Nortel Mobile Communication 3100
Nortel Mobile Communication
3100 Fundamentals
Release: 3.1
Document Revision: 02.02
www.nortel.com
NN42030-109
.

Nortel Mobile Communication 3100
Release: 3.1
Publication: NN42030-109
Document release date: 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
While the information in this document is believed to be accurate and reliable, except as otherwise expressly
agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF
ANY KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are
subject to change without notice.
Nortel, Nortel Networks, the Nortel logo, and the Globemark are trademarks of Nortel Networks.
All other trademarks are the property of their respective owners.
.

3
.
Contents
New in this release 5
Features 5
Administration enhancements 5
Client and Web User Interface enhancements 6
Other changes 7
Overview 9
Mobile Communication 3100 overview 11
MC 3100 product 11
MC 3100 architecture 11
MC 3100 features 12
MCC 3100 for BlackBerry, MCC 3100 for Nokia, and MCC 3100
for Windows Mobile 15
MCC 3100 overview 15
MCC 3100 for BlackBerry 16
MCC 3100 for Nokia 16
MCC 3100 for Windows Mobile 16
MCC 3100 hardware and software 16
Supported devices 17
MCC 3100 software installation 20
MCC 3100 administration and security 20
MC 3100 Web User Interface 21
MCG 3100 23
MCG 3100 overview 23
MCG 3100 features 23
MCG 3100 server components 24
Hardware components 24
Software components 24
MCG 3100 installation and configuration 25
MCG 3100 administration and security 25
Administration 25
Licensing 26
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

4
Certificates 26
Other components 27
LDAP server 27
Documentation roadmap 29
Technical documentation changes 29
New technical documents 29
Retired technical documents 29
Restructured technical documents 29
Roadmap 29
MC 3100 documentation packaging 30
Text conventions 32
Bold Courier text 32
Bold Helvetica text 32
Plain Courier text 32
Special messages 33
Modular, task-based information 34
Work flows and task flows 34
Customer service 35
Nortel Global Services 36
Getting technical documentation 36
Getting product training 36
Getting help from a distributor or reseller 36
Getting technical support from the Nortel Web site 37
Getting help over the telephone 37
MC 3100 communication call flows 39
MCG 3100 registration process 39
MCG 3100 client registration process 40
MCG 3100 call termination process 41
MCG 3100 call origination - Direct Dial call process 42
MCG 3100 call origination - Call-me-First process 43
Terminology 45
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

5
.
New in this release
The following sections detail what’s new in Nortel Mobile Communication
3100 Fundamentals (NN42030-109) in Nortel Mobile Communication 3100
(MC 3100) for Release 3.1.
•"Features" (page 5)
•"Other changes" (page 7)
Features See the following sections for information about feature changes.
•"Administration enhancements" (page 5)
•"Client and Web User Interface enhancements" (page 6)
Administration enhancements
MC 3100 Release 3.1 contains the following administration enhancements.
•A freshly-installed Mobile Communication Gateway 3100 (MCG 3100)
comes with English prompts. The administrator can upload prompts in
other languages onto the MCG 3100. Callers into the MC 3100 hear
prompts in the system default language.
•New configuration parameters for call features appear in the Web
Administration Console.
•Ability to add an audio media file to support Music on Hold.
In the documents, the Web Console has been renamed to the Web
Administration Console.
For more information, see Nortel Mobile Communication 3100
Administration and Security (NN42030-600).
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

