D4D-R
2
Manual Reset Limit Switch
Pull Reset Limit Switch
HEach model features a positive opening
mechanism (NC contacts only) and is
equipped with a lockable head
HConforms to EN standards (positive
opening mechanism is shown by on the
Switch)
HPositive opening mechanism and double
insulation approved by TÜV and BIA
HOperates between --30°C and 70°C
HConforms to these standards and
EC Directives:
Machinery Directive
Low Voltage Directive
EN50047
EN1088
HApproved Standards
Slow-Action Models
Agency Standard File No.
TÜV Rheinland EN60947-5-1
EN81, EN115 R9451184
(Positive opening:
approved)
UL (see note 1) UL508
CSA C22.2 No.14 E76675
BIA (see note 2) GS-ET-15 1-conduit: 9505895
2-conduit: 9509914
SUVA (see note 2) SUVA 1-conduit: 6013Z
2-conduit: 6012Z
Note: 1. CSA C22.2 No. 14 compliance was verified and
approved by UL (Marked with ).
2. Except for adjustable roller lever models.
Eu

onlinecomponents.com
D4D-R
3
Ordering Information
JMODEL NUMBER LEGEND
D4D-jjjjR
123
1. Conduit
1: Pg13.5 (1-conduit, European type)
2: G1/2 (1-conduit, Japanese type)
3: 1/2-14NPT (1-conduit, North American type)
5: Pg13.5 (2-conduit, European type)
6: G1/2 (2-conduit, Japanese type)
2. Built-in Switch
5: 1NC/1NO (Slow-action)
A: 2NC (Slow-action)
3. Actuator
20: Roller lever
21: Adjustable roller lever
27: Adjustable roller lever (with rubber roller)
62: One-way roller arm lever (Horizontal)
72: One-way roller arm lever (Vertical)
31: Plunger
32: Roller plunger
JSWITCHES
Actuator Conduit size/type 1NC/1NO (Slow-action) 2NC (Slow-action)
/
y
p
Positive
opening
(See Note 1)
Part
number Positive opening
(see Note 1)
Part
number
Roller lever 1-conduit Pg13.5 (European) D4D-1520R D4D-1A20R
G1/2 (Japanese) D4D-2520R D4D-2A20R
1/2-14NPT (North American) D4D-3520R D4D-3A20R
2-conduit Pg13.5 (European) D4D-5520R D4D-5A20R
G1/2 (Japanese) D4D-6520R D4D-6A20R
Adjustable roller
l
1-conduit Pg13.5 (European) D4D-1521R D4D-1A21R
j
lever
(
S
e
e
N
o
t
e
2
)
G1/2 (Japanese) D4D-2521R D4D-2A21R
(
S
ee
N
o
t
e
2
)
1/2-14NPT (North American) D4D-3521R D4D-3A21R
2-conduit Pg13.5 (European) D4D-5521R D4D-5A21R
G1/2 (Japanese) D4D-6521R D4D-6A21R
Adjustable roller
l
e
v
e
r
(
w
i
t
h
r
u
b
b
e
r
1-conduit Pg13.5 (European) D4D-1527R D4D-1A27R
lever (with rubber
roller) G1/2 (Japanese) D4D-2527R D4D-2A27R
r
o
l
l
e
r
)
(SeeNote2) 1/2-14NPT (North American) D4D-3527R D4D-3A27R
2-conduit Pg13.5 (European) D4D-5527R D4D-5A27R
G1/2 (Japanese) D4D-6527R D4D-6A27R
Plunger 1-conduit Pg13.5 (European) D4D-1531R D4D-1A31R
P
l
u
n
g
e
r
G1/2 (Japanese) D4D-2531R D4D-2A31R
1/2-14NPT (North American) D4D-3531R D4D-3A31R
2-conduit Pg13.5 (European) D4D-5531R D4D-5A31R
G1/2 (Japanese) D4D-6531R D4D-6A31R
Roller plunger 1-conduit Pg13.5 (European) D4D-1532R D4D-1A32R
p
g
G1/2 (Japanese) D4D-2532R D4D-2A32R
1/2-14NPT (North American) D4D-3532R D4D-3A32R
2-conduit Pg13.5 (European) D4D-5532R D4D-5A32R
G1/2 (Japanese) D4D-6532R D4D-6A32R
(This table continues on the next page.)
Note: 1. The Switches are marked with indicating approval for the positive opening mechanism.
2. The adjustable roller lever models are approved by the EN ratings (TÜV Rheinland) but not by GS-ET-15 (BIA) and SUVA.

