NIVELCO AnaCONT LE-100 Assembly instructions

BKI 11 ATEX 0012 X  le00100a0600p_05  1 / 60
AnaCONT
Manufacturer
Phone (36-1) (36-1)
E-mail: [e-mail] www.nivelco.com
:
H-1043 Budapest, Dugonics u. 11.
: 889-0100 Fax: [phone]
NIVELCO Process Control Co.
LE-100
LP-100
LG-100
Two-wire compact analytical transmitters

2 / 60  le00100a0600p_05  BKI 11 ATEX 0012 X
pH- and ORP- Dissolved oxygen
sensors and transmitters (compact type)
pH- and ORP- Dissolved oxygen
sensors and transmitters (integrated type)

BKI 11 ATEX 0012 X  le00100a0600p_05  3 / 60
TABLE OF CONTENTS
1. INTRODUCTION.............................................................................................................................................................................................................................. 5
1.1. APPLICATION ............................................................................................................................................................................................................................ 5
1.2. OPERATION PRINCIPLE............................................................................................................................................................................................................... 5
1.2.1. Characteristics of an ideal pH electrode .......................................................................................................................................................................................................... 5
1.2.2. Characteristics of an ideal ORP electrode....................................................................................................................................................................................................... 6
1.2.3. Characteristics of an ideal DO sensor ............................................................................................................................................................................................................. 6
2. ORDER CODES............................................................................................................................................................................................................................... 7
2.1. CONFIGURATIONS.................................................................................................................................................................................................................... 11
3. TECHNICAL DATA........................................................................................................................................................................................................................ 16
3.1. TECHNICAL DATA OF THE PHELECTRODES (INCLUDING EX VERSIONS)FOR LP--INSTRUMENTS ................................................................................. 18
3.2. TECHNICAL DATA OF THE ORP ELECTRODES (INCLUDING EX VERSIONS)FOR LR--INSTRUMENTS............................................................................. 20
3.3. TECHNICAL DATA OF THE DO SENSORS (INCLUDING EX VERSIONS)FOR LD--INSTRUMENTS ..................................................................................... 22
3.4. ACCESSORIES......................................................................................................................................................................................................................... 22
4. MAINTENANCE AND REAPAIR................................................................................................................................................................................................... 23
4.1. STORAGE ............................................................................................................................................................................................................................... 23
4.2. PERIODIC SETTING,CALIBRATION AND VERIFICATION .................................................................................................................................................................. 23
4.2.1. Periodic calibration of the pH electrode ......................................................................................................................................................................................................... 24
4.2.2. Verification of the ORP electrode .................................................................................................................................................................................................................. 25
4.2.3. Periodic calibration of the DO sensor ............................................................................................................................................................................................................ 25
4.3. MAINTENANCE OF THE PHAND ORP ELECTRODES .................................................................................................................................................................... 27
4.4. MAINTENANCE OF THE DO SENSOR .......................................................................................................................................................................................... 29
4.5. SOFTWARE UPDATE................................................................................................................................................................................................................. 29
5. INSTALLATION............................................................................................................................................................................................................................. 30
5.1. MOUNTING.............................................................................................................................................................................................................................. 30
5.1.1. Installation of pH and ORP electrodes........................................................................................................................................................................................................... 30
5.1.2. Installation of DO sensor ............................................................................................................................................................................................................................... 31
5.1.3. Special application possibilities of the Integrated type instruments............................................................................................................................................................... 33
5.2. WIRING................................................................................................................................................................................................................................... 34
5.2.1. Wiring of Compact instruments...................................................................................................................................................................................................................... 34
5.2.2. Wiring of Integrated instruments.................................................................................................................................................................................................................... 35
5.3. LOOP CURRENT CHECKING WITH HAND INSTRUMENT.................................................................................................................................................................. 35
5.4. CONDITIONS OF EX APPLICATION .............................................................................................................................................................................................. 35

