TFT COLOR LCD MODULE
NL10276BC24-21
31cm (12.1 Type)
XGA
LVDS interface (1port)
DATA SHEET
DOD-PP-1157 (1st edition)
Downloaded from Arrow.com.

NL10276BC24-21
DATA SHEET DOD-PP-1157 (1st edition) 2
INTRODUCTION
The Copyright to this document belongs to NEC LCD Technologies, Ltd. (hereinafter called "NEC").
No part of this document will be used, reproduced or copied without prior written consent of NEC.
NEC does and will not assume any liability for infringement of patents, copyrights or other intellectual
property rights of any third party arising out of or in connection with application of the products
described herein except for that directly attributable to mechanisms and workmanship thereof. No license,
express or implied, is granted under any patent, copyright or other intellectual property right of NEC.
Some electronic parts/components would fail or malfunction at a certain rate. In spite of every effort to
enhance reliability of products by NEC, the possibility of failures and malfunction might not be avoided
entirely. To prevent the risks of damage to death, human bodily injury or other property arising out
thereof or in connection therewith, each customer is required to take sufficient measures in its safety
designs and plans including, but not limited to, redundant system, fire-containment and anti-failure.
The products are classified into three quality grades: "Standard", "Special", and "Specific" of the
highest grade of a quality assurance program at the choice of a customer. Each quality grade is designed
for applications described below. Any customer who intends to use a product for application other than
that of Standard quality grade is required to contact an NEC sales representative in advance.
The Standard quality grade applies to the products developed, designed and manufactured in
accordance with the NEC standard quality assurance program, which are designed for such application as
any failure or malfunction of the products (sets) or parts/components incorporated therein a customer
uses are, directly or indirectly, free of any damage to death, human bodily injury or other property, like
general electronic devices.
Examples: Computers, office automation equipment, communications equipment, test and measurement
equipment, audio and visual equipment, home electronic appliances, machine tools, personal
electronic equipment, industrial robots, etc.
The Special quality grade applies to the products developed, designed and manufactured in accordance
with an NEC quality assurance program stricter than the standard one, which are designed for such
application as any failure or malfunction of the products (sets) or parts/components incorporated therein
a customer uses might directly cause any damage to death, human bodily injury or other property, or
such application under more severe condition than that defined in the Standard quality grade without
such direct damage.
Examples: Control systems for transportation equipment (automobiles, trains, ships, etc.), traffic control
systems, anti-disaster systems, anti-crime systems, medical equipment not specifically
designed for life support, safety equipment, etc.
The Specific quality grade applies to the products developed, designed and manufactured in accordance
with the standards or quality assurance program designated by a customer who requires an extremely
higher level of reliability and quality for such products.
Examples: Military systems, aircraft control equipment, aerospace equipment, nuclear reactor control
systems, medical equipment/devices/systems for life support, etc.
The quality grade of this product is the "Standard" unless otherwise specified in this document.
Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
DATA SHEET DOD-PP-1157 (1st edition) 3
CONTENTS
INTRODUCTION ..........................................................................................................................................2
1. OUTLINE....................................................................................................................................................4
1.1 STRUCTURE AND PRINCIPLE ........................................................................................................4
1.2 APPLICATION....................................................................................................................................4
1.3 FEATURES..........................................................................................................................................4
2. GENERAL SPECIFICATIONS................................................................................................................5
3. BLOCK DIAGRAM...................................................................................................................................6
4. DETAILED SPECIFICATIONS...............................................................................................................8
4.1 MECHANICAL SPECIFICATIONS...................................................................................................8
4.2 ABSOLUTE MAXIMUM RATINGS..................................................................................................8
4.3 ELECTRICAL CHARACTERISTICS.................................................................................................9
4.3.1 LCD panel signal processing board.............................................................................................9
4.3.2 Backlight lamp...........................................................................................................................10
4.3.3 Power supply voltage ripple.......................................................................................................10
4.3.4 Fuse............................................................................................................................................10
4.4 POWER SUPPLY VOLTAGE SEQUENCE.....................................................................................11
4.4.1 LCD panel signal processing board...........................................................................................11
4.4.2 LED driver board.......................................................................................................................11
4.5 CONNECTIONS AND FUNCTIONS FOR INTERFACE PINS......................................................12
4.5.1 LCD panel signal processing board...........................................................................................12
4.5.2 Backlight lamp...........................................................................................................................13
