Endress+Hauser analytikjena CyBio QuadPrint HQ User manual

Assembly Instructions
CyBio QuadPrint HQ

Manufacturer Analytik Jena GmbH
Konrad-Zuse-Straße 1
07745 Jena / Germany
Phone: [phone]
Phone: [phone]
Mail: [email protected]
Technical Service Analytik Jena GmbH
Konrad-Zuse-Straße 1
07745 Jena / Germany
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
General Information http://www.analytik-jena.com
Documentation Number 30-5004-025-26-MAE
Edition B (03/2023)
Technical Documentation Analytik Jena GmbH
© Copyright 2023, Analytik Jena GmbH
For a proper and safe use of this product follow the instructions. Keep the
operating manual for future reference.

CyBio QuadPrint HQ Table of contents
3
Table of contents
1 General ................................................................................................................................................................. 7
1.1 Notes ................................................................................................................................................................. 7
1.1.1 Scope ................................................................................................................................................................. 8
1.2 Intended use (purpose).................................................................................................................................... 8
1.3 Standards and directives .................................................................................................................................. 9
2 Safety instructions................................................................................................................................................ 10
2.1 General.............................................................................................................................................................. 10
2.2 Safety markings ................................................................................................................................................ 10
2.3 Danger areas and protective devices............................................................................................................... 12
2.3.1 Hazard zones and warning labels.................................................................................................................... 12
2.4 Requirements for the operating personnel..................................................................................................... 13
2.5 Device-specific safety instructions................................................................................................................... 13
2.5.1 Safety instructions for operation ..................................................................................................................... 13
2.5.2 Safety instructions: Transport.......................................................................................................................... 14
2.5.3 Safety instructions – maintenance and service............................................................................................... 14
2.6 Safety instructions ............................................................................................................................................ 14
2.6.1 Handling hazardous substances ...................................................................................................................... 14
2.6.2 Chemical resistance .......................................................................................................................................... 15
2.7 Behavior during emergencies .......................................................................................................................... 15
3 Technical description............................................................................................................................................ 16
3.1 Layout................................................................................................................................................................ 16
3.1.1 Type plate.......................................................................................................................................................... 16
3.1.2 Barcode/label printer ....................................................................................................................................... 17
3.1.3 Turn-Lift module .............................................................................................................................................. 17
3.1.4 Barcode reader.................................................................................................................................................. 19
3.1.5 Ram applicator.................................................................................................................................................. 19
3.1.6 Compressed air control unit ............................................................................................................................. 19
3.2 Functionality ..................................................................................................................................................... 21
4 Commissioning ..................................................................................................................................................... 22
4.1 Location requirements ..................................................................................................................................... 22
4.2 Initial commissioning and configuration......................................................................................................... 23
4.3 Re-commissioning............................................................................................................................................ 23
5 Operation.............................................................................................................................................................. 24
5.1 Switching on ..................................................................................................................................................... 24
5.2 Inserting microplates........................................................................................................................................ 25
5.3 Switching off ..................................................................................................................................................... 25
6 Troubleshooting ................................................................................................................................................... 26
6.1 General information on troubleshooting ........................................................................................................ 26
6.2 Behavior after fault reports.............................................................................................................................. 26
7 Maintenance......................................................................................................................................................... 28
7.1 Safety instructions ............................................................................................................................................ 28

Table of contents CyBio QuadPrint HQ
4
7.2 Maintenance schedule ..................................................................................................................................... 29
7.3 Maintenance instructions ................................................................................................................................ 29
7.3.1 Cleaning the device........................................................................................................................................... 29
7.3.2 Checking compressed air.................................................................................................................................. 30
7.3.3 Changing label roll/transfer ribbon................................................................................................................. 30
8 Transport and storage.......................................................................................................................................... 32
8.1 Transport........................................................................................................................................................... 32
8.2 Storage .............................................................................................................................................................. 33
9 Putting the device out of operation ..................................................................................................................... 34
10 Disposal ................................................................................................................................................................ 35
11 Accessories, spare parts, consumables................................................................................................................. 36
11.1 Consumables and wearing parts...................................................................................................................... 36
11.2 Accessories........................................................................................................................................................ 36
11.3 Spare parts ........................................................................................................................................................ 36
12 Technical data ...................................................................................................................................................... 37
Glossary ................................................................................................................................................................ 39
Index ..................................................................................................................................................................... 40
13 Appendices ........................................................................................................................................................... 41
13.1 Software "CyBio PrintStudio"............................................................................................................................. 41
13.2 Supplier documentation................................................................................................................................... 41

