Olimpia splendid MAESTR SMART Parts list manual

SMART
CAN
USA
DIRECTIVES D’INSTALLATION, D’UTILISATION ET D’ENTRETIEN
INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE
MEX
INSTRUCCIONES DE INSTALACIÓN, USO Y MANTENIMIENTO

WARNINGSAVERTISSEMENTS
1. The appliance may be used by children over 8 years of age and by persons with
reduced physical, sensory or mentalcapacities, or withoutthe required experience
or knowledge, provided they are supervised or have been instructed in the safe
use of the appliance and understand the hazards involved.
2. Children must not play with the equipment.
3. Children must not be allowed to clean the appliance or perform user maintenance
without proper supervision.
4. If the power cable is damaged, it must be replaced by the manufacturer or by its
technical support service or by similarly qualied personnel, to prevent any risk
to the user.
5. Installation,initialstart-upandsubsequentmaintenance,withtheexception of the
ambient air lter cleaning and washing, must be carried out solely by authorized
and qualied personnel.
6. To prevent any risk of electric shocks, it is mandatory to disconnect the plug
from the power socket and/or to switch off the main switch before performing
any electrical connection and any maintenance operation on the appliances.
7. During installation, comply with the minimum clearances shown in Figures 2,3.
8. During the appliance electrical connection, following the indications shown.
1. L’appareil peut être utilisé par des enfants d’au moins 8 ans et par des personnes
ayant des capacités physiques, sensorielles ou mentalesréduites, ou dépourvues
de l’expérience ou des connaissances nécessaires, à condition que ce soit sous
surveillance ou qu’elles aient reçu des instructions relatives à l’utilisation sûre
de l’appareil et à la compréhension des dangers qui y ont liés.
2. Les enfants ne doivent pas jouer avec l’appareil.
3. Le nettoyage et la maintenance destinés à être effectués par l’utilisateur ne doivent
pas être effectués par des enfants sans surveillance.
4. Si le cordon d’alimentation est abîmé, il doit être remplacé par le fabricant ou
par son service d’assistance technique ou, dans tous les cas, par une personne
ayant une qualication similaire, de façon à prévenir tout risque.
5. L’installation, la mise en service et les phases de maintenance ultérieures, à
l’exception du nettoyage du ltre à air, doivent être effectuées exclusivement
par du personnel autorisé et qualié.
6. An de prévenir tout risque d’électrocution, il est indispensable de couper le
courant au disjoncteur principal avant d’effectuer des branchements électriques
et toute opération d’entretien sur les appareils.
7. Pendant l’installation, respecter les références des espaces minimaux indiqués
dans les gures 2,3.
8. Lors du branchement électrique de l’appareil, suivre les indications fournies.
USA
CAN

ADVERTENCIAS
1. El aparato puede ser utilizado por niños mayores de 8 años y por personas
con capacidades físicas, sensoriales o mentales reducidas, o carentes de la
experiencia y conocimiento necesarios, siempre que lo hagan bajo vigilancia o
después de haber recibido instrucciones sobre el uso seguro del aparato y sobre
los peligros inherentes al mismo.
2. Los niños no deben jugar con el aparato.
3. La limpieza y el mantenimiento del aparato no deben ser realizados por niños sin
una adecuada vigilancia.
4.En caso de deterioro, el cable de alimentación debe sersustituido por el fabricante,
por su servicio de asistencia técnica o por personal con cualicación similar,
con el n de
prevenir cualquier riesgo para el usuario.
5.Lainstalación,laprimerapuestaenmarchaylasposterioresfasesdemantenimiento,
excepto la limpieza o el lavado del ltro de aire ambiente, deben ser realizadas
exclusivamente por personal autorizado y cualicado.
6. Para prevenir el riesgo de descargas eléctricas, es indispensable desconectar el
interruptorgeneral antesderealizar conexioneseléctricasy cualquierintervención
de mantenimiento en los aparatos.
7. Durante la instalación, respete los espacios mínimos indicados en las guras 2,3.
8. Durante la conexión eléctrica del aparato, siga las indicaciones.
MEX