onlinecomponents.com
D4D-R
4
Ordering Information Table -- continued from previous page
Actuator Conduit size/type 1NC/1NO (Slow-action) 2NC (Slow-action)
/
y
p
Positive
opening
(See Note 1)
Part
number Positive opening
(See Note 1)
Part
number
One-way roller
l
1-conduit Pg13.5 (European) D4D-1562R D4D-1A62R
y
arm lever
(
H
o
r
i
z
o
n
t
a
l
)
G1/2 (Japanese) D4D-2562R D4D-2A62R
(
H
or
i
zon
t
a
l
)
1/2-14NPT (North American) D4D-3562R D4D-3A62R
2-conduit Pg13.5 (European) D4D-5562R D4D-5A62R
G1/2 (Japanese) D4D-6562R D4D-6A62R
One-way roller
l
1-conduit Pg13.5 (European) D4D-1572R D4D-1A72R
y
arm lever
(
V
e
r
t
i
c
a
l
)
G1/2 (Japanese) D4D-2572R D4D-2A72R
(
V
er
t
i
ca
l
)
1/2-14NPT (North American) D4D-3572R D4D-3A72R
2-conduit Pg13.5 (European) D4D-5572R D4D-5A72R
G1/2 (Japanese) D4D-6572R D4D-6A72R
Note: 1. The Switches are marked with indicating approval for the positive opening mechanism.
2. The adjustable roller lever models are approved by the EN ratings (TÜV Rheinland) but not by GS-ET-15 (BIA) and SUVA.
Specifications
JAPPROVED STANDARD RATINGS
Applicable Standards
TÜV (EN60947-5-1)
Utilization category AC-15
Rated operating current (Ie)2A
Rated operating voltage (Ue)400 V
UL (UL508/CSA C22.2 No.14)
A600
Rated voltage Carry current Current Volt-amperes
y
Make Break Make Break
120 VAC 10 A 60 A 6A 7,200 VA 720 VA
240 VAC 30 A 3A
480 VAC 15 A 1.5 A
600 VAC 12 A 1.2 A

