Oase BioTec Premium 80000 User manual

40115/12 14
BioTec Premium 80000
40115_OASE-GAW_BioTec_Premiuml_80000_A4_01_end_. 16.12.14 08:21 Seite 2

- -
2
A
BTC0016
B
BTC0017

- -
3
C
BTC0030
D
BTC0032

- -
4
E
BTC0027
F
G
BTC0022 BTC0019

- -
5
H I
ProfiClear0040 BTC0018
J
K
BTC0031 BTC0026
L
BTC0020

- -
6
M
BTC0021
N
BTC0025

- -
7
O
BTC0028
P
BTC0029
Q
R
BTC0023 BTC0024

- EN -
32
- EN -
Table of Contents
1Information about these operating instructions................................................................................ 33
1.1Symbols used in these instructions.......................................................................................... 33
2Product Description.......................................................................................................................... 34
2.1Unit configuration..................................................................................................................... 34
2.2Function description................................................................................................................. 35
2.3Intended use ............................................................................................................................ 35
3Safety information ............................................................................................................................ 35
3.1Hazards encountered by the combination of water and electricity.......................................... 36
3.2Danger for persons with pacemakers...................................................................................... 36
3.3Correct electrical installation.................................................................................................... 36
3.4Safe operation.......................................................................................................................... 36
4Installation and connection............................................................................................................... 37
4.1Installation planning ................................................................................................................. 37
4.2Connect the unit....................................................................................................................... 38
4.2.1Information regarding pipes......................................................................................... 38
4.2.2Connecting the inlet..................................................................................................... 38
4.2.3Installation of the UVC clarifying unit........................................................................... 38
4.2.4Connecting the dirt outlet............................................................................................. 39
4.2.5Connecting the coarse dirt outlet................................................................................. 39
4.3Connecting and installing the control system .......................................................................... 39
5Commissioning/start-up ................................................................................................................... 40
5.1Adjusting the level detection device......................................................................................... 40
5.2Biological filter starter............................................................................................................... 40
5.3Order of starting up steps ........................................................................................................ 41
6Operation.......................................................................................................................................... 42
6.1Control system overview.......................................................................................................... 42
6.1Switching ON/OFF................................................................................................................... 42
6.2Operating modes...................................................................................................................... 43
6.1Manual cleaning....................................................................................................................... 43
6.1Settings in the menus .............................................................................................................. 43
6.1.1 CL : Cleaning time "Cleaning"........................................................................................ 43
6.1.2 EC : Extended cleaning time "Extra Cleaning"............................................................... 44
6.1.3 In : Time-dependent cleaning "Interval")....................................................................... 44
6.2Reading out the number of cleaning cycles............................................................................. 45
6.2.1Cleaning cycles in 24 hours......................................................................................... 45
6.2.2Total cleaning cycles ................................................................................................... 45
6.3Loading default settings........................................................................................................... 45
6.4System messages.................................................................................................................... 46
7Remedy of faults .............................................................................................................................. 48
8Maintenance and cleaning............................................................................................................... 50
8.1Cleaning the unit...................................................................................................................... 50
8.2Regular tasks........................................................................................................................... 50
8.3Cleaning foam filters ................................................................................................................ 50
8.4Replacing foam filters............................................................................................................... 51
8.5Cleaning the rinsing device...................................................................................................... 52
8.6Cleaning the screen element................................................................................................... 52
8.6.1Removing/fitting a screen element.............................................................................. 52
8.6.2Decalcifying the screen elements................................................................................ 52
8.7Removing/fitting the filter drum................................................................................................ 53