4 / 60  le00100a0600p_05  BKI 11 ATEX 0012 X
6. PROGRAMMING ........................................................................................................................................................................................................................... 36
6.1. THE SAP-300 DISPLAY UNIT.................................................................................................................................................................................................... 36
6.2. MEASURING WITH THE SAP-300 DISPLAY UNIT.......................................................................................................................................................................... 37
6.3. PROGRAMMING WITH THE SAP-300 DISPLAY MODULE ............................................................................................................................................................... 40
6.3.1. Components of the programming interface ....................................................................................................................................................................................................40
6.3.2. Menu structure................................................................................................................................................................................................................................................41
6.4. PROGRAMMABLE FEATURES DESCRIPTION................................................................................................................................................................................. 42
6.4.1. Basic measurement settings ..........................................................................................................................................................................................................................42
6.4.2. Analogue output .............................................................................................................................................................................................................................................44
6.4.3. Relay output ...................................................................................................................................................................................................................................................45
6.4.4. Digital output...................................................................................................................................................................................................................................................47
6.4.5. Service functions ............................................................................................................................................................................................................................................47
6.5. PHSENSOR CALIBRATION........................................................................................................................................................................................................ 53
6.5.1. Editing one item of the calibration table..........................................................................................................................................................................................................53
6.5.2. Adding an item to the calibration table ...........................................................................................................................................................................................................55
6.5.3. Deleting an element of the calibration table ...................................................................................................................................................................................................55
6.5.4. Reset the calibration table to default ..............................................................................................................................................................................................................55
6.5.5. Calibration procedure .....................................................................................................................................................................................................................................55
6.6. DO SENSOR CALIBRATION....................................................................................................................................................................................................... 56
6.6.1. Calibration of saturated value (100%) ............................................................................................................................................................................................................56
6.6.2. Calibration of Zero point (0%).........................................................................................................................................................................................................................57
6.6.3. Calibration with referential DO instrument......................................................................................................................................................................................................57
6.6.4. Reset the calibration table to default ..............................................................................................................................................................................................................57
6.6.5. Reset Timer....................................................................................................................................................................................................................................................57
6.7. ERROR CODES ........................................................................................................................................................................................................................ 58

BKI 11 ATEX 0012 X  le00100a0600p_05  5 / 60
Thank you for choosing a NIVELCO instrument.
We are sure that you will be satisfied throughout its use!
1. INTRODUCTION
1.1. APPLICATION
The AnaCONT compact transmitters, liquid analytical instruments are suitable for high precision measurement and transmission of acidity or alkalinity - pH
(Hydrogen ion concentration) value -, reducing and oxidizing capability - ORP (Oxidation Reduction Potential) value -, or Dissolved Oxygen content of process
water, wastewater, surface water, ground water and drinking water. These measurements can be widely used in industrial practice and could be of great
relevance. In the field of environmental protection or sewage treatment, instruments like that are suitable for measuring the concentration of hazardous
substances (chromium, cyanide). In chemical- and pharmaceutical industry, high precision measurement has utmost importance in the aspect of the technology
(e.g. solvent feed), in many cases it is quality specification standard.
1.2. OPERATION PRINCIPLE
The intelligent signal processing of the electronics calculates the output signal from the voltage output values of the
electrode and the temperature probe, and compensates it to 25°C. This value composes the basis of all output
signals of the instrument.
1.2.1. Characteristics of an ideal pH electrode
T
he pH electrode immersed into the measured liquid measures a volta
g
e value which is proportional to the h
y
dro
g
en
ion concentration of the liquid.
0mV output at neutral pH value (pH=7.00)
Positive voltage output in acidic liquids (pH<7)
Negative voltage output in alkaline liquids (pH>7)
Total measuring range is 0-14pH
-59.16mV/pH (Nernst potential) slope at 25 °C
The temperature dependency of the Nernst potential is -0.001984 mV / °C.
600
500
400
300
200
100
0
100
200
300
400
500
600
100° C (74.04 mV/pH)
25° C (59.16 mV/pH)
0° C (54.20 mV/pH)
2 4 6 8 10 12 14
1 3 5 7 9 1 1 13
Because the pH electrodes in deed are not ideal (their properties depend on the design of the electrode, manufacturing tolerances and most of all the age of the
electrode) the parameters differ from the given values above. To achieve reliable pH measurement and accuracy these electrodes must be calibrated from time
to time. The time interval between two calibrations depends on the application conditions where the pH probes are used. Calibration of pH electrodes means
offsetting the displayed value (7.00pH) when gauging neutral buffer solution, and adjusting the slope (pH/mV) by measuring buffer solutions with other pH value
(usually with 4.00pH and 10.00pH value) by adjusting the displayed value to exact 4.00 and 10.00pH, respectively.