4.5.3 Positions of plug and socket ......................................................................................................13
4.5.4 Connection between receiver and transmitter for LVDS...........................................................14
4.5.5 Input data mapping ....................................................................................................................17
4.6 DISPLAY COLORS AND INPUT DATA SIGNALS.......................................................................18
4.6.1 Combinations of input data signals, FRC and MSL signal........................................................18
4.6.2 16,777,216 colors.......................................................................................................................19
4.6.3 262,144 colors............................................................................................................................20
4.7 DISPLAY POSITIONS......................................................................................................................21
4.8 SCANNING DIRECTIONS...............................................................................................................21
4.9 INPUT SIGNAL TIMINGS ...............................................................................................................22
4.9.1 Outline of input signal timings ..................................................................................................22
4.9.2 Timing characteristics................................................................................................................23
4.9.3 Input signal timing chart............................................................................................................24
4.10 OPTICS.............................................................................................................................................25
4.10.1 Optical characteristics..............................................................................................................25
4.10.2 Definition of contrast ratio.......................................................................................................26
4.10.3 Definition of luminance uniformity.........................................................................................26
4.10.4 Definition of response times....................................................................................................26
4.10.5 Definition of viewing angles....................................................................................................26
5. ESTIMATED LUMINANCE LIFETIME..............................................................................................27
6. RELIABILITY TESTS ............................................................................................................................28
7. PRECAUTIONS .......................................................................................................................................29
7.1 MEANING OF CAUTION SIGNS....................................................................................................29
7.2 CAUTIONS........................................................................................................................................29
7.3 ATTENTIONS....................................................................................................................................29
7.3.1 Handling of the product.............................................................................................................29
7.3.2 Environment...............................................................................................................................30
7.3.3 Characteristics............................................................................................................................30
7.3.4 Others.........................................................................................................................................30
8. OUTLINE DRAWINGS...........................................................................................................................31
8.1 FRONT VIEW....................................................................................................................................31
8.2 REAR VIEW ......................................................................................................................................32
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
1. OUTLINE
1.1 STRUCTURE AND PRINCIPLE
Color LCD module NL10276BC24-21 is composed of the amorphous silicon thin film transistor liquid
crystal display (a-Si TFT LCD) panel structure with driver LSIs for driving the TFT (Thin Film
Transistor) array and a backlight.
The a-Si TFT LCD panel structure is injected liquid crystal material into a narrow gap between the
TFT array glass substrate and a color-filter glass substrate.
Color (Red, Green, Blue) data signals from a host system (e.g. signal generator, etc.) are modulated
into best form for active matrix system by a signal processing board, and sent to the driver LSIs which
drive the individual TFT arrays.
The TFT array as an electro-optical switch regulates the amount of transmitted light from the backlight
assembly, when it is controlled by data signals. Color images are created by regulating the amount of
transmitted light through the TFT array of red, green and blue dots.
1.2 APPLICATION
•For industrial use
1.3 FEATURES
•Long life LED backlight type
•High luminance
•High contrast
•Wide viewing angle
•Wide temperature range
•LVDS interface
•Reversible-scan direction
•Selectable 8bit or 6bit digital signals for data of RGB
•Replaceable lamp for backlight
•Acquisition product for UL60950-1/CSA C22.2 No.60950-1-03 (File number: E170632)
•Compliant with the European RoHS directive (2002/95/EC)
DATA SHEET DOD-PP-1157 (1st edition) 4
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
2. GENERAL SPECIFICATIONS
Display area 245.76 (H) ×184.32 (V) mm
Diagonal size of display 31cm (12.1 inches)
Drive system a-Si TFT active matrix
Display color 16,777,216 colors (At 8-bit input, FRC terminal= High)
262,144 colors (At 6-bit input, FRC terminal= Low or Open)
Pixel 1,024 (H) ×768 (V) pixels
Pixel arrangement RGB (Red dot, Green dot, Blue dot) vertical stripe
Dot pitch 0.08 (H) ×0.24 (V) mm
Pixel pitch 0.24 (H) ×0.24 (V) mm
Module size 260.5 (W) ×203.0 (H) ×8.7 (D) mm (typ.)
Weight 490 g (typ.)
Contrast ratio 900:1 (typ.)
Viewing angle At the contrast ratio
≥ 10:1
•Horizontal: Right side 80°(typ.), Left side 80°(typ.)