- EN -
33
14.1Cleaning the rinsing pump........................................................................................................53
14.2Replacing the rinsing pump ......................................................................................................54
9Storage/Over-wintering.....................................................................................................................54
10Wear parts.........................................................................................................................................54
11Disposal.............................................................................................................................................54
12Technical data...................................................................................................................................55
Symbols on the unit.................................................................................................................................272
Spare parts..............................................................................................................................................273
Translation of the original Operating Instructions
1 Information about these operating instructions
Welcome to OASE Living Water. You made a good choice with the purchase of this product BioTec
Premium 80000.
Prior to commissioning the unit, please read the instructions of use carefully and fully familiarise yourself
with the unit. Ensure that all work on and with this unit is only carried out in accordance with these
instructions.
Adhere to the safety information for the correct and safe use of the unit.
Keep these instructions in a safe place! Please also hand over the instructions when passing the unit on
to a new owner.
1.1 Symbols used in these instructions
GB The symbols used in this operating manual have the following meanings:
Risk of injury to persons due to dangerous electrical voltage
This symbol indicates an imminent danger, which can lead to death or severe injuries if the appropriate
measures are not taken.
Risk of personal injury caused by a general source of danger
This symbol indicates an imminent danger, which can lead to death or severe injuries if the appropriate
measures are not taken.
Important information for trouble-free operation.
A Reference to one or more figures. In this example: Reference to Fig. A.
→Reference to another section.

- EN -
34
2 Product Description
2.1 Unit configuration
A Description
1 Container cover
2 Level detection device
−Signals the water level in the filter system
3 Signal box with level detection device and temperature probe
−The signal box is connected to the control system.
4 Rollers for guiding the filter drum
5 Temperature probe
−monitors the water temperature
6 Filter drum with 6 screen elements
−screen elements for coarse dirt particles larger than 150 µm
7 Inner cover
−foam filter holder
−integrated water level indicator
8 DN 110 outlet
9 Foam filters with holder
−2x blue
−2x red
−2x violet
10 Rinsing pump for supplying the rinsing device
11 DN 75 dirt outlet with slide valve
12 Connection set, for connecting the Bitron
−2 × 38 / 50 mm (1½ / 2 ") adapters
−2 × 30° inlet bends
−2 × union nuts
−2 × flat seals 60 × 47 × 3 mm
13 Connection set, for connecting filter pumps
−1 × 38 mm (1½ ") hose connector
−1 × 50 mm (2 ") hose connector
−1 × union nut for hose connector
−1 × 40 … 60 mm hose clip
−1 × 90° (2 ") connection bend
−1 × union nut for connection bend
−1 × flat seal 56 × 43 × 3 mm
14 2 × 38 mm (1½") connection, closed with sealing plugs
−optional connection for a Bitron UVC clarifier
15 50 mm (2 ") connection for connecting the filter pumps
16 DN 110 dirt outlet for coarse dirt
17 Drum motor for filter drum
−the motor is connected to the control system
18 Dirt channel
−collects the coarse dirt and rinsing water from the screen elements
19 Rinsing device
−sprays water at high pressure onto the screen elements to rinse off the coarse dirt
20 Grease for the drum seal
21 Control system
22 Connector for drum motor
23 Connector for signal box
24 Power cable
25 Connector for rinsing pump
26 Fuse holder
−Fuse protection of the control system with 5 × 20 mm, T8 A 250 V safety fuse

