Nortel 3050 Operating manual

Nortel VPN Gateway
Command Reference
Release: 7.0
Document Revision: 01.01
www.nortel.com
NN46120-103 216369-E
.

Nortel VPN Gateway
Release: 7.0
Publication: NN46120-103
Document status: Standard
Document release date: 10 September 2007
Copyright © 2007 Nortel Networks
All Rights Reserved.
The information in this document is subject to change without notice. The statements, configurations, technical
data, and recommendations in this document are believed to be accurate and reliable, but are presented without
express or implied warranty. Users must take full responsibility for their applications of any products specified in this
document. The information in this document is proprietary to Nortel Networks.
*Nortel, Nortel Networks, the Nortel logo and the Globemark are trademarks of Nortel Networks.
Export
This product, software and related technology is subject to U.S. export control and may be subject to export or
import regulations in other countries. Purchaser must strictly comply with all such laws and regulations. A license to
export or reexport may be required by the U.S. Department of Commerce.
Licensing
This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (
http://www.openssl.org/)
This product includes cryptographic software written by Eric Young ([email protected]).
This product includes software written by Tim Hudson ([email protected]).
This product includes software developed by the Apache Software Foundation (http://www.apache.org/).
This product includes a TAP-Win32 driver derived from the CIPE-Win32 kernel driver, Copyright © Damion K.
Wilson, and is licensed under the GPL.
See Appendix D, "License Information", in the User’s Guide for more information.
.

3
.
Contents
Preface 5
Who Should Use This Book 6
Related Documentation 7
Product Names 8
Typographic Conventions 9
How to Get Help 10
Getting help from Nortel Web site 10
Getting help over the phone from a Nortel Solutions Center 10
Getting help from a specialist by using an Express Routing Code 10
Getting help through a Nortel distributor or reseller 10
Command Reference 11
Menu Basics 12
Global Commands 13
CommandLine History and Editing 16
Command Line Interface Shortcuts 18
Variables 22
The Main Menu 25
/info Information Menu 26
/stats Statistics Menu 42
/cfg Configuration Menu 81
/cfg/ vpn #/syslog Syslog VPN configuration 419
/boot Boot Menu 468
/maint Maintenance Menu 472
/maint/logLogging system configuration 477
/maint/log/ in-memoryInternal memory configuration 477
CLI Dumps 479
Index 495
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

4
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

5
.
Preface
This Command Reference lists all the CLI commands available in the
Nortel VPN Gateway (NVG) software. The software supports both SSL
Acceleration and VPN.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

6Preface
Who Should Use This Book
This Command Reference is intended for network installers and system
administrators engaged in configuring and maintaining a network. It
assumes that you are familiar with Ethernet concepts and IP addressing.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

Licensing 7
Related Documentation
For full documentation on installing, configuring and using the many
features of the SSL VPN, see the following manuals:
•VPN Gateway 7.0 User’s Guide
(part number 216368-F September 2007)
Describes the initial setup procedure, upgrades, operator user
management, certificate management, troubleshooting and other
general operations that apply to both SSL Acceleration and VPN.
•VPN Gateway 7.0 Command Reference Guide
(part number 216369-E September 2007)
Describes each command line in detail. The commands are listed per
menu according to the order listed in the Command Line Interface
(CLI).
•VPN Gateway 7.0 Application Guide for SSL Acceleration
(part number 216370-D April 2006)
Provides examples on how to configure SSL Acceleration through the
CLI.
•VPN Gateway 7.0 CLI Application Guide for VPN
(part number 216371-E September 2007)
Provides examples on how to configure VPN deployment through the
CLI.
•VPN Gateway 7.0 BBI Application Guide for VPN
(part number 217239-D, September 2007)
Provides examples on how to configure VPN deployment through the
BBI (Browser-Based Management Interface).
•VPN Gateway 7.0 VPN Administrator’s Guide
(part number 217238-D, September 2007)
VPN management guide intended for end-customers in a Secure
Service Partitioning configuration.
•VPN Gateway 3050/3070 Hardware Installation Guide
(part number 216213-B, March 2005)
Describes installation of the VPN Gateway 3050 and 3070 hardware
models.
•VPN Gateway 7.0 Release Notes
(part number 216372-P, September 2007)
Lists new features available in version 7.0 and provides up-to-date
product information.
The preceding manuals are available for download (see “How to Get
Help” (page 10)).
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

8Preface
Product Names
The software described in this manual runs on several different hardware
models. Whenever the terms Nortel VPN Gateway,VPN Gateway or NVG
are used in the documentation, the following hardware models are implied:
•Nortel VPN Gateway 3050 (NVG 3050)
•Nortel VPN Gateway 3070 (NVG 3070)
•Nortel SSL VPN Module 1000 (SVM 1000)
The integrated SSL Accelerator (SSL processor) on the Nortel 2424-SSL
switch Similarly, all references to the old product name iSD-SSL or iSD
in commands or screen outputs should be interpreted as applying to the
preceding hardware models.
Note: Manufacturing of the Nortel SSL Accelerator (formerly Alteon
SSL Accelerator) has been discontinued.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