SMART
CAN
USA
DIRECTIVES D’INSTALLATION,D’UTILISATION ET D’ENTRETIEN
INSTRUCTIONS FOR INSTALLATION,USE AND MAINTENANCE
MEX
INSTRUCCIONES DE INSTALACIÓN,USO Y MANTENIMIENTO
1
2
H
C
L
A
D
G
E
B
F

3
A
4 5

min 300mm
min 12”
ø8mm
8
6 7
9
H
G
G
min 200mm
min 8”
10 11
G
6a

12
F
D
F
G
13 14
ø6mm
15 16
F

19
17
20
18
E
E
E
21

H
L
A
L
24
22 23
25
26 27

32
30 31
J1
P1
P1
P2
28 29
33
9

34
10
9
35
3F
36
37
F1
F2
F1
F2

MAESTRO SMART
US-ENGLISH
USA - 1
MAIN INDEX
0 - WARNINGS...............................................................................................................................................2
0.1 - GENERAL INFORMATION .............................................................................................................2
0.2 - SYMBOLS.......................................................................................................................................2
0.2.1 - Editorial pictograms.........................................................................................................................2
0.3 - GENERAL INFORMATION .............................................................................................................3
1 - UNIT ........................................................................................................................................................5
1.1 - LIST OF SUPPLIED COMPONENTS .............................................................................................5
1.2 - STORAGE.......................................................................................................................................5
1.3 - RECEIPT AND UNPACKING ..........................................................................................................5
1.4 - COMPONENTS DESCRIPTION.....................................................................................................6
2 - INSTALLATION .........................................................................................................................................6
2.1 - INSTALLATION INSTRUCTIONS ...................................................................................................6
2.2 - SIZE AND SPECIFICATIONS OF THE SPACE IN WHICH THE UNIT WILL BE INSTALLED .......6
2.3 - CHOOSING THE POSITION OF THE UNIT...................................................................................7
2.4 - UNIT ASSEMBLY ............................................................................................................................7
2.4.1 - Drilling the wall ...............................................................................................................................7
2.4.2 - Preparing the condensate discharge ..............................................................................................8
2.4.3 - Assembly of the air ducts and external grids ..................................................................................9
2.4.4 - Preparing the holes on the unit ......................................................................................................9
2.4.5 - Fitting the unit on the bracket..........................................................................................................9
2.4.6 - Electric hook-up.............................................................................................................................10
  2.4.7-Top/bottominstallationconguration............................................................................................. 11
2.5 - OPERATING TESTS AND ANOMALY DIAGNOSIS ..................................................................... 11
2.5.1 - Removing condensate water during an emergency......................................................................13
2.6 - ROUTINE MAINTENANCE...........................................................................................................13
  2.6.1-Cleaningtheairlter .....................................................................................................................13
3 - USE AND MAINTENANCE......................................................................................................................14
3.1 - WARNINGS...................................................................................................................................14
3.2 - DESCRIPTION OF THE WARNING PANEL ................................................................................14
3.3 - USING THE REMOTE CONTROL................................................................................................15
3.3.1 - Fitting the batteries........................................................................................................................15
3.3.2 - Description of remote control ........................................................................................................16
3.3.3 - Powering and managing the unit...................................................................................................17
3.4 - OPERATING THE UNIT................................................................................................................18
3.4.1 - Operational Modes - Turning The Unit On/Off...............................................................................18
3.4.2 - Well being key (automatic operating)............................................................................................18
3.4.3 - Cooling Mode ................................................................................................................................18
  3.4.4-DehumidicationMode..................................................................................................................18
3.4.5 - Ventilation Mode............................................................................................................................18
3.4.6 - Heating/ Defrost Mode ..................................................................................................................18
  3.4.7-DirectionalAirowControl .............................................................................................................19
3.4.8 - Adjusting fan speed.......................................................................................................................19
3.4.9 - Night Mode (cooling / heating) ......................................................................................................19
3.5 - SETTING THE TIME .....................................................................................................................20
3.5.1 - Timer and clock setting .................................................................................................................20
3.5.2 - Timer and clock setting .................................................................................................................20
3.5.3 - Timer setting (PROGR. 1 and PROGR. 2) ...................................................................................20
3.5.4 - Resetting all remote-control functions...........................................................................................21
3.5.5 - Operating the unit if the remote control is not available ................................................................21
3.6 - ENERGY SAVING ADVICE...........................................................................................................21
3.7 - DIAGNOSTIC ADVICE..................................................................................................................21
3.8 - TROUBLESHOOTING ..................................................................................................................21
4 - UNIT SPECIFICATIONS ..........................................................................................................................22