6New in this release
Client and Web User Interface enhancements
The Mobile Communication Client 3100 (MCC 3100) for BlackBerry,
MCC 3100 for Nokia, MCC 3100 for Windows Mobile, and the
MCC 3100 Web User Interface (MCC 3100 Web UI) contain the following
enhancements:
•Rapid Call Delivery: The Call Screening Enabled parameter controls
call delivery. When Call Screening Enable is not selected, incoming
calls are sent immediately to the mobile phone.
— When the client is active on a Class A (3G or WiFi, with a data
channel available on a call) device, a data notification message
from the server tells the client if the call is an enterprise call,
resulting in the client coming to the foreground on the device.
— When the client is active on a Class B device, the client must be
brought to the foreground manually.
•Cellular Voicemail Avoidance: When configured, calls to a user
receive a prompt, which the user must acknowledge, before the call is
connected. Because voice mail systems cannot answer the prompt, the
call does not get answered by the voice mail system.
•Native Call Intercept: When configured, the MCC 3100 intercepts all
calls from the native dialer and routes the calls. This feature enables
users to benefit from the MCC 3100 features without dialing from the
MCC 3100 application. When enabled, users can make personal calls
that route to their service provider using Personal mode.
•Presence Simplification: MCC 3100 supports the following presence
states:
— Available
— Away
— Extended Away
— Busy
— Do Not Disturb
— Offline
— On the Phone
Users can also add a custom caption to the states.
The Enterprise Call Server manages Do Not Disturb call handling.
•Music on Hold: The MCG 3100 plays an audio file stored on the
MCG 3100 for any call that is put on hold. The administrator can
replace the file with a customized file, as required,
The MCC 3100 for Nokia user interface contains the following
enhancements:
•updated graphical user interface
•support for the Native Call Intercept feature
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

Other changes 7
The MCC 3100 for BlackBerry and MCC 3100 for Windows Mobile user
interfaces contain the following enhancements:
•when the administrator installs localized prompts on the MCG 3100, the
clients that are configured to use the local language hear the prompts
in that language. Note that the MCC 3100 for Nokia supports only
English prompts.
The MC 3100 Web UI contains the following enhancements:
•Time of Day Routing: Calls can be routed to different locations, based
on the time of day and day of week. The feature also includes a time
zone parameter to configure the user’s time zone, and to enable the
display of call logs using the configured time zone (instead of the
MCG 3100 timestamp).
For more information, see the following documents:
•Nortel Mobile Communication Client 3100 for BlackBerry User Guide
(NN42030-101)
•Nortel Mobile Communication Client 3100 for Nokia User Guide
(NN42030-102)
•Nortel Mobile Communication Client 3100 for Windows Mobile User
Guide (NN42030-107)
•Nortel Mobile Communication 3100 Web User Interface User Guide
(NN42030-110)
Other changes
The following other changes were made to this document.
•Moved the Technical documentation changes section from this chapter
to the Documentation roadmap chapter.
•Updated the Documentation roadmap section to conform with the latest
standards.
Revision history
November 2009 Standard 02.02. This document is issued to support
Nortel Mobile Communication 3100 Release 3.1. Updated
Table 2 "Supported devices" (page 17).
October 2009 Standard 02.01. This document is issued to support
Nortel Mobile Communication 3100 Release 3.1.
July 2009 Standard 01.03. This document is issued to support
Nortel Mobile Communication 2100 Release 3.0 and the
Communication Server 2100 (CS 2100). Information
regarding the CS 2100 is added.
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

8New in this release
April 2009 Standard 01.02. This document is issued to update
technical content to remove the following sections:
•Installing the ECM MCG 3100 software
•Adding the MCG 3100 as an element from the primary
ECM
•Upgrading to a different network framework
•Accessing the MC 3100 Web Console from the ECM
September 2008 Standard 01.01. This document is issued to support
Nortel Mobile Communication 3100 Release 3.0.
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

9
.
Overview
This document describes the Nortel Mobile Communication 3100
(MC 3100) product.
Navigation •"Mobile Communication 3100 overview" (page 11)
•"MCC 3100 for BlackBerry, MCC 3100 for Nokia, and MCC 3100 for
Windows Mobile" (page 15)
•"MC 3100 Web User Interface" (page 21)
•"MCG 3100" (page 23)
•"Other components" (page 27)
•"Documentation roadmap" (page 29)
•"MC 3100 communication call flows" (page 39)
•"Terminology" (page 45)
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

10 Overview
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

11
.
Mobile Communication 3100 overview
This section gives an overview of the Mobile Communication 3100
(MC 3100) product and architecture.
Navigation •"MC 3100 product" (page 11)
•"MC 3100 architecture" (page 11)
•"MC 3100 features" (page 12)
MC 3100 product
The Mobile Communication 3100 (MC 3100) provides access to voice and
messaging services over a wireless and a cellular network and extends
commonly used Private Branch Exchange (PBX) features to mobile
devices.
MC 3100 supports several Nortel communication servers. This document
describes the interworking with MC 3100 and Nortel Communication
Server 1000 (CS 1000) . For the list of supported communication servers,
see the MC 3100 Product Bulletin at www.nortel.com.
MC 3100 consists of the following components:
•Nortel Mobile Communication Client 3100 (MCC 3100) for three
wireless devices:
— MCC 3100 for BlackBerry
— MCC 3100 for Nokia
— MCC 3100 for Windows Mobile
•Nortel MC 3100 Web User Interface (MC 3100 Web UI)
•Nortel Mobile Communication Gateway 3100 (MCG 3100) to
communicate between the clients and the communication server
MC 3100 architecture
The following diagram shows the MC 3100 network architecture.
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

