Nidek Medical RS-3000 User manual

2009.05
Pages in total:144
XSO1**RDA002A
OPTICAL COHERENCE TOMOGRAPHY
Model RS-3000
SERVICE MANUAL

NIDEK CO., LTD. : 34-14, Maehama, Hiroishi-cho, Gamagori, Aichi 443-0038, Japan
(Manufacturer) Telephone: [phone]
Facsimile: 81-533-67-6610
NIDEK CO., LTD : 3F Sumitomo Fudosan Hongo Bldg., 3-22-5, Hongo,
(Tokyo Office) Bunkyo-Ku, Tokyo 113-0033, Japan
Telephone: [phone]
Facsimile: 81-3-5844-2642
NIDEK INCORPORATED : 47651 Westinghouse Drive, Fremont, California 94539, U. S. A.
(United States Agent) Telephone: [phone]
Facsimile: 1-510-226-5750
NIDEK SOCIETE ANONYME : Europarc 13, rue Auguste Perret, 94042 CRETEIL, France
(EU Authorized Representative) Telephone: [phone]
Facsimile: 33-1-49 80 32 08

XSO1**RDA002A
I
Table of Contents
1. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
2. SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
3. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
4. TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
5. SUBTROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5 . 1 Pilot Lamp of Isolation Transformer does not Light Up. . . . . . . . . . . . . . . . . . . . . 9
5 . 2 Main Body does not Start Properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5 . 2 . 1 Pilot lamp of main body does not light up. . . . . . . . . . . . . . . . . . . . . . 11
5 . 2 . 2 Startup screen does not appear on LCD monitor of main body . . . . . 12
5 . 2 . 3 Voltage between each TP and GND of power filter board (10701-BA06)
is abnormal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 . 2 . 4 Error message appears on LCD monitor of main body . . . . . . . . . . . 14
5 . 2 . 4 . 1 ERROR: 001 (EEPROM data). . . . . . . . . . . . . . . . . . . . . . . 14
5 . 2 . 4 . 2 ERROR: 002 (Connection with PC software) . . . . . . . . . . . 14
5 . 2 . 4 . 3 ERROR: 003 (Optical axis adjustment) . . . . . . . . . . . . . . . . 15
5 . 2 . 4 . 4 ERROR: 004 (Body cover open) . . . . . . . . . . . . . . . . . . . . . 15
5 . 2 . 4 . 5 ERROR: 005 (Body cover DIP switch) . . . . . . . . . . . . . . . . 16
5 . 2 . 4 . 6 ERROR: 006 (Base cover) . . . . . . . . . . . . . . . . . . . . . . . . . 16
5 . 2 . 4 . 7 ERROR: 007 (Base DIP switch) . . . . . . . . . . . . . . . . . . . . . 16
5 . 2 . 4 . 8 ERROR: 008 (LCD Backlight) . . . . . . . . . . . . . . . . . . . . . . . 16
5 . 2 . 4 . 9 ERROR: 011 (Spectrometer motor overrun) . . . . . . . . . . . . 17
5 . 2 . 4 . 10 ERROR: 012 (Spectrometer motor stop). . . . . . . . . . . . . . . 17
5 . 2 . 4 . 11 ERROR: 013 (OPL motor overrun) . . . . . . . . . . . . . . . . . . . 17
5 . 2 . 4 . 12 ERROR: 014 (OPL motor stop). . . . . . . . . . . . . . . . . . . . . . 17
5 . 2 . 4 . 13 ERROR: 015 (Focus motor overrun). . . . . . . . . . . . . . . . . . 17
5 . 2 . 4 . 14 ERROR: 016 (Focus motor stop) . . . . . . . . . . . . . . . . . . . . 17
5 . 2 . 4 . 15 ERROR: 017 (Chin-rest motor) . . . . . . . . . . . . . . . . . . . . . . 17
5 . 2 . 4 . 16 ERROR: 018 (Up/Down motor) . . . . . . . . . . . . . . . . . . . . . . 18
5 . 2 . 4 . 17 ERROR: 021 (OCT X galvano driver) . . . . . . . . . . . . . . . . . 19
5 . 2 . 4 . 18 ERROR: 022 (OCT Y galvano driver) . . . . . . . . . . . . . . . . . 19
5 . 2 . 4 . 19 ERROR: 023 (OCT galvano mirror). . . . . . . . . . . . . . . . . . . 19
5 . 2 . 4 . 20 ERROR: 024 (OCT SLD . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5 . 2 . 4 . 21 ERROR: 025 (OCT shutter). . . . . . . . . . . . . . . . . . . . . . . . . 19
5 . 2 . 4 . 22 ERROR: 026 (OCT initialization). . . . . . . . . . . . . . . . . . . . . 19
5 . 2 . 4 . 23 ERROR: 027 (SLD power over) . . . . . . . . . . . . . . . . . . . . . 19
5 . 2 . 4 . 24 ERROR: 028 (Timing of SLD and LD). . . . . . . . . . . . . . . . . 19
5 . 2 . 4 . 25 ERROR: 029 (OCT galvano synchronization). . . . . . . . . . . 20

