places where the temperature could exceed

60°C; e.g. on a car dashboard or on a window sill, behind glass in direct sunlight, etc.

•Do not remove the phone’s battery while the phone is switched on.

•Take care not to allow metal objects, such as coins or key rings, to contact or short-

circuit the battery terminals.

•Do not dispose of battery packs in a fire. Your phone's Li-ion batteries may be safely

disposed of at Li-ion recycling points. For more specific battery and power supply

information, see page 3.

•Do not put your phone's battery in your mouth as battery electrolytes may be toxic if

swallowed.

•Do not attempt to dismantle the phone or any of its accessories.

•This equipment is fitted with an internal battery that can only be replaced by a qualified

service engineer. There is a risk of explosion if the battery is replaced by an incorrect

type. Dispose of the used battery in accordance with the manufacturer's instructions.

•Using any battery pack, AC adapter, Vehicle power adapter (option) or Desktop

charger (option) not specified by the manufacturer for use with this phone creates a

potential safety hazard.

•The earpiece may become warm during normal use and the unit itself may become

warm during charging.

•Use a damp or anti-static cloth to clean the phone. Do NOT use a dry cloth or

electrostatically charged cloth. Do not use chemical or abrasive cleaners as these

could damage the case.

•Remember to recycle: the cardboard packaging supplied with this phone is ideal for

recycling.

•Do not leave the battery pack empty or disconnected for a long time, otherwise some

data may be initialized.

•Your phone contains metal which may cause you an itch, a rash or eczema depending

on your constitution or physical condition.

•Take care not to put your phone in the back pocket of your trousers or skirt and then

sit on it. Also, do not put your phone at the bottom of bag where it may subject to

excessive weight or pressure.

Doing so may damage the LCD and camera lens and cause them malfunction.

•Take care not to hold the Light too close to your or other people’s eyes when the Light

is lit.

•Do not aim or direct the InfraRed (IR) data port towards your or other people’s eyes

when using the IR data exchange.

•The foam covers the earpiece of the headset. Do not put any other part of the headset

in your ears.

Aircraft Safety

•Switch off your phone and remove its battery when inside or near aircraft. The use of

cellphones in aircraft is illegal. It may be dangerous to the operation of the aircraft and

it may disrupt the cellular network. Failure to observe this instruction may lead to

suspension or denial of cellphone service to the offender, or legal action, or both.

•Do not use your phone on the ground without the permission of the ground crew.

Hospital Safety

•Switch off your phone in areas where the use of cellphones is prohibited. Follow the

instructions given by the respective medical facility regarding the use of cellphones on

their premises.

General Safety

•Observe ‘Turn off 2-way radio’ signs, such as those near stores of fuel, chemicals or

explosives.

•Do not allow children to play with the phone, charger or batteries.

•Small parts are included in your phone. Keep them out of reach of small children, for

whom it could be a choking hazard.

•The operation of some medical electronic devices, such as hearing aids and

pacemakers, may be affected if a cellphone is used next to them. Observe any warning

signs and manufacturer's recommendations.

•If you have a weak heart, you should take extra precautions when setting functions

such as the Vibrator and Ringer volume functions for incoming calls.

•If you set the Vibrator setting to anything other than OFF, be careful that the phone is

not near a source of heat (e.g. a heater) and that it does not fall from a desk due to the

vibration.

Road Safety

•You MUST exercise proper control of your vehicle at all times. Give full attention to

driving.

•Observe all the recommendations contained in your local traffic safety documentation.

•Pull off the road and park before making or answering a call if driving conditions so

require.

•You MUST NOT stop on the hard shoulder of a motorway to answer or make a call,

except in an emergency.

•Switch off your phone at a refuelling point, such as a petrol station, even if you are not

refuelling your own car.

•Do not store or carry flammable or explosive materials in the same compartment where

a radio transmitter, such as a cellphone, is placed.

•Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection

systems are not normally affected by radio transmissions. The manufacturer of such

equipment can advise if it is adequately shielded from radio transmissions. If you

suspect vehicle problems caused by radio transmissions, consult your dealer and do

not switch on your phone until it has been checked by qualified approved installers.

Vehicles Equipped with an Air Bag

An air bag inflates with great force. Do not place objects, including either installed or

portable wireless equipment, in the area over the air bag or in the air bag deployment

area. If in-vehicle wireless equipment is improperly installed and the air bag inflates,

serious injury could result.

