Olympus VMF User manual

OLYMPUS STEREO MICROSCOPES
I INSTRUCTION MANUAL I
MODELS VMF,VMT&VMZ
OLYMPUS

This instruction manual has been written for the use of the Olympus Stereo Microscopes Models
VMF, VMT and VMZ. lt is recommended that you read the manual carefully in order to
familiarize yourself fully with the use of the microscope so that you can obtain optimum
performance.
IMPORTANT
• Operation
1. Always handle the microscope with the care it deserves and avoid abrupt motions.
2. Avoid exposure of the microscope to direct sunlight, high temperature, high relative
humidity, dust and vibration.
11 Maintenance
1. Lenses must always be kept clean. Fine dust on lens surfaces should be blown or wiped
off by means of an air blower or gauze. Carefully wipe off oil or fingerprints deposited
on the
lens surfaces, with gauze moistened with a small amount of xylene, alcohol or ether.
2. Do not use organic solutions to wipe the surfaces of various components. Plastic parts,
especially, should
be cleaned with a neutral detergent.
3. Never disassemble the microscope for repair.
4. The microscope should be stored in its container immediately after use. If this is not
possible, it should be covered with the vinyl dust cover provided. lt is best to keep
lenses in a desiccator, containing silica gel.
CONTENTS
I. MAIN CHARACTERISTICS.
11. STANDARD EQUIPMENT
Ill. IDENTIFICATION AND FUNCTION OF VARIOUS COMPONENTS
IV. ASSEMBLY
V. OPERATION
VI. OPTICAL
DATA
VII. USE OF OPTIONAL ACCESSORIES
Page
2
3
4
6
7
A. Auxiliary Lenses VM-AL 0.5X, VM-AL 0.75X, VM-AL 1.5X and VM-AL 2X 7
B. Simple Polarizing Filter Set VM-POL 7
C. Incident Illuminator VM-LSG 8
D. Mounting Bracket VM-STI 8

I. MAIN CHARACTERISTICS
The VM Series Stereo Microscopes include three types of stereomicroscope bodies- VMF,
VMT and VMZ. The Model VMF is provided with one objective pair built into the
binocular stereomicroscope body, and the Model VMT with two parfocal objective pairs
in a
turret built in the microscope body, while the Model VMZ features a continuously
variable zoom system objective control in the body.
1. Model VMF
2. Model VMT 3. Model VMZ
Microscope body Objective Microscope body Objective Objective
VMF-1F 1X VMT-2F
1X- 2X Microscope
body in zoom
VMF-2F
2X VMT-4F 1X- 4X
system
VMZ-4F 1X-4X
VMF-4F
4X
11. STANDARD EQUIPMENT
VMF- VMT-
VMZ-
Component
1-S
1-SA 2-S
2-SA
4-S
4-SA 2-S
2-SA
4-S 4-SA
4-S
4-SA
with built-in
objective 1X 0 0
VMF-1F
with built-in
objective 2X
0 0
VMF-2F
with built-in
objactive 4X
0 0
Binocular VMF-4F
stereomicro-
scope body
with objectives I
1 X-2X in turret 0 0
VMT-2F
with objectives
1
X-4X in turret
0 0
VMT-4F
with zoom system I
objective 1 X-4X 0 I 0
VMZ-4F
Standard stand VM-STA 0 0 0 0 0 0 0 0 0 0 0 0
Widefield eyepieces GW1 OX, paired 0 0 0 0 0 0 0 0 0 0 0 0
Clear glass plate 0 0 0 0 0 0 0 0 0 0 0 0
Stage plates Black and frosted
white plastic plate 0 0 0 0 0 0 0 0 0 0 0 0
Stage clips, paired 0 0 0 0 0 0 0 0 0 0 0 0
Eyeshields, paired 0 0 0 0 0 0 0 0 0 0 0 0
Reflected and transmitted
illumination base VM-1 LA
0 0 0 0 0 0
Vinyl dust cover 0 0 0 0 0 0 0 0 0 0 0 0

Ill. IDENTIFICATION AND FUNCTION OF VARIOUS COMPONENTS
The photo below shows the Model VMT·2·S.
Eyepieces
Oiopter adjustment ring
Rotate to obtain accurate
diopter adjustment.
ification turret (with VMT)
Microscope body
clamping screw
Thread
for incident il-
luminator
Objective shroud
Threaded for mounting
auxiliary lens or polarizing
filter.
Stage plate
clamping screw
Additional holes
for stage clips
2
Binocular observation
tube
Rotate the tube for inter-
pupillary distance adjust-
ment.
Stage plate
Microscope
Thread for reflected il-
luminator
bracket
mounting
knob
Rotate until correct focus
is obtained. From the posi-
tion as photographed the
microscope body can be
raised by 58mm or lowered
by 48mm.
Bushings for mirror unit
Incident light exit
Stage clip