XSO1**RDA002A
II
5 . 2 . 4 . 26 ERROR: 031 (SLO galvano driver) . . . . . . . . . . . . . . . . . . . 21
5 . 2 . 4 . 27 ERROR: 032 (SLO galvano mirror). . . . . . . . . . . . . . . . . . . 21
5 . 2 . 4 . 28 ERROR: 033 (SLO polygon mirror). . . . . . . . . . . . . . . . . . . 21
5 . 2 . 4 . 29 ERROR: 034 (SLO polygon sensor) . . . . . . . . . . . . . . . . . . 21
5 . 2 . 4 . 30 ERROR: 035 (SLO LD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5 . 2 . 4 . 31 ERROR: 036 (FIX LD). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5 . 2 . 4 . 32 ERROR: 037 (SLO shutter). . . . . . . . . . . . . . . . . . . . . . . . . 21
5 . 2 . 5 Initialization is not completed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5 . 3 Anterior Eye is not Displayed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5 . 3 . 1 Anterior eye illumination is not lit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5 . 4 PC does not Start Properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5 . 4 . 1 PC cannot be turned on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5 . 4 . 2 OS is not activated properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5 . 4 . 3 RS-3000 Capture is not activated . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5 . 4 . 4 RS3K Capture error appears on LCD monitor of PC . . . . . . . . . . . . 26
5 . 4 . 4 . 1 ERROR: 1001 (Connection with DB software) . . . . . . . . . . 26
5 . 4 . 4 . 2 ERROR: 1002 (SLO capture board) . . . . . . . . . . . . . . . . . . 26
5 . 4 . 4 . 3 ERROR: 1003 (OCT capture board) . . . . . . . . . . . . . . . . . . 27
5 . 4 . 4 . 4 ERROR: 1004 (Limit over capture board) . . . . . . . . . . . . . . 27
5 . 4 . 4 . 5 ERROR: 1011 (System information) . . . . . . . . . . . . . . . . . . 27
5 . 4 . 4 . 6 ERROR: 1012 (Trigger cable [input]) . . . . . . . . . . . . . . . . . 28
5 . 4 . 4 . 7 ERROR: 1013 (Trigger cable [output]) . . . . . . . . . . . . . . . . 28
5 . 4 . 4 . 8 ERROR: 1014 (Connection with CCD camera). . . . . . . . . . 29
5 . 4 . 4 . 9 ERROR: 1015 (OCT calibration file) . . . . . . . . . . . . . . . . . . 29
5 . 5 Image Capturing Unit does not Move Smoothly along Base Unit . . . . . . . . . . . 30
5 . 6 Turning Joystick does not Move Image Capturing Unit Up or Down. . . . . . . . . . 31
5 . 7 Chinrest does not Move . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5 . 8 External Fixation Target does not Light Up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5 . 9 Internal Fixation Target does not Light Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5 . 10 Hand Light does not Go On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5 . 11 Images cannot be Captured . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5 . 11 . 1 PC and main body cannot be synchronized. . . . . . . . . . . . . . . . . . . . 36
5 . 11 . 2 Operation panel is not operational . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5 . 11. 2 . 1 Function toggle switch and control knob are not
operational. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5 . 11. 2 . 2 Operation panel other than function toggle switch and control
knob is not operational . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5 . 11 . 3 Image capturing cannot be performed properly . . . . . . . . . . . . . . . . . 38
5 . 12 Printout cannot be Performed Properly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5 . 13 Motorized Optical Table does not Move Up or Down . . . . . . . . . . . . . . . . . . . . . 40
6. REMOVAL PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . .41
6 . 1 Removing Main Body Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6 . 1 . 1 Objective lens cover ASSY (10701-2200) . . . . . . . . . . . . . . . . . . . . . 41
6 . 1 . 2 Rear cover ASSY (10701-2300). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6 . 1 . 3 Lid (10701-M462) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