Third Party Equipment

The use of third party equipment, cables or accessories, not made or authorized by NEC,

may invalidate the warranty of your cellphone and also adversely affect the phone’s

operation. For example use only the NEC mains cable supplied with the AC charger.

Service

The cellphone, batteries and charger contain no user-serviceable parts. We recommend

that your NEC cellphone is serviced or repaired by an NEC authorized service centre.

Please contact your Service Provider or NEC for advice.

Non-Ionizing Radiations

The radio equipment shall be connected to the antenna via a non-radiating cable (e.g.

coax).

The antenna shall be mounted in a position such that no part of the human body will

normally rest close to any part of the antenna unless there is an intervening metallic

screen, for example, the metallic roof.

Use only an antenna that has been specifically designed for your phone. Use of

unauthorized antennas, modifications or attachments could damage your phone and

may violate the appropriate regulations, causing loss of performance and radio

frequency (RF) energy above the recommended limits.

Efficient Use

For optimum performance with minimum power consumption, note the following:

•Your phone has the internal antenna. Do not cover part of the internal antenna of the

phone with your hands. This affects call quality, may cause the phone to operate at a

higher power level than needed and may shorten talk and standby times.

Radio Frequency Energy

Your phone is a low-power radio transmitter and receiver. When it is turned on, it

intermittently receives and transmits radio frequency (RF) energy (radio waves). The

system that handles the call controls the power level at which the phone transmits.

Exposure to Radio Frequency Energy

Your phone is designed not to exceed the limits for exposure to RF energy set by

national authorities and international health agencies. * These limits are part of

comprehensive guidelines and establish permitted levels of radio wave exposure for the

general population. The guidelines were developed by independent scientific

organizations such as ICNIRP (International Commission on Non-Ionizing Radiation

Protection) through periodic and thorough evaluation of scientific studies. The limits

include a substantial safety margin designed to assure the safety of all persons,

regardless of age and health, and to account for any variations in measurements.

*Examples of radio frequency exposure guidelines and standards that your phone is

designed to conform to:

•ICNIRP, “Guidelines for limiting exposure to time-varying electric, magnetic, and

electromagnetic fields (up to 300 G Hz)-International Commission on Non-Ionizing

Radiation Protection (ICNIRP)”.

Health Physics, vol. 74. pp, 494-522, April 1998.

•99/519/EC Council Recommendation on the limitation of exposure to the general

public to electromagnetic fields 0 Hz-300 GHz, Official Journal of the European

Communities, July 12,1999.

•ANSI/IEEE C95.1-1992. “Safety levels with respect to human exposure to radio

frequency electromagnetic fields, 3kHz to 300 GHz”. The Institute of Electrical and

Electronics Engineers Inc., New York, 1991.

•FCC Report and Order, ET Docket 93-62, FCC 96-326, Federal Communications

Commission (FCC), August 1996.

•Radio communications (Electromagnetic Radiation Human Exposure) Standard 1999,

Australian Communications Authority (ACA), May 1999.

Declaration of Conformity

•This product complies with the requirements of the R&TTE Directive 1999/5/EC. The

‘Declaration of Conformity’ leaflet can be found within this box.

Licenses

•T9®Text Input and the T9 logo are registered trademarks of Tegic Communication.

“T9 Text Input is licensed under one or more of the following:

U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554, and

6,307,548; Australian Pat. No. 727539; Canadian Pat. No. 1,331,057; United Kingdom

Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore

Pat. No. 51383; Euro. Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL, PT. ES,

SE, GB; Republic of Korea Pat. Nos. KR201211B1 and KR226206B1; and additional

patents are pending worldwide”

•USE OF THIS PRODUCT IN ANY MANNER THAT COMPLIES WITH THE MPEG-4

VISUAL STANDARD IS PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO

(A) DATA OR INFORMATION ENCODED BY A CONSUMER FOR PERSONAL AND

NON-COMMERCIAL USE WITHOUT REMUNERATION; (B) DATA OR

INFORMATION (i) GENERATED BY AND OBTAINED WITHOUT CHARGE FROM A

CONSUMER NOT THEREBY ENGAGED IN A BUSINESS ENTERPRISE, AND (ii)

FOR PERSONAL USE ONLY; AND (C) OTHER USES SPECIFICALLY AND

SEPARATELY LICENSED BY MPEG LA, L.L.C.