12 Mobile Communication 3100 overview
Figure 1
MC 3100 and CS 1000 network architecture
The MCC 3100 for BlackBerry, the MCC 3100 for Nokia, the MCC 3100 for
Windows Mobile, the MC 3100 Web UI, and the Mobile Communication
Gateway 3100 (MCG 3100) depend on the following communication server
components:
Communication Server 1000
•Call server
•SIP Gateway
•SIP Proxy Server (SPS)
For more information, see Nortel Mobile Communication 3100 Planning
and Engineering (NN42030-200).
MC 3100 features
The following table lists the features available in MC 3100.
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

MC 3100 features 13
Table 1
MC 3100 features
Windows Mobile BlackBerry and Nokia
Cellular
Calls WiFi
Calls Cellular
Calls WiFi
Calls
Web UI
Single Enterprise number
reachability √X√X√
Single Enterprise number
identity √X√X√
Enterprise Calling Restrictions
(NCOS) √X√X√
Single Enterprise Voice mail
support with cellular Voice mail
avoidance
√X√X√
Access to Enterprise Dial Plan √X√X√
Access to Corporate Directory √X√XX
Access to Local Directory on
Mobile device √X√XX
Advanced Call Control: Direct
Outbound calls using the
Enterprise voice network
√X√XX
Advanced Call Control:
Call-me-First calls using the
Enterprise voice network
√X√X√
Advanced Call Control:
Dynamically redirect incoming
calls to any phone number
√X√XX
Presence and Instant message
support within closed MCC 3100
user group
√X√XX
Microsoft Office Communicati
ons Server 2007 (OCS 2007)
interoperability support for voice
calls
√X√X√
Integrated Virtual Private
Network (VPN) for Voice over
WLAN (VoWLAN) security
N/A X N/A X N/A
Call Detail Recording (CDR) √X√X√
Message Waiting Indicator
(MWI) √X√X√
Call Logs √X√XX
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

14 Mobile Communication 3100 overview
Table 1
MC 3100 features (cont’d.)
Windows Mobile BlackBerry and Nokia
Cellular
Calls WiFi
Calls Cellular
Calls WiFi
Calls
Web UI
Busy State (Active Call on
Mobile appears on other
line appearances and OCS
presence)
√X√X√
Device Handoff: Move call from
Mobile to Desk phone or vice
versa
√X√X√
Network Handoff: Active call
moved from cellular to WiFi
interface of mobile phone, or
vice versa
√XX XX
Mid Call Feature: Hold √X√X√
Mid Call Feature: Retrieve √X√X√
Mid Call Feature: Consultation
call √X√X√
Mid Call Feature: Drop
consultation call, Back to held
call
√X√X√
Mid Call Feature: Swap
between consultation and
primary call
√X√X√
Mid Call Feature: Blind transfer √X√X√
Mid Call Feature: Consultative
transfer √X√X√
Mid Call Feature: Ad hoc
conference √X√X√
Instant Conferencing: Invite a
list of participants defined by a
group list
√X√XX
Release 2.0 user interface X X BlackBerry: X
Nokia: X XX
Release 3.0 user interface √X√X√
Over the air download of client √X√XX
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

15
.
MCC 3100 for BlackBerry, MCC 3100
for Nokia, and MCC 3100 for Windows
Mobile
Mobile Communication 3100 (MC 3100) provides software applications,
called the Mobile Communication Clients 3100 (MCC 3100), which extend
the MC 3100 functionality to the following devices:
•Research in Motion (RIM) BlackBerry
•Nokia
•Handheld devices that support Microsoft Windows Mobile Version 5.0
(WM5) and Windows Mobile Version 6.0 (WM6).
Navigation •"MCC 3100 overview" (page 15)
•"MCC 3100 hardware and software" (page 16)
MCC 3100 overview
These clients support cellular voice services. The MCC 3100 provides
communication using the Mobile Communication Gateway 3100
(MCG 3100). The client extends Enterprise features, hosted within the
Enterprise infrastructure, to mobile phones.
The following sections explain the device-specific information.
•"MCC 3100 for BlackBerry" (page 16)
•"MCC 3100 for Nokia" (page 16)
•"MCC 3100 for Windows Mobile" (page 16)
For more information on the individual clients, see:
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