Licensing 9
Typographic Conventions
The following table describes the typographic styles used in this book.
Table 1
Typographic Conventions
Typeface or
Symbol Meaning Example
AaBbCc123 This type is used for names
of commands, files, and
directories used within the
text.
View the readme.txt file.
It also depicts on-screen
computer output and
prompts.
Main#
AaBbCc123 This bold type appears in
command examples. It
shows text that must be
typed in exactly as shown.
Main# sys
<AaBbCc123> This italicized type appears
in command examples as
a parameter placeholder.
Replace the indicated text
with the appropriate real
name or value when using
the command. Do not type
the brackets.
To establish a Telnet
session, enter: host#
telnet <IP address>
This also shows book titles,
special terms, or words to
be emphasized.
Read your User’s Guide
thoroughly.
[ ] Command items shown
inside brackets are optional
and can be used or
excluded as the situation
demands. Do not type the
brackets.
host# ls[-a]
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

10 Preface
How to Get Help
This section explains how to get help for Nortel products and services.
Getting help from Nortel Web site
The best way to get technical support for Nortel products is from the Nortel
Technical Support Web site: www.nortel.com/support
This site provides quick access to software, documentation, bulletins, and
tools to address issues with Nortel products. From this site, you can:
•download software, documentation, and product bulletins for answers
to technical issues
•sign up for automatic notification of new software and documentation
for Nortel equipment
•open and manage technical support cases
Getting help over the phone from a Nortel Solutions Center
If you do not find the information you require on the Nortel Technical
Support web site, and have a Nortel support contract, you can also get
help over the phone from a Nortel Solutions Center.
In North America, call 1-800-4NORTEL (1-800-466-7835). Outside North
America, go to the following web site to obtain the phone number for your
region: www.nortel.com/callus
Getting help from a specialist by using an Express Routing Code
An Express Routing Code (ERC) is available for many Nortel products and
services. When you use an ERC, your call is routed to a technical support
person who specializes in supporting that product or service. To locate the
ERC for your product or service, go to:www.nortel.com/erc
Getting help through a Nortel distributor or reseller
If you purchased a service contract for your Nortel product from a
distributor or authorized reseller, contact the technical support staff for that
distributor or reseller.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

11
.
Command Reference
This chapter describes how to use the command line interface on the
Nortel VPN Gateway (NVG). The chapter also provides explanations of all
available commands.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

12 Command Reference
Menu Basics
The Command Line Interface (CLI) is used for viewing information and
statistics. In addition, the administrator can use the CLI for configuring all
levels of the VPN Gateway.
The various CLI commands are grouped into a series of menus and
submenus. Each menu displays a list of commands and/or submenus that
are available, along with a summary of what each command will do. Below
each menu is a prompt where you can enter any command appropriate
to the current menu.
When creating new CLI objects, for example a new interface or a new
group, you will enter a wizard providing the relevant questions for that
object. The regular menu for the object will be displayed after the wizard is
completed.
This section describes the Main menu commands, and provides a list of
commands and shortcuts that are commonly available from all the menus
within the CLI.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

Getting help through a Nortel distributor or reseller 13
Global Commands
Some basic commands are recognized throughout the menu hierarchy.
These commands are useful for obtaining online help, navigating through
menus, and for applying and saving configuration changes:
Table 2
Global Commands
Command Action
help Display a summary of the global commands.
help <command> Displays help on a specific command in the
command line interface.
Example: Typing the "/cfg/sys" command at any
prompt in the CLI will display the System menu.
The same result is achieved by only typing /cfg/sys
(no quotation marks) at any menu prompt.
.Display the current menu.
print Display the current menu.
.. Go up one level in the menu structure.
up Go up one level in the menu structure.
/If placed at the beginning of a command, go to the
Main menu. Otherwise, this is used to separate
multiple commands placed on the same line.
cd "<menu/path> "Display the menu indicated within quotation marks.
Example: Typing cd "/cfg/sys" at any prompt in
the CLI will display the System menu. The same
result is achieved by only typing /cfg/sys (no
quotation marks) at any menu prompt.
pwd Display the command path used to reach the
current menu.
apply Apply pending configuration changes.
diff Show any pending configuration changes.
Passwords and secrets (if any) are displayed as
(SECRET).
revert Remove pending configuration changes between
"apply" commands. Use this command to restore
configuration parameters set since last "apply"
command.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

