USER’S MANUAL
Model No. NTEVRW59216.0
Serial No.
Write the serial number in the space
above for reference.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference. www.iconeurope.com
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: [email protected]
Write:
ICON Health & Fitness, Ltd.
Unit 1D, The Gateway
Fryers Way, Silkwood Park
OSSETT
WF5 9TJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: [email protected]
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA

2
NORDICTRACK is a registered trademark of ICON Health & Fitness, Inc.
WARNING DECAL PLACEMENT
TABLE OF CONTENTS
This drawing shows the location(s) of the warning decal(s). If a decal is missing or illegible, see the
front cover of this manual and request a free replacement decal. Apply the decal in the location
shown. Note: The decal(s) may not be shown at actual size.
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS..................................................................3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
HOW TO USE THE ROWER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
MAINTENANCE AND TROUBLESHOOTING.....................................................16
EXERCISE GUIDELINES ....................................................................17
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
ORDERING REPLACEMENT PARTS .................................................. Back Cover
RECYCLING INFORMATION ......................................................... Back Cover

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your rower before using your rower. ICON assumes
no responsibility for personal injury or property damage sustained by or through the use of this
product.
1. It is the responsibility of the owner to ensure
that all users of the rower are adequately
informed of all precautions.
2. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
3. The rower is not intended for use by persons
with reduced physical, sensory, or mental
capabilities or lack of experience and knowl-
edge, unless they are given supervision or
instruction about use of the rower by some-
one responsible for their safety.
4. Use the rower only as described in this
manual.
5. The rower is intended for home use only. Do
not use the rower in a commercial, rental, or
institutional setting.
6. Keep the rower indoors, away from moisture
and dust. Do not put the rower in a garage or
covered patio, or near water.
7. Place the rower on a level surface, with a mat
beneath it to protect the floor or carpet.
8. Make sure that there is at least 2 ft. (0.6 m) of
clearance around the rower.
9. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
10. Keep children under age 13 and pets away
from the rower at all times.
11. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the rower. Always wear athletic
shoes for foot protection.
12. The rower should not be used by persons
weighing more than 286 lbs. (130 kg).
13. Always keep your back straight while using
the rower; do not arch your back.
14. Do not release the row bar while the bungee
is extended.
15. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.

4
Thank you for selecting the new NORDICTRACK®
RX 800 rower. Rowing is an effective exercise for
increasing cardiovascular fitness, building endurance,
and toning the body. The RX 800 rower is designed to
let you enjoy this effective exercise in the convenience
and privacy of your home.
For your benefit, read this manual carefully before
you use the rower. If you have questions after reading
this manual, please see the front cover of this manual.
To help us assist you, note the product model number
and serial number before contacting us. The model
number and the location of the serial number decal are
shown on the front cover of this manual.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
Folding Clamp
Rail Handle
Frame Handle Wheel
Footrest
Seat
Resistance Handle
Rail
Row Bar
BEFORE YOU BEGIN
Length: 7 ft. 3 in. (220 cm)
Width: 1 ft. 10 in. (56 cm)
Weight: 90 lbs. (41 kg)
Strap
Knob
Console
Adjustable Neck

5
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you nish all assembly steps.
• Assembly requires the following tool(s):
one Phillips screwdriver
one adjustable wrench
To avoid damaging parts, do not use power tools.
ASSEMBLY
2. If there are shipping tubes (not shown) attached
to the rower, remove and discard the shipping
tubes and the hardware attaching them.
With the help of a second person, pull the
Rail (2) outward and rotate the Stabilizer (3)
downward.
2
3
1
2
1. Go to www.iconsupport.eu on your computer
and register your product.
• activates your warranty
• saves you time if you ever need to contact
Customer Service
• allows us to notify you of upgrades and offers
Note: If you do not have internet access, call
Customer Service (see the front cover of this
manual) and register your product.

6
3. Have a second person hold the Rail (2)
during this step.
Attach the Stabilizer (3) to the Frame (1) with
two M10 x 20mm Screws (61).
Then, hold the Rail Handle (34), pull the Rail (2)
outward, and rest the Rail on the floor.
61
3
4. Orient the Seat (23) as shown, and slide the
Seat Carriage (5) onto the Rail (2). 4
23
2
2
5
34
3
1