6 / 60  le00100a0600p_05  BKI 11 ATEX 0012 X
1.2.2. Characteristics of an ideal ORP electrode
Negative voltage output in liquids with reduction potential,
Positive voltage output in liquids with oxidation potential,
Output voltage is equal to the redox potential (according to the Nernst equation)
pH independent measurement with certain types
To achieve reliable measurement and accuracy, these electrodes have to be thoroughly checked before
installation and during usage from time to time. The time interval between two calibrations depends on the
application and conditions where the ORP probes are used.
1.2.3. Characteristics of an ideal DO sensor
The dissolved oxygen level indicates the amount (in mg/l or ppm) of physically dissolved gas-form oxygen in
liquid phase.
Oxygen-permeable membrane amperometric DC sensor wetted in the measurement medium gives output
c
urrent proportional to the dissolved oxygen concentration of the medium.
i
air
i
zero
O
u
t
p
u
t
c
u
rre
n
t
of the DO sensor
Dissolved oxygen (DO), ppm sat´n0
Slope = /ppm oxygen Output current of the
DO sensor
The ideal DO sensor has:
Izero=0,
Temperature independent output current
Real DO sensor gives off a minimal Izero≠0ppm current in case of 0 ppm dissolved oxygen concentration and its oxygen-permeable capability is temperature-
dependent. Oxygen-permeable capability of the membrane is increasing according to the increase of the temperature, at 25 °C it can be 4%/°C. Temperature
proportional correction is necessary for reliable measurement.
The DO sensors in deed are not ideal (their properties depend on the design of the electrode, manufacturing tolerances and most of all the age of the electrode),
so the parameters differ from the given values above. To give reliable DO measurement and accuracy these electrodes must be calibrated from time to time. In
case of DO sensors the calibration means that 0 ppm output value have to be set by offsetting in an oxygen-free solution. For DO measurement of other
mediums (for example dry air 20.95%@25°C or oxygen-saturated water) adjustment of slope (nA/ppm) has to done accurately according to the properties of
these mediums.

BKI 11 ATEX 0012 X  le00100a0600p_05  7 / 60
2. ORDER CODES
Not all combinations possible!
AnaCONT instruments:
AnaCONT L- -
*
TYPE CODE FUNCTION CODE HOUSING CODE PROBE** PROC.CONN./
MATERIAL CODE OUTPUT CODE
Transmitter E pH P Plastic 1 BSP 1½ “ / PP 1 4 … 20 mA 2
Transmitter +
display G ORP R Aluminium 2 BSP 1½ “ / PVDF 2 4 … 20 mA / HART 4
Integrated P DO DNPT 1½ “ / PP 4 4 … 20 mA / Ex 6
NPT 1½ “ / PVDF 5 4 … 20 mA / HART / Ex 8
4 … 20 mA / Relay R
4 … 20 mA / HART / Realy H
PHPROBE CODE ORP PROBE CODE DO PROBE CODE
4xpher112seph 14xorrherpseor 1 4x085g0023ydo /20ppm 1
4xphed112seph 24xorrhexpseor 2 4x085g0022ydo /10ppm 2
4xphex112seph 34xorrheptseor 3
4xpheph314sph 44xorrhespseor 4
4xphe1120seph 54xorrheppseor 5
4xphes112seph 64xorrheklseor 6
4xphep112seph 7
4xphekl112seph 8
* The order code of an Ex version should end in “Ex”!
** Probe selection is detailed in 3rd chapter.

