NordicTrack A.C.T. NTCW90907.1 User manual

Nord.cTracICA.C r
Model No. NTCW90907.1
Serial No. _
Write the serial number in the
space above for reference.
Serial Number Decal
(under frame)
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete customer
satisfaction. If you have questions,
or if parts are damaged or missing,
PLEASE DO NOT CONTACT THE
STORE; please contact Customer
Care.
IMPORTANT: You
must note the
product model number and serial
number (see the drawing above)
before contacting
us:
CALL TOLL-FREE:
1-888-825-2588
Mon.-Fri. 6 a.m.-6 p.m. MST
Sat. 8
a.m.-4 p.m. MST
ON THE WEB:
www.nordictrackservice.com
A CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
"'::";"::'~~
.. Visit our website'at
~ . ,. ',.
"'l! .,
www.nordictrack.com
new products, prizes,
fitness tips, and much more!

-~I.N.;//;t1- Arm
HOW TO USE THE ELLIPTICAL EXERCISER
"
HOW TO PLUG IN THE POWER SUPPLY
Plug one end of the included power supply into the
jack on the front of the elliptical exerciser. Plug the
other end of the power supply into an appropriate out-
let that is properly installed
in accordance with all local
codes and ordinances.
HOW TO MOVE THE ELLIPTICAL EXERCISER
Due
to the size and weight of the elliptical
exerciser,moving it requires two persons. Stand in
front of the elliptical exerciser, hold the upright, and
place one foot against one of the front wheels. Pull on
the upright and have a second person lift the frame
until the elliptical exerciser will roll on the front wheels.
Carefully move the elliptical exerciser to the desired
location, and then lower it to the floor.
/
Pull on
upright
Place
your foot
here
HOW TO LEVEL THE ELLIPTICAL EXERCISER
If the elliptical exer-
ciser rocks slightly
on your floor during
use, turn one.or
both of the leveling
feet beneath the
front and rear of the Leveling
frame until the rock- Foot
------.\.\~-
ing motion is
eliminated.
HOW TO ADJUST THE STRIDE OF THE
ELLIPTICAL EXERCISER
To adjust the stride of the elliptical exerciser, turn the
adjustment knob clockwise while pulling it outward
until the adjustment arm pivots freely. Pivot the adjust-
ment arm until the adjustment knob is aligned with one
of the holes
in the handlebar leg, and gently release
the knob. Then, pivot the adjustment arm back and
forth slightly to make sure that the adjustment pin is
engaged
in one of the holes in the handlebar leg.
Adjust the other side of the elliptical exerciser in
the same way.
Adjustment
'.
Adjustment
Knob
13

HOW TO EXERCISE ON THE ELLIPTICAL
EXERCISER
To mount the elliptical exerciser, hold the handlebars
and step onto the pedal that
is in the lower position.
Then, step onto the other pedal. Push the pedals until
they begin to move with a continuous motion. Note:
The pedals can turn in either direction. It is recom-
mended that you turn the pedals in the direction
shown by the arrow; however, for variety, you can
turn the pedals in the opposite direction.
To dismount the elliptical exerciser, wait until the ped-
als come to a complete stop. Note: The elliptical
exerciser does not have a free wheel; the pedals
will continue to move until the flywheel stops.
When the pedals are stationary, step off the higher
pedal first. Then, step off the lower pedal.
14

CONSOLE DIAGRAM
, ,.
20
5:05
640
19
TIME REVOLUTIONS
18
3.64
97 36
17
CALORIES WATTS RPM
16
(c
)~
8 8
>
1 v
11
1 STEP RESISTANCE 1 STEP RESISTANCE
9
8
7
6
5
4
3
2
15
14
13
12
FEATURES OF THE CONSOLE
The advanced console offers an array of features
designed to make your workouts more effective and
enjoyable. When you select the manual mode of the
console, you can change the resistance of the pedals
with the touch of a button. As you exercise, the con-
sole will provide continuous exercise feedback.
You
can even measure your heart rate using the handgrip
pulse sensor.
The console also offers twenty preset workouts. Each
workout automatically changes the resistance of the
pedals and prompts you to increase or decrease your
pedaling pace as it guides you through an effective
workout.
The console features the iFit Interactive Workout
System, which enables the console to accept iFit
cards containing workouts designed to help you
achieve specific fitness goals. For example, lose
unwanted pounds with the 8-week Weight Loss work-
out. iFit workouts control the resistance of the pedals
while the voice of a personal trainer coaches you
through your workouts. iFit cards are available sepa-
rately. To
purchase iFit cards, go to www.iFit.com
or see the front cover of this manual. iFit cards are
also available at select stores.
You can even connect your MP3 player or CD player
to the console's sound system and listen to your
favorite music or audio books while you exercise.
To
use the manual mode, see page 16. To use a
preset workout, see page 18. To use an iFIT work-
out, see page 19. To use the sound system, see
page 19.
Note: If there is a sheet of clear plastic on the face of
the console, remove the plastic.
15

