Olympia Protect 6XXX Series User manual

RProtect 6XXX Series Wireless Alarm System
Instruction Manual
17.12.2012 en

Olympia Business Systems Vertriebs GmbH
Zum Kraftwerk 1
45527 Hattingen

Contents
Giu
OPERATING
INSTRUCTIONS 3Page
Introduction 5....................................
Warranty 5..................................................
User Information 5...........................................
Disclaimer of Liability 5........................................
Intended Use 5..............................................
Product Features 6...............................
Scope of Delivery 6...............................
Safety Information 7..............................
Significance of the Symbols 7..................................
Important Safety Information 7..................................
Installation, Base Unit 8..........................
Informationon Selecting the Installation Location 8................
Preparing and Connecting the Base Unit 8.......................
Positioning the Base Unit 9....................................
Wall Installation 9............................................
Operating Elements and Indicators 10..............
Function Assignment to Buttons, Base Unit 10.....................
Display Icons 11..............................................
Overview of LEDs 12..........................................
Function Assignment to Buttons, Remote Control 12................
Menu Structure 13.................................
Configuration 15..................................
General Information 15.........................................
Selecting the Language 15......................................
Entry Code 15................................................
Setting the Date/Time 16.......................................
Individual Outgoing Messages 16................................
Activating the Internal Telephone Dialling Unit with OGM Function 17..
Saving an SOS (Emergency Call) Number 18......................
Trigger Delay 19..............................................
Arming Delay 19..............................................
Alarm Period 20...............................................
Key Tone On/Off 20...........................................
Setting the Display Contrast 20..................................
Remote Control 21............................................
Flood and Smoke Detectors 21..................................
Overview of Monitoring Functions 22...............
Switching the Monitoring Functions On/Off 22......
Alarm Mode 23...............................................
At Home Mode 23.............................................
Silent Mode 23................................................
Disarmed Mode 24............................................

Contents
OPERATING
INSTRUCTIONS
Giu
4Page
Panic Alarm 24....................................
Emergency Call (SOS) 24..........................
Remote Access Via Telephone 25..................
Resetting the Factory Settings (RESET) 26..........
Registering Sensors 27............................
Deregistering Sensors 27..........................
System Extension 27..............................
Changing the Batteries 28..........................
Remote Control 28............................................
Base Unit 28.................................................
Regular Maintenance and Servicing 29..............
Base Unit 29.................................................
Information on Disposal 30........................
Technical Data 31.................................
Base Unit 31.................................................
Remote Control 31............................................
Technical Modifications 31......................................
CE Mark 32.......................................

Introduction
Giu
OPERATING
INSTRUCTIONS 5Page
Introduction
Warranty
Dear Customer,
we are pleased that you have chosen this equipment.
In the case of a defect, please return the device together with the receipt
and original packing material to the point-of-sale.
User Information
The alarm system is a passive security product and has been conceived
as a deterrent. Additional measures are necessary to prevent and hinder
burglary and theft. You can obtain all the necessary information on this
from your local police station.
Read the operating instruction manual thoroughly before connecting and
starting the system for the first time. The operating instruction manual will
help prevent application errors and, at the same time, ensure you can ex
ploit all the technical options provided by the wireless alarm system to the
full.
Disclaimer of Liability
We cannot guarantee that the information which relates to the technical
properties of the product or to the product itself contained in this document
is correct. The product and its accessories described in this document are
subject to constant improvement and further development. For this reason,
we reserve the right to modify components, accessories, technical specific
ations and related documentation of the product described herein at any
time without notice.
Intended Use
The wireless alarm systems from the Protect6XXX-Series enable you to
monitor rooms and buildings as long as the local conditions are such that
they enable a reliable transmission link to the sensors (e.g. door/window
contact, smoke detector). In addition, all doors and windows must be
equipped with door/window contacts. A condition for complying with the
intended use is that the equipment is installed correctly and the information
in this operating instruction manual is observed and maintained.
Any other use is considered unintended use. Unauthorised modifications or
reconstructions not described in this operating instruction manual are not
permitted and could cause the product to be damaged. Furthermore, risks
through short-circuits, fire, electric shock etc. cannot be ruled out.