- EN -
35
2.2 Function description
The filter system must be installed above the water level of the pond. A filter pump pumps the dirty pond
water out of the pond into the filter system. The clean water is returned to the pond through a pipe via
gravity.
The task of the BioTec Premium 80000 is to separate the dirt from the water. Screens (150 μm) remove
all types of dirt particles and foam filters provide a surface for the colonisation of bacteria for biological
filtration.
The separation of suspended solids and the activity of the filter bacteria on the foam filters removes a
large amount of the nutrients from the water.
The control system with integrated microcontroller system automatically controls and monitors the filtration
process. The automatic self-cleaning function can be individually adjusted to meet the user's
requirements.
The drum filter can be extended by connecting filter modules from the ProfiClear Classic series, for which
the drum filter has to be positioned 20 cm higher. In addition, the DN 110 outlet has to be replaced with a
DN 150 outlet, provided with the ProfiClear Classic.
Advantages of the filter system:
►Minimal installation work required
►High flow rate of 12500 l/h
►Simple extension using modules from the ProfiClear Classic series
►Easy upstream connection of UVC clarifiers
►Perfectly tailored to the AquaMax Eco Premium filter pump from OASE
2.3 Intended use
BioTec Premium 80000, referred to in the following as "unit", may only be used as specified in the
following:
►For cleaning garden ponds.
►Operation under observance of the technical data.
The following restrictions apply to the unit:
►Only operate with water at a water temperature of +4 °C to +35 °C.
►Never use the unit to convey fluids other than water.
►Do not use for commercial or industrial purposes.
►Not suitable for salt water.
►Never run the unit without water.
►Do not use in conjunction with chemicals, foodstuff, easily flammable or explosive substances.
3 Safety information
Hazards to persons and assets may emanate from this unit if it is used in an improper manner or not in
accordance with its intended use, or if the safety instructions are ignored.
This unit can be used by children from the age of 8 and by persons with physical, sensory
or mental impairments or lack of experience and knowledge, as long as they are
supervised or instructed on how to use the unit safely and are able to understand the
potential hazards. Do not allow children to play with the unit. Do not allow children to
clean or maintain the unit without close supervision.

- EN -
36
3.1 Hazards encountered by the combination of water and electricity
►The combination of water and electricity can lead to death or severe injury from electrocution, if the
unit is incorrectly connected or misused.
►Prior to reaching into the water, always switch off the mains voltage to all units used in the water.
3.2 Danger for persons with pacemakers
►The container cover contains a magnet with a strong magnetic field that may affect the operation of
pacemakers or implantable cardioverter defibrillators (ICDs). Always keep magnets at least 20 cm
away from implanted devices.
3.3 Correct electrical installation
►Electrical installations must meet the national regulations and may only be carried out by a qualified
electrician.
►A person is regarded as a qualified electrician, if, due to his/her vocational education, knowledge and
experience, he or she is capable of and authorised to judge and carry out the work commissioned to
him/her. This also includes the recognition of possible hazards and the adherence to the pertinent
regional and national standards, rules and regulations.
►For your own safety, please consult a qualified electrician.
►The unit may only be connected when the electrical data of the unit and the power supply coincide.
The unit data is to be found on the unit type plate or on the packaging, or in this manual.
►Ensure that the unit is fused for a rated fault current of max. 30 mA by means of a fault current
protection device.
►Extension cables and power distributors (e. g. outlet strips) must be suitable for outdoor use.
►Protect the plug connections from moisture.
►Only plug the unit into a correctly fitted socket.
3.4 Safe operation
►Never operate the unit if either the electrical cables or the housing are defective!
►Do not carry or pull the unit by its electrical cable.
►Route cords/hoses/lines in a way that they are protected against damage, and ensure that they do not
present a tripping obstacle.
►Only open the unit housing or its attendant components, when this is explicitly required in the operating
instructions.
►Only execute work on the unit that is described in thismanual. If problems cannot be overcome, please
contact an authorised customer service point or, when in doubt, the manufacturer.
►Only use original spare parts and accessories for the unit.
►Never carry out technical modifications to the unit.
►The power connection cables cannot be replaced. When the cable is damaged, the unit or the
component needs to be disposed of.
►Keep the socket and power plug dry.
►Overvoltage in the mains could lead to operating malfunctions of the unit. For information, please refer
to chapter "Remedy of faults".
►Do not breath in the spray from the rinsing device. The spray may contain harmful bacteria. When the
container cover is lifted up, the rinsing device continues operating.