•Helvetica is a registered Trademark of Heidelberger Druckmaschinen AG which may

be registered in certain jurisdictions.

•Powered by Mascot Capsule®/Micro3D Edition™

•Java and all Java-based trademarks and logos are trademarks or registered

trademarks of Sun Microsystems, Inc in the U.S. and other countries.

•This product contains ACCESS Co., LTD’s Compact NetFront™ Plus internet browser

software.

Compact NetFront™ is a registered trademark or trademark of ACCESS CO., LTD in

Japan and selected countries worldwide.

•This product contains ACCESS CO., LTD’s JV-Lite2™ Java virtual machine software.

JV-Lite2™ is a registered trade mark or trademark of ACCESS COl, LTD, in Japan and

selected countries world wide.

•This product contains ACCESS CO., LTD's IrFront® Infrared communication software.

•i-mode and i-mode logos are trademarks or registered trademarks of NTT DoCoMo.

For the purpose of improvement, the specifications for this product and its accessories

are subject to complete or partial change without prior notice.

iii

Before You Start

Cellphone system structure

It is worth remembering that every time you use your phone, three or four different organizations are involved:

All the features described in this user’s manual are supported by your phone. However, for all these features to work, you must have a SIM card (supplied

by your service provider) that also supports these features. Even if you have a fully featured SIM card, any feature not supported by the Network

transmitting your call will not work. This last point is especially important when you are roaming networks (see page 12).

User’s manual conventions

The instructions in this user’s manual make use of the shortcuts selection except special cases.

The following markers are used throughout the user’s manual to attract your attention:

/This type of paragraph will contain details of where to find information related to the topic in question.

2This type of paragraph will contain information worth noting.

,This type of paragraph will contain important information.

The people that supply

your SIM card and bills

Service

Provider

Thepeoplethat

transmit your calls

Network

Thepeoplethat

provide your Internet services

i-mode Service Provider

Thepeoplethat

make your phone

N400i

Display information

,The LCDs on your phone are manufactured using high-precision technology. Even so, the LCDs may contain pixels (dots) that fail to light

or that remain permanently lit. Note that this is normal and does not indicate a problem with your display.

Check box/Radio button

A check box enables/disables an option out of a set of options, and multiple check boxes can be selected at the same time. On the other hand, selecting

a radio button automatically cancels the previous selection, so only one radio button can be selected at one time.

A check box/radio button option can be selected/cancelled by highlighting it and pressing .

Status bar area

This area contains icons

which indicate the battery

strength, new SMS/mail/

MMS message(s), signal

strength, etc. (see

page vii).

On screens other than the

standby screen, the clock

display is placed in this

area.

Help area

This area contains help information

appropriate for the current screen

(e.g. key presses remaining when

composing a message).

Softkey area

This area contains context sensitive

descriptions of the Softkeys’

functions appropriate for the current

screen.

Shortcut number

Press the appropriate number

to jump straight to a next

menu.

The row colour is changed

when selected (e.g. to

activate/deactivate a facility).

Help icons

Displayed when you can use the

key represented by these icons

(see page vii).

Next menu icon

Displayed when you can press the key

or the shortcut number to show the next

menu.

▼

Page scroll bar

Displayed when you can

press the ▼key to scroll to

the next page.

Shortcut menu number

The current menu number is

displayed.

Menu title

Parts and functions

N400i

Side up key

Earpiece

Main-LCD

4 way navigation key( )

Phonebook key

Center key( )

End/on-off key

Through-hole

for straps

Earphone

jack cover

Mouthpiece

Side down key

Charger

connection

cover

Softkey 2Softkey 1

MENU key

Send key

Clear(CLR)/Back key

Alphanumeric keys

Internal antenna

2nd-LCD

LED

Camera

Light

IR port

Battery lock

Battery

Speaker

Keypad shortcuts

The following operations are available from the standby screen.

