NEW BRUNSWICK SCIENTIFIC innova 4900 User manual

Photosynthetic Light
Manifold (option)
MANUAL NO: M1197-0052
Revision J
May 15, 2003
NEW BRUNSWICK SCIENTIFIC CO., INC.
BOX 4005 •44 TALMADGE ROAD •EDISON, NJ 08818-4005
Telephone: [phone] •1-800-631-5417
Fax: [phone] •Telex: 4753012 NBSCO
Internet: http://www.nbsc.com •E-mail: [email protected]

2
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide

3
INTERNATIONAL OFFICES:
BELGIUM
New Brunswick Scientific NV-SA
Stationsstraat 180/4
3110 Rotselaar
België/Belgique
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
GERMANY
New Brunswick Scientific GmbH
In Der Au 14
D-72622 Nürtingen
Deutschland
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
CHINA
New Brunswick Scientific Co., Inc.
Room 1501, Xiangjiang Building, No. 18
Lane 1265, Zhongshan Road (W)
Shanghai 200051, P.R. China
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
THE NETHERLANDS
New Brunswick Scientific BV
Kerkenbos 1101, 6546 BC Nijmegen
P.O Box 6826, 6503 GH Nijmegen
Nederland
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
FRANCE
New Brunswick Scientific SARL
3, rue des Deux-Boules
75001 Paris
France
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
UNITED KINGDOM
New Brunswick Scientific (UK) Ltd.
163 Dixons Hill Road
North Mymms, Hatfield, Herts. AL9 7JE
United Kingdom
Tel: [phone] or 0800 581331
Fax: [phone]
E-mail: [email protected]
Web: www.nbsuk.co.uk
New Brunswick Scientific User’s Guide

4
THIS PAGE IS INTENTIONALLY BLANK
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide

5
CAUTION!
This equipment must be operated as described in this
manual. If operational guidelines are not followed,
equipment damage and personal injury can occur.
Please read the entire User’s Guide before attempting to
use this unit.
Do not use this equipment in a hazardous atmosphere or
with hazardous materials for which the equipment was not
designed.
New Brunswick Scientific Co., Inc. (NBS) is not responsible
for any damage to this equipment that may result from the
use of an accessory not manufactured by NBS.
New Brunswick Scientific User’s Guide

6
THIS PAGE IS INTENTIONALLY BLANK
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide

7
Copyright Notice
New Brunswick Scientific Company, Inc.
Box 4005 44 Talmadge Road
Edison, New Jersey 08818-4005
©Copyright 2003 New Brunswick Scientific Co., Inc.
All Rights Reserved.
Reproduction, adaptation, or translation without prior written permission
from
New Brunswick Scientific is prohibited.
Disclaimer Notice
New Brunswick Scientific Co., Inc. reserves the right to change
information in this document without notice. Updates to information in
this document reflect our commitment to continuing product
development and improvement.
Manual Conventions
NOTE:
Notes contain essential information that
deserves special attention.
CAUTION!
Caution messages appear before procedures
which, if caution is not observed, could result
in damage to the equipment.
WARNING!
Warning messages alert you to specific
procedures or practices which, if not followed
correctly, could result in serious personal
injury.
Bold Text in bold face type emphasizes key words or
phrases.
New Brunswick Scientific User’s Guide