16 MCC 3100 for BlackBerry, MCC 3100 for Nokia, and MCC 3100 for Windows Mobile
•Nortel Mobile Communication Client 3100 for BlackBerry User Guide
(NN42030-101)
•Nortel Mobile Communication Client 3100 for Nokia User Guide
(NN42030-102)
•Nortel Mobile Communication Client 3100 for Windows Mobile User
Guide (NN42030-107)
MCC 3100 for BlackBerry
The MCC 3100 for BlackBerry operates on RIM BlackBerry devices.
The MCC 3100 for BlackBerry is a single mode client that provides
single-mode communication using the Mobile Communication Gateway
3100 (MCG 3100).
The Enterprise-hosted BlackBerry Enterprise Server (BES) defines the
data networking requirements between the BlackBerry device and the
BES. The BES configuration must include the BlackBerry Mobile Data
System (MDS) to allow the MCC 3100 for BlackBerry to route Hypertext
Transfer Protocol (HTTP) traffic to the BES, and then to the Enterprise
MCG 3100.
When you deploy the MCG 3100, data originates from the BES for all of
the MCC 3100 for BlackBerry clients. The RIM infrastructure manages the
boundary between the untrusted and trusted network, making the overall
solution deployment less complex.
MCC 3100 for Nokia
The MCC 3100 for Nokia operates on Nokia mobile devices. The
MCC 3100 for Nokia connects directly to the MCG 3100 and requires a
Wireless Access Point or an Internet connection through the Enterprise
firewall.
The MCC 3100 for Nokia does not contain integrated VPN software. Any
industry-standard VPN software for the Nokia device can be used.
MCC 3100 for Windows Mobile
The MCC 3100 for Windows Mobile operates on a wireless-enabled
Windows Mobile handheld device. MCC 3100 for Windows is available in
Single Mode and Dual Mode. The difference between Single Mode and
Dual Mode is that Dual Mode enables the MCC 3100 to make and receive
SIP calls over WiFi. For supported modes, see the MC 3100 Product
Bulletin at www.nortel.com.
MCC 3100 hardware and software
This section documents the hardware and software for MCC 3100.
•"Supported devices" (page 17)
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

MCC 3100 hardware and software 17
•"MCC 3100 software installation" (page 20)
•"MCC 3100 administration and security" (page 20)
Supported devices
MCC 3100 supports the devices in the following table.
Attention: The following table displays the supported devices at the time
this document was released. For a complete list of supported devices, see
the MC 3100 Product Bulletin at http://www.nortel.com.
Table 2
Supported devices
Device
brand Model number Operating
system
(OS)
MC 3100
Release
2.0
MC 3100
Release
2.1
MC 3100
Release
3.0
(SU145)
MC 3100
Release
3.1
BlackBerry 71XX RIM OS
v4.2.1 and
later
SSSS
BlackBerry 72xx RIM OS
V4.0 SS
BlackBerry 77xx RIM OS
V4.0 SS
BlackBerry 87xx RIM OS
v4.2.1 and
later
SSSS
BlackBerry 81xx (Pearl) RIM OS
v4.1 and
later
SSSS
BlackBerry 88xx RIM OS
v4.1 and
later
SSSS
BlackBerry 83xx
(Curve) RIM OS
v4.1 and
later
SSS
BlackBerry 89xx
(Curve) RIM OS
v4.2.1 and
later
SS
S represents single mode client in current release.
D2 represents dual mode with Release 2.0.
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