Key Operation that involves pressing a key See page Operation that involves pressing and holding a key See page

Accessing the Main menu screen 18 Setting the Side key lock 19

Softkey 1 Accessing the Mail screen 47 Accessing the Inbox screen 48

Softkey 2 Accessing the i-mode menu screen 44 Accessing the list of Java™ applications 72

Accessing the Phonebook list screen 55 Accessing the Message screen 29

▲Accessing the Phone modes screen 21 Setting the phone to Meeting mode 21

▼Accessing the My data screen 67 Accessing the voice recall 8

Accessing the received calls list 8 – –

Accessing the missed calls list 8 – –

Accessing the dialled calls list 8 – –

Accessing the camera view finder screen 63 Accessing the video camera view finder screen 64

Ending a call or returning to the standby screen – Powering off 3

CLR Deleting character or returning to the previous screen – Deleting all characters when you enter text –

1Entering phone numbers 5 Calling the Voice mail centre 61

2to 9Entering phone numbers 5 Going to the corresponding phone number in the phone-

book(SIM) (One-touch dial) 7

0Entering phone numbers 5 Entering + when you make an international call 12

#Entering #6 Entering a pause –

Entering 6Switching the ALS line 1/2 19

Muting or retrieving the sound during a call 8

Side up Adjusting the volume when your phone is open 18 Displaying the homepage 46

Activating the ring silencer function when you receive a call 19

Side down Adjusting the volume when your phone is open 18 Turning on the light

(To turn it off, press any key or open/close your phone.) –

Activating the ring silencer function when you receive a call 19

▼

vii

LCD and displayed icons

Main-LCD

Indicates the battery level.

Appears while charging.

Indicates that there is a new message(s) in your

phone.

Indicates that there is a new message(s) on the

network.

Indicates that the SIM memory is full.

Indicates that the Inbox in your phone is full.

(green)

Indicates that there is a mail on the server.

(blue)

Indicates that there is an MMS on the server.

(pink)

Indicates that there are both mail and MMS on the

server.

(beige)

Indicates that there are unread mail/MMS on your

phone.

2This beige icon blinks while mail/MMS are being

downloaded.

Indicates that the memory for mail/MMS is full.

(red, red/green, green)

Indicates that new voice mail messages are on the

network (No ALS/ALS Line 1/2).

Indicates secured communication on SSL.

Indicates that GPRS is active for purposes other

than i-mode connections.

(gray)

Indicates that the phone is in the GSM network

sevice area and GPRS is active.

(yellow)

Indicates that the GPRS is available and i-mode is

active.

Indicates that the i-mode connection is carried out.

Indicates that the i-mode lock is on.

2No icon appears when the phone is outside the

GSM network service area, or when the phone is

in the GSM network service area and GPRS is

not attached.

Indicates the line status (ALS line 1/2 no ALS).The

icon with displayed in red indicates that the

ALS line 1or 2 is unencrypted/no ALS.

Indicates that the call diversion is set.

Indicates the Meeting mode, Pocket mode, Car

mode.

2No icon appears when the phone is in the Normal

mode.

Indicates the signal strength level.

Appears when you are outside the service area.

Indicates single/burst mode (camera).

Indicates the video mode.

Indicates that the video is played in normal/enlarged

screen size.

Indicates the camera’s shot environment.

Indicates the photo/video screen size.

Indicates the quality of the picture.

Indicates that the self timer is on.

Indicates that the camera’s light is on.

Indicates the brightness setting of the camera.

Indicates the zoom level.

123

54 6 7 8

viii

Indicates alarm-on,

sound-off

and vibrator-on.

Indicates that the auto start of a Java™ application has

failed.

Network Name (indicated in orange when using

roaming service)

Remote time

Local time

Day of week

Date

Indicates that you can use the options menu by

pressing .

Indicates that you can use the phonebook list by

pressing .

Indicates that you can move to the camera view

finder screen by pressing , or to the video camera

view finder screen by pressing and holding .

Indicates that a Java™ application is in operation.

Indicates the usable keys in black, while using the i-

mode facility or a Java™ application is in operation.

2nd-LCD

Indicates the signal strength level.

Appears when you are outside the service area.

Indicates the battery level.

Appears while charging.

Indicates that there is a new message(s) in your

phone.

Indicates that there is a new message(s) on the

network.

Indicates that the SIM memory is full.

Indicates that the Inbox in your phone is full.

(green)

Indicates that there is a mail on the server.

(blue)

Indicates that there is an MMS on the server.

(pink)

Indicates that there are both mail and MMS on the

server.

(yellow)

Indicates that there is a new mail/MMS in your

phone.