•Vertical: Up side 80°(typ.), Down side 80°(typ.)
Designed viewing direction
At DPS= Low or Open: Normal scan
•Viewing direction without image reversal: Up side (12 o'clock)
•Viewing direction with contrast peak: Down side (6 o'clock)
•Viewing angle with optimum grayscale (γ≒2.2): Normal axis
(perpendicular)
Polarizer surface Clear
Polarizer pencil-hardness 3H (min.) [by JIS K5600]
Color gamut At, LCD panel center
40 % (typ.) [against NTSC color space]
Response time Ton+Toff (10%
←→ 90%)
18 ms (typ.)
Luminance At IL= 50mA/One circuit
450 cd/m2(typ.)
Signal system
LVDS 1port
(Receiver: THC63LVDF84B, THine Electronics Inc. or equivalent)
[8bit/6bit digital signals for data of RGB colors, Dot clock (CLK),
Data enable (DE)]
Power supply voltage LCD panel signal processing board: 3.3V
Backlight
LED backlight type:
Replaceable part
•Lamp holder set: Type No. 121LHS26
Recommended LED driver board (Option)
•LED driver board: Type No. 104PW03F
•Corresponding wiring harness: Type No. 121CBL02
Power consumption At IL= 50mA/One circuit, Checkered flag pattern
5.2 W (typ.)
DATA SHEET DOD-PP-1157 (1st edition) 5
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
3. BLOCK DIAGRAM
Host
3,072 lines
LCD panel
H: 1,024 × 3 (R, G, B)
V: 768
768 lines
LCD module (Product)
H-driver
D0+
D0-
D1+
D1-
D2+
D2-
D3+
D3-
100Ω
100Ω
100Ω
100Ω
CLK+
CLK-
100Ω
Controller with receiver for LVDS
V-driver
DPS
FRC
50kΩ
Power supply
for gradation
50kΩ
MSL
47kΩ
LCD panel signal processing board
Cathode
Anode 4
4 Backlight Note3
DC/DC
converter
Fuse
Note1
Note2
FG
GND
Note1
Note2
VCC
Note1: Relations between GND (Signal ground) and FG (Frame ground) in the LCD module are as
follows.
GND - FG Not connected
Note2: GND and FG must be connected to customer equipment’s ground, and it is recommended that
these grounds be connected together in customer equipment.
DATA SHEET DOD-PP-1157 (1st edition) 6
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
Note3: Backlight in detail
Backlight
Anode 1
Anode 3
Anode 2
Cathode 1
Cathode 2
Cathode 3
Anode 4
Cathode 4
DATA SHEET DOD-PP-1157 (1st edition) 7
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
DATA SHEET DOD-PP-1157 (1st edition) 8
4. DETAILED SPECIFICATIONS
4.1 MECHANICAL SPECIFICATIONS
Parameter Specification Unit
Module size 260.5 ±0.5 (W) ×203.0 ±0.5 (H) ×8.7 ±0.5 (D) Note1 mm
Display area 245.76 (H) ×184.32 (V) Note1 mm
Weight 490(typ.), 540(max.) g
Note1: See "8. OUTLINE DRAWINGS".
4.2 ABSOLUTE MAXIMUM RATINGS
Parameter Symbol Rating Unit Remarks
Power supply
voltage LCD panel signal processing board VCC -0.3 to +4.0 V
Display signals
Note1 VD
Input voltage
for signals Function signals
Note2 VF -0.3 to VCC +0.3 V -
Backlight Forward current IL 60 mA per one circuit
Storage temperature Tst -30 to +80 °C -
Front surface TopF -30 to +80 °C Note3
Operating temperature Rear surface TopR -30 to +80 °C Note4
≤95 % Ta ≤40°C
≤85 % 40°C < Ta ≤50°C
≤55 % 50°C < Ta ≤60°C
≤36 % 60°C < Ta ≤70°C
Relative humidity
Note5 RH
≤24 % 70°C < Ta ≤80°C
Absolute humidity
Note5 AH ≤70
Note6 g/m3-
Note1: D0+/-, D1+/-, D2+/-, D3+/- and CLK+/-
Note2: DPS, FRC and MSL.
