OAKWORKS Nova Setup guide

Toll Free: 800.558.8850 • Phone: [phone] • www.oakworks.com
*patent pending
The ABC System allows you to customize the table to your client’s needs.
The cushion is adjusted to a comfortable
level allowing great support with less
pressure.
The adjustable cushion also offers a
great head support for both men &
women.
This position is very comfortable for
short periods of time and creates a
great stretch.
OAKWORKS®
Nova with ABC System
TABLE SET UP & CARE
RECOMMENDED USE &
POSITIONING TECHNIQUES

TO SET-UP THE TABLE:
Place the folded table sitting on
the rubber bumpers. With the
heel of your hand, bump the
UniLock™ tab between the face
rest outlets and the table will
open. Open the table up until
the legs are fully extended.
TABLE SET UP
When the table is fully opened, use your foot as a
brace on one of the leg extensions. Using the handle, tilt
the table upright until all four feet are on the floor.
Lift one end of the table, press down on the middle and
tension the cables a little.
TO CHANGE THE TABLE HEIGHT:
FOOT PUMP & HAND VALVE PLACEMENT:
page 1 www.oakworks.com
UniLock™ Check for and
remove any kinks
in the tubing system.
Place the foot pump on the floor
below the table but within easy
reach of your foot. Run the tube
to the hand control through the
table handle to insure it is easy
to reach.
CAUTION: Make sure the cables are slightly
tensioned before getting on the table.
When the table is set up, the
height should be adjusted to
the proper working height
for the therapist. Once this
is determined, adjust the legs
accordingly. Choose the hole
that represents the desired
height. After removing the
knob, put the bolt through
that hole. Replace and tighten
the knob by hand until snug.
Repeat on all other leg exten-
sions, setting all extensions
at same height.
SHIATSU CABLES
1. With the table on its side,
remove the wing nut from
the bolt and remove long
brace, cable and washers
from the short brace.
Reassemble them without
the cable. Repeat on the
second wing nut.
2. Turn the Unilock™ clasp to
the side.
3. Fold the legs against the
underside and lay the table
down flat on the floor.
CAUTION: Shiatsu Cables must
be installed as shown when using
table in normal height ranges.

www.oakworks.com page 2
CLIENT COMFORT - POSITIONING TIPS
To raise the height of the platform, be sure the thumb
valve is closed by rolling the tension roller towards the
end of the tube. Pump the foot pump slowly to raise
the height of the platform. If the platform is tilted, you
can easily level it with your hand. To lower the platform,
open the thumb valve by rolling the tension roller
away from the end of the tube. To maintain height be
sure the hand valve is closed by rolling the tension roller
towards the end of the tube.
Thumb Valve Closed
Foot Pump Thumb Valve Open
Your ABC System works well under a fitted sheet. Start
with the platform level with all clients and slowly lower
by partially releasing the thumb valve for a few seconds
at a time. A little goes a long way! Generally the best
position offers some support. If you go too far, just make
sure the thumb valve is closed and use the foot pump
to slowly raise the platform back up. Check in with the
client after a few minutes to see if any adjustment is
needed.
Great as an adjustable head
support for treatments where
the client is on their back
(supine). Slowly raise the
platform above level until
the client is comfortable.
This position is very
comfortable for short
periods of time and creates
a great stretch. The head
rest crescent pad should
be turned around to act
as a good neck support.
THE ABC SYSTEM CAN BE USED FOR
PRONE OR SUPINE POSITIONING
FOR BOTH MEN & WOMEN
The ABC system is
designed to accommodate
any size client comfortably
and with no fuss. The
system is designed to be
used with sheets.
ADJUSTING THE LEVEL
OF THE ABC PLATFORM:
ATTACHING THE FACE REST
To attach the Adjustable face rest, insert the dowels
into the holes on the end of the table. Wrap the
Velcro®strip that is attached to the table around the
horizontal bar on the face rest as shown to secure
into place. Attach crescent to top of platform. Follow
face rest instructions to adjust further.
CAUTION: Do not press hard on the foot pump.
It should take very little pressure to lift
your client.
Check to make sure no tubes are kinked
or constricted as you can damage your foot
pump if too much pressure is applied.
To prevent leakage, make sure the thumb
valve is securely closed.
Start with the platform level and use the foot pump to
slowly lift the person off the table. Do not overinflate!
Lifting a person too much can be uncomfortable,
generally a couple of inches is plenty.

PACKING UPYOUR TABLE
Turn the table on its side with the rubber bumpers
down. Store the face-rest, crescent and foot pump
under the table as shown.
Open the hand control valve and be sure there are
no kinks in the tube system so that any extra air
can escape the bladder when deflated.
Partially close the table top. Fold the legs into
the table and make sure the
cables are inside of the table
and that no tubes are being
pinched. Push the two halves
of your table together until
you hear the click of the
UniLock™.
To protect your table during
travel or storage, insert your
table into the carry case.
MAINTENANCE & TROUBLESHOOTING
The ABC system is designed to require no maintenance and offer years of service. The components in the system
are all easily replaced if there is a problem.
IF THE FOOT PUMP IS NOT LIFTING THE PLATFORM:
IF THE PLATFORM DOES NOT HOLD ITS POSITION:
Thumb Valve Open
UniLock™
Be sure the thumb
valve is closed.
Be sure there are no
kinks in the tube.
Note: there is a small amount of air leakage expected
in this system, it is not designed to hold it’s position
for extended periods of time. Just add a little air via
the foot pump when needed.
First make sure the thumb
valve is securely closed.
Check the hoses for holes,
connections are tight, and
listen for air leaks when the
system is pumped up to its
capacity.
No Kinks
Part No. MMINWC0008-EN Revision: 1 Revision Date: 02/20/2018
All portable tables: U.S. Patent 5,009,170
Unilock™ U.S. Patent 7,472,656
Integra Hinge™ U.S. Patent 5,943,965
CS System: U.S. Patent 6,192,809
Toll Free Phone: [phone]
Phone: [phone]
FAX: [phone]
www.oakworks.com
OAKWORKS®, Inc.
923 East Wellspring Rd.,
New Freedom, PA 17349
NOTE: OakwOrks®is not liable for injuries or damages sustained
when table is not used in the manner prescribed.
IF THE PLATFORM DOES NOT SEEM LEVEL:
The platform is designed to tilt and accommodate
breasts of different sizes. When using as a head
support, you may need to guide it with your hand.
CLEANING:
The ABC system features an
inflatable bladder located in
a sewn bag. The bag may
be cleaned with a damp
cloth if needed.
REPLACEMENT PARTS:
Replacement parts are available thru Oakworks.
Call customer service if needed. 800.558.8850
We recommend cleaning your upholstery fabric with
a mild detergent to protect it against oil stains and
dirt which will cause cracking and permanent stains
over time. Household products you can use include a
4:1 diluted solution of 409®cleaner, Fantastik®or any
non-abrasive with a non-alcohol content. Products
with a high alcohol content, when used over time,
will dry and eventually crack your upholstery fabric.