Product Features / Scope of Delivery
OPERATING
INSTRUCTIONS
Giu
6Page
Product Features
SWireless alarm system with emergency call, panic, room screening
and handsfree functions.
STransmit function to activate outdoor sirens etc.
SIntegrated telephone dialling unit with outgoing message.
SUp to 10 alarm call numbers and 1 emergency call number (SOS)
can be stored.
SMessages for alarm calls can be set up individually for each re
spective sensor, up to max. 10 seconds long.
SAutomatic dialling of the next number when the number called is
"engaged".
SHandsfree function on the base unit in the case of an SOS.
STelephone (silent) alarm/siren alarm can be set individually or com
bined.
SLarge LC display, 1 numeric line in 7 segments for 24 characters,
1 alphanumeric line in 5x7 dot matrix for 13 characters, 9 icons as
status indicators.
SDisplay lighting in yellow and blue.
SWarning in the event of a low battery charge status (base unit and
all registered sensors).
SPower failure backup in the base unit.
SBase unit has a remote control facility.
SUpgradable for operation with max. 32 sensors.
SSimple integration of new sensors/smoke detectors, Plug-and-Play.
Scope of Delivery
Base unit 1
Power adapter plug 1
Telephone connection cable 1
Remote control 1
Batteries 3x alkaline AAA
1x lithium CR2430 3 V
Assembly material Screws, dowels, adhesive tape
Operating instructions 1
Please check the contents of the package carefully. If anything is missing
or has been damaged during transport, DO NOT put the wireless alarm
system into operation! In such cases, contact your sales outlet, with your
purchase receipt to hand, or the OLYMPIA service centre.
NOTE: Keep the packaging in a safe place to protect
the equipment from damage should it need to
be dispatched in future.
NOTE: This operating instruction manual relates to
the base unit of the alarm system. The sensors
are described in separate manuals.

Safety Information
Giu
OPERATING
INSTRUCTIONS 7Page
Safety Information
Significance of the Symbols
WARNING: Indicates potentially dangerous situations
which could lead to fatal or severe personal
injury if the information is ignored.
CAUTION: Indicates potentially dangerous situations
which could lead to minor personal injury if the
information is ignored.
NOTE: Indicates potentially dangerous situations
which could lead to property or environmental
damage if the information is ignored.
Important Safety Information
Please observe the following safety information to ensure the wireless
alarm system can be used safely and reliably:
SIf you are uncertain or have any doubts about the functioning meth
od of the equipment during assembly and installation, contact a
specialist. In case of doubt, do not complete assembly and installa
tion work yourself.
SNever open the equipment! Never use the device when it is wet or
in the vicinity of a bathtub, shower or such!
SRepairs to defective equipment must always be completed by au
thorised service technicians.
SNever touch the power adapter plug on the base unit with wet or
damp hands.
SIf the power adapter plug shows signs of damage, disconnect the
fuse in the fuse box prior disconnecting the relevant plug from the
power socket.
SThe wireless alarm system and packaging materials must not be
used as toys by children.
NOTE: This operating instruction manual contains
important information on setting up and hand
ling the equipment. The manual must be en
closed with the equipment if handed over to
others.