7
5. Slide the Seat (23) to the front of the Rail (2).
Next, attach a Stop (32) to each side of the Rail
(2) with an M4 x 19mm Screw (69).
Then, attach the Rail Cap (38) to the Rail (2)
with two M4 x 19mm Screws (69).
6. While a second person holds the Console (75)
and the Upright (77) near the Frame (1), connect
the Upright Wire (84) to the Reed Switch Wire
(47). Insert the excess wire into the Frame.
Tip: Avoid pinching the wires. Attach
the Upright (77) to the Frame (1) with four
M8 x 35mm Screws (82); start all the Screws,
and then tighten them.
7. Identify the Right and Left Upright Covers
(80, 81), and orient them as shown.
Press the Right and Left Upright Covers (80, 81)
together around the Upright (77), and attach
them to the Upright with two M4 x 19mm
Screws (69).
Then, insert the Knob (78) into the Right Upright
Cover (80) and tighten it into the Upright (77).
5
6
7
82
77
81
80
77
69
69
78
1
84
75
47
Avoid pinching
the wires
2
38
69
69
32
32
23
69
69

8
9. Make sure that all parts are properly tightened before you use the rower. Extra parts may be included.
Place a mat under the rower to protect the floor.
8. The Console (75) can use four D batteries (not
included); alkaline batteries are recommended.
Do not use old and new batteries together or
alkaline, standard, and rechargeable batter-
ies together. IMPORTANT: If the Console has
been exposed to cold temperatures, allow
it to warm to room temperature before you
insert batteries. Otherwise, you may damage
the displays or other electronic compo-
nents. Remove the screws (A) and the battery
covers (B), insert batteries into the battery
compartments, and then reattach the battery
covers. Make sure to orient the batteries as
shown by the diagrams inside the battery
compartments.
To purchase an optional power adapter, call
the telephone number on the cover of this
manual. To avoid damaging the Console (75),
use only a manufacturer-supplied regulated
power adapter. Plug one end of the power
adapter into the receptacle (C) on the Console;
plug the other end into an outlet installed in
accordance with all local codes and ordinances.
75
75
A
A
B
B
C
8
C

9
HOW TO ADJUST THE RESISTANCE
To vary the
intensity of your
exercise, you
can adjust the
resistance that
you feel when
you pull the row
bar. To increase
the resistance,
move the resis-
tance handle
toward the front
of the rower; to
decrease the
resistance, move the resistance handle toward the
rear of the rower.
HOW TO ADJUST THE FOOT PADS
First, sit on the seat and place your feet in the foot
pads.
Next, press the
footrest bracket,
slide the foot pad
to the desired
position, and
then release the
footrest bracket
so that the tab
engages a slot
in the foot pad.
Then, tighten the
strap over your foot.
Adjust the other foot pad in the same way. Make
sure to adjust both foot pads to the same position.
HOW TO ADJUST THE CONSOLE VIEWING ANGLE
To adjust the
console to the
desired viewing
angle, loosen
the knob in the
upright, move
the neck to the
desired angle,
and then tighten
the knob; do not
hold or pull on
the console.
HOW TO FOLD AND STORE THE ROWER
The rower can be stored in a folded position to con-
serve space. Store the rower in a location where
children cannot tip it. Remove the batteries from the
console when storing the rower for extended periods of
time.
To store the rower, first slide the Seat (23) to the rear of
the Rail (2).
Next, hold and lift the Frame Handle (52) and the Rail
Handle (34), and tip the rower forward onto the Shields
(7, 8) and the Storage Feet (43).
Handle
Pad
Tab
Bracket
Knob
Neck
23
2
34
52
3
43
7, 8
HOW TO USE THE ROWER

10
Then, pull the Rail Handle (34) inward until the Folding
Clamp (35) engages the bar on the Stabilizer (3).
To unfold the rower, first place your foot on a Stabilizer
Foot (41) and pull the Rail Handle (34) outward to dis-
engage the Folding Clamp (35).
Then, hold the Rail Handle (34) and the Frame Handle
(52), pull the Rail Handle outward, and lower the Rail
(2) to the floor.
HOW TO MOVE THE ROWER IN THE UNFOLDED
POSITION
Stand behind
the rower and lift
the rail until the
rower will roll on
the wheels. Then,
carefully move
the rower to the
desired location,
and lower the rail
to the floor. Do
not hold or pull
on the console
when moving the rower.
HOW TO MOVE THE ROWER IN THE FOLDED
POSITION
See HOW TO FOLD AND STORE THE ROWER on
page 9, and fold the rower. Then, hold the frame
handle, place your foot on a stabilizer foot, and tip the
rower until it will roll on the wheels. Carefully move the
rower to the desired location, and then tip it into the
storage position. Do not hold or pull on the console
when moving the rower.
52
41
41
35
2
3
34
Lift
here
Handle
Place
your foot
here