XSO1**RDA002A
III
6 . 1 . 4 Chinrest ASSY front cover (10701-M502) . . . . . . . . . . . . . . . . . . . . . 43
6 . 1 . 5 Front cover (10701-M701) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6 . 1 . 6 Top cover (10701-M702) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6 . 1 . 7 Left cover (10701-M704) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6 . 1 . 8 Right cover (10701-M705) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6 . 1 . 9 Body front cover (10701-M722) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6 . 1 . 10 Brake cover (10701-M723). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6 . 1 . 11 Removing board covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6 . 1 . 11. 1 Board cover (10701-M221) . . . . . . . . . . . . . . . . . . . . . . . . . 49
6 . 1 . 11. 2 Board cover (10701-M222) . . . . . . . . . . . . . . . . . . . . . . . . . 49
6 . 2 Removing Isolation Transformer Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6 . 2 . 1 Cover (10701-M782) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6 . 2 . 2 Power cord guard 1 (10701-M783) . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6 . 3 Removing PC Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7. REPLACEMENT PROCEDURE . . . . . . . . . . . . . . . . . . . . . .53
7 . 1 Main Body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7 . 1 . 1 ASSYs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7 . 1 . 1 . 1 Main body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7 . 1 . 1 . 2 Operation panel ASSY (10701-1220) . . . . . . . . . . . . . . . . . 54
7 . 1 . 1 . 3 LCD ASSY (10701-1300) . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7 . 1 . 1 . 4 Chinrest ASSY (10701-1500) . . . . . . . . . . . . . . . . . . . . . . . 55
7 . 1 . 1 . 5 External fixation target ASSY (10701-1520) . . . . . . . . . . . . 56
7 . 1 . 1 . 6 Lens cap ASSY (10701-2400). . . . . . . . . . . . . . . . . . . . . . . 56
7 . 1 . 1 . 7 Joystick ASSY (30601-2600). . . . . . . . . . . . . . . . . . . . . . . . 57
7 . 1 . 2 Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7 . 1 . 2 . 1 Main board (10701-BA01) . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7 . 1 . 2 . 2 SW board (10701-BA03) . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7 . 1 . 2 . 3 UDM DRV board (10701-BA04) . . . . . . . . . . . . . . . . . . . . . 60
7 . 1 . 2 . 4 Power filter board (10701-BA06) . . . . . . . . . . . . . . . . . . . . . 60
7 . 1 . 2 . 5 Hand light board (10701-BA23). . . . . . . . . . . . . . . . . . . . . . 61
7 . 1 . 2 . 6 UD sensor board (10701-BA24) . . . . . . . . . . . . . . . . . . . . . 61
7 . 1 . 3 Electrical components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7 . 1 . 3 . 1 L. body fan cable (10701-EA55) . . . . . . . . . . . . . . . . . . . . . 62
7 . 1 . 3 . 2 M. body fan cable (10701-EA65). . . . . . . . . . . . . . . . . . . . . 62
7 . 1 . 3 . 3 R. body fan cable (10701-EA66) . . . . . . . . . . . . . . . . . . . . . 62
7 . 1 . 3 . 4 Rotary encoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7 . 1 . 3 . 5 Fuses of main body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
7 . 1 . 4 Other parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7 . 1 . 4 . 1 Lens cap (15401-M811) . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7 . 1 . 4 . 2 Coil cord (15401-M814). . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7 . 1 . 4 . 3 Sliding plate (32105-M102) . . . . . . . . . . . . . . . . . . . . . . . . . 67
7 . 2 Isolation Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7 . 2 . 1 Indicator cable (10701-EA71). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7 . 2 . 2 Fuses of isolation transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