- EN -
37
4 Installation and connection
Important: If the planned installation deviates significantly from the recommendations contained in this
manual:
►Have your specialist retailer check whether all technical specifications were adhered to. This is crucial
for a problem-free operation.
4.1 Installation planning
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injuries caused by electric shock from electrical units
operated in or near water.
Protective measures for accessible ponds:
►Only use electrical units or installations with a rated voltage of UAC ≤12 V or UDC ≤30 V in the water.
►Electrical installations with a rated voltage of UAC > 12 V or UDC > 30 V must be located at a distance
of at least 2 m from the water.
Protective measures for non-accessible ponds:
►Electrical installations with a rated voltage of UAC > 12 V or UDC > 30 V must be located at a distance
of at least 2 m from the water.
Note:
Use suitable transport and lifting aids to transport and install the unit.
The unit weighs more than 25 kg (→Technical Data).
Note!
The filter system operates day and night and causes rinsing noises during the automatic cleaning
cycles. (→Technical data)
►Please protect the general public and your neighbourhood from noise disturbance and comply with
the statutory noise regulations.
►The filter system can be enclosed such that the enclosure effectively absorbs the noises.
►Select the location of the filter system in order to avoid noise disturbance.
Plan the installation of the filter system. With careful planning, taking the ambient conditions into account,
you will obtain optimum operating results.
The following conditions must be met:
►The filter system starts the cleaningcycles automatically - day and night. These cleaning cycles cause
noise emissions (→Technical data).
►As the filter module is very heavy when filled, it must be placed on a suitable base (at least on slabs,
but preferably on a poured concrete base) to prevent it from subsiding.
►Horizontally align the base slab.
−The filter system must be horizontally positioned (max. deviation d ± 5 mm).
−Tip: Use commercially available concrete slabs, each measuring 500 × 500 mm. One concrete slab
is required for the operation of the filter system on its own; four concrete slabs are required for
operation of the filter system together with the ProfiClear Classic modules.
►Plan sufficient space for carrying out cleaning and maintenance work.
►Drain the dirty water into the drain or far enough away from the pond so that it cannot flow back into
the pond.
−If the coarse soiling and dirty water both run into the same pipe, it is important to use at least DN
110 pipes.
►Position the inlet in the pond (e.g. via a water course or waterfall) so that it is lower than the outlet of
the filter system.
Note:
A water course or waterfall guarantees optimum water return to the pond.
In this way, the filtered pond water is enriched with oxygen before it is returned to the pond.

- EN -
38
4.2 Connect the unit
4.2.1 Information regarding pipes
►Use suitable pipes.
►Do not use any right-angled bends. Bends with a maximum angle of 45° are very efficient.
►Standing water in pipes can freeze when there is a hard frost and cause pipes to burst. For this reason,
lay the pipes and hoses with a gradient (50 mm/m) to ensure that they can run empty.
4.2.2 Connecting the inlet
The filter system is equipped with a 50 mm (2 ") or 38 mm (1.5 ") connection for the filter pump.
►You can additionally connect a UVC clarifier. (→Fitting a UVC clarifier)
►The maximum flow rate is 12500 l/h.
►It is necessary to remove a screen element to access the internal connection. (→Removing/fitting a
screen element)
►Leave the connection for the filter pump on the container closed if it is to remain unused.
How to proceed:
B, C
1. Unscrew the cover cap.
2. Screwthe union nut with 50mm (2 ") or38 mm (1.5 ") hoseconnectorand flatseal ontothe connection.
Hand-tighten the union nut.
3. Slip the 50 mm (2") hose of the filter pump onto the hose connector and secure with a hose clip.
4. Screw the union nut with the 90° connection bend (2 ") and the seal onto the connection on the inside
of the container. Hand-tighten the union nut.
−Ensure that the connection bend points downwards.
−A correctly positioned connection bend prevents unintended overflow (emptying of the pond) and
also serves to reduce noise emissions.
Note!
If two pumps are connected but only one pump is switched on, water can flow back via the hose of the
switched-off pump without being filtered.
Protective measures:
►Always fit a non-return valve into the hose.
►Always switch on both pumps.
4.2.3 Installation of the UVC clarifying unit
The Bitron UVC clarifier is fitted to the drum filter module. The max. flow rate of the Bitron and the overall
system is 12500 l/h.
It is necessary to remove a screen element to access the sealing plugs. (→Removing/fitting a screen
element)
How to proceed:
D, E
1. Undo the screws with a screwdriver and remove the sealing plugs.
2. Guide the outlet sockets of the Bitron with flat seals through the holes in the container wall.
3. Screw the adapters onto the outlet sockets and hand-tighten.
4. Screw the 30° inlet bends with cap nuts onto the adapters and hand-tighten.
−Position the inlet bends so that they are pointing downwards.
−Correctly positioned inlet bends prevent unintended overflow (emptying of the pond) and also serve
to reduce noise emissions.
5. Connect the Bitron to the filter pump in accordance with the operating manual.