Reflected and Transmitted Illumination Base VM-ILA
Fuse holder
On-off switch
Mirror unit
Mounting pin
IV. ASSEMBLY
Light path selector switch
T: Transmitted light.
R: Reflected light.
R. Reflected and transmitted
T light.
Clamping screws
Clamp base to stand.
socket
Lamp housing
The lamp housing cover can be
opened by pulling down the
knob; or closed by pushing it
up until it
snaps in place.
Before pushing,
ascertain that
the knob is positioned as
shown in the picture below
right, marked with circle.
§jjx~o
The picture below illustrates the sequential procedure of assembly. The numbers indicate
the assembly order
of various components.
Eyeshield J)
'\®
~Eyepiece
~
Microscope body
Clamping screw
*See NOTE.
Stage clip _.-if Cl)
L.....:::-------,
=
Stage plates: Clear
=
B&W
3
Incident illu-
minator mount-
ing thread
Standard stand
*NOTE:
As this screw can also be
used at the incident illu-
minator mounting thread,
you can choose a better
position
for mounting the
incident
illuminator so that
it does not block your
smooth operation.

V. OPERATION
The stage plates fit into the circular opening in the base. The clear plate can be used for
both reflected and transmitted illumination. Colored background can be achieved by
placing suitable material beneath the plate, for contrast, etc. The frosted plate is used
with reflected illumination. The plate is frosted white on one side, and black on the
other. If the specimen is white or brightly colored, use the black side of the plate to
increase image contrast by darkening the background. For dark or black specimens, reverse
the plate with the white frosted side facing the objective.
1. Tension Adjustment of Focusing Knobs
This focusing mechanism makes its motion freely
adjustable for either heavy or light movement
depending on the observer's preference. To adjust
the tension hold the two focusing knobs with both
hands and slightly rotate them in the opposite
directions, at the same time. (Fig. 1)
2. Specimen on the Stage Plate
Place a specimen in
the center of the stage plate and
clamp it with the stage clips, if necessary. (Fig. 2)
3. Interpupillary Distance Adjustment
Hold the right and left eyepiece tubes with both
hands and push or pull the tubes in the arrow
directions until perfect binocular vision is obtained.
(Fig. 3)
4. Diopter Adjustment
Fig. 1
Fig. 2
a) Looking through the right eyepiece with your right eye, focus on the specimen with
the focusing knobs.
NOTE: In case of the Model VMT or Model VMZ. ascertain that the high magnification
objectives are used for this adjustment.
b)
Look at the image through the left eyepiece with your left eye, and rotate the diopter
adjustment ring CD to focus on the specimen, without using the focusing knobs. (Fig. 4)
Fig. 3
NOTE: If accurate interpupillary distance and diopter adjustments are not accom-
plished, prolonged observation
would put considerable strain on the observer's
eyes.
Fig. 4
4

5. Objective Changes
The Model VMT is provided with two objective pairs. Rotate the turret until the objective
pair of your choke is engaged.
In case of the Model VMZ, rotate the zoom control ring until you obtain the desired
magnification
within the magnification range.
6. Use of Eyeshields
Eyeshields
are recommended to prevent glare and loss of contrast caused by ambient
light hitting the eye.
7. Use of the Reflected and Transmitted Illumination Base VM-ILA
a) Water sealed light exits on the base prevent damage from water spi!ls.
b) lt provides even illumination with all objective powers except the auxiliary lens
VM-AL 0.5X.
c) If light intensity is too high, it can be reduced by placing a 45mm-diameter NO filter
on the light exit on the base.
d) Setup.
Mirror unit "'[1J.
Standard stand
Clamping screw CC
Tungsten bu Ib
Insert into lamp socket,
push and rotate clockwise.
e) Use.
1I Activate the on-off switch CD .
2) Set the light path selector switch CV .
T: Transmitted light. Use clear stage plate.
R: Reflected light via mirror unit. Adjust the
mirror ® so that the light hits the center
of the stage plate.
~: Combination reflected and transmitted light.
5
Fig. 5

