2
Pressure Sensor E8F2
“Cube-Type” Pressure Sensor, with
LED Display, Offers High-Precision
Sensing
HNew psi version available
HCompact style: 28 x 28 x 29 mm
(1.10 x 1.10 x 1.14 in) saves mounting
space
HEasy-to-read LEDs
HDisplays both analog bar and digital
pressure values
HTwo independent discrete outputs
available—plus one analog output
HSelect either NPN and PNP output type
Orderin
g
Information
JSENSORS
Type Digital output Analog output Pressure range Part number
Positive NPN open collector (independent, two outputs) 1to5V 0to100kPa E8F2-A01C
P
o
s
i
t
i
v
e
pressure
N
P
N
o
p
e
n
c
o
l
l
e
c
t
o
r
(
i
n
d
e
p
e
n
d
e
n
t
,
t
w
o
o
u
t
p
u
t
s
)
1
t
o
5
V
0to1MPa E8F2-B10C
0to14.5psi E8F2-D01C
0 to 145 psi E8F2-D10C
PNP open collector (independent, two outputs) 0to100kPa E8F2-A01B
P
N
P
o
p
e
n
c
o
l
l
e
c
t
o
r
(
i
n
d
e
p
e
n
d
e
n
t
,
t
w
o
o
u
t
p
u
t
s
)
0to1MPa E8F2-B10B
Negative NPN open collector (independent, two outputs) 0to--101kPa E8F2-AN0C
N
e
g
a
t
i
v
e
pressure
N
P
N
o
p
e
n
c
o
l
l
e
c
t
o
r
(
i
n
d
e
p
e
n
d
e
n
t
,
t
w
o
o
u
t
p
u
t
s
)
0to-14.6psi E8F2-DN0C
PNP open collector (independent, two outputs) 0 to-101 kPa E8F2-AN0B
JACCESSORIES (ORDER SEPARATELY)
Description Part number
Panel-mounting bracket E89-F4

E8F2 E8F2
3
Application Examples
JPCB AND WAFER
ATTACHMENT CHECKS
E8F2
E8F2
E8F2
JAIR PRESSURE
CHECKS
JCHIP ATTACHMENT
CHECKS
Specifications
JRATINGS/CHARACTERISTICS
Item E8F2-
A01C
E8F2-
B10C
E8F2-
AN0C
E8F2-
D01C
E8F2-
D10C
E8F2-
DN0C
E8F2-
A01B
E8F2-
B10B
E8F2-
AN0B
Power supply voltage 12 to 24 VDC ±10% with a ripple (p-p) of 10% max.
Current consumption 70 mA max. (See Note 1.)
Pressure type Gauge pressure
Rated pressure range 0to100
kPa
0to1
MPa
0to
--101
kPa
0to14.5
psi
0to145
psi
0to
--14.6
psi
0to100
kPa
0to1
MPa
0to
--101
kPa
Pressure setting range 0to100
kPa
0to1
MPa
0to
--101
kPa
0to14.5
psi
0to145
psi
0to
--14.6
psi
0to100
kPa
0to1
MPa
0to
--101
kPa
Withstand pressure 400 kPa 1.5 MPa 400 kP 58 psi 217.6
psi
58 psi 400 kPa 1.5 MPa 400 kPa
Applicable fluid Non-corrosive gas and non-flammable gas
Operating mode(s) Hysteresis mode
Window mode
Auto-teaching mode
Repeat accuracy (ON/OFF output) ±1% FS max.
Linearity ±1% FS max.
Response time (ON/OFF output) 5msmax.
Linear output 1to5V±5% FS with an output impedance of 1 kΩand a permissible resistive load of 500 kΩmin.
ON/OFF output NPN open collector (NO/NC)
Load current: 30 mA max.
Output applied voltage: 30 VDC max.
Residual voltage: 1 V max. with a load current of 30 mA
Display (See Note 2.) 3.5-digit red LED
Green LED bar indicator
The orange LED is lit for two independent outputs with output transistor turned ON
Green unit indicator
Display accuracy ±3% FS ±1 digit max.
Circuit protection Reverse polarity connection, load short-circuiting