14 Command Reference
Table 2
Global Commands (cont’d.)
Command Action
paste Lets you restore a previously dumped
configuration. Before pasting the configuration, you
need to provide the password phrase you specified
when executing the dump command. For more
information, see the dump command.
exit Terminate the current session and log out. If
you have unapplied (pending) configuration
changes when using the exit command, you
will be notified. If you choose to log out anyhow
without using the apply command, your pending
configuration changes will be lost.
quit Same as Exit. If you have unapplied (pending)
configuration changes when using the quit
command, you will be notified. If you choose to log
out anyhow without using the apply command, your
pending configuration changes will be lost.
CTRL+^ Exit from the command line interface in case
the VPN Gateway has stopped responding.
This command should only be used when
connected to a specific VPN Gateway through a
console connection, not when connected to the
Management IP of the cluster through a Telnet or
SSH connection.
netstat Use this command to show the current network
status of the VPN Gateway. The netstat command
provides information about active TCP connections,
as well as the state of all TCP/IP servers and the
sockets used by them.
nslookup Use this command to find the IP address or host
name of a machine. To use this command, you
must have configured the VPN Gateway to use a
DNS server.
Example: >> Configuration# nslookup Enter
Hostname | IpAddress: 47.80.21.24; Server:
zsc4s011.us.nortel.com ; Address: 47.81.2.10
ping Use this command to verify station-to-station
connectivity across the network. The format is as
follows:
ping <IP address or host name>
The DNS parameters must be configured
if specifying host names (see /cfg/vpn <id>
/adv/dns/servers DNS Servers Configuration).
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

Getting help through a Nortel distributor or reseller 15
Table 2
Global Commands (cont’d.)
Command Action
traceroute Use this command to identify the route used for
station-to-station connectivity across the network.
The format is as follows:
traceroute <IP address or host name of
target station>
As with ping, the DNS parameters must be
configured if specifying host names.
cur Use this command to view all the current settings
for the active menu. Passwords and secrets (if any)
are displayed as (SECRET).
curb Use this command for a brief version of the current
settings for the active menu.
dump Use this command to dump the current
configuration for the active menu. The dumped
information can be cut and pasted in to another
operator’s CLI at the same menu level.
The dump command is also available in all statistics
menus to display statistics information for the
active menu. When the dump command is used,
no secret value will be dumped unless a dump
password has been given, and in this case the
secret value is encrypted. To paste a dump, the
paste command should be used. The password
given at the dumpcommand should then be
supplied.
lines nSet the number of lines (n) that is displayed on the
screen at one time. The default value is 24 lines.
When used without a value, the current setting is
displayed.
verbose
n
Sets the level of information displayed on the
screen:
0 = Quiet: Nothing appears except errors—not
even prompts.
1 = Normal: Prompts and requested output are
shown, but no menus.
2 = Verbose: Everything is shown.
The default level is 2. When used without a value,
the current setting is displayed.
slist Use this command to display a list of all Admin
user sessions currently running in the cluster.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

16 Command Reference
CommandLine History and Editing
Using the command line interface, you can retrieve and modify previously
entered commands with just a few keystrokes. The following options are
available globally at the command line:
Table 3
Command Line History and Editing Options
Option Description
history Display a numbered list of the last 10 previously entered
commands.
!! Repeat the last entered command.
!nRepeat the nth command shown on the history list.
pushd "Bookmarks" your current position in the menu structure. After
moving to another level or command in the menu structure,
you can easily return to the bookmarked position by typing the
popd command.
The pushd command can be combined with command
stacking, as in this example:
>> Information# pushd "/cfg/ssl/server 1/ssl"
>> SSL Settings# When you issue the popd command,
you are immediately taken back to the prompt from where you
issued the pushd command, the Information prompt in this
example.
popd Takes you back to a position in the menu structure that has
been "bookmarked" by using the pushd command.
<Ctrl-p> (Also the up arrow key.) Recall the previous command from the
history list. This can be used multiple times to work backward
through the last 10 commands. The recalled command can be
entered as is, or edited using the following options.
<Ctrl-n> (Also the down arrow key.) Recall the next command from the
history list. This can be used multiple times to work forward
through the last 10 commands. The recalled command can be
entered as is, or edited using the following options.
<Ctrl-a> Move the cursor to the beginning of command line.
<Ctrl-e> Move cursor to the end of the command line.
<Ctrl-b> (Also the left arrow key.) Move the cursor back one position to
the left.
<Ctrl-f> (Also the right arrow key.) Move the cursor forward one
position to the right.
<Backspace> (Also the Delete key.) Erase one character to the left of the
cursor position.
<Ctrl-d> Delete one character at the cursor position.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

Getting help through a Nortel distributor or reseller 17
Table 3
Command Line History and Editing Options (cont’d.)
Option Description
<Ctrl-k> Kill (erase) all characters from the cursor position to the end of
the command line.
<Ctrl-l> Rewrites the most recent command.
<Ctrl-c> Abort an on-going transaction. If pressed when there is no
on-going transaction, the current menu is displayed.
Note: Using <Ctrl-c> will not abort screen output generated from
using the cur command. To abort the heavy screen output that
may result from using the cur command, press <q>.
<Ctrl-u> Clear the entire line.
Other keys Insert new characters at the cursor position.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

