Omron R3 Intellisense User manual

HEM-6200-E_D_M02_100510.pdf
Manufacturer OMRON HEALTHCARE Co., Ltd.
24, Yamanouchi Yamanoshita-cho, Ukyo-ku, Kyoto
615-0084 JAPAN
EU-representative OMRON HEALTHCARE EUROPE B.V.
Kruisweg 577, 2132 NA Hoofddorp, THE NETHERLANDS
www.omron-healthcare.com
OMRON (DALIAN) CO., LTD.
Economic & Technical Development Zone
Dalian 116600, CHINA
OMRON HEALTHCARE UK LIMITED
Opal Drive, Fox Milne Milton Keynes, MK15 0DG U.K.
OMRON MEDIZINTECHNIK HANDELSGESELLSCHAFT mbH
John-Deere-Str. 81a 68163 Mannheim, GERMANY
www.omron-medizintechnik.de
OMRON Santé France SAS
14, rue de Lisbonne 93561 Rosny-sous-Bois Cedex, FRANCE
Wrist Blood Pressure Monitor
Model R3
Instruction Manual
English
Français
Deutsch
Italiano
Español
Nederlands
IM-HEM-6200-E-02-06/2010
5329513-9A
Русский
WristBlood Pressure Monitor
ModelR3
InstructionManual
English
Français
Deutsch
Italiano
Espanõl
Nederlands
IM-HEM-6200-E-02-06/2010
5325660-5D
Production facility
Site de production
Produktionsstätte
Stabilimento di produzione
Oficina de producción
Productiefaciliteit
Производственное подразделение
Subsidiary
Succursale
Niederlassung
Consociata
Empresa filial
Dochteronderneming
Дочерняя компания
Prodotto in Cina
Сделано в КитаеHergestellt in China
Geproduceerd in ChinaFabriqué en Chine
Fabricado en ChinaMade in China
Check following components!
Vérifier les composants suivants !
Prüfen Sie folgende Teile des Lieferumfangs!
Controllare i componenti indicati di seguito!
¡Compruebe los siguientes componentes!
Controleer de volgende onderdelen!
Проверьте следующие компоненты!

a
e
f
c
d
b
Contents
Thank you for purchasing the OMRON R3 Wrist Blood Pressure Monitor.
The OMRON R3 is a compact and easy to use blood pressure monitor, operating on the oscillometric
principle. It measures your blood pressure and pulse rate simply and quickly. For comfortable
controlled inflation without the need of pressure pre-setting or re-inflation the devices uses its
advanced “IntelliSense” technology.
Important Safety Information.......................... ... 1
1. Overview......... .............................................. 3
2. Preparation ................................................ ... 4
2.1 Installing/Replacing the Batteries ............ 4
2.2 Setting the Date and Time....................... 5
3. Using the Unit .............................................. 6
3.1 Applying the Wrist Cuff............................6
3.2 How to Sit Correctly.................................7
3.3 Taking a Reading .................................... 8
3.4 Using the Memory Function .................. 10
4. Troubleshooting and Maintenance ..........12
4.1 The Icons and Error Messages .............12
4.2 Troubleshooting.....................................14
4.3 Maintenance..........................................16
5. Technical Data............................................18
6. Some Useful Information about Blood Pressure ... 21
Please read this instruction manual thoroughly before using the unit.
Please keep for future reference.
For specific information about your own blood pressure, CONSULT YOUR DOCTOR.
J
K
N
O
M
PRS
H I
L
Q
C
A
BD
E
F
G
Intended Use
This product is designed to measure the blood pressure and pulse rate of people within the range of
the designated wrist cuff, following the instructions in this instruction manual.
It is mainly designed for general household use. Please read the Important Safety Information in this
instruction manual before using the unit.

1
EN
Important Safety Information
Consult your doctor prior to using in pregnancy or if diagnosed with arrhythmia or arteriosclerosis.
Please read this section carefully before using the unit.
Warning:
• Indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injury.
(General Usage)
• Always consult your doctor. Self-diagnosis of measurement results and self-treatment are
dangerous.
• People with severe blood flow problems, or blood disorders, should consult a doctor before
using the unit, as cuff inflation can cause internal bleeding.
(Battery Usage)
• If battery fluid should get in your eyes, immediately rinse with plenty of clean water. Consult a
doctor immediately.
Caution:
• Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury to the user or patient or damage to the equipment or other property.
(General Usage)
• Do not leave the unit unattended with infants or persons who cannot express their consent.
• Do not use the unit for any purpose other than measuring blood pressure.
• Do not disassemble the unit or wrist cuff.
• Do not inflate the wrist cuff over 299 mmHg.
HEM-6200-E_D_M_main.book Page 1 Friday, May 21, 2010 11:46 AM