E8F2 E8F2
4
Item E8F2-
A01C
E8F2-
B10C
E8F2-
AN0C
E8F2-
D01C
E8F2-
D10C
E8F2-
DN0C
E8F2-
A01B
E8F2-
B10B
E8F2-
AN0B
Temperature influence ±3% FS max.
Ambient temperature Operating: 0°Cto55°C(32°F to 131°F)
Storage: -- 1 0 °Cto60°C(14°F to 140°F) with no icing
Ambient humidity Operating/Storage: 35% to 85% (with no condensation)
Voltage influence ±1.5% FS max.
Insulation resistance 100 MΩmin. (at 500 VDC) between current-carry parts and case
Dielectric strength 1,000 VAC at 1 min
Vibration resistance Destruction: 10 to 500 Hz, 1.0-mm double amplitude or 150 m/s2,3timeseachfor11mininX,
Y,and Z directions
Shock resistance 300 m/s2(30G) 3 times each in X, Y, and Z directions
Degree of protection IEC60529, IP50
Pressure port 1/8 NPT male screw and M5 female screw
Connection method Pre-wired (standard length: 2 m)
Cable Approved by UL
Weight (incl. packing material) Approx. 110 g (3.88 oz)
Material Pressure port: aluminum die cast
Case: heat-resistant ABS
Accessories Mounting bracket
Instruction sheet
Note: 1. The current consumption is approximately 43 mA in energy-saving mode.
2. Display Example of Digital Indicator
Model Setting unit
M
o
d
e
l
kPa psi
Applied
pressure
Digital display Applied
pressure
Digital display
E8F2-A01C/E8F2-A01B 100 1000
E8F2-B10C/E8F2-B10B 1,000 1000
E8F2-AN0C/E8F2-AN0B --101 -- 1 0 1 0
E8F2-D01C 14.5 1450
E8F2-D10C 145 1450
E8F2-DN0C -14.5 -1 4 6 0
Note: The “.” in the display indicates the decimal point. Its position will not change unless the setting unit is changed.

E8F2 E8F2
5
En
g
ineerin
g
Data
JTEMPERATURE VS. LINEAR OUTPUT
CURRENT FLUCTUATION (TYPICAL)
JTEMPERATURE VS. OPERATING
PRESSURE FLUCTUATION (TYPICAL)
Linear output fluctuation (% FS)
Pressure 0 Rated pressure
Temperature (°C)
Operating pressure fluctuation (% FS)
Temperature (°C)
E8F2-A01C E8F2-A01C
JPRESSURE VS. LINEAR OUTPUT
(TYPICAL)
JLINEARITY (TYPICAL)
E8F2-A01C E8F2-A01C
Linear output voltage (V)
Pressure (kPa)
Linearity deviation (%FS)
Pressure (kPa)

E8F2 E8F2
6
Nomenclature
JE8F2 PRESSURE SENSOR (PSI TYPE)
(1)
(4)
(5)
(2)
(3)
(8)(7)(6)
Display Panel
1. Bar indicator (green)
Indicates the degree of the measured pressure according to the the set pressure.
2. Numeric and menu display (red)
Indicates measurement values and menu setting items.
3. Unit indicator (green)
Indicates the unit used for detection; the indicator shows which unit is the one currently set.
4. OUT1 indicator (orange)
OUT1 indicator turns ON when OUT1 is turned ON.
5. OUT2 indicator (orange)
OUT2 indicator turns ON when OUT2 is turned ON.
Operation
6. Up key
7. Down key
•Both the Up and the Down key are used to select or change the set items, set contents, and set values in setting
mode.
•Press either key (Up or Down key) to check the ON and OFF points in measurement mode. The values are reset by
pressing both keys simultaneously.
•Use either the Up or the Down key (as necessary) together with the SET key for setting the Sensor to a special setting
mode or energy-saving mode.
8. SET key
•Used for entering the set contents and set values in setting mode.
•Used for setting the Sensor to basic setting mode or pressure setting mode.
kPa Torr PsiOUT1 OUT2

E8F2 E8F2
7
O
p
eration
JOUTPUT STAGE CIRCUIT
Output type NPN output (normally open) NPN output (normally closed)
Model E8F2-A01C
E8F2-B10C
E8F2-AN0C
Timing
chart
Hysteresis
mode
Pressure
ON point
OFF point
Output
OUT
indicator
(orange) OFF
ON
OFF
ON
Pressure
ON point
OFF point
Output
OUT
indicator
(orange) OFF
ON
Window
mode
Pressure
OFF point
ON point
Output
OUT
indicator
(orange) OFF
ON
OFF point -- 10% FS
max.
ON point -- 10% FS
max.
OFF
ON
Pressure
OFF point
ON point
Output
OUT
indicator
(orange) OFF
ON
OFF point -- 10% FS
max.
ON point -- 10% FS
max.
Output circuit
Pressure
Sensor
main
circuit
Brown
Black
(ON/OFF1)
30 mA
max.
Load
30 mA
max.
White (ON/OFF2)
Gray
(linear) 1to5V
Load
Blue 0V
12 to 24 V
Load