US-ENGLISH
USA - 2
0 - WARNINGS
0.1 - GENERAL INFORMATION
First of all, we would like to thank you for choosing our appliance.
 Thisdocumentiscondentialpursuanttothelawandmaynotbereproducedor
transferred to third parties without the explicit authorisation of the manufacturer.
The appliance may undergo updates and therefore have details different from those
represented, without prejudice to the texts contained in this manual.
0.2 - SYMBOLS
The symbols outlined in the following section provide the correct safety guidelines to
follow for proper unit operation.
0.2.1 - EDITORIAL PICTOGRAMS
Service
Referstosituations in which you should inform the SERVICEdepartmentinthe company:
CUSTOMER TECHNICAL SERVICE.
Index
Paragraphs marked with this symbol contain very important information and
recommendations, particularly as regards safety.
Failure to comply with them may result in:
- danger of injury to the operators
- loss of the warranty
- refusal of liability by the manufacturer.
Raised hand
Refers to actions that absolutely must not be performed.
DANGER OF HIGH VOLTAGE
Signals to the personnel that the operation described could cause electrocution if not
performed according to the safety rules.
Index
MAIN INDEX
The main index of this manual
is given on page “EN-1”
DRAWINGS
The drawings are provided at the beginning of the manual

MAESTRO SMART
US-ENGLISH
USA - 3
0.3 - GENERAL INFORMATION
1. OLIMPIA SPLENDID would like to thank you for choosing our product. This
product represents the state-of-the-art in-home air-conditioning technology
and will provide the user with many years of indoor comfort. This manual
is designed to provide you with the information needed to safely use the
product. Please read the manual carefully before using the equipment. By
following the instructions in this manual, the product you purchased will
operate properly providing optimum room temperatures with minimum
energy costs.
GENERAL INFORMATION
Aimed at the installer and the end user this chapter includes technical data
and warnings which must be understood before installing and using the
unit.
INSTALLATION
Aimed at the installer this chapter contains all the information necessary for
the positioning and mounting the unit. Installation by unqualied persons
may invalidate the warranty.
USE AND MAINTENANCE
Aimed at the end user this chapter contains useful information for
understanding the use and programming of the conditioner and themost
common maintenance interventions.
2. This document contains proprietary information protected by law.
The reproduction or transmission to third parties without the explicit
authorization of OLIMPIA SPLENDID is forbidden. All products are subject
to updating and as such may appear different from the designs contained
herein, although this does not in any way invalidate the texts contained in
the manual. Read this manual carefully before performing any operation
(installation, maintenance, use) and follow the instructions contained in
each chapter.
3. THE MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGE TO PROPERTY
OR PERSONS CAUSED BY FAILURE TO FOLLOW THE INSTRUCTIONS IN
THIS MANUAL.
4. OLIMPIA SPLENDID reserves the right to modify at any time its models
without changing the fundamental characteristics described in this manual.
GENERIC DANGER
It informs the personnel concerned that if the operation is not carried out in
compliance with the safety regulations, it presents the risk of suffering physical
damage.
DANGER FROM HEAT
It informs the personnel concerned that if the operation is not carried out in
compliance with the safety regulations, it presents the risk of burns due to contact
with components at very high temperatures.

