NEC N900IG Guide

Front Assy
Reference Code Description Drawing No.
Main-LCD MAS-PH0022-A001 LTM022D220 MODULE,LCD MAS-PH0022-A001
Sub-LCD MAS-PH0020-A001 TM03D16VM1EA MODULE,LCD MAS-PH0020-A001
CIF-Camera MAS-PP0011-A001 GP-KM351MN camera module MAS-PP0011-A001
Mega-Camera MAS-PP0010-A001 GP-KM1001VN camera module MAS-PP0010-A001
Speaker MAS-DG0006-A001 DG0006-A SPEAKER MAS-DG0006-A001
MIC1100 MAS-DA0011-A001 DA0011-A MAS-DA0011-A001
MIC2400 MAS-DA0012-A001 DA0012-A MAS-DA0012-A001
SP2400 MAS-DB0011-A001 DB0011-A MAS-DB0011-A001
VIB MAS-BL0006-A001 404008A01 vaibration-mortor MAS-BL0006-A001
W-ANT MAS-ED0020-A001
ED0020(W-CDMA)built-in antenna
MAS-ED0020-A001
Wsub-ANT MAS-EY0003-A001
EY0003(W-CDMA)auxiliary antenna
MAS-EY0003-A001
GSM-ANT MAS-ED0021-A001 ED0021(GSM)built-in antenna MAS-ED0021-A001
GSMsub-ANT MAS-EY0004-A001 EY0004(GSM)auxiliary antenna MAS-EY0004-A001
Main-BL MAS-PM0015-A001 NSY-09A-4 MODULE,BACKLIGHT MAS-PM0015-A001
Sub-BL MAS-PM0016-A001 CBL1469A MODULE,BACKLIGHT MAS-PM0016-A001
Battery MAS-BD0024-A001
3.8V 1000MAH lithium secondary battery
MAS-BD0024-A001

Power Output Adjustment Procedure for 2G
•Connect HHP, Vanquish RS Tool and personal computer.
•Start up Maintenance Tool(OMTN2) for the adjustment.
•Press the PWR button to turn on the phone.
•The screen of the PC
1, Connection>Open
2, Renew>CCPU

3, Operation>scenario
4, Transmitter SIG is opened.
5, SUSPEND SET is chosen, and CCPU is checked, and Transmit button is pushed.
6, TRANCEMITTER SET is chosen, Transmit button is pushed.
•Power Output Adjustment
7, It is changed in the data window
#TRANSMITTER_SET/ In message / PCS 661ch PL 0 #
DATA 3B 00 0F 95 02 01 02 00 00 01 01
46 00 46 00 46 00 46 00 46 00 46 00 98 00
D8 00 2F 01 8E 01 EA 01 3C 02 AC 02 D9 02
B2 02 B2 02 B2 02
A4 02 7B 02 3C 02 EA 01 8E 01 2F 01 D8 00 98 00
46 00 46 00 46 00 46 00 46 00 46 00 46 00

8, After the values of highlight are changed, Send button is pushed.
: The values of the highlight are changed to change Mid-Burst power.
:C7 02=256*2+178=690

Appendix 1 command list
#SUSPEND_SET 0x21#
00 10 52 21 # SN DI MN SMN
34 00 # DATA
#TRANSMITTER_SET/ In message / PCS 661ch PL 0 #
00 10 52 13 # SN DI MN SMN
3B # Function ID Number
00 # Function Version
0F # flag;
9502 # carrierARFCN;
01 # transBurstType;
02 # modulation;
00 # powLevel;
00 # rampIndFlag(message -0, use default-1)
01 # carrierBAND;
01 # multiSlot;
46 00 46 00 46 00 46 00 46 00 46 00 98 00
D8 00 2F 01 8E 01 EA 01 3C 02 AC 02 D9 02
B2 02 B2 02 B2 02
A4 02 7B 02 3C 02 EA 01 8E 01 2F 01 D8 00 98 00
46 00 46 00 46 00 46 00 46 00 46 00 46 00 # Ramp data
00 # TCOMP FCOMP