XSO1**RDA002A
IV
7 . 3 PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
7 . 3 . 1 PC ASSY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
7 . 3 . 2 Capture board (10701-BA20) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
7 . 3 . 3 PC monitor (10701-E013) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
7 . 3 . 4 Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
7 . 3 . 5 Coin-shaped lithium battery (10701-E100). . . . . . . . . . . . . . . . . . . . . 74
7 . 3 . 6 Memory module (10701-E101). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
7 . 3 . 7 System disk (10701-E102) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
7 . 3 . 8 Graphic board (10701-E103) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
7 . 4 Motorized Optical Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
7 . 4 . 1 Fuses of motorized optical table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
8. ADJUSTMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
8 . 1 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8 . 1 . 1 Service mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8 . 1 . 1 . 1 Activating service mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8 . 1 . 1 . 2 MAINTENANCE mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8 . 1 . 1 . 3 PROGRAM VERSION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8 . 1 . 1 . 4 ERROR HISTORY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8 . 1 . 1 . 5 E2PROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8 . 1 . 2 Packing mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8 . 2 Checking Anterior Eye Illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
8 . 3 Setting Boards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
8 . 3 . 1 Capture board (10701-BA20) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
8 . 4 Loading OCT Calibration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
8 . 5 Upgrading Software Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
8 . 5 . 1 Main body software upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
8 . 6 Checking Error Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8 . 6 . 1 Error log of main body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8 . 6 . 2 Error log file of RS-3000 Capture . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8 . 7 Free Space in Hard Disk Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
8 . 8 PC Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
8 . 8 . 1 BIOS setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
8 . 8 . 2 Date and time setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
8 . 8 . 3 Time zone setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
8 . 9 Motorized Optical Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
8 . 9 . 1 Injecting grease . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
9. SUPPLEMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
9 . 1 Appearance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
9 . 1 . 1 System configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
9 . 1 . 2 Main body. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
9 . 1 . 3 Operation panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9 . 1 . 4 Isolation transformer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9 . 2 Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
9 . 2 . 1 Transformer box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

XSO1**RDA002A
V
9 . 2 . 2 Main body. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
9 . 2 . 3 Motorized optical table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
9 . 3 Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
9 . 4 Connector Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
9 . 5 Switch Positions on Boards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
9 . 6 Parameter List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
9 . 7 Error Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
9 . 7 . 1 Main body. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
9 . 7 . 2 PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
9 . 8 Layout Drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
9 . 8 . 1 ASSYs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
9 . 8 . 2 Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
9 . 8 . 3 Electrical components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
9 . 9 Jigs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
9 . 10 Consumable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
9 . 11 List of Replacement Parts and Required Adjustments . . . . . . . . . . . . . . . . . . . 135
9 . 12 Screw List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

XSO1**RDA002A
VI
This page is intentionally left blank

XSO1**RDA002A
1
1 INTRODUCTION
This Service Manual is for the NIDEK OPTICAL COHERENCE TOMOGRAPHY, RS-3000.
For correct service, thorough understanding of the contents in this manual is required prior to the
service.
Refer to the Operator’s Manual and Parts List for the RS-3000.
Refer to the Service Manual Annex for important changes.
Descriptions in this manual are subject to change without notice for improvement.

XSO1**RDA002A
2
This page is intentionally left blank

XSO1**RDA002A
3
2 SAFETY PRECAUTIONS
1 . General precautions
1 ) Servicing must be performed by NIDEK service persons or other qualified personnel.
2 ) In case the system cannot be repaired by the procedures described in this manual,
please report the serial number of the system and details of the symptom or symp-
toms.
3 ) Observe the procedures described in this manual.
4 ) Failure to do so may cause accident or malfunction.
5 ) When performing maintenance work, turn off the power switch and disconnect the
power cord from the wall outlet unless the power needs to be on.
6 ) Never wipe the covers using an organic solvent such as paint thinner. Doing so may
ruin the surface and impair the appearance of the system.
2 . Maintenance cautions
1 ) In case of the system malfunction, check the symptom and turn off the power switch.
2 ) Do not drop parts or screws inside the system, nor bump it against surrounding
objects.
3 ) Prepare storage cases so as not to lose the removed parts or screws.
4 ) Tighten or loosen screws with proper tools.
5 ) After loosening the screws fastened by a threadlocking adhesive, be sure to reapply
the threadlocking adhesive to the screws when retightening them.
6 ) After replacing parts, confirm that they are fastened in their original positions securely
before turning on the power.
7 ) Should you observe smoke or strange odors being issued from the system, immedi-
ately turn off the power switch, disconnect the power cord from the outlet, and investi-
gate the cause.
8 ) If the system is powered in abnormal conditions, fire, electric shock, or total loss of the
system may result.
9 ) See Wiring Diagram and Connecting Cable to check cable breaks as described in
TROUBLESHOOTING. In addition, check cables for the following:
a . Connectors are connected and crimped properly.
b . No contact failure occurs after re-connection of connectors.
c . Cables are soldered properly.
* Do not yank the cables with excessive force.Doing so could cause cable break-
age.
* Never perform servicing with wet hands. Doing so could cause electric shock or
malfunction.
10) The labeled area indicates high voltage. Take proper precautions against electric
shock.
11 ) When a cable with any of the following marks is disconnected and reconnected, be
sure to confirm that the screws are tightened securely.
a . Protective ground
b . Functional ground
c . Equipotential