18 Command Reference
Command Line Interface Shortcuts
Command Stacking
You can type multiple commands separated by forward slashes (/) on a
single line to access a submenu and one of the related menu options.
Type as many commands as required to access the desired submenu
and menu option. For example, the keyboard shortcut to access the list
command in the NTP Servers menu from the Main menu prompt is as
follows:
>> Main# cfg/sys/time/ntp/list
You can also use command stacking to go up one or more levels in the
menu system, and then go directly to another submenu and one of the
related menu options in that submenu. For example, to go up two levels
from the NTP Servers menu to the System menu, and from there to the
DNS settings menu to access the DNS servers menu, you would type:
>> NTP Servers# ../../dns/servers
Command Abbreviation
Most commands can be abbreviated by entering the first characters which
distinguish the command from the others in the same menu or submenu.
For example, the command shown in the first preceding example could
also be entered as follows:
>> Main# c/sy/t/n/l
TAB Command Completion
By typing the first letter of a command at any menu prompt and pressing
TAB, all commands in that menu beginning with the letter you typed
are displayed. By typing additional letters, you can further refine the list
of commands or options displayed. If only one command matches the
letter(s) you typed, that command is supplied on the command line when
pressing TAB. You can then execute the command by pressing ENTER.
If the TAB key is pressed without any input on the command line, the
currently active menu is displayed.
TAB Value Presentation
Pressing the TAB key also displays available options, for example if you
want to view previously configured values.
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

UsingSubmenu Name as Command Argument 19
>> Main# cfg/vpn #/linkset #/link
Enter Link number (1-256): <press TAB> Windows file share
link(1) Net Direct link(2)
Enter Link number (1-256):
In the preceding example, with the object name followed by the object ID
within parenthesis, both the name and the integer (for example 2) can be
used to select the object.
Example: To select Net Direct link, enter N and press TAB. This will
complete the object name so that the full name is printed. Then press
ENTER to select this value.
In the example below, with the object ID followed by the object name
within parenthesis, only the integer (for example 2) can be used to select
the object.
>> AAA# defippool <press TAB>
Usage: defippool <integer>
2(RADIUS) 1(Local)
UsingSubmenu Name as Command Argument
To display the properties related to a specific submenu, you can provide
the submenu name as an argument to the cur command (at a menu
prompt one level up from the desired submenu information).
For example, to display system information at the Configuration menu
prompt (/cfg), type the following command:
>> Configuration# cur sys
System:
Management IP (MIP) address = 192.168.128.211
Cluster Host 1: Type of the host = master
IP address = 192.168.128.213
SysName =
SysLocation =
License =
IPsec user sessions: 250
Secure Service Partitioning
PortalGuard
TPS: unlimited
SSL user sessions: 250
Default gateway address = 192.168.128.3
Ports = 1 : 2
Hardware platform = 3070
Host Routes:
No items configured
Nortel VPN Gateway
Command Reference
NN46120-103 01.01 Standard
10 September 2007
Copyright © 2007 Nortel Networks
.

20 Command Reference
Host Interface 1:
IP address = 10.1.82.145
Network mask = 255.255.255.0
Default gateway address = 0.0.0.0
VLAN tag id = 0
Mode = failover
Primary port = 0
Host Interface Routes:
No items configured
Without having to descend into the System menu (/cfg/sys),
system-specific information only is displayed directly at the Configuration
menu prompt. If the cur command had been used without the sys
submenu argument in the preceding example, information related to both
the Configuration menu and all submenus would have been displayed.
UsingSlashes (/) and Spaces in Commands
If you need to use a forward slash (/) or a space in a command string,
make sure the string containing the slash or space is within double
quotation marks before you run the command. One example of a
command where double quotation marks is required, is when you specify
a directory path and file name on the same line as the ftp command in
the CLI.
Example:
>> Software Management# download ftp 10.0.0.1 "pub/SSL-7.0.1-
upgrade_complete.pkg"
IP Address and Network Mask Formats
IP Addresses
IP addresses can be specified in different ways in the CLI:
•Dotted decimal notation. Specify the IP address as is, for example
10.0.0.1.
•According to the formats below:
A.B.C.D = A.B.C.D, i.e. same as above
A.B.D = A.B.0.D, i.e. 10.1.10 translates to 10.1.0.10
A.D = A.0.0.D, i.e. 10.1translates to 10.0.0.1
D = 0.0.0.D, i.e. 10translates to 0.0.0.10
Network Masks
A network mask can be entered in number of bits or in dotted decimal
notation.