HOW TO USE THE MANUAL MODE
1. Press any button on the console or begin ped-
aling
to turn on the console.
When you turn on the console, the display will
light. A tone will then sound and the console will
be ready for use.
2. Select the manual mode.
When you turn on the console, the manual mode
will be selected. If you have selected a workout,
reselect the manual mode by pressing
the
Workouts button repeatedly until zeros appear in
the display.
0:00
o
TIME REVOLUTIONS
0.0 o 0
CALORIES WAITS
RPM
3. Press Start or begin pedaling and change the
resistance
of the pedals as desired.
As you pedal, change the resistance of the pedals
by pressing one of the numbered 1 Step
Resistance buttons. Note: After you press the but-
tons, it will take a moment for the pedals to reach
the selected resistance level.
4. Follow your progress with the display.
While you pedal, the upper left corner of the dis-
plaY' will show the elapsed time. Note: During a
preset workout, the display will show the time
remaining in the workout.
The upper right corner
of the display will show the
distance (total number of revolutions) you have
pedaled. The display will also show your heart rate
when you use the handgrip pulse sensor (see step
5 on page 17).
CALORIES WAITS RPM
The lower left corner of the display will show the
approximate number of calories you have burned.
The lower center of the display will show your
power output in watts.
The lower right corner
of the display will show your
pedaling speed
in revolutions per minute (rpm).
The resistance level of the pedals will appear in
the display for a few seconds each time the resis-
tance level changes.
You can also view selected information at a larger
size. Press the Display button repeatedly to view
the elapsed time and the distance you have ped-
aled, the elapsed time and the approximate
number of calories you have burned, the elapsed
time, or the approximate number of calories you
have burned. Press the Display button again to
view a workout history
of resistance levels and
pedaling pace.
To again view the time, distance, approximate
number of calories burned, your power output in
watts, and pedaling speed, press the Display but-
ton again.
You can also adjust the contrast of the display.
First, press and hold down the Display button for
several seconds until the display is blank. Then,
release the Display button and follow the instruc-
tions in the display to adjust the contrast.
16

5. Measure your heart rate if desired.
If there are
sheets
of clear Contacts
plastic on the
metal contacts on
the handgrip
pulse sensor,
remove
the plas-
tic. In addition,
make
sure that
your hands are
clean.
To measure
your heart rate,
hold the handgrip pulse sensor with your palms
resting against the metal contacts.
Avoid moving
your hands or gripping the contacts tightly.
When your pulse is detected, your heart rate will
be shown
in the display: For the most accurate
heart rate reading, hold the contacts for at least 15
seconds.
If your heart rate is not shown, make sure that
your hands are positioned as described.
Be care-
ful not to move your hands excessively or to
squeeze the metal contacts tightly. For optimal
performance, clean the metal contacts using a soft
cloth; never
use alcohol, abrasives, or chemi-
cals to clean the contacts.
6. Turn on the fan if desired.
To turn on the fan at high speed, press the Fan
button.
To turn on the fan at low speed, press the
Fan button a second time.
To select the auto
mode, press the Fan button again; when the auto
mode is selected, the speed of the fan will auto-
matically increase or decrease as you increase or
decrease your pedaling speed.
Pivot the fan louvers above the display upward or
downward to direct the airflow from the fan.
To turn off the fan, press the Fan button again.
Note:
If the pedals are not moved for about thirty
seconds, the fan will automatically turn off.
7. When
you are finished exercising, the console
will turn off automatically.
If the pedals are not moved for several seconds, a
series of tones will sound and the console will
pause.
If the pedals are not moved for about five minutes,
the console will turn off and the display will be
reset.
When you are finished exercising, unplug the
power supply. IMPORTANT:
If you do not do this,
the electrical
components of the exercise cycle
may wear prematurely.
17