onlinecomponents.com
D4D-R
5
JCHARACTERISTICS
Degree of protection IP65 (EN60947-5-1)
Life expectancy (see note) Mechanical: 1,000,000 operations min.
Electrical: 150,000 operations min.
Operating speed 1 mm/s to 0.5 m/s
Contact gap 2x2mmmin.
Operating frequency 30 operations/min
Rated frequency 50/60 Hz
Insulation resistance 100 MΩmin. (at 500 VDC) between terminals of the same polarity, and between each
terminal and non-current-carrying metal part
Contact resistance 25 mΩmax. (initial value)
Dielectric strength Uimp 4 kV between terminals of the same polarity, between terminals of different polarity,
and between each terminal and non-current-carrying metal part (EN60947-5-1)
Rated insulation voltage (Ui)400 V (EN60947-5-1)
Switching overvoltage 1,500 V max. (EN60947-5-1)
Pollution degree (operating environment) 3 (EN60947-5-1)
Conditional short-circuit current 100 A (EN60947-5-1)
Conventional enclosed thermal current
(Ithe)10 A (EN60947-5-1)
Protection against electric shock Class II (double insulation)
Vibration resistance Malfunction: 10 to 55 Hz, 0.75-mm single amplitude
Shock resistance Destruction: 1,000 m/s2min.
Malfunction: 300 m/s2min.
Ambient temperature Operating: --30°Cto70°C (with no icing)
Ambient humidity Operating: 95% max.
Weight Approx. 80 g (for D4D-1120R)
Note: Life expectancy values are calculated at an operating temperature of 5°Cto35°C and an operating humidity of 40% to 70%.
Contact your OMRON sales representative for more detailed information on other operating environments.
JOPERATING CHARACTERISTICS
1-Conduit Models
Part number D4D-1520R
D4D-2520R
D4D-3520R
D4D-1A20R
D4D-2A20R
D4D-3A20R
D4D-1521R
D4D-2521R
D4D-3521R
D4D-1A21R
D4D-2A21R
D4D-3A21R
(SeeNote1)
D4D-1527R
D4D-2527R
D4D-3527R
D4D-1A27R
D4D-2A27R
D4D-3A27R
(SeeNote2)
D4D-1531R
D4D-2531R
D4D-3531R
D4D-1A31R
D4D-2A31R
D4D-3A31R
D4D-1532R
D4D-2532R
D4D-3532R
D4D-1A32R
D4D-2A32R
D4D-3A32R
D4D-1562R
D4D-2562R
D4D-3562R
D4D-1A62R
D4D-2A62R
D4D-3A62R
D4D-1572R
D4D-2572R
D4D-3572R
D4D-1A72R
D4D-2A72R
D4D-3A72R
LF max. 6.37 N 5.59 N 5.39 N 10.79 N 10.79 N 7.35 N 7.85 N
LT max. 55°55°55°4.5 mm 4.5 mm 7mm 7mm
PT1 max.
(SeeNote3) 18°to 27°18°to 27°18°to 27°2mm 2mm 4mm 4mm
PT2
(SeeNote4) 44°44°44°2.9 mm 2.9 mm 5.2 mm 4.3 mm
OP --- --- --- 34±0.5 mm 44.4±0.8 mm 53±0.8 mm 27±0.8 mm
TT
(SeeNote5) 70°70°70°6mm 6mm 9mm 9mm
POF min.
(see note 6) 19.61 N 19.61 N 19.61 N 19.61 N 19.61 N 19.61 N 19.61 N
POT min.
(SeeNote6) 50°50°50°3.2 mm 3.2 mm 5.8 mm 4.8 mm
Note: 1. The operating characteristics of these Switches were measured with the roller lever set at 30 mm.
2. The operating characteristics of these Switches were measured with the roller lever set at 31 mm.
3. These PT1 values are possible when the NC contacts are OFF.
4. These PT2 values are possible when the NO contacts are ON (applicable to D4D-jR models with 1NC and 1NO contact
each).
5. Reference value.
6. POT (positive opening travel) and POF (positive opening force) are required values for positive opening.

onlinecomponents.com
D4D-R
6
2-Conduit Models
Part number D4D-5520R
D4D-6520R
D4D-5A20R
D4D-6A20R
D4D-5521R
D4D-6521R
D4D-5A21R
D4D-6A21R
D4D-5527R
D4D-6527R
D4D-5A27R
D4D-6A27R
D4D-5531R
D4D-6531R
D4D-5A31R
D4D-6A31R
D4D-5532R
D4D-6532R
D4D-5A32R
D4D-6A32R
D4D-5562R
D4D-6562R
D4D-5A62R
D4D-6A62R
D4D-5572R
D4D-6572R
D4D-5A72R
D4D-6A72R
LF max. 6.37 N 5.59 N 5.39 N 10.79 N 10.79 N 7.35 N 7.85 N
LT max. 55°55°55°4.5 mm 4.5 mm 7mm 7mm
PT1 max.
(SeeNote3) 18°to 27°18°to 27°18°to 27°2mm 2mm 4mm 4mm
PT2
(SeeNote4) 44°44°44°2.9 mm 2.9 mm 5.2 mm 4.3 mm
OP --- --- --- 34±0.5 mm 44.4±0.8 mm 53±0.8 mm 27±0.8 mm
TT
(SeeNote5) 70°70°70°6mm 6mm 9mm 9mm
POF min.
(SeeNote6) 19.61 N 19.61 N 19.61 N 19.61 N 19.61 N 19.61 N 19.61 N
POT min.
(SeeNote6) 50°50°50°3.2 mm 3.2 mm 5.8 mm 4.8 mm
Note: 1. The operating characteristics of these Switches were measured with the roller lever set at 30 mm.
2. The operating characteristics of these Switches were measured with the roller lever set at 31 mm.
3. These PT1 values are possible when the NC contacts are OFF.
4. These PT2 values are possible when the NO contacts are ON (applicable to D4D-jR models with 1NC and 1NO contact
each).
5. Reference value.
6. POT (positive opening travel) and POF (positive opening force) are required values for positive opening.
Nomenclature
Head
With roller lever models, the direction of the switch head can
be adjusted to any of the four directions by loosening the
roller lever switch screws at the four corners of the head.
Safety-Oriented Lever Setting
Grooves which engage the lever every 90°are cut in the
operation indicator disk to prevent the lever from slipping
against the rotary shaft.
Cover
The cover, with a hinge on its lower part, can be opened by
removing the screw of the cover, which ensures ease of
maintenance and wiring.
Built-in Switch
Has a positive opening mechanism separating the con-
tacts when the contacts are welded.
Conduit
Wide switch variations.
Pg13.5: 1-conduit, 2-conduit models
G1/2: 1-conduit, 2-conduit models
1/2-14NPT: 1-conduit models
Reset Head
The direction of the reset head can be adjusted to any of
the four directions.
Note: The D4D-jRusesNBR.