Note3: Measured at LCD panel surface (including self-heat)
Note4: Measured at LCD module's rear shield surface (including self-heat)
Note5: No condensation
Note6: Water amount at Ta= 80°C and RH= 24%
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
4.3 ELECTRICAL CHARACTERISTICS
4.3.1 LCD panel signal processing board (Ta= 25°C)
Parameter Symbol min. typ. max. Unit Remarks
Power supply voltage VCC 3.0 3.3 3.6 V -
Power supply current ICC - 460
Note1 720 Note2 mA at VCC= 3.3V
Permissible ripple voltage VRP - - 100 mVp-p for VCC
High VTH - - +100 mV
Differential input threshold
voltage Low VTL -100 - - mV
at VCM= 1.2V
Note3
Terminating resistance RT - 100 -
Ω-
High VFH 0.7VCC - VCC V
Input voltage for DPS, FRC
and MSL signals Low VFL 0 - 0.3VCC V CMOS level
High IFH - - 300 μA
Input current for DPS, FRC
and MSL signals Low IFL -300 - - μA -
Note1: Checkered flag pattern [by EIAJ ED-2522]
Note2: Pattern for maximum current
Note3: Common mode voltage for LVDS receiver
DATA SHEET DOD-PP-1157 (1st edition) 9
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
4.3.2 Backlight lamp (Ta= 25°C, Note1, Note2)
Parameter Symbol min. typ. max. Unit Remarks
Forward current IL - 50.0 55.0 mA -
15.9 18.0 20.4 V Ta= +25°C
at IL= 50 mA
/One circuit
14.3 - - V Ta= +80°C
at IL= 50 mA
/One circuit
- - 22.4 V
Ta= -30°C
at IL= 50 mA
/One circuit
Forward Voltage VL
- - 22.6 V
Ta= -30°C
at IL= 55 mA
/One circuit
Note1: Please drive with constant current.
Note2: The Luminance uniformity may be changed depending on the current variation between 4
circuits. It is recommended that the current value difference among the circuits be less than
5%.
4.3.3 Power supply voltage ripple
This product works if the ripple voltage levels are over the permissible values as the following table,
but there might be noise on the display image.
Power supply voltage Ripple voltage Note1
(Measure at input terminal of power supply) Unit
VCC 3.3V ≤100 mVp-p
Note1: The permissible ripple voltage includes spike noise.
4.3.4 Fuse
Fuse
Parameter Type Supplier Rating Fusing current Remarks
2.0A
VCC FCC16202AB
KAMAYA ELECTRIC
Co., Ltd. 36V 4.0A Note1
Note1: The power supply’s rated current must be more than the fusing current. If it is less than the
fusing current, the fuse may not blow in a short time, and then nasty smell, smoke and so on
may occur.
DATA SHEET DOD-PP-1157 (1st edition) 10
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
4.4 POWER SUPPLY VOLTAGE SEQUENCE
4.4.1 LCD panel signal processing board
0ms < t < 35ms
VALID period
OFF
0ms < t < 35ms
ON
3.0V
0V 10μs ≤Tr < 50ms
VCC
Note1
Display signals*
Function signals
Note2
Toff ≥50ms
0V
0.3V
ON
* These signals should be measured at the terminal of 100Ωresistance.
Note1: If there is a voltage variation (voltage drop) at the rising edge of VCC below 3.0V, there is a
possibility that a product does not work due to a protection circuit.
Note2: Display signals (D0+/-, D1+/-, D2+/-, D3+/- and CLK+/-) and function signals (DPS, FRC
and MSL) must be set to Low or High-impedance, except the VALID period (See above
sequence diagram), in order to avoid the circuitry damage.
If some of display and function signals of this product are cut while this product is working,
even if the signal input to it once again, it might not work normally. If a customer stops the
display and function signals, VCC also must be shut down.
4.4.2 LED driver board
Display signals,
Function signals
Note1
LED backlight: ON
VALID period
Note2
Note1: These are the display and function signals for LCD panel signal processing board.
Note2: The backlight should be turned on within the valid period of display and function signals, in
order to avoid unstable data display.