Indicates that the memory for mail/MMS is full.

(red, green/red, green)

Indicates that a new voice mail message is on the

network (No ALS/ALS Line 1/2).

Indicates that the phone is in the Meeting mode.

Indicates that the phone is in the Pocket mode.

Indicates that the phone is in the Car mode.

2No icon appears when the phone is in the Normal

mode.

<When 2nd-LCD is used as the camera view

finder screen>

Indicates single or burst mode of the camera.

Indicates the video mode.

Indicates that the self timer is on.

Indicates the brightness setting of the camera. The

“+2” setting is the brightest.

Indicates the quality of the picture (super fine, fine,

normal, economy or super economy).

Indicates that the video is in operation.

Overview of menu function

Key Main menu Second level menu

1 Settings Phone

Phone modes

Main-LCD

2nd-LCD

Power saving

Calls

Security

Network

Reset settings

2 Message Inbox

Drafts

Outbox

Sent

Folder1

Folder2

Key Main menu Second level menu

7 Java Programs

Prog backlight

8 Accessory Calculator

Clock alarm

Scheduler

ToDo list

Notepad

Voice memo

Currency

IR receive

9 SIM toolkit

➡➡

Standby screen Main menu screen

CLR

Key Main menu Second level menu

3 i-mode i-mode

Settings

4 Phonebook Lists

Information #

Call options

5 Camera Camera

Video recorder

6 My data Pictures

Videos

Sounds

Getting Started 1

Caring for Batteries 3

Basic Calls & Phone Use 5

Text Entry 13

IR Data Exchange 16

Selecting Features 18

Settings 18

Message 29

i-mode 37

Phonebook 53

Camera 62

My data 67

Java 72

Accessory 74

Abbreviations 82

Index 83

Before You Start iii

Cellphone system structure ............................................ iii

Display information ......................................................... iv

Parts and functions .......................................................... v

LCD and displayed icons ............................................... vii

Overview of menu function ............................................. ix

Getting Started 1

Preparing the phone ........................................................1

Start-up ............................................................................3

Caring for Batteries 3

Standby and talk times.....................................................3

Checking the battery ........................................................4

Low battery alarm ............................................................4

Other battery alarms ........................................................4

Changing the battery........................................................4

Basic Calls & Phone Use 5

Making basic calls............................................................5

Ending a call ....................................................................5

Receiving an incoming call ..............................................5

Putting a call on hold........................................................6

Unsuccessful calls ...........................................................6

Emergency calls...............................................................6

Last number redial ...........................................................6

One-touch dial..................................................................7

Fast dialling......................................................................7

Displaying your own phone number.................................7

Multi-party calls ................................................................7

Voice recall ......................................................................8

Mute.................................................................................8

Call options ......................................................................8

Call settings ................................................................... 10

International dialling codes ............................................12

Roaming.........................................................................12

Text Entry 13

Mode change ................................................................. 13

T9®English text input ....................................................14

Normal text input............................................................14

Numeric input.................................................................15

Key allocations...............................................................15

IR Data Exchange 16

Positioning of the phones...............................................16

IR send...........................................................................16

IR receive.......................................................................17

Selecting Features 18

Main menu .....................................................................18

Menu shortcuts selection ...............................................18

Settings 18

Phone.............................................................................18

Phone modes.................................................................21

Main-LCD.......................................................................24

2nd-LCD.........................................................................24

Power saving .................................................................26

Calls...............................................................................26

Security..........................................................................26

Network..........................................................................29

xii

Reset settings ................................................................ 29

Message 29

Message overview ......................................................... 29

Reading messages ........................................................ 30

Options menus............................................................... 31

Creating a message....................................................... 33

Cell broadcast ................................................................ 36

i-mode 37

i-mode operations .......................................................... 37

i-mode screen ................................................................ 43

i-mode menu screen ...................................................... 44

iMenu screen ................................................................. 46

Mail screen .................................................................... 47

i-mode glossary ............................................................. 52

Phonebook 53

Accessing your phonebook............................................ 53

Phonebook types ........................................................... 53

Phonebook list Options menu........................................ 55

Personal data Options menu .........................................60

Scratchpad number ....................................................... 61

Voice mail ...................................................................... 61

Camera 62

Notes on using the camera............................................ 62

Taking a picture ............................................................. 63

