Ogawa iModa PLUS User manual

User Manual
OS 3128 使用手册
OS 3128.indd 1 5/26/2016 11:28:30 AM

1
OS 3108.indd 1 5/26/2016 11:28:31 AM

2
CONTENTS
30snoitcurtsnIytefaS
60smialCytnarraW
70riahCehtgnivoM
80seirosseccAdnastraPtcudorP
90margaiDrellortnoC
31serutaeFtcudorP
Product Specifications 41
41ecnanetniaMtcudorP
51gnitoohselbuorT
61sutcatnoC
OS 3108.indd 2 5/26/2016 11:28:31 AM

3
Safety Instructions
i. Usage environment
●Do not use the appliance in a wet condition or dusty environment as this may
result in malfunction or electric shock.
●Do not use the appliance in the bathroom.
●Do not place or store the appliance where it can fall or be pulled into a tub or
sink.
●Place the appliance in a safe location.
●Do not expose the appliance to a heater or direct sunlight.
ii. Unsuitable user
If you are experiencing health complications or conditions as stated below, please
consult your doctor before use:
- Suffering from heart disease
- Pregnancy
- Any health concerns
iii. When the product should not be used
●If the use exceeds 15 minutes at one time.
●This unit should not be used by children or invalids without adult supervision.
●Do not use this product before sleep.
●If the fabric cover is torn.
●If liquid is spilled onto the appliance.
●If the user feels abnormal or severe pain during the massage.
●If the user detects any malfunction or other abnormal conditions during
operation.
OS 3108.indd 3 5/26/2016 11:28:31 AM
If there is lightning.
●

4
Safety Instructions
iv. Caution and warning
●Unplug the appliance from the outlet when not in use.
●Do not use any attachments that are not recommended by OGAWA.
●Do not operate this appliance if it has a damaged cord or plug. Please return
the unit to OGAWA Service Center for examination and repairs.
●Do not insert your hands or any object into the massager’s vents and gaps.
●Use the heated surfaces carefully. It should not be used by children or
incapacitated persons. May be dangerous.
●Do not lift or carry this appliance by the power cord or any cord.
●This product is only intended for home use only.
Commercial use is prohibited.
●Do not cover the appliance during operation.
●Do not crush appliance and avoid it from sharp folds.
OS 3108.indd 4 5/26/2016 11:28:31 AM

5
Safety Instructions
v. Note
●Please read these safety notes thoroughly beforehand to ensure the safety
and correct use of the appliance.
●The appliance is not intended for use by persons suffering from physical,
sensory or mental disabilities, or persons who lack experience and knowledge
about the product. They need to be supervised and instructed by a person
responsible for their safety.
●Extensive usage could lead to excessive heating and shorter product lifespan.
Should this occur, discontinue usage and allow the unit to cool before
operating.
●Some levels of noise during usage are normal due to vibration.
●Consult the doctor before use if the person using it is under medication or with
a medical condition. Please do not use the product if you are not feeling well.
●Do not increase the room temperature abruptly if the appliance is used in the
cold room. It is advisable that the temperature should increase gradually to a
normal level.
●If the appliance is stored in a cold place or in a warm environment, please
wait for one hour before use to reach the optimum massaging level.
●Do not remove the cover of the appliance. Touching the internal components
may result in malfunction or electric shock.
●Do not connect or disconnect the power cord from the electrical outlet with
wet hands.
●Do not use the appliance if the electrical outlet is loose.
OS 3108.indd 5 5/26/2016 11:28:31 AM
The appliance has a heated surface. Persons insensitive to heat must be
careful when using the appliance.
●

6
Warranty Claims
1. Warranty is not transferable.
2. This warranty is effective only if the product is purchased from OGAWA.
3. Proof of purchase (original receipt) is required for all warranty repairs.
4. All implied warranties, including but not limited to these implied warranties of fitness
and merchantability, are limited to the duration stated in the warranty policy.
5. Damage due to misuse, improper treatment and unauthorized modification and
repair are not covered by this warranty.
6. Warranty does not cover accessories and attachments which do not belong to the
massage unit.
7. Warranty is not effective to rental, business, commercial, institutional or other non-
residential users.
8. All services covered by this warranty must be approved by OGAWA and repaired
by authorized technicians only.
9. If replacement parts for defective materials are not available, OGAWA reserves the
right to make substitution in lieu of repair or replacement.
OS 3108.indd 6OS 3108.indd 6 5/26/2016 11:28:31 AM5/26/2016 11:28:31 AM

7
Moving the Chair

Caution:
Avoid moving the massage chair when there is someone seated on it.
Placing a mat underneath the massage chair is advisable, as the moving process
might scratch the floor surface.
OS 3108.indd 7OS 3108.indd 7 5/26/2016 11:28:31 AM5/26/2016 11:28:31 AM