DATA SHEET DOD-PP-1157 (1st edition) 11
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
4.5 CONNECTIONS AND FUNCTIONS FOR INTERFACE PINS
4.5.1 LCD panel signal processing board
CN1 socket (LCD module side): FI-SE20P-HFE (Japan Aviation Electronics Industry Limited (JAE))
Adaptable plug: FI-S20S (Japan Aviation Electronics Industry Limited (JAE))
Input data signal: 8bit
Pin No. Symbol Signal MAP A MAP B Input data
signal: 6bit Remarks
A D3+ Pixel data R0-R1,G0-G1,B0-B1 R6-R7,G6-G7,B6-B7 - Note1,
Note2
1 B GND Ground - Ground Note3
A D3- Pixel data R0-R1,G0-G1,B0-B1 R6-R7,G6-G7,B6-B7 - Note1,
Note2
2 B GND Ground - Ground Note3
3 DPS Selection
of scan direction High : Reverse scan Low or Open : Normal scan Note4
4 FRC Selection of the
number of colors High Low or Open Note1 Note5
5 GND Ground Ground Note3
6 CLK+
7 CLK- Pixel clock Pixel clock Note2
8 GND Ground Ground Note3
9 D2+
10 D2- Pixel data B4-B7,DE B2-B5,DE Note2
11 GND Ground Ground Note3
12 D1+
13 D1- Pixel data G3-G7,B2-B3 G1-G5,B0-B1 Note2
14 GND Ground Ground Note3
15 D0+
16 D0- Pixel data R2-R7,G2 R0-R5,G0 Note2
17 GND Ground Ground Note3
18 MSL Selection of
LVDS input map Low High Low Note5
19 VCC
20 VCC Power supply Power supply Note3
Note1: See "4.6 DISPLAY COLORS AND INPUT DATA SIGNALS".
Note2: Twist pair wires with 100Ω(Characteristic impedance) should be used between LCD panel
signal processing board and LVDS transmitter.
Note3: All GND and VCC terminals should be used without any non-connected lines.
Note4: See "4.8 SCANNING DIRECTIONS".
Note5: See "4.5.4 Connection between receiver and transmitter for LVDS".
DATA SHEET DOD-PP-1157 (1st edition) 12
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
4.5.2 Backlight lamp
CN2 plug (LCD module side): SM08B-SRSS-TB (J.S.T. Mfg. Co., Ltd.)
Adaptable socket: SHR-08V-S, SHR-08V-S-B (J.S.T. Mfg. Co., Ltd.)
Pin No. Symbol Signal Remarks
1 A1 Anode1 -
2 K1 Cathode1 -
3 A2 Anode2 -
4 K2 Cathode2 -
5 A3. Anode3 -
6 K3 Cathode3 -
7 A4 Anode4 -
8 K4 Cathode4 -
DATA SHEET DOD-PP-1157 (1st edition) 13
4.5.3 Positions of plug and socket
Insert direction
Rear side
CN1
1
20
CN2 1
8
Insert direction
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
4.5.4 Connection between receiver and transmitter for LVDS
(1) Input data signal: 8bit, MAP A
DATA SHEET DOD-PP-1157 (1st edition) 14
Note1: Recommended transmitter: THC63LVDM83R (THine Electronics Inc.) or equivalent
R2
R3
R4
R5
R6
R7
G2
G3
G4
G5
G6
G7
B2
B3
B4
B5
B6
B7
Note4
Note4
DE
R0
R1
G0
G1
B0
B1
Note4
CLK
VCC
GND
DPS
FRC
MSL
LVDS transmitter
THC63LVDM83R or equivalent
Note1
Host
D3+
D3-
DPS
FRC
GND
CLK+
CLK-
GND
D2+
D2-
GND
D1+
D1-
GND
D0+
D0-
GND
MSL
VCC
VCC
TA0
TA1
TA2
TA3
TA4
TA5
TA6
TB0
TB1
TB2
TB3
TB4
TB5
TB6
TC0
TC1
TC2
TC3
TC4
TC5
TC6
TD0
TD1
TD2
TD3
TD4
TD5
TD6
CLK IN
TD+
TD-
TCLK+
TCLK-
TC+
TC-
TB+
TB-
TA+
TA-
1A
2A
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
GND
CN1
RD+
RD-
RCLK+
RCLK-
RC+
RC-
RB+
RB-
RA+
RA-
GND
Signal
processor
DPS
FRC
MSL
VCC
Note3
Note2
LCD module (Product)
LCD controller
Receiver for LVDS
Equivalent of
THC63LVDF84B
LCD panel signal processing board
Note2: LSB (Least Significant Bit) – R0, G0, B0 MSB (Most Significant Bit) – R7, G7, B7
Note3: Twist pair wires with 100Ω(Characteristic impedance) should be used between LCD panel
signal processing board and LVDS transmitter.