XSO1**RDA002A
4
3 . Adjustment precautions
1 ) Confirm that the following conditions are met before installation.
a . A place which is level and stable without vibration and shock
b . No exposure to direct sunlight or ultraviolet rays
c . A place with minimal external light source
d . No exposure to water
e . A place where temperature and humidity meet the specifications for use
2 ) Never use the adjustment jigs for purposes other than those intended.

XSO1**RDA002A
5
3 SPECIFICATIONS
1 . Specifications
1 ) Measurement principle SLO image: Confocal laser scanning method (refraction)
OCT image: Spectral OCT (spectral domain OCT)
Anterior eye observation image: CCD
2 ) Source wavelength SLO: 785 nm
OCT: 880 nm
Internal fixation target: 635 nm
3 ) Optical resolution SLO: 25 µm (XY direction)
OCT: 20 µm (XY direction) 7 µm (Z direction, eye interior)
4 ) Display resolution SLO: 7.5 µm or less (XY direction)
OCT: 3 µm or less (XY direction) 4 µm (Z direction, eye inter-
ior)
5 ) Working distance 35.5 mm (From the objective lens to the pupil)
6 ) Minimum pupil diameter ø2.5 mm (ø3 mm or more is recommended for capturing.)
required
7 ) Main body LCD monitor 8.4-inch TFT color LCD
8 ) Diopter correction range -15 D to +10 D (VD = 12 mm)
9 ) Angle of view for capturing SLO image: 40 × 30º (20 × 15º when zoomed)
OCT image: 10 to 30º (changeable in increments of 1º)
10) Image capturing unit vertical movement 32 mm
11 ) Image capturing unit horizontal movement forward and backward: 40 mm
right and left: 85 mm
12) Chinrest vertical movement 62 mm
13) Interface Main body: USB (only for program upgrade)
PC: USB, Ethernet
2 . Power specifications
1 ) Power source: AC 120 V (±10%)/AC 230 V (±10%) 50/60 Hz
2 ) Power consumption: Maximum 1000 VA
3 . Dimensions and weight
1 ) Main body dimensions: 567 (W) × 472 (D) × 600 to 845 (H) mm
2 ) PC dimensions: 452 (W) × 630 (D) × 703 (H) mm
3 ) Gross weight: 138 kg
(with the optional rack and motorized optical table installed)

XSO1**RDA002A
6
This page is intentionally left blank

XSO1**RDA002A
7
4 TROUBLESHOOTING
Turn on power to the isolation transformer.
Does the pilot lamp of the isolation transformer light
up?
No
5.1 Pilot Lamp of Isolation Transformer does not
Light Up
Yes
Turn on power to the main body. Does the main
body start properly?
No
5.2 Main Body does not Start Properly
Yes
Is the anterior eye displayed?
No
5.3 Anterior Eye is not Displayed
Yes
Turn on power to the PC. Does the PC start
properly?
No
5.4 PC does not Start Properly
Yes
Does the image capturing unit move horizontally?
No
5.5 Image Capturing Unit does not Move Smoothly
along Base Unit
Yes
Does turning the joystick move the image capturing
unit up and down?
No
5.6 Turning Joystick does not Move Image
Capturing Unit Up or Down
Yes
Does the chinrest move up and down smoothly?
No
5.7 Chinrest does not Move
Yes

XSO1**RDA002A
8
Does the external fixation target light up?
No
5.8 External Fixation Target does not Light Up
Yes
Does the internal fixation target light up?
No
5.9 Internal Fixation Target does not Light Up
Yes
Does the hand light go on?
No
5.10 Hand Light does not Go On
Yes
Can image capture be performed?
No
5.11 Images cannot be Captured
Yes
Can printout be performed properly?
No
5.12 Printout cannot be Performed Properly
Yes
Does the motorized optical table move up and
down?
No
5.13 Motorized Optical Table does not Move Up or
Down
Yes
Exit the software. Turn off power to the main body
and isolation transformer.