8
Product Parts and Accessories
rellortnoC
OS 3108.indd 8 5/26/2016 11:28:32 AM
riahCegassaMehtfoydoB

9
Controller Diagram
OS 3108.indd 9 5/26/2016 11:28:32 AM
1
3
4
2
6
7
9
10
12
14
5
11
13
8

10
Control Buttons for the Massage Chair
1. ON / OFF
Press this button to activate air pressure massage.Press again to turn off this function.
OS 3108.indd 10 5/26/2016 11:28:32 AM
Insert the plug of the massage chair into an appropriate outlet to power the chair.
If massage rollers are not at the waist, then they will return to their original position
(during this process, the ON / OFF indicator is lit, but no buttons work),and the indicator
will be unlit later. Press the ON / OFF button to activate the chair, the indicator will be lit,
then a desired massage function can be selected. After the chair is activated,the timer
is preset at 15 minutes will be displayed on the controller. Long press the ON / OFF
button after the chair is activated or the preset program ends, all functions will stop and
the massage rollers will return to their original position.
2. KNEADING
When the chair is operating, short press the KNEADING button, the indicator will be lit,
light will lit. Press the button again to close the mode. If the tapping function is activated
the kneading function, then both functions will work together.
and the kneading function will start. The intensity is preset at high level, strength button
3. TAPPING + ROLLING
When the chair is operating, short press this button to activate the tapping function and
rolling massage. The the intensity is preset high level, speed button light will lit.Press this
button again to close the mode. If the kneading function is activated before the tapping
function, then both functions will work together. If the present kneading function is in the
Spot massage mode, press this button, the chair will resume its moving and the indicator
will be lit.
4. AIR PRESSURE MASSAGE

11
5. STRENGTH
The Strength Adjustment Button for Kneading - high and low level to be adjusted.
Afterr activating the Kneading function,every time the button is pressed,the strength
can be adjusted to "high>low" in one cycle.In high level,the light is lit,in low level the
6. SPEED
The Speed Adjustment Button for Tapping and Rolling - high and low level to be adjusted.
After activating the Tapping and Rolling,every time the button is pressed, the speed can
be adjusted to "high > low" in one cycle.In high level the light is lit inlow level the light will
flash.
7. INTENSITY
After the air massage is activated, short press the INTENSITY button to switch among
high and low intensity in cycle.Light flash for low intensity, and light lit for high intensity.
9. HEAT / WIDTH ADJUSTMENT
OS 3108.indd 11 5/26/2016 11:28:32 AM
light will flash and Rolling.
8. SPOT OR LOCALISED MASSAGE
Under the kneading function after the chair activation, press the SPOT button (up and
down arrows) to start the Spot massage function, and the mode light will flash. Press
and hold the up or down arrow to move the massage rollers upward or downward.
Release the button to stop the roller adjustment and start the Spot massage function.
Meanwhile, the corresponding upward or downward indicator light will be turned off.
When the chair is operating, press this button to start the HEAT function independently,
and the HEAT indicator will be lit. Short press the button again to stop the function, and
the indicator will be unlit.
When the Tapping mode is activated, long press the HEAT / WIDTH adjusment button
2 second to adjust the Tapping width.The indicator will be lit in the process of the adjus-
-tment and unlit after the adjustment.

12
10. ARCH NECK
When the chair is operating,short press this button to start the Arch Neck AUTO mode,
and the indicator will be lit. Press it again to close the mode.
14. TRAVELLER
12. TVAHOLIC
OS 3108.indd 12 5/26/2016 11:28:32 AM
11. SHAPE N' TONE
When the chair is operating,short press this button to start the Shape n' Tone AUTO
mode,and the indicator will be lit. Press it again to close the mode.
When the chair is operating,short press this button to start the TVaholic AUTO mode,
and the indicator will be lit. Press it again to close the mode.
13. OFFICE PRO
When the chair is operating,short press this button to start the Office Pro AUTO mode,
and the indicator will be lit. Press it again to close the mode.
When the chair is operating,short press this button to start the Traveller AUTO mode,
and the indicator will be lit. Press it again to close the mode.

13
Product Features
●With a compact size and fashionable appearance, the massage chair is an
excellent partner for a healthy life.
●Its “L” shape rail is designed to make your neck, back, waist and hip more comfortable,
giving you a better massage experience.
●Besides the traditional kneading massage, a tapping function is added to create a more
professional feeling of massage by human hands.
●5 automatic massage modes are optional for different requirements to improve your
physical conditions.
●Its precise program focuses on waist and hip massage by strengthening hip
muscles and shaping beautiful curves of the hip.
OS 3108.indd 14 5/26/2016 11:28:32 AM
●With excellent and thoughtful design in details, it is an ideal choice for a delicate life
and a high-quality home.