CyBio QuadPrint HQ Table of figures
5
Table of figures
Fig. 1 Safety markings on the CyBio QuadPrint HQ ..................................................................................................... 11
Fig. 2 Hazard zones........................................................................................................................................................ 12
Fig. 3 Design of the CyBio QuadPrint HQ...................................................................................................................... 16
Fig. 4 Turn-lift module with control unit ...................................................................................................................... 17
Fig. 5 Lift-turn module control unit, connection terminals ......................................................................................... 18
Fig. 6 Compressed air control unit ................................................................................................................................ 20
Fig. 7 Turn-lift module with microplate........................................................................................................................ 21
Fig. 8 Compressed air control unit ................................................................................................................................ 30
Fig. 9 Replacing the label roll and the transfer ribbon ................................................................................................ 31
Fig. 10 QuadPrint HQ: Use the handles. ......................................................................................................................... 32

List of Tables CyBio QuadPrint HQ
6
List of Tables
Table 1 Scope of these instructions...................................................................................................................... 8
Table 2 Warning symbols ..................................................................................................................................... 11
Table 3 Permissible disinfection methods and disinfectants.............................................................................. 15
Table 4 Maintenance schedule............................................................................................................................. 29
Table 5 Wearing parts........................................................................................................................................... 36
Table 6 Consumables ............................................................................................................................................ 36
Table 7 Device component spare parts list .......................................................................................................... 36
Table 8 Operation, storage and transport conditions ........................................................................................ 38

CyBio QuadPrint HQ General
7
1 General
1.1 Notes
This document contains information about the setup and operation of the device CyBio
QuadPrint and provides the operating personnel with the necessary know-how for the
safe handling of the device.
The supplier documentation for the label printer and the label applicator is provided
with the device and is also available on the website of the manufacturer cab Produkt-
technik.
Conventions Instructions for actions occurring in chronological order are numbered and combined
into action units.
Warnings are indicated by a warning triangle and a signal word. The type, source and
consequences of the hazard are stated together with notes on preventing the hazard.
Elements of the control and analysis program are indicated as follows:
¡Program terms are in bold (e.g., the System menu).
¡Menu items are separated by vertical lines (e.g., System|Device).
Symbols and signal words used
in this manual
The user manual uses the following symbols and signal words to indicate hazards or in-
structions. These warnings are always placed before an action.
WARNING
Indicates a potentially hazardous situation which can cause death or very serious (possi-
bly permanent) injury.
CAUTION
Indicates a potentially hazardous situation which can cause slight or minor injuries.
NOTICE
Provides information on potential material or environmental damage.

General CyBio QuadPrint HQ
8
1.1.1 Scope
These instructions apply for
Name CyBio QuadPrint HQ
Type key 30-5004-025-26
Table1 Scope of these instructions
1.2 Intended use (purpose)
The operator is responsible to use of the device as intended.
The CyBio QuadPrint barcode labeling device has been designed for the automatic pro-
cessing of labware in chemical and biological laboratories. In the field of medicine and
diagnostics its use is limited to research.
The labware that can be processed with the device are microplates in ANSI/SLAS format,
including deep-well and rigid full-skirted PCR plates. It is not possible to process flexible
full-skirted PCR plates and half-skirted PCR plates with this device.
We recommend processing only empty or sealed filled labware.
The basic functions are the automatic printing of barcode labels and the attachment of
labels on labware items which are transferred by an automated transport system or a ro-
bot to an access module for this purpose.
It is not permitted to manually transfer the labware to the access module for labeling
purposes.
Please observe the following:
¡The device must only be operated by qualified and trained personnel.
¡The device must only be used in accordance with this manual. This applies in partic-
ular to the adherence to the connection values, conditions of use and notes on the
maintenance, transport, and disposal.
¡The safety instructions in this manual must be observed.
It is not permissible
¡to operate this equipment in a medical laboratory,
¡to work with explosive substances in this device,
¡to operate this device in an explosive environment.
¡to smoke or use a naked flame at the installation location.
As regards the safe handling of dangerous substances (radioactive, infectious, toxic, cor-
rosive, combustible, and other hazardous substances), the owner/operator will be re-
sponsible in accordance with applicable laws and guidelines.