2
Important Safety Information
• Do not use a mobile phone or other devices that emit electromagnetic fields, near the unit. This
may result in incorrect operation of the unit.
• Do not operate unit in a moving vehicle (car, airplane).
(Battery Usage)
• If battery fluid should get on your skin or clothing, immediately rinse with plenty of clean water.
• Use only two “AAA” alkaline (LR03) batteries with this unit. Do not use other types of batteries.
• Do not insert the batteries with their polarities incorrectly aligned.
• Replace old batteries with new ones immediately. Replace both batteries at the same time.
• Remove the batteries if the unit will not be used for three months or more.
• Do not use new and used batteries together.
General Precautions
• Do not apply strong shocks and vibrations to or drop the unit.
• Do not take measurements after bathing, drinking alcohol, smoking, exercising or eating.
• Do not inflate the wrist cuff when it is not wrapped around your wrist.
• Do not wash the wrist cuff or immerse it in water.
• Read and follow the “Important information regarding Electro Magnetic Compatibility (EMC)” in the
Technical Data Section.
• Read and follow the “Correct Disposal of This Product” in the Technical Data Section when
disposing of the device and any used accessories or optional parts.
HEM-6200-E_D_M_main.book Page 2 Friday, May 21, 2010 11:46 AM

3
EN
1. Overview
Main unit
Display
Battery compartment cover
Wrist cuff
MEM (Memory) button
O/I START ( ) button
SET ( ) button
Date/Time setting ( ) button
Display
Systolic blood pressure
Diastolic blood pressure
Memory symbol
Average value symbol
Irregular heartbeat symbol
Pulse display
Movement error symbol
Battery low symbol
Date/Time display
Heartbeat symbol
(Flashes during measurement.)
Deflation symbol
Blood pressure level indicator
Open the rear cover page to read following:
The alphabet in the rear cover page correspond to those in the body page.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
HEM-6200-E_D_M_main.book Page 3 Friday, May 21, 2010 11:46 AM

4
2. Preparation
2.1 Installing/Replacing the Batteries
1. Remove the battery cover.
1) Push the hook on the bottom of the battery cover.
2) Pull the cover off the main unit.
2. Insert two 1.5V “AAA” alkaline (LR03)
batteries as indicated in the battery
compartment and then replace the
battery cover.
Notes:
• If the battery low symbol ( ) appears on the display, turn
the unit off then replace both batteries at the same time.
• The measurement values continue to be stored in memory even after the batteries are
replaced.
Disposal of used batteries should be carried out in accordance with the national regulations for
the disposal of batteries.
1
2
HEM-6200-E_D_M_main.book Page 4 Friday, May 21, 2010 11:46 AM

2. Preparation
5
EN
2.2 Setting the Date and Time
1. Set the monitor to the correct date and time before taking
a measurement for the first time.
Press the button.
2. Press the O/I START button to store the setting.
Notes:
• To reset the date and time, hold down the button while the power is off.
• If the batteries have been removed for 30 seconds or more, the date and time setting will
need to be reset.
• If the date and time are not set, “-:--” appears during or after measurement.
1)
2)
Push the button to
change.
• Hold down to advance
the digit rapidly.
Push the button to
confirm.
Next setting appears.
Year
Month
Day
Hour
Minute
HEM-6200-E_D_M_main.book Page 5 Friday, May 21, 2010 11:46 AM

6
3. Using the Unit
3.1 Applying the Wrist Cuff
Do not apply over clothing.
1. Place the wrist cuff over your wrist.
2. Wrap the wrist cuff around your wrist.
Make sure that the wrist cuff does not cover the protruding part of the wrist bone (ulna) on the
outside of the wrist. ---
Your thumb should face upward.
Notes:
• You can take a measurement on either your left or right wrist.
• Wrap the wrist cuff securely around the wrist for taking accurate measurements.
• The blood pressure can differ between the right arm and the left arm, and therefore also the
measured blood pressure values can be different. Omron recommends to always use the
same arm for measurement. If the values between the two arms differ substantially, please
check with your physician which arm to use for your measurement.
Open both the front and rear covers to read following:
The alphabet and number in the cover page correspond to those in the body page.
a
b
HEM-6200-E_D_M_main.book Page 6 Friday, May 21, 2010 11:46 AM

3. Using the Unit
7
EN
3.2 How to Sit Correctly
To take a measurement, you need to be relaxed and comfortably seated, under comfortable room
temperature. No eating, smoking or exercising 30 minutes before taking a measurement.
• Sit on a chair with your feet flat on the floor.
• Sit upright with your back straight. ---
• The cuff should be at the same level as your heart. ---
• Relax your wrist and hand. Do not bend your wrist back, clench your fist, or bend your wrist
forward. ---
• Do not use your other hand to support the wrist cuff. This can result in inaccurate
measurement results. ---
c
d
e
f
HEM-6200-E_D_M_main.book Page 7 Friday, May 21, 2010 11:46 AM

3. Using the Unit
8
3.3 Taking a Reading
Notes:
• To cancel a measurement, press the O/I START button at any time during measurement.
• Remain still while taking a measurement.
1. Press the O/I START button.
The wrist cuff will start to inflate automatically.
2. Undo the wrist cuff and remove the unit.
3. Press the O/I START button to turn off the monitor.
The monitor automatically stores the measurement in its memory.
It will automatically turn off after two minutes.
START INFLATE DEFLATE COMPLETE
Alternating date/time display
HEM-6200-E_D_M_main.book Page 8 Friday, May 21, 2010 11:46 AM
