Neptronic BT060X8 User manual

BT-X8/060303 1
A
ctua
t
or for smoke damper
Specification & Installation instruction
Technical Data BT060X8 BT160X8 BT260X8 BT080X8 BT180X8 BT280X8
Power supply 22 to 26VAC
50/60Hz or 24VDC 110 to 130 VAC 50/60Hz 220 to 250 VAC 50/60Hz 22 to 26VAC 50/60Hz or 24VDC 110 to 130 VAC 50/60Hz 220 to 250 VAC 50/60Hz
Auxiliary switches No 2 switches rated 250VAC, 5A
switching points: 5˚& 85˚+/-5˚
Torque 70 in.lb. [8 Nm] at rated voltage
Fail safe - Enerdrive Yes
Power consumption Running 15VA, Holding 5VA
Control signal 2 wire / 2 position
Running time through 90º 20 to 30 sec Torque dependant
Fail safe: 15 sec. max at rated torque.
Electrical connection 18 AWG [0.8mm2] minimum
Inlet bushing 2 inlet bushing of 5/8 in [15.9 mm] & 7/8 in [22.2 mm]
Angle of rotation 0 to 90 degrees, mechanically adjustable (factory set with 90º stroke)
Direction of rotation Reversible, Clockwise (CW) or Counterclockwise (CCW) (factory set with CW direction)
Ambient temperature
Operation 0ºF to +122ºF [-18º C to +50º C] 3 cycles at +250˚F [+121º C]
Storage temperature -22ºF to +122ºF [-30º C to +50º C]
Relative Humidity 5 to 95 % non condensing.
Enclosure type NEMA type 2 / IP42
Weight 3 lbs. [1.4 kg]
Warning: Do not press the clutch when actuator is powered
Warning for BT160/260/180/280X8: High Voltage. Risk of electric chock.
Dimensions
A
B
C
D
Dimension Inches Metric (mm)
A 1.50 38.1
B 3.26 82.8
C 6.60 167.5
D3.72 94.5
Caution
We strongly recommend that all neptronic® products be wired to a separate transformer and that transformer shall service only neptronic® products. This precaution will
prevent interference with, and/or possible damage to incompatible equipment.
When multiple actuators are wired on a single transformer, polarity must be observed. Long wiring runs create voltage drop which may affect the actuator performance.
1Enerdrive System U.S.A. Patent #5,278,454
BT060X8
BT160X8
BT260X8
BT080X8
BT180X8
BT280X8
Feature:
•Designed to operate reliably in smoke control systems requiring
Underwriter’s Laboratories UL555S (rated at 250˚F).
•Mounts easy on round & square shaft (optional).
•External clutch for manual adjustments.
•Maintenance free.
•Position indicator.
•Fail safe by Enerdrive System1
•2 auxiliary switches (only on models 080, 180 & 280)

Actuator for smoke damper
BT060/160/260/080/180/280X8 Specification & Installation instruction
2
Mechanical installation
CLUTCH
MOUNTING
BRACKET
1. Manually close the damper blades and positioned the
actuator at 0º or 90º.
2. Slide the actuator onto the shaft.
3. Tighten the nuts on the “U” bolt to the shaft with a 8mm
wrench to a torque of 60 in.lb. [6,7 Nm].
4. Slide the mounting bracket under the actuator. Ensure free
movement of the slot at the base of the actuator. The
bracket pin must be placed in the mid distance of the slot.
5. Fix the bracket to the ductwork with #8 self-tapping screws.
Wiring Diagrams
Power supply - 2 wire / 2 position (ON-OFF)
NEUTRAL (-)
DRIVE CW
SUPPLY (+)
1 2
Warning for BT160/260/180/280X8:
High Voltage. Risk of electric chock.
Auxiliary switches (only on models BT080/180/280X8)
Red
White
Black
Common
Contact closed at 5° +/-5°
Contact closed at 85° +/-5°
Actuator
3 wire 105ºC cable 18 AWG, 1 meter long
PC Board
Power supply clip in
terminals
1 2
Rotation
direction
jumper
Transformer
Only on model
BT160/260X8
& BT180/
280X8
Potentiometer
Rotation direction Jumper
Rotation direction
direct CW (0 to 90°)
Rotation direction
reverse CCW (90 to 0°)
Stroke adjustment
To adjust the stroke, move the adjustment screws at the desired position.