US-ENGLISH
USA - 4
5. The installation and maintenance of air-conditioners like this one may be
hazardous as they contain a cooling gas under pressure as well as powered
parts.
6. Therefore, the installation, rst startup and subsequent maintenance
should be carried out exclusively by authorized, qualied personnel.
7. Failing to comply with the instructions contained in this manual and using
the unit with temperatures exceeding the permissible range will invalidate
the warranty.
8. Routine maintenance of the lters and general external cleaning can be
done by the user as these operations are not difcult or dangerous.
9. During the assembly and each maintenance operation, always pay attention
to the warnings described in this manual and on the labels afxed inside
the appliances, and respect anything suggested by common sense and
those of the Safety Norms in force in the place of installation.
10. Always wear Personal Protection Devices when servicing the unit.
These units MUST NEVER be installed in rooms where ammable gas,
explosive gas, or excessive humidity (laundry rooms, greenhouses, etc.), or
in rooms where there are other units that generate excessive heat. Should
components need replacing, always use OLIMPIA SPLENDID original spare
parts.
11. IMPORTANT!
To avoid any risk of electric shock always deenergize the unit before making
electrical connections or any maintenance procedures.
12. IMPORTANT!
Do not allow R-410A to escape into the atmosphere: R-410A is a uorinated
greenhouse gas, as cited in the Kyoto Protocol, with a Potential Global
Warming effect (GWP) = 2088.
13. WARNING
The unit should be used for the exclusive purpose of producing hot or
cool air for the sole purpose of obtaining a comfortable temperature in the
room. Improper use of the equipment, which may cause injury/damage to
persons, property or animals, relieves OLIMPIA SPLENDID of any liability.

MAESTRO SMART
US-ENGLISH
USA - 5
1 - UNIT
1.1 - LIST OF SUPPLIED COMPONENTS (Fig.1)
In addition to the unit this package includes the parts listed below. Before installing verify the parts are within
easy reach.
A. Paper template to make holes
B. Remote control
C. Use and maintenance booklets and warranty document
D. Strip of adhesive isolating tape
E. Air inlet and outlet external grids including chains and kit for installing the grids (x 2)
F. Internalanges(x2)
G. Sheet for wall pipes
H. Kit of screws and anchor bolts
L. Wall anchoring bracket
1.2 - STORAGE
Store units in an area protected from outdoor ambient conditions. Units should be stored on pallets or beams
to isolate from the ground.
DO NOT TURN THE UNIT OVER OR DAMAGE WILL RESULT.
1.3 - RECEIPT AND UNPACKING
Theproductsarepackagedbyqualiedpersonnelusingsuitablepackagingmaterial.Theunitsareshipped
complete and in perfect condition when leaving our facility. However, we suggest that you perform the
following checks:
a. Upon receipt check if the package is damaged. If damage is found note this on the shipping documents
taking photographs of any damage. Notify the shipper by registered mail with 3 days of receipt.
b. Unpack and check the contents against the packing list.
c. Check that none of the components have been damaged during transport; if damage is found notify the
shipper by registered letter, which should include photographic evidence within 3 days of receiving the
unit.
d. Send the same information by fax to OLIMPIA SPLENDID.
e. No claims for damage will be accepted if made more than 3 days after the delivery of the goods.
It is recommended to keep the packaging during the warranty period for any
possible delivery of the product to a service center. After the warranty period
ends dispose of the packaging in compliance with prevailing regulations.