8 / 60  le00100a0600p_05  BKI 11 ATEX 0012 X
The extension unit, adjustment unit and the sensor housing can be ordered to every analytical device, apart from the type of the electrode, measurement
principal and measured quantity. Sensor protection tube is available only for LP--, or LR--instruments.
EXTENSIONS L A – – 0
TYPE CODE MATERIAL CODE CODE LENGTH (L) CODE
Pipe R PP 1 0 0 m 0 m 0
Cable K PVDF 2 1 1 m 0.1 m 1
Suspended pipe F 2 2 m 0.2 m 2
3 3 m 0.3 m 3
4 4 m 0.4 m 4
5 5 m 0.5 m 5
6 6 m 0.6 m 6
7 7 m 0.7 m 7
8 8 m 0.8 m 8
9 9 m 09 m 9
A 10 m
PIPE EXTENSION:LAR--0 CABLE EXTENSION:LAK--0 SUSPENDED PIPE EXTENSION:LAF--0
L=0,2-3m
BSP2"
Ø63
L=-m
110
101
L = 0,2 - 3m
Ø3
Ø63
BSP2"

BKI 11 ATEX 0012 X  le00100a0600p_05  9 / 60
SLIDING SLEEVE: L A A – 1 0 – 0
CODE
DN80 PN16 / PP 2
DN100 PN16 / PP 3
DN125 PN16 / PP 4
DN150 PN16 / PP 5
DN200 PN16 / PP 6
Console mounting bracket, 200 mm K
Mounting bracket, 200 mm T
SLIDING SLEEVE WITH FLANGE:LAA-10-0
DN80 - DN200
63
DO
pH/ORP
CONSOLE MOUNTING BRACKET:
LAA-10K-0
MOUNTING BRACKET:LAA-10T-0
70
20 mm0
Ø12
105
2
ØA
101
80
DO pH/ORP
FOR EXTENSION TYPE
ØA =63.5MM
FOR BASIC TYPE
ØA =70.5MM

BKI 11 ATEX 0012 X  le00100a0600p_05  10 / 60
MATERIAL SIZE
SENSOR PROTECTION TUBE:L A P
–
1PP 11½” 0
–
0
2PVDF 22”
PROTECTION TUBE 1½”: LAP-10-0
FOR EXTENSION TYPE
PROTECTION TUBE 2”: LAP-20-0
FOR BASIC TYPE
BSP1 1/2"
130
Ø51
55
Ø51
BSP1 1/2"
112
BSP 2"
Sensor protection tube is available only for LP--, or LR--instruments

BKI 11 ATEX 0012 X  le00100a0600p_05  11 / 60
2.1. CONFIGURATIONS
COMPACT STANDARD TYPE:ANACONT LE--,
LG--
(+SENSOR PROTECTION TUBE:LAP-20-0)*
INTEGRATED STANDARD TYPE:ANACONT LP --
(+SENSOR PROTECTION TUBE:LAP-20-0)*
BSP1 1/2"
120 160
~90
120 ~200
Ø95
BSP1 1/2"
*Further configuration drawings show only compact types, however many accessories are available to order with integrated types.
Essential dimension values are shown in the drawings of the standard types.

12 / 60  le00100a0600p_05  BKI 11 ATEX 0012 X
STANDARD TYPE:ANACONT L--
(+SENSOR PROTECTION TUBE:LAP-20-0)*
STANDARD TYPE:ANACONT L--
+PIPE EXTENSION:LAR--0
(+SENSOR PROTECTION TUBE:LAP-10-0)*
~90
BSP1 1/2"
10
pH/ORP
112
BSP2"
BSP1 1/2"
DO
160
120
52
90
108
As per order
codes
BSP 1 ½"
120
pH/ORP
DO
10
Ø51
Ø63
* Sensor protection tube is available only for LP--, or LR--instruments.