- EN -
39
4.2.4 Connecting the dirt outlet
The water in the container can be drained via the DN 75 dirt outlet with slide valve at the bottom of the
container if required (for cleaning, repair, overwintering).
►Connect a suitable DN 75 pipe and drain the dirty water into the sewer system.
How to proceed:
F
1. Remove the cap nuts and push the dirt outlet onto the connection.
2. Tighten the hose clip.
3. Tighten the cap nuts.
Connect the DN 75 pipe to the DN 110 pipe and drain the dirty water via a DN 110 pipe into the sewer
system. This will ensure that the dirty water pipe will be conveniently flushed out with sufficient pressure.
4.2.5 Connecting the coarse dirt outlet
G
The coarse dirt that collects in the dirt channel drains away via the DN 110 coarse dirt outlet (top outlet
on the container) on the input side.
►Connect a suitable DN 110 pipe and drain the dirty water into the sewer system.
4.3 Connecting and installing the control system
The cable harness of the Drum Filter Module contains the connection cables of the signal box, the drum
motor and the rinsing pump.
Connecting
H
►Connect the three connectors of the cable harness to the control system sockets. Hand-tighten the
union nuts.
−The connections are designed to prevent misconnection.
−First flood the container with water, then connect the control system to the mains voltage/power
supply.
Installation
I
►Protect the control system from direct sunlight.
►The control system is splash-proof and may be exposed to rain.
►Suspended installation of the control system: Either on the mount on the container wall of the drum
filter module or using the threaded hooks in another position.

- EN -
40
5 Commissioning/start-up
►Thoroughly clean the pond before starting up the filter system for the first time to ensure that it is not
overloaded by excessively soiled water. OASE recommends using the PondoVac pond vacuum
cleaner for cleaning the pond.
−This cleaning measure is normally not necessary for newly installed ponds.
►It is necessary to operate the filter system for 24 hours a day during the pond season.
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Isolate the unit prior to reaching into the water and carrying out any work on the
unit. Secure the unit from being switched on inadvertantly.
Attention! Sensitive electrical components.
Possible consequence: The unit will be destroyed.
Protective measure:
►Do not connect the unit to a dimmable power supply.
►Do not operate the unit with a timer.
Attention! Never allow the rinsing pump to run dry!
Possible consequences: The rinsing pump will be destroyed.
Protective measures:
►Check the water level at regular intervals. Ensure that the rinsing pump is always under water during
operation.
►Do not switch on the control system until the container is flooded with water.
5.1 Adjusting the level detection device
A rise in the water level during operation indicates that the system is soiled. The level detection device
signals possible soiling to the control system and the cleaning cycle is started.
The water level in the filter system is independent of the water level in the pond. The water level in the
filter system is dependent upon the circulation capacity. Therefore it may be necessary to adjust the level
detection device.
The level detection device can be fitted in two positions.
►Position 1: Suitable for circulation capacities greater than 8000 l/h (factory default setting).
►Position 2: Suitable for circulation capacities smaller than 8000 l/h and short automatic cleaning
intervals.
How to proceed:
J
1. Undo both lock nuts. Remove nuts and Allen screws.
2. Move the level detection device according to the hole pattern and fix in place with Allen screws and
lock nuts. Tighten both nuts.
5.2 Biological filter starter
The foam filters take several weeks to reach their full biological cleaning effect. We recommend the OASE
filter starter Biokick to ensure fast growth of bacterial populations. Micro-organisms colonise the filter
system, multiply and ensure an enhanced quality of the pond water by the decomposition of excess
nutrients.