HOW TO USE A PRESET WORKOUT 3. Begin pedaling to start the workout.
1. Press
any button on the console or begin ped-
aling to
turn on the console.
When you turn on the console, the display will
light. A tone will then sound and the console will
be ready for use.
2. Select a preset workout.
To select one of the twenty preset workouts, first
press the Workouts button. A menu of workout
profiles will then appear
in the display. Press the
left, right, up, and down arrows to highlight the
desired workout profile.
When a workout profile is highlighted, the workout
time and the maximum resistance level of the
workout will appear
in the display. To select a high-
lighted workout, press the Enter button.
When you select a preset workout, the workout
time and a profile of the resistance levels of the
workout will appear
in the display.
Profile
.....-.....
I I I
20:00 0
TIME REVOLUTIONS
Each workout is divided into 20, 30, or 45 one-
minute segments. One resistance level and one
target pace setting are programmed for each seg-
ment. Note: The same resistance level and/or
target pace setting may be programmed for con-
secutive segments.
During the workout, the workout profile will show
your progress (see the drawing
.to the lower left).
The flashing segment of the profile represents the
current segment of the workout. The height of the
flashing segment indicates the resistance level for
the current segment. At the end of each segment
of the workout, a series of tones will sound and
the next segment of the profile will begin to flash.
If a different resistance level is programmed for
.the next segment, the resistance level will appear
in the display for a few seconds to alert you. The
resistance of the pedals will then change.
As you exercise, you
will be prompted to
keep your pedaling
15:35
SPEED
OKAY
pace near the target TIME F
pace setting for the cur-
rent segment. When the
words SPEED UP appear in the display, increase
your pace. When the words SLOW DOWN appear,
decrease your pace. When the words SPEED
OKAY appear, maintain your current pace.
IMPORTANT: The target pace settings are
intended
only to provide motivation. Make sure
to pedal at a pace that is comfortable for you.
If the resistance level for the current segment is
too high or too low, you can manually override the
setting by pressing the 1 Step Resistance buttons.
However, when the current segment ends, the
pedals will automatically adjust to the resistance
level for the next segment.
If you stop pedaling for several seconds, a series
of tones will sound and the workout will pause.
To
restart the workout, press Start or simply resume
pedaling. The workout will continue until the last
segment of the profile flashes and the last seg-
ment of the workout ends.
18

4. Follow your progress with the display.
During the workout, the display will show the work-
out profile, the time remaining in the workout, and
the distance you have pedaled.
To view the profile, your pedaling pace, and the
distance you have pedaled, press the Display but-
ton. .
To view the time remaining in the workout and the
distance pedaled, press the Display button. Press
the Display button again to view the time remain-
ing and the approximate number of calories
burned.
To view the time remaining, distance pedaled,
approximate number of calories burned, your
power output
in watts, and pedaling pace, press
the Display button again.
To view the first display again, press the Display
button again.
5. Measure your heart rate if desired.
See step 5 on page 17.
6. Turn on the fan if desired.
See step 6 on page 17.
7. When you are finished exercising, the console
will turn off automatically.
See step 7 on page 17.
HOW TO USE AN IFIT WORKOUT
iFit cards are available separately. To purchase iFit
cards, go to www.iFit.com or see the front cover of this
manual. iFit cards are also available at select stores.
1. Press any button on the console or begin ped-
aling
to turn on the console.
When you turn on the console, the display will
light. A tone will then sound and the console will
be ready for use.
2. Insert an iFIT card and select a workout.
To use an iFIT workout, insert an iFIT card into the
iFIT slot; make sure that the iFIT card is oriented
so the metal contacts are face-down and are fac-
ing the slot. When the iFIT card is properly
inserted, the indicator next to the slot will light and
words will appear
in the display.
«Q f )~
~,
iFI~ 1[~lt~ ----j
iFIT Car.d
Next, select the desired workout on the iFIT card
by pressing the up and down buttons next to the
iFIT slot.
A moment after you select a workout, the voice of
a personal trainer will begin gUiding you through
your workout. iFIT workouts function
in the same
way as preset workouts.
To use the workout, see
steps 3 to 6
on pages 18 and 19.
3. When you are finished exercising, remove the
iFIT card.
Remove the iFIT card when you are finished exer-
cising. Store the iFIT card
in a secure place.
HOW TO USE THE SOUND SYSTEM
To play music or audio
books through the con-
sole's sound system while
you exercise, first locate Cable
the audio cable
in the cen-
ter of the console above
the speakers. Plug the
cable into a jack
on your MP3 player or CD player;
make sure that the audio cable is fully plugged in.
Next, press the play button on your MP3 player or CD
player. Adjust the volume
of the speakers using the
volume control on your MP3 player or CD player.
When not
in use, insert the audio cable into the stor-
age recess on the console.
19