CyBio QuadPrint HQ General
9
The same applies in terms of compliance with environmental protection rules (e. g. for
disposal of reagents and consumables).
The device may only be used for the processes described in the user manual. Only the
specified use is regarded to be the intended use. Using the device for any other purpose
may compromise the safety of the user and the device.
1.3 Standards and directives
The device was manufactured according to the currently applicable generally recognized
codes of practice and the generally accepted safety-related regulations. The relevant
safety and health requirements of the applicable laws, standards and regulations were
applied during the construction of the device.
EU directives The device is regulated by the directive 2006/42/EG and is considered an unfinished
machine. This means that the safety requirements are specified in the declaration of in-
corporation.
Furthermore, the following applies in this context: The unfinished machine may only be
put into operation if it has been determined that the machine or installation into which
the unfinished machine is to be incorporated complies with the provisions of the direc-
tive 2006/42/EG and that a corresponding declaration of conformity in accordance with
annexII, part1, sectionA has been issued.
The device meets the requirements of the directives 2014/30/EU and 2011/65/EU.
Any information regarding safety corresponds to the currently valid regulations of the
European Union. Other specific national laws and regulations must be observed.
Guard all hazard zones described in this manual for the safe integration of the device
into a machine or installation as far as possible from unintentional access. Preferably,
use a separating protective device to do this.

Safety instructions CyBio QuadPrint HQ
10
2 Safety instructions
2.1 General
For your own safety and to ensure error-free and safe operation of the device, please
read this chapter carefully before commissioning.
Screen Observe all safety instructions listed in these instructions, as well as all messages and in-
structions displayed by the control and analysis software on the monitor.
Besides the safety instructions in these instructions and the local safety regulations that
apply to the operation of the device, the general applicable regulations regarding acci-
dent prevention, occupational health and safety and environmental protection have to
be observed and complied with.
2.2 Safety markings
The warning labels and safety symbols attached to the device are part of the device and
must be strictly observed.
CAUTION
Risk of incorrect handling resulting in personal injury and material damage
due to missing warning labels!
Do not remove any warning labels or safety symbols!
Before switching on the device, check that the warning labels and safety symbols are
complete and intact.
Do not put the device into operation if warning labels or safety symbols are missing or
damaged.
Damaged or missing warning labels or safety symbols must be replaced immediately.

CyBio QuadPrint HQ Safety instructions
11
Fig.1 Safety markings on the CyBio QuadPrint HQ
The following symbols are attached to the device:
Icon Meaning Comment
Dangerous electrical volt-
age warning!
Never open the device!
All repairs must be performed by quali-
fied personnel only!
Only replace defective fuses with fuses
of the specified type!

Safety instructions CyBio QuadPrint HQ
12
Icon Meaning Comment
Hand injuries warning Warning of crushing injuries from mov-
ing device components
(label applicator)
Table2 Warning symbols
2.3 Danger areas and protective devices
2.3.1 Hazard zones and warning labels
12
Fig.2 Hazard zones
1 Range of movement of the turn-lift module
2 Range of movement of the label applicator