onlinecomponents.com
D4D-R
7
Operation
JCONTACT FORM
Model Contact Diagrams Remarks
D4D-j5jN1NC/1NO
(slow-action) 11 12
23 24
Zb 11-12
23-24
Stroke
ON
Only NC contact 11-12 has an
approved positive opening
mechanism.
Terminals 11-12 and 23-24 can be
used as unlike poles.
D4D-jAjN2NC
(slow-action) 11
21
12
22
Zb 11-12
21-22
Stroke
ON
NC contacts 11-12 and 21-22 have an
approved positive opening
mechanism.
Terminals 11-12 and 21-22 can be
used as unlike poles.
Note: Terminals are numbered according to EN50013 and contacts are marked according to EN60947-5-1.
JPOSITIVE OPENING MECHANISM
1NC/1NO Contact (Slow-Action) 2NC Contact (Slow-Action)
Contact spring
Return spring
Fixed contact (NC)
Movable contact
Plunger
Fixed contact (NO)
Contact spring
Return spring
Fixed contact (NC)
Movable contact
Plunger
Only the NC contacts have a positive
opening function.
When metal deposition occurs, the contacts
are separated from each other by pushing in
the plunger.
Conforms to EN60947-5-1 Positive Opening
Both NC contacts have a positive opening
function.
When metal deposition occurs, the contacts
are separated from each other by pushing in
the plunger.
Conforms to EN60947-5-1 Positive Opening
Note: The Switches are marked with “ ” indicating approval for the positive opening mechanism.

onlinecomponents.com
D4D-R
8
Dimensions
Unit: mm
Note: 1. Unless otherwise specified, a tolerance of ±0.4 mm applies to all dimensions.
2. The minimum number of screw threads is five when the Pg13.5 conduit is used and four when the G1/2 conduit is used.
JSWITCHES
1-Conduit Models
Roller Lever
D4D-1520R
D4D-2520R
D4D-3520R
D4D-1A20R
D4D-2A20R
D4D-3A20R
Adjustable Roller Lever
D4D-1521R
D4D-2521R
D4D-3521R
D4D-1A21R
D4D-2A21R
D4D-3A21R
Adjustable Roller Lever
(Rubber Roller Lever)
D4D-1527R
D4D-2527R
D4D-3527R
D4D-1A27R
D4D-2A27R
D4D-3A27R
17.5 dia. x 6.8
resin roller
R2.15±0.05
mounting holes
depth: 5
14 dia.
SeeNote2,
referring to
the min. no.
of screw
threads.
Two. 4 +0.15
0dia. holes
20.5 x 20.5
17.5 dia. x 6.8
resin roller
R2.15±0.05
mounting holes
depth: 5
14 dia.
Two. 4 +0.15
0dia. holes
20.5 x 20.5
R20to65
R2.15±0.05
mounting holes
14 dia.
20.5 x 20.5
R31to65
50 dia. x 8
rubber roller
depth: 5
Two. 4 +0.15
0dia. holes
See Note 2,
referring to
the min. no.
of screw
threads.
SeeNote2,
referring to
the min. no.
of screw
threads.