Recording a video.......................................................... 64

Camera Options menu................................................... 65

My data 67

Pictures.......................................................................... 67

Videos............................................................................ 68

Sounds........................................................................... 69

File selector Options menu............................................ 70

Java 72

Programs ....................................................................... 72

Prog backlight ................................................................ 73

Accessory 74

Calculator....................................................................... 74

Clock alarm.................................................................... 75

Scheduler....................................................................... 76

ToDo list......................................................................... 78

Notepad ......................................................................... 79

Voice memo................................................................... 80

Currency converter ........................................................ 81

IR receive....................................................................... 82

Abbreviations 82

Index 83

Getting Started

Preparing the phone

Before trying to use your phone, make sure a valid SIM card is inserted and the battery is charged.

SIM card

Before using your phone, you must sign-up with one of the digital network service providers. In addition to your subscription details you will receive a

personal SIM (Subscriber Identity Module) card which is inserted into your phone.

If the SIM card is removed, the phone becomes unusable until a valid SIM card is fitted. It is possible to transfer your SIM card to another compatible

phone and resume your network subscription. The screen on your phone will display appropriate messages if no SIM card is fitted.

,If the phone, or the SIM card, is lost or stolen then you should contact your service provider immediately in order to bar it from use.

2The phone supports a number of languages and the keyboard symbols have been chosen for world-wide operation.

2The digital technology of your phone helps to ensure that your conversations are kept secure.

2The SIM card contains personal data such as your electronic phonebook, messages (see page 29) and also details of the network services you have

subscribed to. The phone will not work (except for emergency calls on some networks) unless a valid SIM card is fitted.

,Be sure to turn the phone off before inserting and removing a SIM card. Otherwise damage to the SIM card can occur.

Inserting a SIM card

☛Release the battery lock in the direction of arrow ➀, and then lift the battery up in the direction of arrow ➁to remove it.

☛Place the straight end of SIM card with the metal part facing down.

☛Carefully move to slide the SIM card lock in the direction of arrow ➂and push the SIM card in the direction of arrow ➃to place the SIM card under

the lock.

SIM card lock SIM card

,Never pull the SIM card lock upward. Doing so may break the lock.

,If the SIM card is not fully inserted when the battery is replaced, damage to the SIM card can occur.

/If the SIM card is already fitted, see “Start-up” on page 3.

Removing a SIM card

☛With the battery removed and lightly holding down the SIM card, slide the SIM card lock in the direction of arrow ➂and remove the SIM card.

2The SIM card may pop out when you release the SIM card lock. Be careful not to drop it.

Charging the battery

Before trying to use your phone, insert the phone’s battery, connect the NEC battery charger (AC

adapter) supplied with your phone to a suitable mains power socket and then connect the charger’s

output to the phone’s charger connector.

☛Connect the charger plug (AC adapter) into the connector at the side of the phone. If your

phone is turned on, a message will be displayed on the 2nd-LCD. LED will turn on in red while

charging. When charging is complete, the LEC will turn off.

You are recommended to switch off the phone while charging. If you need to receive calls, your

phone can be switched on and left in standby while being charged, although the total time

taken to charge is then increased.

,Using any battery pack, AC adapter, vehicle power adapter (option) or desktop charger

(option) not specified by NEC for use with this phone can be dangerous and may invalidate

any warranty and approval given to the cellphone. Do not connect more than one charger

at any time. Do not leave the charger connected to the mains supply when it is not in use.

,Do not try to charge the battery if the ambient temperature is below 5°C (41°F) or above 35°C (95°F).

,DO NOT connect a charger or any other external DC source until the phone’s battery is inserted.

2If the phone does not respond, please wait for a few minutes. The charging will then start.

2If you use the phone while charging, handle the phone carefully since the cable or adapter is connected.

2If you make/receive a call while charging, the charging may temporarily be interrupted.

2You can also charge the phone using a desktop charger (option).

2Charging takes approximately 3 hours with your phone turned off.

Charger connector

LED

Charger plug

Start-up

Switching the phone on

☛Hold down for about a second to switch on. The screen will display the selected greeting (see page 24) and the phone is then in standby.

2You may need to charge the battery before using your phone. If the phone gives no response when switched on, read the information about batteries

on page 3.

2When your phone is turned on, the specified ringer may sound.

