About this document
Purpose and audience
This document describes how to install and configure a Mediatrix
Analog Station Gateway in a Communication Server 2100 network.
How to check the version and issue of this document
The version and issue of the document are indicated by numbers (for
example, 01.01).
The first two digits indicate the version. The version number increases
each time the document is updated to support a new software release.
For example, the first release of a document is 01.01. In the next
software release cycle, the first release of the same document is 02.01.
The second two digits indicate the issue. The issue number increases
eachtimethedocumentisrevisedbutre-releasedinthesamesoftware
release cycle. For example, the second release of a document in the
same software release cycle is 01.02.
References in this document
Refer to the following documents for further information relevant to the
topics discussed in this document:
•Meridian SL-100/Communication Server 2100 Product Guide,
555-4001-806
•Meridian SL-100/Communication Server 2100 Application Planning
Guide, 555-4001-108
FOR MORE INFORMATION
To determine whether you have the latest version of this
document and how documentation for your product is
organized,checkthereleaseinformationinthe MeridianSL-100
Master Index of Publications.

x
555-4031-902 Standard 01.02 January 2005

11
Mediatrix 1124, 1104 and 1102 Installation and Setup Guide
Overview
Description TheCommunication Server2100supportsboththeMediatrix 1124and
1104 units, with Mediatrix being the supporting owner of these
products. The 1124 and the 1104 both use the same internal four-port
cards, with the only difference being the amount of cards used and the
box in which they reside. In this section, the 1124 is described in detail.
The Mediatrix 1124 (24 analog ports) unit is a telecommunications
device that provides full duplex communications for audio/fax/modems
over IP-based networks for the 2500-type analog telephone set or
G3-type fax machines. Each of the ports on the Mediatrix has its own
number. The Mediatrix unit automatically connects its Foreign
Exchange Service (FXS) port 1 to the PSTN in occurrences of power
failures, LAN faults or for maintenance purposes. You can install the
Mediatrixunitineitherwiringclosetswhereexistingwiringisterminated
or in office space.
The Mediatrix unit supports G.711 (A-law and Mu-Law), G.723.1 and
G.729 Annex A and B. It uses standard silence suppression algorithms
and Silence ID (SID) packet transport over RTP/RTCP on G.729A.
Annex B of G.729 refers to this standard. Silence suppression cannot
be activated with G.711.
The Mediatrix 1124 Analog Station Gateway (ASGW)
• is a standalone analog line gateway that connects up to 24 analog
phones, Group 3 fax machines, modems, and answering machines
to a LAN through a single 10/100BaseT Ethernet port to deliver a
wide range of Meridian SL-100 features.
• uses the Media Gateway Control Protocol (MGCP) to communicate
with the Gateway Controller located in the Communication Server
2100.
• operates on both hybrid and pure IP Communication Server 2100
platforms.

12 Overview
555-4031-902 Standard 01.02 January 2005
• uses the Mediatrix Unit Manager Network (UMN) GUI for
provisioning and configuration using the SNMP protocol. Unit
Manager Network installs on a PC connected to the same network
that hosts the Mediatrix unit. Unit Manager Network does not
interface with any Nortel Networks Communication Server 2100
OAM&P components.
• automatically connects the FXS port 1 to the PSTN using a RJ-11
bypassconnectionforemergencyfail-safeiftheIP connectiontothe
LAN fails (for example, power failure, LAN faults or maintenance).
• uses an RJ-45 connector for 10/100 Base-T to connect to the LAN,
an RJ-21 connector to a maximum of 24 analog lines, and an RJ-11
bypass connection to the PSTN.
Figure 1 illustrates the Mediatrix 1124 Analog Station Gateway (front
view). On the back of the Mediatrix unit, there is a power receptacle
connector and a fan. There are also three LED indicators: one for
POWER, one for LAN, and one for READY. Refer to the Mediatrix
1104/1124 Hardware and Software Product Specifications
documentation for more information.
Figure 1
Mediatrix 1124 Analog Station Gateway (front view)
FOR MORE INFORMATION
Refer to the user documentation for Mediatrix the 1104/1124.
1124
Mediatrix
G100372
RJ-11 Bypass connector – connects
to a maximum of 24 analog lines
RJ-45 connector – connects
with 10/100 BaseT auto sense
Ethernet to LAN
RJ-21X connector – connects
to a maximum of 24 analog lines
Factory default
settings switch