- EN -
41
5.3 Order of starting up steps
How to proceed:
1. Close the slide valve for the dirt outlet at the bottom of the container.
2. Check that the entire filter system (pipes and hoses) is complete.
3. Remove the container cover.
4. Manually turn the filter drum for one whole rotation to ensure unobstructed movement.
5. Fill the filter with water until the rinsing pump is submerged (dry run protection of the rinsing pump).
6. Fit the container cover.
−The filter drum is stopped for safety reasons if the filter cover is lifted.
7. Switch on the control system and perform any necessary adjustments. (→Operation)
8. Switch on the filter pump and UVC clarifier (if applicable).
−Ensure that the water is returned to the pond via the return pipe.
9. Check all pipes, hoses and their connections for leaks.
−Expansion seals may leak initially until they have fully expanded on contact with water.
When using filter starter, medicines or pond water treatments, leave the UVC clarifying unit switched off
for at least 36 hours so as not to impair their efficacy.

- EN -
42
6 Operation
6.1 Control system overview
ProfiClear_0001
1 Display
−for displaying the operating status
−for displaying the menus and values for setting the drum filter
−the current water temperature [°C] is displayed as standard
2 On|Off button, Quit Error
−for switching the drum filter on or off
−for resetting error messages
3 LED, 2 colours
−LED is lit red: Control system switched OFF ( OFF )
−LED is lit green: Control system switched ON ( ON )
4 Menu button
For selecting the following menus and changing the values:
−cleaning time "Cleaning" ( CL )
−extended cleaning time "Extra Cleaning" ( EC )
−time-dependent cleaning "Interval" ( In )
5 Clean button
−for starting the manual cleaning cycle and for cancelling the active cleaning cycle
−LED (6) is lit when the cleaning cycle is active
6 Blue LED
−LED is lit: Cleaning cycle active
6.2 Switching ON/OFF
How to proceed Information
Switching on:
Press for 3 s.
−LED (3) is lit green.
−The display indicates On for approx 5 s.
−The display indicates the water temperature as standard.
−If there is a voltage interruption, the control system will remain switched
on.
Switching off:
Press for 3 s.
−LED (3) is lit red.
−The display indicates OFF .
−The control system switches off all functions.
−If there is a voltage interruption, the control system will remain switched
off.
On|Off
On|Off