Switching the phone off

☛Hold down until the display shows the switch off message.

PIN code

The SIM card issued by your service provider has a security feature called PIN code protection. The PIN (Personal Identification Number) is a number

put on to the card by your service provider, and is 4 to 8 digits long. Some service providers supply SIM cards which will cause your phone to prompt for

a PIN code when it is turned on. If this is the case, enter your code with the phone’s keypad. If you insert a SIM card other than your own, information

such as call logs may be lost.

Caring for Batteries

Standby and talk times

Your phone works closely with the network you are using to provide the services you need, and the standby and talk times achieved will depend on how

you use the phone and choices made by the network operator.

In particular, factors such as your location within the network, the frequency at which this location is updated, the type of SIM card you have, your

reception of area messages or cell broadcast messages and the use of full rate or enhanced full rate speech, will affect both standby and talk times.

,IMPORTANT BATTERY CHARGING INFORMATION (Charging a very low battery)

The battery’s charge continues to drop after the low battery warning is displayed. In extreme cases where the battery is left uncharged for some

considerable time after this warning, a trickle charge is used to slowly top-up the battery to the safe level at which the fast charging can begin. The

phone can be in trickle charge for a few minutes before the fast charging starts.

,DO NOT connect a charger or any other external DC source if the phone’s battery is not inserted.

Checking the battery

☛Check icon at the top of the standby screen.

The block on the display shows the charge of your battery pack.

Full battery power Partial battery power Low battery power Battery empty

Low battery alarm

When the battery voltage falls below the working level, a low battery warning is displayed on screen accompanied by a short tone along with an empty

battery icon. The phone will automatically power down shortly afterwards.

2Please charge the battery as much as possible when the battery is very low.

Other battery alarms

Your phone may display warnings when the battery temperature is too high or the voltage of the battery or the charger is over the appropriate level. Follow

the instruction given by these warnings immediately, such as turning off the phone and removing the battery or charger.

Changing the battery

,Be sure to turn the phone off before replacing the battery pack.

☛Release the battery lock in the direction of arrow ➀, and then lift the battery up in the direction of arrow ➁to remove it.

☛Put the new battery, release the battery lock in the direction of arrow ➂, and push to slide the battery down under the lock (➃).

Battery lock

New battery

Basic Calls & Phone Use

Making basic calls

You make a simple call in the same way as you would with a normal phone, except that you need to press after entering the area STD code and the

phone number. To make international calls, you must first enter the international dialling code (see page 12).

2Use the full STD area code even if you are calling to a person in the same town. If the numbers are too long to be displayed within one line, excess

part is deleted and ‘...’ is added at its end.

2The main-LCD display shows the strength of the radio signal that links your phone to the network. The maximum signal strength is shown by 4 shaded

blocks and the minimum signal strength by 1 block.

Starting a call

☛Key in the phone number. Check the number on the display.

☛Press to send the input number to start the call.

When the call is sent, the screen displays the number called or the name stored in the phonebook and a connection graphic or a CLI picture that has

been allocated to the number called (see page 54).

Correcting mistakes

Use the and keys to move the cursor and then press CLR to clear individual digits, or hold down CLR to completely clear a phone number.

Ending a call

☛While talking, press briefly or close your phone. The phone returns to the standby screen.

2If is held down, your phone will turn off.

2When you use the headset, you can also end a call by pressing and hodling the button on it.

Receiving an incoming call

When someone calls your number, the ringer will sound (if set - see page 22), the LED glows in the specified colour, and the phone number of the caller

may be displayed if the calling line identification facility is available and the caller has activated the feature. If the caller’s phone number has been related

and stored in your phonebook with a name and a CLI picture (see page 57), that name and picture will be displayed. If the caller has withheld their identity,

the screen will give a message that the caller’s number is being withheld.

2You also have options for holding and forwarding calls. These options depend on your network and your subscription arrangements.

▼

Accepting an incoming call

☛While receiving an incoming call, press .

2When you use the headset, you can also accept an incoming call by pressing the button on it.

Rejecting an incoming call

☛While receiving an incoming call, press briefly or close your phone.

2When you use the headset, you can also reject an incoming call by pressing and holding the button on it.

If your phone receives a call and you do not answer it, the screen will display the phone number (or the name if stored) of the caller (if available). This
