Nortel Norstar M7100 Parts list manual

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○
M7100
Telephone
User Card

2
Release button
cancels active calls.
Display
shows the time, date, call information and guides
you while using Norstar* features.
Memory button
is programmable to store a feature or to
automatically dial internal or external
number.
Dial pad
Feature button
starts or ends a feature.
Volume control
Hold button
Your Norstar M7100 telephone
Button inquiry Confirm that your memory button has the correct snap-on cap by checking its
programming.
1. Release all calls and open lines with dial tone.
2. Press ƒ•‚ .
3. Read the display.
4. Press ƒ ␣ when finished.
1. Press ƒ•‡ .
2. Press ⁄ ␣ to · ␣ for the level you want.
1. Press ĥfl .
2. Press ⁄ , ¤ , ‹ or › to hear the different types of rings.
3. While the telephone is ringing, press √ to adjust the volume.
4. Press ƒ to store the ring.
1. Press √ when using the receiver or the speaker.
Adjusting display
contrast
Selecting a ring type
and volume
Adjusting receiver or
telephone speaker
volume
* Meridian and Norstar are trademarks of Northern Telecom.
softer louder
softer louder
Important: All M7100 telephones Release 09 (REL 09) and higher comply with the Americans with Disabilities Act
(ADA). See the label on the bottom of the telephone for the Release marking.

3
1. Pick up the receiver.
2. Dial the internal number.
1. Pick up the receiver.
2. Dial · (or your system's external line access code).
3. Dial the external telephone number.
Note: Internal numbers and the external access code are supplied by your
System Coordinator.
The M7100 telephone allows you to have two calls active at the same time.
By using ˙ you can switch between calls.
To answer a second call while on another call
1. Press ˙ to put the first call on hold.
The second call automatically comes onto the line.
To hold a call and make a second call
1. Press ˙ to put the first call on hold.
2. Dial the telephone number for the second call.
To return to the first call
1. Press ˙ ␣ again to return to the first call on hold.
The second call is automatically put on hold.
To hold a call
1. Press ˙ .
2. Press ˙ again to return to the call on hold.
Check the display for confirmation or additional information.
Internal calls
External calls
Making calls
Making and
answering a second
call
˙

4
About the
memory button
The memory button can store a
telephone number or feature
code to give you one touch
dialing or feature activation. You
can change the memory button
by programming it with a new
number or feature code.
Programming the memory button
Programming
memory buttons
Remember: Press ƒ•‚ to check the memory button.
External autodial
1. If you are on a call or an open line with dial tone, press ˙
or ® .
2. Press ƒ•⁄ .
3. Dial the external number.
4. Press ˙ ␣ to store the number.
5. Label your new button.
Internal autodial
1. If you are on a call or an open line with dial tone, press ˙
or ® .
2. Press ƒ•¤ .
3. Dial the internal number.
4. Label your new button.
Features
1. If you are on a call or an open line with dial tone, press ˙ ␣
or ® .
2. Press ƒ•‹ .
3. Press ƒ and the feature code.
4. Label your new button.
Erasing memory buttons
1. If you are on a call or an open line with dial tone, press ˙
or ® .
2. Press ƒ•⁄ .
3. Press ˙ ␣ to erase the button.
Memory button
P0749846 Issue 02 Printed in Canada