CyBio QuadPrint HQ Safety instructions
13
Note the following:
¡Guard the hazard zone from unintentional access as far as possible, preferably by
means of a separating protective device.
¡Always correct any incorrect movement with the aid of the PC. Incorrect handling
and operation can result in material damage and personal injury.
¡Ensure proper compressed-air connection.
¡In addition, keep in mind that the printer (or parts of it – the print head in particu-
lar) can heat up during printing (approx. 50°C); for this reason, do not touch it (dur-
ing operation) and only carry out material change or removal after the printer has
cooled down.
¡Always close the housing of the printer before operation. When the housing is open,
it is possible to access the print head which puts the operator at risk and may result
in injuries. The printer’s cover must only be opened to carry out one of the following
installation or maintenance tasks:
– Setting up the printer
– Replacing the label roll or the transfer ribbon
– Troubleshooting
¡If the applicator is running, moving components are accessible. This particularly ap-
plies to the area in which the applicator is moved back and forth between its basic
position and the labeling position. During operation, do not reach into this area and
keep hair, loose clothing and jewelry away from this area. When working in this
area, shut off the compressed-air supply.
2.4 Requirements for the operating personnel
The device may only be operated by trained specialist personnel instructed in technical
safety. The operating personnel must have read and understood the operating instruc-
tions.
The personal protective equipment must be worn to operate or service the device.
The operating personnel must be familiar with the dangers arising from the substances
used.
2.5 Device-specific safety instructions
The system must be installed by the service personnel of the manufacturer or duly
trained and authorized expert personnel under any circumstances.
Do not use aggressive substances of a type that may compromise the stable perfor-
mance of the system
Before connecting to the mains, check the electrical requirements of the device.
Observe prescribed maintenance intervals!
Only use the accessory items, consumables and spare parts specified in this document or
provided or recommended by the manufacturer!
2.5.1 Safety instructions for operation
The operator of the device must ensure that the device is in sound condition before each
use. This applies especially after any modification or adaptation of the device or any re-
pair.

Safety instructions CyBio QuadPrint HQ
14
Do not operate the system with defective safety devices or with improperly installed
safety and protection devices.
Do not remove, modify or disable any safety and protection devices during operation.
Ensure easy access to the main power switch, as well as to any emergency shutdown
systems and locks at all times during operation.
Ensure that all ventilation devices on the device are in proper functional condition. Cov-
ered ventilation grates or slots, etc. can result in malfunctions or device damage.
Only operate the device when connected to a power socket with grounding conductor.
The grounding conductor must not be interrupted (e.g., when using a voltage regulating
transformer). Only use extension cables equipped with grounding conductors!
When replacing the power cable, ensure that the new power cable has the proper di-
mensions for the intended operating voltage (see technical data).
Do not insert any objects into any device openings, and ensure that no liquid can get
into the device through openings or joints.
Do not short-circuit the device fuses and only use fuses corresponding to the informa-
tion in these instructions when replacing these.
2.5.2 Safety instructions: Transport
Only transport the device and its components in the original packaging! Ensure that all
transport locks and safety devices have been fitted and that the device components are
fully emptied and decontaminated if applicable.
2.5.3 Safety instructions – maintenance and service
Service and repairs and work for the commissioning or dismantling the device for trans-
port must only be carried out by authorized service personnel!
The operator may only carry out the tasks listed in the chapter "Maintenance and care".
Only carry out maintenance and service work on the device when it is switched off. Dis-
connect the power cord from the mains socket beforehand.
2.6 Safety instructions
2.6.1 Handling hazardous substances
Even with intended use there is a risk of health damage when handling hazardous sub-
stances. The operator is solely responsible for the compliance with all safety require-
ments to protect individuals and property when handling radioactive, infectious, toxic,
caustic, flammable and other hazardous substances.
¡Control the handling of hazardous substances in accordance with the safety category
of the lab, the details in the safety data sheets of the respective substances, the
manufacturer recommendations for use and additional national and international
regulations (WHO, “Laboratory Biosafety Manual").
¡Wear personal protective equipment when working with the device.
¡Observe all notices on the cleaning and decontamination of the device.

CyBio QuadPrint HQ Safety instructions
15
2.6.2 Chemical resistance
Aggressive substances may damage the device. Although the materials used are resis-
tant to most of the commonly used substances, material damage from aggressive sub-
stances cannot be completely excluded.
¡Before using any aggressive substances (e.g., bases, acids or organic solutions):
Check that the materials with direct contact to these substances are resistant.
¡When in doubt, consult the manufacturer.
Prohibited substances
Hydrofluoric acid (HF/hydrofluoric acid)
Highly concentrated acids
Cleaning powder
Paint thinner
Naphtha (crude gasoline)
Gasoline
Acetone
Cleaning spray
Ozone
¡Substances not listed in this table are not necessarily suitable.
¡Do not use solvents (thinners), aggressive detergents, flammable liquids or caustic
alkaline solutions for cleaning. These can lead to damage to the housing compo-
nents.
Disinfection method Disinfectant Can be used for
Wipe disinfection Incidin Liquid (ECOLAB) – Housing parts
– Accessories
Table3 Permissible disinfection methods and disinfectants
2.7 Behavior during emergencies
Emergency or dangerous situation:
}Switch off main switch
}Unplug power cord