E8F2 E8F2
8
JFUNCTIONS AND SETTINGS
Function/Setting Description
Zero-reset function Sets the measurement value to 0 when the Sensor is exposed to the air.
Basic setting Unit setting Changes the unit for detection.
B
a
s
i
c
s
e
t
t
i
n
g
mode Pressure setting method ---
Output-type setting Selects normally-open or normally-closed output.
Pressure Manual setting Sets the ON and OFF points manually.
P
r
e
s
s
u
r
e
setting mode Auto-teaching setting Automatically sets the ON and OFF points depending upon the actual sensing of
objects.
Special setting
mode
Key-protect setting Protects the set value against the incorrect operation of the keys.
Prevents the set value against the careless operation of the keys.
Hysteresis width setting Changes the hysteresis range.
Window range setting Changes the window mode setting.
Display refresh interval setting Changes the display refresh interval to make the displayed value easier to see.
Measurement value averaging
time setting
Prevents incorrect output due to sudden, instantaneous changes that may occur
with pressure.
Special setting
mode
LED bar indicator range setting Changes the display range of the LED bar indicator in hysteresis mode.
Energy-saving Energy-saving function 1 Displays the LED bar indicator but turns the red LED display OFF.
E
n
e
r
g
y
s
a
v
i
n
g
mode Energy-saving function 2 The LED bar indicator and red LED display flash in window mode if the measured
value exceeds the set range.
ON/OFF set value check function Checks the set ON and OFF points.
JSETTINGS
Digital Display
The E8F2 displays alphanumeric characters, such as the
measurement values and menu items, with 7-segment LEDs.
Refer to the examples shown below.
Display Meaning
ope In output operation
kpa Unit (kPa)
wid Width
The following abbreviations are used for the digital display of the
Controller.
Abbreviation Meaning Abbreviation Meaning
Unt Unit DSP Display
M-A Manual/Auto AVE Average
OPE Operation BAR Bar
PRT Protect AUT Auto
HYS Hysteresis ECO Economy
WID Width
abcdefghijklmnop rstuUwxy=
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z

E8F2 E8F2
9
JMODES
In addition to displaying measurement values, the E8F2 has a variety of functions. These functions are available in four main modes as
described below: Measurement Mode, Basic Setting Mode, Pressure Setting Mode, Special Setting Mode. Three functions are available
in measurement mode. For the relationships among each mode and for switching methods, refer to the following figure.
Power ON
Zero-reset function
ON- and OFF-point
check function
No key operation
No key operation
Measurement
Mode
Energy-saving function 1
Energy-saving function 2
or
or
Basic Setting Mode
unt: Measurement unit selection
m-a: Pre ssure setting me thod
selection
ope: Output-type selection
Pressure Setting Mode
on: OUT1 ON-point setting
off: OUT1 OFF-point setting
Manual setting
on: OUT2 ON-point setting
off: OUT2 OFF-point setting
t.h1: OUT1 two-point teaching
t.w: OUT1 one-point teaching
Auto-teaching setting
t.h1: OUT2 two-point teaching
t.w: OUT2 one-point teaching
prt: Key-protect setting
Special Setting Mode
hys: Hysteresis width setting
wid: Window width setting
dsp: Measurement value display
refresh interval setting
aUe: Number of measurement times
setting for measurement value averaging
bar: LED bar indicator range setting
or
or
Note: 1. and indicate that the key must be pressed for approximately 2 or 3 s respectively.
2. The following will result when the E8F2 in basic, pressure setting, or special setting mode is reset to measurement mode.
: The set values are entered.
: The set values are not entered (left as they are).
*1.Manual setting is available by selecting m(manual) in the pressure setting method selection in basic setting mode.
*2.Auto-teaching setting is available by selecting a(auto-teaching) in the pressure setting method selection in basic setting mode.

E8F2 E8F2
10
Measurement mode Normal
Error
OUT1 OUT2 kPa Torr Psi OUT1 OUT2 kPa Torr Psi
OUT1 OUT2 kPa Torr Psi
The displayed measurement value is reset to 0 by pressing the Up and Down keys simultaneously. The reset range is within ±5% (FS)
of the rated pressure. If the value is not within the range, an error will be displayed and the reset will not be enabled.
Use the zero-reset function with the Sensor exposed to the air.
Basic Setting Mode
The unit of measurement, pressure setting method, and output type are set in basic setting mode.
1. Press the SET key for approximately 2 s so that the E8F2 will be set to basic setting mode and unt will be displayed.
2. Set the items unt,m--a, and ope withUporDownkey.
Measurement
mode
Setting item
Setting item
Unit setting Pressure setting method selection Output-type setting
OUT1 OUT2 kPa Torr Psi OUT1OUT2
kPa Torr Psi
kPa Torr Psi
OUT1 OUT2 kPa Torr Psi
Zero-reset Function
OUT1 OUT2 kPa Torr Psi

E8F2 E8F2
11
1. Press the SET key while unt is displayed to display the unit presently set.
2. Press the Up or Down key to select the unit.
3. Press the SET key to select the displayed unit and display unt again.
4. Press the Up and Down keys simultaneously, to display unt again without selecting the unit.
Unit Setting
Unit setting in E8F2-AN0C
OUT1 OUT2 kPa Torr Psi OUT1 OUT2 kPa Torr Psi OUT1 OUT2 kPa Torr Psi OUT1 OUT2 kPa Torr Psi
kPa
Pressure Setting Method Selection
Setting item
Pressure setting
Manual setting Auto-teaching
m: Manual setting (The ON and
OFF points are manually set.)
a: Auto-teaching (The ON and OFF
points are set automatically.)
or
OUT1 OUT2 kPa Torr Psi OUT1 OUT2 kPa Torr Psi OUT1 OUT2 kPa Torr Psi
1. Press the SET key while m--a is displayed to display the pressure setting method presently set.
2. Press the Up or Down key to select the pressure setting method.
3. Press the SET key to select the displayed pressure setting method and display m--a again.
4. Press the Up and Down keys simultaneously to display m--a without selecting the unit.