5
3a
3
8
7
9
21
6
4
A
US-ENGLISH
USA - 6
1.4 - COMPONENTS DESCRIPTION
2 - INSTALLATION
2.1 - INSTALLATION INSTRUCTIONS
To obtain the best results and optimum performance follow the instructions in this manual. Failure to
follow the instructions may cause malfunction of the appliance and relieves the manufacturer, OLIMPIA
SPLENDID, of any form of liability for damages to persons, animals or property.
The electrical system must comply with all national and/or local codes and reg-
ulations. In addition, the specication and requirements in the technical sheet
must be followed. This includes a proper ground.
2.2 - SIZE AND SPECIFICATIONS OF THE SPACE IN WHICH THE UNIT WILL BE
INSTALLED
Before selecting an air conditioner or heat pump it is essential to make an accurate calculation of the
heat load, including sensible and latent gains for cooling mode and for heat pumps the sensible loss for
heating mode. OLIMPIA SPLENDID strongly encourages design practitioners to follow local and national
codes for the unit location. We also recommend you apply the guidelines found in ACCA’s Manual J for
residential load calculations and Manual S for proper equipment selection. Other ACCA manuals may
be relevant to your application depending on the construction type of the structure.
1. Airoutletap
2. Function and alarms display
console
3. Aspiration grill (front)
3a. Air aspiration grill (rear)
4. Airlters
5. Purifyinglterandactivecar-
bonslter
6. Condensate discharge
7. Emergency condensate dis-
charge
8. Power cord
9. Lower guard

MAESTRO SMART
US-ENGLISH
USA - 7
2.3 - CHOOSING THE POSITION OF THE UNIT (g.2-3)
The unit must be installed on a wall that directly communicates with the outside. The position for installing
the unit must have the following prerequisites:
• Theheightoftheunit’sloweredgefromtheoorshouldbeatleast100mm/4”ifxedtothewallinthe
lowest position.
• Ifxedtothewallinthehighestposition,itshouldbeatleast90mm/3.5”fromtheceiling.
• Thewallonwhichtheinsideunitisinstalledmustbeofsufcientstrengthtowithstanditsweight.
• Theremustbeadequatespacearoundtheunitforanymaintenanceorservicethatmaybenecessary.
• Thereshouldbenothinginthewayoftheairthatneedstocirculatebothonthetopair-intake(curtains,
plants, furniture) or at the front where the air exits. This could cause air swirls that cause the performance
andefciencyoftheunittosuffer.
• Itmustbepossibletoleaveroomaroundtheunitforanymaintenanceoperationsthatmaybenecessary.
• Nothingcanbeinthewayoftheairthatneedstocirculatebothonthetopair-intake(curtains,plants,
furniture) and at the front where the air exits. This could cause air swirls that would inhibit the working
efciencyoftheunit.
When selecting the unit’s location as described above the installer must insure there are no
structures or systems (beams, piers, pipes, wires, etc.) at the points where the holes are to be
drilled. Interference from any item would prevent drilling the holes required to install the unit.
• Theunitshouldnotbeplacedundercurtainsthatmayblockfreemovementoftheair.
• Donotspraywaterorotherliquidsofanykinddirectlyontheunit.
• Theunitshouldnotbeinstalledinapositionwheretheairowcandirectlystrikeoccupantsinthecon-
ditioned space.
• Neverforceopentheairowfap.
• Donotplaceanyotherobjectontheairgrillthatmayevenpartiallyobstructthegrillitself.
• Theunitshouldnotbeinstalleddirectlyoveranotherappliance,suchasatelevisionset,radio,refriger-
ator, etc., or over any other source of heat.
• Donotstoreanythingontheunitasitwilllimitairow,reducecapacityandincreaseenergycosts.
• Donotattempttomanuallyopenorclosethemodulatingdamperorspraycorrosivecleaningagents
into the unit.
• Donotallowcurtainsorotherhangingmaterialstoblocktheowofairenteringorexitingtheunit.
• Donotallowairowtodirectlystrikeoccupantsastheircomfortwillbenegativelyimpacted.Also,donot
install the unit in close proximity to heat producing appliances or devices.
2.4 - UNIT ASSEMBLY
The maximum length allowed for pipes is 990 mm/39”. The pipes must be smooth on the inside with a diam-
eter of 200 mm/8”. Pipes cannot be curved or bent. It is strongly recommended to use the grilles provided,
or grilles which provide the same features.
2.4.1 - DRILLING THE WALL (g.4-5-6)
Install the unit by drilling two holes (diameter of both pipes must be either 160 mm/6.4” or 200 mm/8” through
the wall as indicated on the drilling template. The 200 mm/8” holes will ensure best performance and lowest
air noise. Drill the wall using the proper tools, taking care to prevent excess damage to the wall or surround-
ing areas.
To drill the holes, proceed as follows:
• Fastenthedrillingtemplatetothewallwithadhesivetapethatwillnotdamagethesurface,leavingthe
necessaryspacefromtheceiling,oorandsidewallsasshownonthetemplate.Useasmalldrillor
punch to mark the exact center of each of the holes to be drilled.