BKI 11 ATEX 0012 X  le00100a0600p_05  13 / 60
STANDARD TYPE :ANACONT L--
+PIPE EXTENSION :LAR--0
+SLIDING SLEEVE WITH FLANGE:LAA-10-0
(+SENSOR PROTECTION TUBE:LAP-10-0)*
STANDARD TYPE:ANACONT L--
+PIPE EXTENSION:LAR--0
+CONSOLE MOUNTING BRACKET:LAA-10K-0
(+SENSOR PROTECTION TUBE:LAP-10-0)*
52
As per order codes
BSP 1 ½"
120
DO Ø51
90
108
10
pH/ORP
52
90
108
As per order codes
BSP 1 ½"
120
pH/ORP
DO
10
Ø51
* Sensor protection tube is available only for LP--, or LR--instruments.

14 / 60  le00100a0600p_05  BKI 11 ATEX 0012 X
STANDARD TYPE ANACONT L--
+CABLE EXTENSION:LAK--0
(+SENSOR PROTECTION TUBE:LAP-20-0)*
STANDARD TYPE:ANACONT L--
+CABLE EXTENSION:LAK--0
+SUSPENDED PIPE EXTENSION:LAF--0
(+SENSOR PROTECTION TUBE:LAP-10-0)*
98
BSP 1 ½"
120
pH/ORP
DO
10
112
BSP2"
BSP1 1/2"
90
175
A
s per order
codes
120
DO
90
175
As per order
codes
As per order
codes
1 ½"
52
110
Ø63
10
Ø51
BSP1 ½"
pH/ORP
* Sensor protection tube is available only for LP--, or LR--instruments.

BKI 11 ATEX 0012 X  le00100a0600p_05  15 / 60
STANDARD TYPE:ANACONT L--
+CABLE EXTENSION:LAK--0
+SUSPENDED PIPE EXTENSION:LAF--0
+SLIDING SLEEVE WITH FLANGE:LAA-10-0
(+SENSOR PROTECTION TUBE:LAP-10-0)*
STANDARD TYPE:ANACONT L--
+CABLE EXTENSION:LAK--0
+SUSPENDED PIPE EXTENSION:LAF--0
+CONSOLE MOUNTING BRACKET:LAA-10K-0
(+SENSOR PROTECTION TUBE:LAP-10-0)*
52
As per order codes
BSP 1 ½"
120
pH/ORP
DO
10
90
175
A
s per order
codes
45
from
DN80
Ø51
BSP1 ½"
52
As per order codes
BSP 1 ½"
120
pH/ORP
DO
10
Ø51
BSP1 ½"
90
175
A
s per order
codes
* Sensor protection tube is available only for LP--, or LR--instruments.

16 / 60  le00100a0600p_05  BKI 11 ATEX 0012 X
3. TECHNICAL DATA
GENERAL DATA
Material of sensor housing Polypropylene (PP), PVDF
Electrode As per order code
Housing material Compact type: Plastic: Glass fibre plastic PBT Metal: Powder paint coated Aluminium
Integrated type: Same as the sensor housing
Medium temperature
(pressure dependent) *
PP sensor housing: –10 °C ... +90 °C,
PVDF sensor housing: -15 °C …. +100 °C
with DO probe: 0 °C ... +50 °C
Ambient temperature Metal housing: -30 °C …+70 °C, Plastic housing: -25 °C … +70 °C, both with display: -20 °C … +70 °C
Pressure (absolute)* With pH and ORP probe: 0.05 … 1 MPa (0.5 … 10 bar) @25°C
With DO probe: 0,1…0,2 MPa (1…2 bar)@25°C
Sealing PP sensor housing: EPDM. all other sensor housing: FPM (Viton)
Ingress protection Compact type: Sensor housing: IP 68, Housing: IP 67 (NEMA 6)
Integrated type: IP 68
Power supply / Consumption 12 … 36 V DC / 48 mW … 720 mW, galvanic isolation, protection against surge transients
Electrode input With pH and ORP probe: Combined electrode, galvanic isolation, input impedance: >1012 ohm, connection: SN6.
With DO probe: Galvanic isolated current input, 0.725V polarisation voltage, connection: SN6
Liquid potential (complementary) electrode** Stainless steel housing of the temperature sensor (1.4571) , connection: SN6
Temperature measuring
(semiconductive sensor) Range: -50…130°C, Accuracy: ±0.5°C, Resolution: 0.1°C
Analogue: 4 … 20 mA, (3.9 … 20.5 mA), Rtmax = 1200 Ώ( [Ut– 12 V] / 0.022 A)
galvanic isolation, protection against surge transients
Relay: SPDT 30 V DC, 1A DC
Display: SAP-300 (128x64 pixels monochrome LCD, 41x24mm with effective display interface)
Outputs
Serial line: (optional) HART interface, terminal resistor 250 ohm
Electrical connections
Compact type: 2 x M20x1.5 metal cable gland, cable diameter: 7 … 13 mm, or 2 x M20x1.5 plastic cable gland, cable
diameter: 6 … 12 mm; connecting cable cross section: 0.5 ... 1.5 mm2(shielded cable is recommended) +
internal thread 2x NPT 1 / 2" cable protective pipe
Integrated type: 6x0.5mm2shielded cable 6 mm x 5 m (up to max. 30 m cable length)
Electrical protection Class III. electric shock protection, less than 24V voltage feed
* Depends on the selected electrode!
**In case of LP--and LR--instruments.