XSO1**RDA002A
9
5 SUBTROUBLESHOOTING
5.1 Pilot Lamp of Isolation Transformer does not Light Up
Is the power supply voltage proper?
No
Use the wall outlet that supplies proper voltage.
Yes
Are there any breaks in the power cord of the
isolation transformer?
Yes
Replace the power cord of the isolation transformer
(see 9.3).
No
Are the fuses of the isolation transformer blown?
Yes
Replace the fuses of the isolation transformer (see
7.2.2).
No
Is the power output from the isolation transformer
outlet AC 100 V ±10%?
No
Return the device to NIDEK.
Yes
Replace the indicator cable (10701-EA71) (see
7.2.1).

XSO1**RDA002A
10
5.2 Main Body does not Start Properly
Turn on power to the main body. Does the pilot
lamp of the main body light up?
No
5.2.1 Pilot lamp of main body does not light up
Yes
Does the startup screen appear on the LCD
monitor of the main body?
No
5.2.2 Startup screen does not appear on LCD
monitor of main body
Yes
Does the error beep sound (continuously 10 times)
and any error message appear on the LCD monitor
of the main body?
Yes
5.2.4 Error message appears on LCD monitor of
main body
No
Is the initialization completed?
No
5.2.5 Initialization is not completed
Yes
End

XSO1**RDA002A
11
5.2.1 Pilot lamp of main body does not light up
Are the fuses of the main body blown?
Yes
Replace the fuses of the main body (see 7.1.3.5).
No
Are there any breaks in the power cord of the main
body (ULHP grade power cord [80511-00038])?
Yes
Replace the ULHP grade power cord (80511-
00038) (see 9.3).
No
Is the voltage between each TP and GND of the
power filter board (10701-BA06) as below?
Between TP1 and GND: +24 V
Between TP2 and GND: +15 V
Between TP3 and GND: -15 V
Between TP4 and GND: +12 V
Between TP5 and GND: +5 V
Between TP6 and GND: +5 V
Between TP7 and GND: +3.3 V
No
The voltage between each TP and GND of the
power filter board (10701-BA06) is abnormal (see
5.2.3).
Yes
Are there any breaks in power cable 2 (10701-
EA14)?
Yes
Replace power cable 2 (10701-EA14) (see 9.3).
No
Are there any breaks in power cable 3 (10701-
EA15)?
Yes
Replace power cable 3 (10701-EA15) (see 9.3).
No
Are there any breaks in SW DRV cable (10701-
EA31)?
Yes
Replace SW DRV cable (10701-EA31) (see 9.3).
No
Replace the SW board (10701-BA03) (see 7.1.2.2).
Is the problem resolved?
No
Replace the main body (see 7.1.1.1).
Yes
End

XSO1**RDA002A
12
5.2.2 Startup screen does not appear on LCD monitor of main body
Does the error beep sound (continuously 10 times)
and the function indicator of the operation panel
blink in blue and white alternately?
Yes
5.2.4.8 ERROR: 008 (LCD Backlight)
No
Is the voltage between each TP and GND of the
power filter board (10701-BA06) as below?
Between TP1 and GND: +24 V
Between TP2 and GND: +15 V
Between TP3 and GND: -15 V
Between TP4 and GND: +12 V
Between TP5 and GND: +5 V
Between TP6 and GND: +5 V
Between TP7 and GND: +3.3 V
No
The voltage between each TP and GND of the
power filter board (10701-BA06) is abnormal (see
5.2.3).
Yes
Are there any breaks in power cable 1 (10701-
EA11)?
Yes
Replace power cable 1 (10701-EA11) (see 9.3).
No
Are there any breaks in the LCD cable (10701-
EA07)?
Yes
Replace the LCD cable (10701-EA07) (see 9.3).
No
Replace the main board (10701-BA01) (see
7.1.2.1).
Is the problem resolved?
Yes
End
No
Replace the LCD ASSY (10701-1300) (see
7.1.1.3).