Note4: Input signals to TC4, TC5 and TD6 are not used inside the product, but do not keep TC4, TC5
and TD6 open to avoid noise problem.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
(2) Input data signal: 8bit, MAP B
R0
R1
R2
R3
R4
R5
G0
G1
G2
G3
G4
G5
B0
B1
B2
B3
B4
B5
Note4
Note4
DE
R6
R7
G6
G7
B6
B7
Note4
CLK
VCC
GND
DPS
FRC
MSL
LVDS transmitter
THC63LVDM83R or equivalent
Note1
Host
D3+
D3-
DPS
FRC
GND
CLK+
CLK-
GND
D2+
D2-
GND
D1+
D1-
GND
D0+
D0-
GND
MSL
VCC
VCC
TA0
TA1
TA2
TA3
TA4
TA5
TA6
TB0
TB1
TB2
TB3
TB4
TB5
TB6
TC0
TC1
TC2
TC3
TC4
TC5
TC6
TD0
TD1
TD2
TD3
TD4
TD5
TD6
CLK IN
TD+
TD-
TCLK+
TCLK-
TC+
TC-
TB+
TB-
TA+
TA-
1A
2A
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
GND
CN1
RD+
RD-
RCLK+
RCLK-
RC+
RC-
RB+
RB-
RA+
RA-
GND
Signal
processor
DPS
FRC
MSL
VCC
Note3
Note2
LCD module (Product)
LCD controller
Receiver for LVDS
Equivalent of
THC63LVDF84B
LCD panel signal processing board
Note1: Recommended transmitter: THC63LVDM83R (THine Electronics Inc.) or equivalent
Note2: LSB (Least Significant Bit) – R0, G0, B0 MSB (Most Significant Bit) – R7, G7, B7
Note3: Twist pair wires with 100Ω(Characteristic impedance) should be used between LCD panel
signal processing board and LVDS transmitter.
Note4: Input signals to TC4, TC5 and TD6 are not used inside the product, but do not keep TC4, TC5
and TD6 open to avoid noise problem.
DATA SHEET DOD-PP-1157 (1st edition) 15
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
(3) Input data signal: 6bit
Host
GND
GND
DPS
FRC
GND
CLK+
CLK-
GND
D2+
D2-
GND
D1+
D1-
GND
D0+
D0-
GND
MSL
VCC
VCC
TA0
TA1
TA2
TA3
TA4
TA5
TA6
TB0
TB1
TB2
TB3
TB4
TB5
TB6
TC0
TC1
TC2
TC3
TC4
TC5
TC6
CLK IN
TCLK+
TCLK-
TC+
TC-
TB+
TB-
TA+
TA-
1B
2B
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
GND
CN1
RCLK+
RCLK-
RC+
RC-
RB+
RB-
RA+
RA-
GND
Signal
processor
DPS
FRC
MSL
VCC
Note3
R0
R1
R2
R3
R4
R5
G0
G1
G2
G3
G4
G5
B0
B1
B2
B3
B4
B5
Note4
Note4
DE
CLK
VCC
GND
DPS
FRC
MSL
Note2
LCD module (Product)
Receiver for LVDS
Equivalent of
THC63LVDF84B
LCD controller
LVDS transmitter
THC63LVDM83R or equivalent
Note1
LCD panel signal processing board
Note1: Recommended transmitter THC63LVDM83R (THine Electronics Inc.) or equivalent
Note2: LSB (Least Significant Bit) – R0, G0, B0 MSB (Most Significant Bit) – R5, G5, B5
Note3: Twist pair wires with 100Ω(Characteristic impedance) should be used between LCD panel
signal processing board and LVDS transmitter.
Note4: Input signals to TC4 and TC5 are not used inside the product, but do not keep TC4 and TC5
open to avoid noise problem.