BKI 11 ATEX 0012 X  le00100a0600p_05  17 / 60
MEASUREMENT DATA
pH measurement Range: 0…14pH, Reserve: ±2pH, Accuracy*: 0.1% of the measured value ±1 digit ±0.01% /°C,
Linearity: ±0.004pH, Resolution: 0.01pH, (internal resolution 0.004pH), Measuring cycle: 300msec, on display: 1 sec
ORP measurement Range: ±1000mV, Reserve: ±200mV, Accuracy*: 0.1% of the measured value ±1 digit ±0.01% /°C,
Linearity: ±0.001%, Resolution: 0.1mV, Measuring cycle: 300msec, on display: 1sec
DO measurement Range: 0…20ppm v. 0…10ppm, Reserve: 20%, Accuracy*: 0.5% of the measurement range ±1 digit ±0.01% /°C,
Linearity: ±0.05ppm, Resolution: 0.01ppm, (internal resolution 0.005ppm), Measuring cycle: 300msec, on display: 1sec
* Depends on the selected electrode / sensor!
SPECIAL DATA FOR EX APPROVED MODELS
Ex marking II1G Ex ia IIB T6 Ga
Intrinsically safe data Ci ≤15 nF, Li ≤200
 H, Ui ≤30 V, Ii ≤140 mA, Pi ≤1 W
For Ex transmitter only Ex ia power supply should be used
Ex power supply Uo < 30 V, Io < 140 mA, Po < 1 W, power supply voltage range 12 V … 30 V, Rtmax = [Ut– 12 V] / 0.022 A
Medium temperature With pH and ORP probe: for PP sensor housing: –10... +70 °C, PVDF sensor housing: –15... +80 °C
With DO probe: : 0… +50 °C
Ambient temperature Metal housing: -30 °C … +70 °C with display: -20 °C … +70 °C, Plastic housing : -20 °C … +70 °C