Installation
OPERATING
INSTRUCTIONS
Giu
8Page
Installation, Base Unit
Information on Selecting the Installation Location
SThe base unit should be installed or positioned in a central location
(e.g. in the hallway of an apartment/house) in relation to the area to
be monitored in order to keep all transmission paths as short as
possible.
SPlace the base unit in a location where a power socket
(230 V / 50 Hz) and telephone connection socket (for the integrated
telephone dialling unit) are available.
SChoose a location within the area being monitored to ensure that no
intruders can approach the base unit and manipulate it.
SThe base unit and power adapter plug must not be used in damp
rooms (cellar, bathroom, etc.) or in the direct vicinity of sources of
heat.
SThe base unit should not be installed/setup on or in the direct vicin
ity of large metallic objects or sources of electrical interference be
cause this reduces the transmission range.
Examples of sources of interference
Metallic objects Source of electrical interference
Radiators Loudspeaker systems
Mirrors Motors
Concrete steel
walls
Unshielded electrical apparatus
Metal doors
Preparing and Connecting the Base Unit
NOTE: The alarm system can also be operated without
a telephone connection. In the event the alarm
is triggered, however, the internal telephone
dialling unit is not activated!
RJ11
connector
TAE
connector
Power socket
Telephone
connection
socket
N
RESET Power
adapter
plug
1. Use a screwdriver to loosen the screw in the battery and connection
socket compartment on the underside of the base unit.
2. Remove the lid from the battery and connection socket compartment.
3. Plug the RJ11 connector in the base unit socket.
4. Insert three AAA alkaline batteries in the battery compartment (pay
attention to correct polarity).
5. Connect the power adapter plug to the base unit.
6. Replace the lid on the battery and connection socket compartment.
7. Replace and tighten the screw.

Installation
Giu
OPERATING
INSTRUCTIONS 9Page
Positioning the Base Unit
It is possible to setup the device in a user-friendly, inclined position on a
table or desk. To do this, insert the two legs (1) supplied in the recesses for
the wall installation bracket (2) on the rear of the base unit.
1
Wall Installation
After having found a suitable location for the base unit, you can begin with
the installation.
WARNING: Risk of fatal injury through electric shock or
gas explosion. Pay attention that you do not
damage electric cables or gas pipes.
NOTE: Also pay attention to water pipes.
1. At the installation location, insert two screws in the wall, 100 mm
apart and aligned horizontally. (It may be necessary to drill the holes
first and then insert dowels in which to tighten the screws, depending
on the properties of the wall.)
2. Screw the screws in the wall using a screwdriver until there is approx.
3 mm clearance from the bottom edge of the screw head to the wall.
3. Hook the base unit over the screws.
4. Plug the TAE connector in the socket labelled Non the telephone
connection socket of your telephone connection.
5. Connect the power adapter plug to a properly installed 230 V / 50 Hz
power socket. The base unit is then ready to use.
2

Operating Elements and Indicators
OPERATING
INSTRUCTIONS
Giu
10Page
Operating Elements and Indicators
The base unit is equipped with an SOS (emergency call) button for emer
gency situations and a Panic button in the event of a direct threat. The
wireless remote control unit is provided with a button which can be con
figured either as an Emergency Call or Panic button (refer to "Configuring
the Wireless Remote Control Unit").
Pressing the Panic button triggers an immediate acoustic signal,
intended as a deterrent, regardless of whether the alarm system is active
or inactive. The acoustic alarm can be switched off via the base unit or the
wireless remote control (refer to "Disarmed Mode" in Chapter "Monitoring
Functions").
Pressing the SOS (emergency call) button activates the internal
telephone dialling unit, as long as phone numbers have been entered and
stored beforehand (refer to "Configuring the Internal Telephone Dialling
Unit with OGM Function"). The unit is activated regardless of whether the
alarm system is armed or disarmed. The emergency call number is dialled
first, then up to 10 stored phone numbers in succession. A voice message
requests the subscriber answering to press the [1] button on their phone.
The handsfree function is automatically activated on the base unit and
enables communication between the caller and subscriber called.
Function Assignment to Buttons, Base Unit
Button Function
Emergency Call button: Activates the internal telephone
dialling unit
Confirmation
Panic button: Triggers an acoustic alarm signal
Open the menu; scroll up in the menu;
increase the loudspeaker volume in Handsfree mode
Open the Location Key function for phone numbers;
scroll down in the menu;
reduce the loudspeaker volume in Handsfree mode
Disarmed mode: The system is deactivated; close the
menu; stop the countdown
Silent mode: The system is armed;
when the alarm is tripped, the internal telephone dialling
unit is activated; delete digits and letters
Alarm mode: The system is armed;
on burglary, the acoustic alarm signal and internal tele
phone dialling unit are activated