onlinecomponents.com
D4D-R
9
Plunger
D4D-1531R
D4D-2531R
D4D-3531R
D4D-1A31R
D4D-2A31R
D4D-3A31R
Roller Plunger
D4D-1532R
D4D-2532R
D4D-3532R
D4D-1A32R
D4D-2A32R
D4D-3A32R
One-way Roller Arm Lever
(Horizontal)
D4D-1562R
D4D-2562R
D4D-3562R
D4D-1A62R
D4D-2A62R
D4D-3A62R
One-way Roller Arm Lever
(Vertical)
D4D-1572R
D4D-2572R
D4D-3572R
D4D-1A72R
D4D-2A72R
D4D-3A72R
14 dia.
R2.15±0.05
mounting holes
6dia.
20.5 x 20.5
20.5 x 20.5
9.5 dia. x 5
resin roller
R2.15±0.05
mounting holes
depth: 5
Two. 4 +0.15
0dia. holes
14 dia.
depth: 5
Two. 4 +0.15
0dia. holes
12 dia. x 5
resin roller
R2.15±0.05
mounting holes
14 dia.
12 dia. x 5
resin roller
14 dia.
R2.15±0.05
mounting holes
depth: 5
Two. 4 +0.15
0dia. holes
depth: 5
Two. 4 +0.15
0dia. holes
See Note 2,
referring to
the min. no.
of screw
threads.
See Note 2,
referring to
the min. no.
of screw
threads.
SeeNote2,
referring to
the min. no.
of screw
threads.
SeeNote2,
referring to
the min. no.
of screw
threads.

onlinecomponents.com
D4D-R
10
2-Conduit Models
Roller Lever
D4D-5520R
D4D-6520R
D4D-5A20R
D4D-6A20R
Adjustable Roller Lever
D4D-5521R
D4D-6521R
D4D-5A21R
D4D-6A21R
Adjustable Roller Lever
(Rubber Roller Lever)
D4D-5527R
D4D-6527R
D4D-5A27R
D4D-6A27R
17.5 dia. x 6.8
resin roller
14 dia.
R2.15±0.05
mounting holes Cap
25 dia.
20.5 x 20.5
17.5 dia. x 6.8
resin roller
R20to65
R2.15±0.05
mounting holes
depth: 5
Two. 4 +0.15
0dia. holes
Cap
25 dia.
20.5 x 20.5
14 dia.
depth: 5
Two. 4 +0.15
0dia. holes
R2.15±0.05
mounting holes
depth: 5
Two. 4 +0.15
0dia. holes
Cap
25 dia.
14 dia.
R31to65
50 dia. x 8
rubber roller
20.5 x 20.5
See Note 2,
referring to
the min. no.
of screw
threads.
SeeNote2,
referring to
the min. no.
of screw
threads.
SeeNote2,
referring to
the min. no.
of screw
threads.

onlinecomponents.com
D4D-R
11
JLEVERS
Refer to the following for the angles and positions of the dogs.
Roller Lever
D4D-jj20R Adjustable Roller Lever D4D-jj21R Adjustable Roller Lever
(Rubber Roller Lever)
D4D-jj27R
Sealed Plunger
D4D-jj31R
Roller Plunger
D4D-jj32R
One-Way Roller Arm Lever
(Horizontal)
D4D-jj62R
One-Way Roller Arm Lever
(Vertical)
D4D-jj72R
Dog
20 min.
10 min.
5min.
Dog
Dog
40 min.
10 min.
15 min.
45 min.
10 min.
25 min.
Dog
31 min.
Dog
Dog
20 min.
10 min.
Dog
41 min.
Dog
20 min.
30 max.
5.0 min.
10 min. Dog
10 min.
5min.
20 min.
Precautions
!CAUTION
Do not use metal connectors or conduits with this Switch. Rigid
connectors and conduits may damage the Switch. A broken
conduit hole may cause an electrical shock hazard.
If the D4D-jR is applied to an emergency stop circuit or safety
circuit for prevention of injury, use the D4D-jR model that has
an NC contact equipped with a force-separation mechanism and
make sure that the D4D-jR operates in the positive mode. In
addition, secure the D4D-jR with screws or equivalent parts that
are tightened in a single direction so that the D4D-jR cannot be
easily removed. Then provide a protection cover for the D4D-jR
and post a warning label near the D4D-jR.
Ensure that the actuator is pushed into the lock position by, for
example, setting up a dog. Not doing so may result in the
actuator becoming unlocked and causing an accident.
When the Limit Switch locks due to a fault in the system, be sure
to reset it manually before resupplying power after confirming the
safety of the system.
Be sure to connect a fuse with a breaking current 1.5 to 2 times
larger than the rated current to the Limit Switch in parallel, to
protect it from damage due to short-circuiting.
When using the Limit Switch for the EN ratings, use the gI or gG
10-A fuse.
Do not use the Limit Switch as a stopper.
Actuation of the Limit Switch over a long time may cause Switch
parts to deteriorate, and a releasing failure may result. Be sure to
check the condition of the Limit Switch regularly.
When using the Limit Switch as a safety component, be sure to
check the system design for both operational and circuit safety.