14
Product Specifications
a PlusdoMiemaNtcudorP
2813SOledoMtcudorP
~V042-001egatloVdetaR
W69rewoPdetaR
mm056xmm059xmm079noisnemiD
setunim51remiT
Product Maintenance
●Do not use water or other cleaning detergents to wash the massage chair.
●Do not stack, knock with hard objects, pull harshly or scratch the surface of the
massage chair.
●Press the buttons gently during operation; avoid pressing with sharp objects.
●Always pull out the power supply plug after use or before cleaning.
●Please keep the controller away from water or liquid.
OS 3108.indd 15 5/26/2016 11:28:32 AM

15
Troubleshooting
If you are caught in any problems when using this product, please refer to the following
tips or possible solutions. If the solutions are not applicable, please send the product to
our service centre or contact our authorized technical staff for inspection and repair.
Possible situations Possible reason Solutions
The chair won’t
operate
1. No power
supply
2. The ON/OFF
button is off
1. Check whether the power is
connected or connected well
2. Check whether the power switch at
the right bottom of the chair is turned
on to “I”
The chair stops
functioning suddenly
or won’t operate as
usual
1. Power off
2. Machine failure
1. Check whether the power plug is
well connected
2. Contact the service centre for help
The ON/OFF
indicator of the
controller keeps
flashing
The chair returns
to its original
position
Keep the chair in regular settings
OS 3108.indd 16 5/26/2016 11:28:32 AM
The chair has seized
up with unusual
sounds
1. The chair is
overloaded
2. Machine failure
1. Adjust the sitting position and restart
the chair
2. Contact the service centre for
assistance

16
Contact us
MALAYSIA
Healthy World Lifestyle Sdn Bhd
No. 22 Jalan Anggerik Mokara 31/47
Kota Kemuning, 40460 Shah Alam
Selangor Darul Ehsan, Malaysia
Tel: [phone]
Fax: [phone]
SINGAPORE
OGAWA Health-Care Pte Ltd
27 Tampines Industrial Avenue 5,
T5 @ Tampines
Singapore 528623
Tel: [phone]
Fax: [phone]
INDONESIA
Pt Healthy World
Lodan Center Block O No 20
Jalan Lodan Raya No 2
Jakarta Utara 14430
Tel: [phone]
Fax: [phone]
HONG KONG, CHINA
OGAWA Health Care International (HK) Ltd
31/F,YHC tower,1Sheung Yuet Road
Kowloon Bay
Kowloon
Hong Kong
Tel: [phone]
Fax: [phone]
VIETNAM
OGAWA Vietnam Co Ltd
12 Tan Trao,Tan Phu ward
District 7
Ho Chi Minh
Tel: [phone]
Fax: [phone]
PHILIPPINES
O-Healthcare Solution Phil. Inc.
2303, 4th Floor, G&A Building,
Chino Roces Avenue Extension,
Makati City, Philippines
Tel: [phone]
Fax: [phone]
OS 3108.indd 18 5/26/2016 11:28:32 AM

17
目录
81明说全安
12限权修保
22明说动移品产
32件配及件零品产
42明说器控遥
28点特品产
28格规品产
28养保品产
29除排障故
03们我系联
OS 3108.indd 19 5/26/2016 11:28:33 AM

18
安全说明
i. 使用环境
●请勿在潮湿或灰尘密集的环境下使用本产品，以免导致触电或机器故障。
●请勿在浴室中使用本产品。
●请勿将此产品放在浴缸或水槽旁，以免脱落。
●请将本产品存放在安全的地方。
●请勿将此产品暴露于热源或阳光直射下。
ii. 不适宜人群
以下人士，请在使用前先咨询医生的意见：
- 心脏病患者
- 孕妇
- 身体不适者
iii. 以下情况请勿使用本产品
●当一次使用本产品超过15分钟时。
●小孩或残病人士在无人监督的情况下。
●睡前。
●产品外层破损。
●液体泼溅到产品上。
●使用过程中感到不寻常或剧烈疼痛。
●使用中过程中发觉任何机件故障或不寻常状况。
OS 3108.indd 20 5/26/2016 11:28:33 AM
●打雷时。

19
安全说明
iv. 警告
●没有使用时，请拔下电源插头。
●请勿使用非 OGAWA 提供的配件。
●当电源线或插头损坏时，请勿使用并及时联系 OGAWA 服务中心进行维修检查。
●请勿将手或任何异物塞入按摩器间隙中。
●请务必谨慎使用按摩器的导热功能，勿用于对热能反应较为迟钝的皮肤上及血液循环
不良的部位。请勿让儿童或身心功能障碍者自行使用导热功能。
●请勿扯动电源线来移动本产品。
●本产品仅为个人使用，禁止用于商业用途。
●请勿在使用中覆盖本产品，以免引起故障或火灾。
●请勿挤压或用尖锐物刮破本产品。
OS 3108.indd 21 5/26/2016 11:28:33 AM