DATA SHEET DOD-PP-1157 (1st edition) 16
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
4.5.5 Input data mapping
(1) Input data signal: 8bit, MAP A
DATA SHEET DOD-PP-1157 (1st edition) 17
(2) Input data signal: 8bit, MAP B
R2R3R4R5R6R7G2
G3G4
G5G6
G7
B2B3
CLK+/-
D0+/-
D1+/-
B4
B5B6B7
-
DE
D2+/- -
1CLK
tc
R0
R1G0G1
B0
D3+/- B1
R0R1R2R3R4R5G0
G1G2
G3G4
G5
B0B1
B2
B3B4B5
-
DE -
1CLK
tc
R6
R7G6G7
B6
B7
D3+/-
CLK+/-
D2+/-
D1+/-
D0+/-
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
(3) Input data signal: 6bit
R0R1R2R3R4R5G0
G1G2
G3G4
G5
B0B1
B2
B3B4B5
-
DE
CLK+/-
D0+/-
D1+/-
D2+/- -
1CLK
tc
4.6 DISPLAY COLORS AND INPUT DATA SIGNALS
4.6.1 Combinations of input data signals, FRC and MSL signal
This product can display 16,777,216 colors equivalent with 256 gray scales and 262,144 colors with
64 gray scales by combination of input data signals, FRC and MSL signal. See the following table.
Combination Input data
signals Input Data
mapping CN1- Pin No.1 and 2 FRC terminal MSL terminal Display colors Remarks
①8 bit MAP A D3+/- High Low 16,777,216 Note1
②8 bit MAP B D3+/- High High 16,777,216 Note1
③6 bit - GND Low or Open Low 262,144 Note2
Note1: See "4.6.2 16,777,216 colors".
Note2: See "4.6.3 262,144 colors".
DATA SHEET DOD-PP-1157 (1st edition) 18
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
DATA SHEET DOD-PP-1157 (1st edition) 19
4.6.2 16,777,216 colors
This product can display 16,777,216 colors equivalent with 256 gray scales by combination ①or ②.
(See "4.6.1 Combinations of input data signals, FRC and MSL signal".)
Also the relation between display colors and input data signals is as follows.
Data signal (0: Low level, 1: High level)
Display colors R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0
Basic Colors
Black
Blue
Red
Magenta
Green
Cyan
Yellow
White
00000000
00000000
11111111
11111111
00000000
00000000
11111111
11111111
00000000
00000000
00000000
00000000
11111111
11111111
11111111
11111111
00000000
11111111
00000000
11111111
00000000
11111111
00000000
11111111
Red gray scale
Black
dark
↑
↓
bright
Red
00000000
00000001
00000010
:
:
11111101
11111110
11111111
00000000
00000000
00000000
:
:
00000000
00000000
00000000
00000000
00000000
00000000
:
:
00000000
00000000
00000000
Green gray scale
Black
dark
↑
↓
bright
Green
00000000
00000000
00000000
:
:
00000000
00000000
00000000
00000000
00000001
00000010
:
:
11111101
11111110
11111111
00000000
00000000
00000000
:
:
00000000
00000000
00000000
Blue gray scale
Black
dark
↑
↓
bright
Blue
00000000
00000000
00000000
:
:
00000000
00000000
00000000
00000000
00000000
00000000
:
:
00000000
00000000
00000000
00000000
00000001
00000010
:
:
11111101
11111110
11111111
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

NL10276BC24-21
DATA SHEET DOD-PP-1157 (1st edition) 20
4.6.3 262,144 colors
This product can display 262,144 colors with 64 gray scales by combination ③.
(See "4.6.1 Combinations of input data signals, FRC and MSL signal ".)
Also the relation between display colors and input data signals is as follows.
Data signal (0: Low level, 1: High level)
Display colors R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Basic colors
Black
Blue
Red
Magenta
Green
Cyan
Yellow
White
000000
000000
111111
111111
000000
000000
111111
111111
000000
000000
000000
000000
111111
111111
111111
111111
000000
111111
000000
111111
000000
111111
000000
111111
Red gray scale
Black
dark
↑
↓
bright
Red
000000
000001
000010
:
:
111101
111110
111111
000000
000000
000000
:
:
000000
000000
000000
000000
000000
000000
:
:
000000
000000
000000
Green gray scale
Black
dark
↑
↓
bright
Green
000000
000000
000000
:
:
000000
000000
000000
000000
000001
000010
:
:
111101
111110
111111
000000
000000
000000
:
:
000000
000000
000000
Blue gray scale
Black
dark
↑
↓
bright
Blue
000000
000000
000000
:
:
000000
000000
000000
000000
000000
000000
:
:
000000
000000
000000
000000
000001
000010
:
:
111101
111110
111111
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.