18 / 60  le00100a0600p_05  BKI 11 ATEX 0012 X
3.1. TECHNICAL DATA OF THE PHELECTRODES (INCLUDING EX VERSIONS)FOR LP--INSTRUMENTS
Type 4xpher112seph 4xphed112seph 4xphex112seph
Range [pH] 1...12 1...12 1...12
Process temperature °C 0…80 0…80 0…100
Max. process pressure [bar] 6 8 16 (<25°C), 6 (<100°C)
Min. conductivity µs/cm 50 150 500
Diaphragm (the conductive aperture of the reference
electrode)/electrolyte in closed glass-house PTFE (Teflon) ring / 3 mol KCl 2 pcs ceramic rod / 3 mol KCl Concentrical gap/ 3 mol KCl
Connection / insertion length [mm] SN6 & PG13,5 / 120 SN6 & PG13,5 / 120 SN6 & PG13,5 / 120
Main application areas
Public and industrial
wastewater, process water,
drinking water, water in
chemical industry, water with
suspended solid particles.
Industrial water, drinking water,
slightly contaminated
wastewater, cooling tower
water, galvanic industry,
technologic water with Cr 6+,
CN
Wastewater, process water, water
in chemical industry, emulsions,
suspensions, mediums containing
proteins or sulphides, water with
high concentration of solid
particles.
Not applicable for
Steam sterilization, water with
low conductivity, sudden
temperature changes.
Steam sterilization, water with
low conductivity, sudden
temperature changes.
Steam sterilization, water with low
conductivity, sudden temperature
changes. Clear water!!
Type 4xpheph314sph 4xphe112seph 4xphes112seph
Range [pH] 3...14 1...12 1...12
Process temperature °C 0…100 0…60 0…60
Max. process pressure [bar] 6 (<25°C), 3 (<100°C) 0.5 3
Min. conductivity µs/cm 150 150 150
Diaphragm (the conductive aperture of the reference
electrode)/electrolyte in closed glass-house Ceramic / 3 mol KCl Ceramic / 3 mol KCl Ceramic / 3 mol KCl
Connection / insertion length [mm] SN6 & PG13.5 / 120 SN6 & PG13,5 / 120 SN6 & PG13,5 / 120
Main application areas
Monitoring or controlling of
chemical processes of
mediums from neutral to very
alkaline.
Swimming pools, applications
in atmospheric pressure,
drinking water, slightly
contaminated wastewater.
Swimming pools, applications
under pressure, drinking water,
slightly contaminated industrial
and wastewater.
Not applicable for
Steam sterilization, water with
low conductivity, sudden
temperature changes.
Steam sterilization, water with
low conductivity, sudden
temperature changes, above
atmospheric pressure.
Steam sterilization, water with low
conductivity, sudden temperature
changes

BKI 11 ATEX 0012 X  le00100a0600p_05  19 / 60
TYPE 4xphep112seph 4xphekl112sph
Range [pH] 1...12 1...12
Process temperature °C 0…80 0…60
Max. process pressure [bar] 6 3
Min. conductivity µs/cm 150 150
Diaphragm (the conductive aperture of the reference
electrode)/electrolyte in closed glass-house Ceramic / 3 mol KCl Ceramic (polycarbonate)
Connection / insertion length [mm] SN6 & PG13,5 / 120 SN6 & PG13,5 / 120
Main application areas
Swimming pools, drinking water, process water,
slightly contaminated wastewater, electrolytic
metallization.
Swimming pools, drinking water, process water,
slightly contaminated wastewater.
Not applicable for Steam sterilization, water with low conductivity,
sudden temperature changes.
Steam sterilization, water with low conductivity,
sudden temperature changes.

20 / 60  le00100a0600p_05  BKI 11 ATEX 0012 X
3.2. TECHNICAL DATA OF THE ORP ELECTRODES (INCLUDING EX VERSIONS)
FOR LR--INSTRUMENTS
TYPE 4xorrherpseor 4xorrhexpseor 4xorrheptseor
Process temperature °C 0…80 0…100 0…60
Max. process pressure [bar] 6 16 (<25°C), 6 (<100°C) 1
Min. conductivity µs/cm 50 500 150
Diaphragm (the conductive aperture
of the reference electrode)/electrolyte
in closed glass-house
PTFE (teflon) ring / KCl Circular recess / solid electrolyte Ceramic
Connection / insertion length [mm] SN6 & PG13,5 / 120 SN6 & PG13,5 / 120 SN6 & PG13,5 / 120
Main application areas
public and industrial wastewater
process water
drinking water
water in chemical industry
water with suspended solid particles
polluted water
emulsions, mediums containing
sulphides
high pressure applications
drinking water
pools in atmospheric pressure
slightly polluted water
Not applicable for
steam sterilization
water with low conductivity
sudden temperature changes
steam sterilization
water with low conductivity
sudden temperature changes
clean water
steam sterilization
water with low conductivity
sudden temperature changes