Technical description CyBio QuadPrint HQ
16
3 Technical description
3.1 Layout
Fig.3 Design of the CyBio QuadPrint HQ
1 Printer 2 Touchscreen display
3 Label applicator 4 Opticon NLV 3101 barcode reader (op-
tional)
5 Turn-Lift module 6 Basic frame
7 Handles 8 Type plate
The CyBio QuadPrint HQ is a device for printing labels with 1D/2D barcodes, text or
other information with subsequent labeling of microplates. Labels can be applied to all
four sides of the microplates.
The label height is automatically adjusted to the microplate type via the Turn-Lift mod-
ule. The printing process settings are made via the CyBio QuadPrint Studio control soft-
ware. (→ "Software "CyBio PrintStudio"" 41)
3.1.1 Type plate
The type plate contains this information:
¡Manufacturer specifications
¡Product designations (type designation, trade name)
¡Identification data (model, serial number)
¡Year of manufacture

CyBio QuadPrint HQ Technical description
17
3.1.2 Barcode/label printer
NOTICE
Observe the associated documentation of the manufacturer.
The barcode/label printer is used to print the barcodes/labels using the thermal printing
method.
The printer is connected directly to the mains socket via its mains connection socket.
For control, the printer is connected to the control module via its interface.
3.1.3 Turn-Lift module
Fig.4 Turn-lift module with control unit
The turn-lift module can perform 2types of movement.
¡Turn: The tray turns the microplate.
¡Lift: The tray lifts the microplate to a height specified in the software.
Function:
1. The microplate to be labeled is placed on the tray by a robot or by an automatic
transport system.
2. The tray with the microplate is turned and lifted in accordance with the stored con-
figuration.
3. The positioned microplate is labeled by the label applicator.
4. The labeled microplate is removed from the tray by a robot or by an automatic
transport system.

Technical description CyBio QuadPrint HQ
18
Fig.5 Lift-turn module control unit, connection terminals
1 ESTOP1
Integration into an external safety cir-
cuit
2 SENS2
Sensor connection
3 SENS1
Sensor connection
4 COM2
RS-232 cascade, not used
5 COM1
RS232 interface
6 Status LED (service)
7 SW
Switching output
8 Main switch turn-lift module
9 SERVICE
Service interface
10 ESTOP2
External safety circuit (forwarding or
termination)
11 SENS3
Sensor connection
12 COM3
RS-232 cascade, not used
13 BC
Barcode reader connection
14 Mains connection socket

CyBio QuadPrint HQ Technical description
19
3.1.4 Barcode reader
The barcode reader is used to capture the data of the label attached to the micro plates.
It is checked whether the label is error-free and legible, and whether it corresponds to
the desired presetting. If the barcode is OK, the information can be stored in a database
and will then be available to other applications.
A signal tone confirms the successful reading process of the barcode reader.
3.1.5 Ram applicator
NOTICE
Observe the information in the corresponding documentation provided by the manufac-
turer. In particular, read the safety instructions that must be observed when operating
the label applicator.
The label applicator removes the labels from the printer.
After the label applicator has picked up a label, it moves into the labeling position.
The label is then attached to the specified position on the microplate.
The transport lock must be released before putting the device into service. For this pur-
pose, customer service removes the cover and moves the end position as far to the right
as required for the label applicator to reach all microplates in all positions.
3.1.6 Compressed air control unit
The ram applicator on the CyBio QuadPrint is moved with filtered compressed air.
A compressed air control unit attached to the rear is used to set or monitor the required
compressed air. Observe the following:
¡The compressed air can be switched on or off via the shut-off valve (1).
¡The required pressure is set with the filter regulator knob (4).
¡Any condensate that occurs is collected in the condensate collector (7). The conden-
sate collector must be emptied at regular intervals (8).

Technical description CyBio QuadPrint HQ
20
1
2
3
4
5
6
7
8
Fig.6 Compressed air control unit
1 Shut-off valve 2 Compressed air power supply line
3 Filter 4 Filter regulator knob
5 Manometer 6 Line to the ram applicator
7 Condensate collector 8 Drain plug for condensate