18 MCC 3100 for BlackBerry, MCC 3100 for Nokia, and MCC 3100 for Windows Mobile
Table 2
Supported devices (cont’d.)
Device
brand Model number Operating
system
(OS)
MC 3100
Release
2.0
MC 3100
Release
2.1
MC 3100
Release
3.0
(SU145)
MC 3100
Release
3.1
BlackBerry 90xx (Bold) RIM OS
v4.6 SS
BlackBerry 9200
(Curve) RIM OS
v4.6 S
BlackBerry 9900 (Bold) RIM OS
v4.6 S
BlackBerry 9600 (Tour) RIM OS
v4.7 S
BlackBerry Storm RIM OS
v4.7 S
Motorola Q WM5 S S
Motorola Q (9h) WM6 S S S
Motorola Q Global WM6 S S
Motorola Q9c WM6 S S
Nokia E50 Symbian
v9.1 S60
3rd Ed.
SS
Nokia E51 Symbianv9
.2 S60 3rd
Ed. FP1
SS
Nokia E60 Symbian
v9.2 S60
3rd Ed.
SSS
Nokia E61 Symbian
v9.1 S60
3rd Ed.
SSSS
Nokia E62 Symbian
v9.1 S60
3rd Ed.
SSS
Nokia E63 Symbian
v9.2 3rd Ed. S
Nokia E65 Symbian
v9.1 S60
3rd Ed.
SSSS
S represents single mode client in current release.
D2 represents dual mode with Release 2.0.
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

MCC 3100 hardware and software 19
Table 2
Supported devices (cont’d.)
Device
brand Model number Operating
system
(OS)
MC 3100
Release
2.0
MC 3100
Release
2.1
MC 3100
Release
3.0
(SU145)
MC 3100
Release
3.1
Nokia E66 Symbian
v9.2 S60
3rd Ed.
FP1
S
Nokia E71 Symbian
v9.2 S60
3rd Ed.
FP1
SS
Nolia E75 Symbian
v9.3 S60
3rd Ed.
FP2
S
Nokia E90 Symbian
v9.2 3rd Ed.
FP1
SS
Nokia N95 Symbian
v9.2 3rd Ed.
FP1
SS
Palm 750wx WM5 S S S
Samsung Blackjack WM5 S S S
Samsung Blackjack WM6 S S
Samsung BlackJack II WM6 S S
Samsung Ace WM6 S S
HP iPAQ hw69
xx Series WM5 D2 D2 D2, S D2
HP iPAQ 510 WM6 S S
HTC TyTn WM5 D2 D2 D2, S D2
HTC TyTn WM6 S S
HTC 6800 (Titan) WM5 D2 D2 D2, S D2
HTC 6800 (Titan) WM6 S S
HTC SMT5800 WM6 S
HTC Universal WM5 D2 D2 D2, S D2
HTC Apache WM5 D2 D2 D2, S D2
S represents single mode client in current release.
D2 represents dual mode with Release 2.0.
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.

20 MCC 3100 for BlackBerry, MCC 3100 for Nokia, and MCC 3100 for Windows Mobile
Table 2
Supported devices (cont’d.)
Device
brand Model number Operating
system
(OS)
MC 3100
Release
2.0
MC 3100
Release
2.1
MC 3100
Release
3.0
(SU145)
MC 3100
Release
3.1
HTC TyTn II WM6.1 S S
HTC AT&T
8925/Tilt WM6.1 S S
HTC S720 WM6 S
HTC S620/S621 WM5 S
HTC S620/S621 WM6 S S
HTC S710 WM6 S S
HTC Touch
Diamond WM6 S S
HTC Mogul WM6 S S
S represents single mode client in current release.
D2 represents dual mode with Release 2.0.
Users with unsupported devices can access MC 3100 features using the
Mobile Communication 3100 Web User Interface (see "MC 3100 Web User
Interface" (page 21)).
MCC 3100 software installation
MCC 3100 software installs on the devices using one of the following
methods:
•Over the air download: The device downloads the software from a web
page.
•Computer download: The user downloads the software to a computer,
connects the device to the computer, and downloads the software to
the device.
•Push download: For BlackBerry devices only, the BES can push the
software to the device.
MCC 3100 administration and security
After installing the MCC 3100 software, you must enter your account
username and password, the address of the MCG 3100, and your cell
phone number.
Nortel Mobile Communication 3100
Nortel Mobile Communication 3100 Fundamentals
NN42030-109 02.02 23 November 2009
Copyright © 2008-2009 Nortel Networks. All Rights Reserved.
.