8
THIS PAGE IS INTENTIONALLY BLANK
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide

9
Innova Shakers are warranted by New Brunswick Scientific Co., Inc.
for two years or 10,000 hours of actual shaker use, whichever comes later.
This warranty covers parts and labor for the entire machine, with the exception
of glassware and its contents. This warranty covers faulty components and
assembly, and our obligation under this warranty is limited to repairing or replacing
the shaker or part thereof which shall, within two years after date of shipment or
10,000 hours of operating time, prove to be defective after examination. This
warranty does not cover any loss of time, materials, biological or biochemical by-
products caused by any work interruption resulting from shaker failure, nor does it
extend to any Innova Shaker which has been subjected to misuse, neglect, accident
or improper installation or application. In addition, the warranty does not apply to
any Innova Shaker that has been repaired or altered outside the NBS factory without
prior authorization from New Brunswick Scientific. For a period of two years (or
more) after the shipment date, the Innova warranty will be in effect as long as
the shaker has not been in operation for a total of 10,000 hours. After the
10,000 hours of operating time have elapsed, the Innova warranty may
still be in effect, as long as the two-year minimum warranty period
has not been reached. Operating time is based on actual usage
of the shaker, as determined by the shaker’s internal
electronic clock. Any tampering or alteration of
the clock will void the 10,000-hour
warranty.
W A R R A N T Y
New Brunswick Scientific User’s Guide

10
THIS PAGE IS INTENTIONALLY BLANK
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide

11
TABLE OF CONTENTS
1INTRODUCTION........................................................................................................ 13
2OVERVIEW................................................................................................................. 15
2.1 GENERAL DESCRIPTION........................................................................................... 15
2.2 PROGRAMMABLE LIGHT CONTROL PANEL .............................................................. 15
3INSPECTION & VERIFICATION............................................................................ 17
3.1 INSPECTION OF BOXES............................................................................................. 17
3.2 PACKING LIST VERIFICATION.................................................................................. 17
4INSTALLATION ......................................................................................................... 19
4.1 TOOLS NEEDED ....................................................................................................... 19
4.2 BEGINNING THE INSTALLATION............................................................................... 20
4.2.1 Harness Modification for Older Units........................................................... 21
4.3 CONTINUING THE INSTALLATION ............................................................................ 22
4.3.1 Installing the Timer Module........................................................................... 23
4.4 CONTINUING THE INSTALLATION 2.......................................................................... 23
4.5 INSTALLING A SECOND LIGHT MANIFOLD............................................................... 24
4.6 FINISHING THE INSTALLATION................................................................................. 25
5OPERATION................................................................................................................ 27
5.1 PROGRAMMING ILLUMINATION ............................................................................... 27
5.2 COMPUTER-CONTROLLED OPERATION.................................................................... 27
6MAINTENANCE & SERVICE.................................................................................. 29
6.1 CLEANING ............................................................................................................... 29
6.2 LAMP REPLACEMENT .............................................................................................. 29
6.3 LAMP STARTER REPLACEMENT............................................................................... 29
6.4 ELECTRONIC BOARD REPLACEMENT....................................................................... 30
6.4.1 ESD Precautions ............................................................................................ 30
6.5 SERVICE PARTS ....................................................................................................... 31
7SPECIFICATIONS...................................................................................................... 33
7.1 ALTERNATE SETPOINT ............................................................................................ 33
7.2 ILLUMINATION ........................................................................................................ 33
7.3 PROGRAMMABLE ILLUMINATION TIMER ................................................................. 33
8ILLUSTRATION INDEX ........................................................................................... 35
9INDEX...........................................................................................................................37
New Brunswick Scientific User’s Guide

12
THIS PAGE IS INTENTIONALLY BLANK
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide

13
1
1 I IN
NT TR RO OD DU UC CT TI IO ON N
When you select the optional Innova 4900 Photosynthetic Light Manifold for your Innova
4900 Multi-Shaker Environmental Chamber, you can rest assured it will provide you with the
reliable and maintenance-free operation characteristic of all NBS products.
The Innova 4900 and all of its optional accessories is among the newest generation of NBS
products. The entire Innova 4900 line of products incorporates a variety of state-of-the-art
components and features for your exacting scientific experiments.
This manual is intended to provide you with an understanding of how the Photosynthetic
Light Manifold operates, its basic components, and information about preventive maintenance
and service issues. This manual also includes a guide to the installation and operation of the
Photosynthetic Light Manifold.
It is recommended that you completely familiarize yourself with this manual, prior to actually
installing and operating the Photosynthetic Light Manifold.
New Brunswick Scientific User’s Guide