VI. OPTICAL DATA
• Models VMF and VMT
Eyepieces
GW10X *GWH10X(23) G15X(13)
Objectives (Field number 22) Optional
*Total
*Field Total Field Total Field
magnif.
of view magnif. of view magnif.
of view
1X
10X 22mm
10X 23mm 15X 13mm
-*W.D.
~
90mm
20X
11mm 20X 11.5mm 30X 6.5mm
4X 40X 5.5mm
40X 5.75mm 60X 3.25mm
11 Model VMZ (Data below are obtained at zoom magnification setting positions}
Eyepieces
Objective GW10X *GWH10X(23) G15X(13)
(Zoom (Field number 22)
magnif. Optional
1Xto4X)
*Total *Field
Total Field Total Field
magnif. of view magnif. of view
magnif. of view
1X
10X 22mm 10X 23mm 15X 13mm
-
2X
*W.D.
20X 11mm 20X
11.5mm 30X 6.5mm
-
3X
90mm
30X 7.33mm 30X
7.67mm 45X
4.33mm
-
4X
40X 5.5mm 40X 5.75mm 60X
3.25mm
*REMARKS
GWH10X: Widefield high eyepoint eyepiece.
W.D.: Working distance between specimen
and objective front lens.
Total magnification
=Objective power x Eyepiece power
Field number
of eyepiece
Field
of view diameter = Objective power
6
G20X(12.2)
Total Field
magnif. of view
20X 12.2mm
40X
6.1mm
sox 3.05mm
G20X(12.2)
Total Field
magnif.
of view
20X 12.2mm
40X
6.10mm
60X 4.07mm
BOX 3.05mm

VII. USE OF OPTIONAL ACCESSORIES
A. Auxiliary Lenses VM-AL 0.5X, VM-AL 0.75X, VM-AL 1.5X and VM-AL 2X
VM-AL 0.5X V
M-AL 0.75X VM-AL 1.5X
VM-AL 2X
When threaded into the objective shroud, each of these auxiliary lenses permits change of
total magnification without changing objective or eyepiece.
Auxiliary lens *VM-AL 0.5X
VM-AL 0.75X
VM-AL 1.5X
W.D.
156mm(6.14")
101mm(4")
43mm(1.7")
Total magnification = Objective power x Eyepiece power x Auxiliary lens power
F. Id f ·
d" . Field number of eyepiece
1e o v1ew 1ameter 1n mm = - -----···--;'-~---
Objective power x Auxiliary lens power
*NOTE: The VM-AL 0.5X requires an exten-
sion tube (VM-ET) in conjunction with
the standard stand because of its
considerably long working distance.
After screwing the VM-AL 0.5X into
the objective shroud, attach the exten-
sion
tube in position between the
objective shroud and the standard
stand as illustrated right: Extension tube
VM-ET
VM-AL 2X
29mm(1.14")
r
l ~ Standecd stand
B. Simple Polarizing Filter Set VM-POL
This unit enables observation of birefringent material in transmitted light.
Analyzer
Polarizer
Rotation
Insert the polarizer into the base opening beneath the stage plate, aligning the white dot
to the recess in the opening edge, and screw the analyzer into the threaded objective shroud.
Rotate the analyzer
rotation knob, looking through the eyep-Ieces, until exf1nction "1s
achieved.
7

C. Incident Illuminator VM·LSG
The Model VM-LSG is connected to the transformer TL and can be inserted into the
microscope stand or clamped to the transformer by means of a jointed bracket for incident
illumination.
a) Setup.
~ Illuminator
Bulb ILS 15)
CJ;l]
\ L
Illuminator~~
bracket ~
Jointed
bracket
Standard stand
Screw
Voltage adjust-
ment knob
Tr~a-n"'st'"o-rm..Je~r~ ~d
(to AC outlet}
b) The light intensity of the incident il!uminator is adjusted by means of the voltage
adjustment knob on the transformer.
c) A daylight filter 25C and a green contrast filter 25G533 are provided.
D.
Mounting Bracket VM-STI
Permits mounting of the microscope body to the universal table stands Models VS-4, VS-5
or on a custom mounting post on any machine or instrument you own or manufacture,
through the 24.5mm diameter opening.
Focusi knob
Tension adjustment identical
to standard stand.
Focusing range: 58.5mm.
m diameter
screw
8

0
1YMPlrs OLYMPUS OPTICAL CO ., LTD . ~
SAN-El BUILDING, 22-2, NISHISHINJUKU
1 -CHOME, SHINJUKU-KU TOKYO , JAPAN.
Printed in Japan 8503 M 30