US-ENGLISH
USA - 8
Drill the holes slightly downwards (outside being lowest) to prevent water from being fed back
through the ducts (g. 5).
• Thematerialbeingremovedbydrillingisexpelledoutwardssotheinstallermustinsureitdoesnothit
any person or object when it falls out.
• Tominimizedamagetotheexterior wall, proceed carefully with thelastpartofholebydecreasing
pressureonthedrill.Next,drilltheholesforanchoringthefasteningbracketstothewallusingasarst
option the 4 holes on the ends of the bracket as shown on the drilling template.
• Ifthewallisnotverysolid,itisadvisabletouseextraanchorbolts.Asshownonthetemplatethebracket
can be fastened in a number of different ways and positions.
• Themajorityoftheweightoftheapplianceistotherightsidesoensurethemountinghardwareisap-
propriate for the weight.
In all cases the wall should be inspected carefully to determine the best possible anchorage and type
ofboltssuitableforyourspecicapplication.
Olimpia Splendid shall not be held liable for any underestimates made in the
structural consistency of the wall or the anchoring materials used by the installer.
As such pay close attention when mounting the units to avoid the potential for
serious injury to people or damage to property if carried out incorrectly.
When installing heat pump models, if no condensate line was built into the wall, it will be necessary
to drill a hole through the wall as shown on the template.
2.4.2 - PREPARING THE CONDENSATE DISCHARGE (g.7)
• Forheatpumpsconnecttheunittothecondensatedischargepipe(supplied)bycouplingitwiththe
specicventonthebackoftheunit(removecap6a).Whenthemaxlevelisreached,asolenoidvalve
ensuresthecondensatewillowoutfromtheinternaltray.
• ForACunitsconnectthecondensatedischargepipeifyouintendrunningtheunitatlowoutdoortem-
peratures below 23°C (73ºF). Since condensate drains by gravity, there must be a minimum slope of at
least 3% at every point of the discharge line.
• Usearigidorexibletubehavinganinsidediameterofatleast160mm/6.3”.
If the line empties into a sewerage system, assuming local and/or national codes allow the practice,
install a trap before the point in which the pipe reaches the main discharge, at least 300 mm/12” below
theinletfromtheunit(g.8).
• Ifthedrainpipedrainsintoavessel(tankorothercontainer),thiscontainershouldnotbesealed,andthe
drainpipeshouldnotremainimmersedinthewater(seeg.9).Theholethroughwhichthecondensate
pipepassesshouldalwaysslopetowardstheoutside(seeg.5).Theexactpositioninwhichtoplace
the pipe inlet, as compared to the unit, is shown on the drilling template.
Make certain the condensate disposed outside does not damage or disturb persons or property.
During cold weather when the ambient temperature drops below 32ºF the condensate may cause
sheets of ice to form. When the condensate lines are installed ensure you do not compress or kink
the rubber hose.