- EN -
43
6.3 Operating modes
Description Information
Automatic mode:
−Operating mode for normal operation. −The display indicates the water temperature as standard. −A cleaning cycle is automatically started if the level detection device
signals an excessive deviation in the water level.
−The level exceeds a certain water level.
−After 20 automatic cleaning cycles, a cleaning cycle with extended
cleaning time is performed.
Time-dependent operation −In addition to the automatic cleaning cycle (dependent upon the water
level in the drum filter), a time-dependent cleaning cycle can be
performed. (→
In : Time-dependent cleaning "Interval")
−The duration of the cleaning cycle corresponds to the time set in the
cleaning time "Cleaning" menu. (→
CL : Cleaning time "Cleaning")
6.4 Manual cleaning
How to proceed Information
Press for 3 s
−LED (6) is lit
−The display indicates CL
−To cancel the process: Press the button again
−The drum motor is stopped for safety reasons if the filter cover is lifted.
The rinsing pump can still be manually started to check the function of the
nozzles.
−Each active cleaning cycle (automatic, time-dependent or manual) can be
stopped by pressing the button.
6.5 Settings in the menus
Note:
Settings can only be made in the menus when the control system is switched on. (→Switching on / off).
6.5.1 CL : Cleaning time "Cleaning"
Setting the cleaning time changes the duration of the cleaning cycle. Extend the cleaning time if the dirt is
not completely carried away by the water, for example if the drain pipes are very long or have lots of
bends, or there is a particularly large amount of sticky dirt (e.g. during spawning).
Please take into consideration that an extended cleaning time leads to increased water consumption. The
default setting of 10 s is normally sufficient (corresponds to approx. a 7/8drum rotation).
How to proceed Information
1. Press several times until
Cl appears in
the display.
−To cancel and exit the menu: Either wait for 10 s or press or .
2. Press for 5 s until the time is indicated in
the display. −To cancel and exit the menu: Either wait for 5 s or press or .
3. Press several times to change the
value.
−To change the value quickly: Hold down the
button
−Settable range: 10 – 30 s
−Increment: 1 s
−The number can only be changed upwards. Once the value 30 is reached,
the display returns to 10.
−Saving the set value: Wait for 5 s until the menu is automatically exited.
−Cancel without saving and exit the menu: Press or .
Clean
Menu On|Off
Clean
Menu On|Off
Clean
Menu
On|Off
Clean

- EN -
44
6.5.2 EC : Extended cleaning time "Extra Cleaning"
To prevent larger deposits from building up in the dirt channel or pipework, the unit performs a cleaning
cycle with an extended cleaning time after every 20 cleaning cycles. This ensures that the pipework is
flushed out at regular intervals.
However, if dirt and residue build up due to unfavourable conditions, you can increase the cleaning time
and flush out the pipe with additional water. The default setting for the extended cleaning time is 20 s.
How to proceed Information
1. Press several times until
EC appears in
the display.
−To cancel and exit the menu: Either wait for 10 s or press or .
2. Press for 5 s until the cleaning time is
indicated in the display. −To cancel and exit the menu: Either wait for 5 s or press or .
3. Press several times to change the
value.
−To change the value quickly: Hold down the
button.
−Settable range: 10 – 60 s
−Increment: 1 s
−The number can only be changed upwards. Once the value 60 is reached,
the display returns to 10.
−Saving the set value: Wait for 5 s until the menu is automatically exited.
−Cancel without saving and exit the menu: Press or .
6.5.3 In : Time-dependent cleaning "Interval")
In addition to automatic cleaning, the unit can also perform a time-dependent cleaning cycle. This is
particularly useful for ponds containing fish because even if there is only a small amount of dirt, excrement
is always removed from the water cycle before it leads to build-up of nutrients.
Adjust the time interval to meet the requirements. The Drum Filter Module is normally optimally set with a
time interval of 20 minutes (default setting). The function is deactivated with a time setting of 0 minutes.
The time-dependent cleaning cycle does not have any influence on the automatic cleaning cycle that starts
when the water level is too low. After each automatic cleaning cycle, the time interval is reset and starts
again from the beginning.
The time-dependent cleaning cycle also protects the filter system from freezing. For this, please refer to
the information about safe overwintering. (→Storage/overwintering)
How to proceed Information
1. Press several times until
In appears in
the display.
−To cancel and exit the menu: Either wait for 10 s or press or .
2. Press for 5 s until the time is indicated in
the display. −To cancel and exit the menu: Either wait for 5 s or press or .
3. Press several times to change the
value.
−To change the value quickly: Hold down the
button.
−Settable range: 0, 3 – 60 min
−0 min: No time-dependent cleaning
−Increment: 1 min
−The number can only be changed upwards. Once the value 60 is reached,
the display returns to 0.
−Saving the set value: Wait for 5 s until the menu is automatically exited.
−Cancel without saving and exit the menu: Press or .
Menu On|Off
Clean
Menu On|Off
Clean
Menu
On|Off
Clean
Menu On|Off
Clean
Menu On|Off
Clean
Menu
On|Off
Clean