Overview 13
Mediatrix 1124, 1104 and 1102 Installation and Setup Guide
Figure 2 illustrates a sample Mediatrix 1124 Analog Station Gateway
configuration supporting various analog devices. Add the supported
devices in any configuration to a maximum of 24 devices per Mediatrix
1124 unit.
Figure 2
Mediatrix 1124 Analog Station Gateway configuration supporting analog devices
Figure 3 on page 14 illustrates a sample Mediatrix 1124 Analog Station
Gateway configuration in the CS 2100 configuration.
G100371
PSTN
IP Network
Multiple FAX machines
for large enterprises
Multiple analog phones,
modems, and FAX
machines for large
enterprise
Fail to POTS
Emergency Line
Analog Station
Gateway
Analog Station
Gateway
Multiple modems
for large enterprises
Analog Station
Gateway
1124
XXXXXXX
Multiple analog phones
for large enterprises
Analog Station
Gateway
1124
XXXXXXX
1124
XXXXXXX
1124
XXXXXXX
Nortel Networks
Communication Server
2100
CS LAN
Gateway
Controller
RJ-11 Bypass connection
10/100 Base-T
10/100 Base-T
10/100 Base-T
10/100 Base-T

14 Overview
555-4031-902 Standard 01.02 January 2005
Figure 3
Mediatrix 1124 Analog Station Gateway in a Communication Server 2100
configuration
G100389
IP Client
Manager
Subscriber D
Subscriber E
Subscriber C
Subscriber F
2004 2002
m6350
Nortel Networks
Communication
Server 2100
PVG
Gateway
Controller
PSTN
SuperNode
Data Manager
Sun
IP Network
IP Network
DMS
Signaling
Legend
Bearer
E
N
ET
I
SM
XA-
Co
r
e
M
S
L
PP
Subscriber A Subscriber B
1124
Mediatrix
Mediatrix Analog
Station Gateway
H.248
H.248
CCS7
PRI T1
UniStim
MGCP
MGCP

Overview 15
Mediatrix 1124, 1104 and 1102 Installation and Setup Guide
Hardware and software requirements
The following hardware components are required to implement this
solution:
• Mediatrix 1124/1104 Analog Station Gateway
• Cabling per Mediatrix unit:
— 1 RJ-45 10/100 BaseT Ethernet cable
— 1 RJ-11 telephone cord
— 1 RJ-21X cable
• A PC client/server using Microsoft Windows 9x/NT/2000/XP
operating system containing the Mediatrix Unit Manager Network
(UMN) software.
• For the Mediatrix 1124, up to 24analog devices:analog phones,G3
fax machines, modems, and answering machines.
• A LAN (with access to an Intranet or Internet) that connects to the
Mediatrix unit, Gateway Controller and client/server PC containing
the Unit Manager Network.
The following software components are required to implement this
solution:
• Mediatrix Unit Manager Network (UMN) – a Web-based GUI
accessed from a PC client/server that connects to the Mediatrix
Analog Station Gateway and provides configuration and
provisioning functions.
• The PC server running the UMN software must use Microsoft
Windows 9x/NT/2000 operating system.
• Management Information Base (MIB) files – included on the
Mediatrix installation disk.
References Consult the Mediatrix 1104/1124 user documentation for detailed
information about the Mediatrix 1104/1124 Analog Station Gateway.
The Mediatrix Web site is at www.mediatrix.com

