USER’S MANUAL
2
CONTROL BUTTONS
TOP PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
USB input
Microphone input / Guitar input
SD card input
Microphone volume
Control the microphone volume in all modes, from CV00
to CV16. In TWS mode, this function is not available.
Volume +/–
Control volume in all modes, from VL00 to VL32
Treble +/–
Adjust the treble, from –9 to 9
Bass +/–
Adjust the bass, from –9 to 9
Pevious
In USB / SD / Bluetooth modes, tap to skip back to the
previous song
Equaliser / Mega Bass
Tap the equaliser to browse through different styles of
music: NOR, rock, jazz, classical, pop, country
Press and hold: Select on / off for mega bass function
6
4
14
5
715
1
11910 12813
2 3
16 17
18 19 20

ENGLISH
3
16
17
18
19
20
POWER
Power on / off
LIGHT SW
Turn on / off the light
AC IN
For connecting the AC cable to get power supply
AUX OUT
To connect more speakers togheter
AUX-IN
For connecting the external device under AUX-IN mode
BACK PANEL DESCRIPTION10
11
12
13
14
15
Play / Pause
Under USB / SD modes, this button is play/pause
In BT mode, tap to play / pause
In TWS mode, press and hold to connect and disconnect
the TWS (5 seconds)
Under AUX-IN mode, this button has no function
Mode
Press shortly to skip to Wireless BT / AUX-IN / USB / SD
modes
In BT mode, press and hold to disconnect Bluetooth (3
seconds)
Next
Under USB / SD / BT modes, tap to skip forward to the
next song
Standby mode
By pressing standby, all functions will stop working
Echo
Press and adjust the value with the multifunction from
EC00 to EC30
Guitar volume
Control the guitar volume under guitar-input mode
Note:
To fully disconnect the electrical cable, please disconnect
the plug from the electrical power point it is connected to.
The base of the power point should be easy to access.

USER’S MANUAL
4
1
2
3
4
5
6
7
8
10
12
14
16
17
19
20
9
11
13
15
18
USING THE REMOTE CONTROL
Installing the batteries
Remove the battery cover from
the back of the remote control
as shown and insert 2xAAA
size batteries ensuring correct
polarity.
Note: Please point at the LED screen when you are using the
remote controller
1
2
Mute
Press this button, sound off. Press again, sound on
Previous
Under USB / SD / Bluetooth mode, press shortly for
previous sound source

ENGLISH
5
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
MODE
Press shortly to skip to Wireless BT / AUX-IN / USB (with
USB card plug in) / SD (with SD card plug in) mode
REC
Under any mode, press “REC” button to record sound
with connected microphone and record in USB stick /
SD card
LIGHT
The color changes from red, green, blue, purple four color
automatically. Press “LIGHT” button, the light will twinkle
& change color with the music. Press the “LIGHT” again,
the light will be off.
BASS +/–
Adjust the bass
M. VOL +/–
Control the microphone volume
Play / Pause
Under USB / SD / BT modes, this button is play/pause
Under AUX-IN mode, this button has no function
STANDBY
Press shortly to put speaker in standby
Press again to turn on speaker
Next
Under USB / SD / BT modes, press shortly for next song
VOICE
Sound effects key which can emphasize the voice
REPEAT
Repeat one, repeat all (only available under USB / SD
modes)
REC PLAY
Play the recorded files into USB / SD
R-DEL
Delete the recorded file (only available under REC PLAY
mode)
RGB
Change LED lights colours between red, green and blue
M-PRI
Gives priority to mic voice against music
TREBLE +/–
Adjust the treble
EQ
Equalizer to browse through different music styles: NOR,
rock, jazz, classical, pop, country
VOL +/–
Control the volume
0-9 keys
Under USB / SD modes to select songs
For other modes, number buttons have no function