14
THIS PAGE IS INTENTIONALLY BLANK
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide

15
2
2 O OV
VE ER RV VI IE EW W
2.1 General Description
The 4900 Photosynthetic Light Manifold has six 20-watt fluorescent grow lamps
which are designed specifically for photosynthetic investigations. These lamps can be
operated manually or by a programmable electronic timer.
The electronic digital timer is a 24-hour, 7-day timer. It can control two banks of
lamps with up to 16 program steps of cycle operation. There is a second independent
timer channel which allows programmable activation of alternate temperature
setpoint. The timer assembly has an internal battery, which maintains correct time of
day when the power is off.
2.2 Programmable Light Control Panel
The programmable Light Control Panel is located on the main console of the Innova
4900 environmental chamber (see Figure 1). It can control up to two Photosynthetic
Light Manifolds.
Figure 1: Front View of Innova 4900
New Brunswick Scientific User’s Guide

16
The two rocker Illumination Switches allow you to select each light bank
independently.
The programmable electronic timer allows the operator to program illumination
periods on a daily or weekly basis, with up to 16 steps of memory or continuous
cycles. In addition, the timer may be used to activate or de-activate the alternate
temperature setpoint for the incubator. The timer maintains time of day and day of
week even when the Innova 4900 is turned off.
Illumination and alternate temperature are controlled by separate channels; they are
entirely are independent of one another. Each channel has a manual override switch
which allows the channel to be overridden on or off.
The Photosynthetic Light Manifold can be operated manually or in a programmed
mode (via the digital timer mounted on the main console), or it also can be controlled
by an optional computer.
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide

17
3
3 I IN
NS SP PE EC CT TI IO ON N &
& V VE
ER RI IF FI IC CA AT TI IO ON N
3.1 Inspection of Boxes
After you have received your order from New Brunswick Scientific, inspect the boxes
carefully for any damage that may have occurred during shipping. Report any damage
immediately to the carrier and to your local NBS Sales Order Department or local
NBS distributor.
3.2 Packing List Verification
Verify against your NBS packing list that you have received the correct materials. If
anything is missing or incorrect, contact your local NBS Sales Order Department or
local NBS distributor.
New Brunswick Scientific User’s Guide

18
THIS PAGE IS INTENTIONALLY BLANK
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide

19
4
4 I IN
NS ST TA AL LL LA AT TI IO ON N
4.1 Tools Needed
You will need the following tools to install the Light Manifold:
 A Phillips head screwdriver
 A ½-inch socket
 A 3/8-inch socket
 A socket wrench with six-inch extension
NOTE:
Before installing the Light Manifold, you must locate the position where
is will be installed. If this is the only Light Manifold system, it must be
mounted in the top set of mounting holes. See Figure 2 for possible
positions.
Figure 2: Light Manifold Locations in Innova 4900
New Brunswick Scientific User’s Guide

20
4.2 Beginning the Installation
1. Place the Innova 4900’s power switch in the OFF position, and disconnect the unit
from its power source.
2. Pull off the two trim strips from the main console panel (see Figure 1, repeated
below).
Figure 1: Front View of Innova 4900
3. Locate the following in your kit:
a. One ballast plate assembly M1197-5701.
b. Six 10-32 hex nuts
c. Six No. 10 flat washers
d. Six No. 10 split lock washers
4. Remove the lower panel assembly (see Figure 1). Save the hardware.
NOTE:
Where you position the ballast plate depends on the location you
choose for the Light Manifold. If you plan to mount the Light Manifold
in the upper half, mount the ballast plate on the left side of the panel. If
you plan to mount the Light Manifold in the lower half, mount the
ballast plate on the right side of the panel. See Figure 3 for reference.
Innova 4900 Photosynthetic Light Manifold M1197-0052 User’s Guide