16 Overview
555-4031-902 Standard 01.02 January 2005

17
Mediatrix 1124, 1104 and 1102 Installation and Setup Guide
Installation and configuration
procedures
This chapter describes the procedures for installing and configuring a
Mediatrix Analog Station Gateway in a Communication Server 2100
network.
Installing a Mediatrix Analog Station Gateway
Before configuring a Mediatrix Analog Station Gateway, you must first
make the physical connections. Figure 1 on page 12 shows a front view
of a Mediatrix 1124 and its connectors. Figure 4 shows the pinouts that
areusedtoconnecttheanaloglines(secondarrowfrom righton Figure
1 on page 12).
Figure 4
RJ21X receptacle pin out
25 1
50 26
G10061
2

18 Installation and configuration procedures
555-4031-902 Standard 01.02 January 2005
Table 1 describes the Mediatrix 1124 connectors.
Table 1
Mediatrix 1124 connectors
Connector Description
Ethernet RJ-45 Teladapt connector to provide the 10/100
Base-T auto sense LAN Connection.
Bypass RJ-11 Teladapt connector to provide line cord
connection to the telephone network.
Port 1 to 24 RJ-21X connector to provide connection to analog
phones (pins 49-50 are unused).
Power Connector (AC
Version) Standard power cord receptacle (IEC 320 – C14) for universal AC input internal SMPS.
Power Connector (DC
Version) Barrier terminal strip.
Reset Switch Reboots the Mediatrix 1124 in recovery mode or
factory reset mode.

Installation and configuration procedures 19
Mediatrix 1124, 1104 and 1102 Installation and Setup Guide
Configuring a Mediatrix Analog Station Gateway
Application
Use this procedure to setup a Mediatrix Analog Station Gateway.
Prerequisites
This procedure has the following prerequisites:
• The Mediatrix Analog Station Gateway must be connected to the
network.
• The Unit Manager Network application must be installed.
Note: Unit Manager Express can also be used, but most end user
will find Unit Manger Network easier to use.
Steps of procedure
Follow the steps in Procedure 1 to configure a Mediatrix Analog Station
Gateway.
Procedure 1
Configure the Mediatrix Analog Station Gateway
With the Unit Manager Network software installed on your PC
1Power off the Mediatrix.
2With a 10/100 base hub: plug a LAN cable from your laptop to the hub and
plug a LAN cable from the Mediatrix to the hub.
Note: A cross over cable can be used, instead of the hub – in which case
the connection would be from the PC to the Mediatrix.
3Configure your laptop with an IP address of 192.168.0.10 and the subnet of
255.255.255.0.
4You will need a paper clip.
aPress the reset button and power on the Mediatrix (refer to Figure 1 on
page 12).
CAUTION
Possible service interruption
Perform this procedure during a maintenance window or a
period of low traffic.
!
FOR MORE INFORMATION
Unit Manager Network installation information is contained in the
Unit Manager Express User’s Manual that comes with the Mediatrix
software CD.

20 Installation and configuration procedures
555-4031-902 Standard 01.02 January 2005
bHold until the LEDs start blinking.
5At this point you can start provisioning the Mediatrix (enter the values that the
example in Table 2 on page 20 shows).
6Once completed, unplug the power from the Mediatrix and unplug all
temporary LAN cables.
This procedure is now complete
Plug Mediatrix into the network LAN and power the Mediatrix up.
Enter the values that Table 2 shows, in the order they appear, to bring
up a Mediatrix Analog Station Gateway.
Table 2
Mediatrix configuration parameters example
Field Value
mediatrixConfig
localHostSelectConfigSource static
localHostFqdnSelectConfigSource static
ipAddressConfigLocalHostStatic
localHostStaticAddress 47.104.52.43
localHostStaticPrimaryDns 47.103.120.20
localHostStaticSecondaryDns 47.103.121.21
localHostStaticDefaultRouter 47.104.52.1
localHostStaticSnmpPort 161
localHostStaticFqdn MTL100.MED4.COM
ipaddressConfigMgcpCallAgent
mgcpCASelectConfigSource static
ipAddressConfigMgcpCAstatic
mgcpCAStaticHost 10.224.2.200 (active address
in the Gateway Controller)
mgcpCAStaticPort 2727