onlinecomponents.com
D4D-R
12
JCORRECT USE
Operating Environment
The Limit Switch is intended for indoor use only. Using the Limit
Switch outdoors may result in a malfunction.
Correct Tightening Torque
A loose screw may result in a malfunction. Be sure to tighten
each screw to the proper tightening torque as shown below.
No. Type Torque
1Terminal screw 0.59 to 0.78 N Sm
2Cover mounting
screw 0.78 to 0.88 N Sm
3Head mounting
screw 0.78 to 0.88 N Sm
4Lever mounting
screw 1.57 to 1.77 N Sm
5Switch mounting
screw (M4) 0.49 to 0.69 N Sm
6Connector 1.77 to 2.16 N Sm
1.37 to 1.77 N Sm (see note)
7Cap screw 1.27 to 1.67 N Sm
Note: This applies to the 1/2-14NPT connector.
Mounting
FastentheSwitchwithtwoM4Allen-headboltsandwashers.
Provide a stud with a diameter of 4-0.05/-0.15 and a height of 4.8
mm max. at two places as shown below so that the Switch is
firmly fixed at four points.
Mounting hole
Mounting surface
Hole for stud insertion
4--0.05
--0.15 dia. height, 4.8 max.
2-Conduit
4--0.05
--0.15 dia. height, 4.8 max.
4--0.05
--0.15 dia. height, 4.8 max.
Standard 1-Conduit
Mounting Holes/Studs
Changing the Head Direction
If the head direction has been changed, check the torque of each
screw and make sure that the screws are free of foreign
substances, and that each screw is tightened to the proper
torque.
dz dia. 3.7
Ddia. 4.5
B: 7.0
L: 20.2
F: 7.7
ℓ:9.0(mm)
Ddia.
dz dia.
Wiring
Do not connect the bare lead wires directly to the terminals,
but be sure to connect each of them by using an insulation
tube and M3.5 round solderless terminals and tighten each
terminal screw within the specified torque range.
Theproperleadwireis20to14AWG(0.5to2.5mm
2)in
size.
To avoid an electrical shock, do not touch the terminals while
power is being supplied.

onlinecomponents.com
D4D-R
13
Perform wiring for the crimp terminals in the orientation shown
below, so that they do not rest on the case or the cover.
Crimp-style terminal
Terminal screw
Correct Incorrect
Crimp-style terminal
Crimp-style terminal
Correct
Incorrect
Processing the Conduit Opening
Tighten the connector to a torque of 1.8 to 2.2 N Sm (1.37 to
1.77 N Sm if it is a 1/2-14NPT). Excessive tightening torque may
damage the casing. To satisfy IP65, apply sealing tape to the
connector conduit. The diameter of the cable must be suited to
the corresponding connector.
Insert a cap screw provided with the D4D-jR into any unused
conduit opening of the D4D-jR and tighten the cap screw to a
torque of 1.27 to 1.67 N Sm.
Recommended Connector
Conduit size Manufacturer Model Applicable
cable diameter
G1/2 OMRON SC-6 7.5to9.0mm
LAPP
(see note 1) ST-PF1/2 5380-1002 6.0to12.0mm
Ohm Denki
(see note 2) OA-W1609 7.0to9.0mm
Pg13.5 LAPP
(see note 1) ST13.5 5301-5030 5.0to12.0mm
1/2-14NPT LAPP
(see note 1) ST-NPT1/2 5301-6030 6.0to12.0mm
Note: 1. LAPP is a German manufacturer.
2. Ohm Denki is a Japanese manufacturer.
Maintenance and Repairs
The user must not maintain or repair equipment incorporating any
D4D-jR model. Contact the manufacturer of the equipment for
any maintenance or repairs required.
Rubber Roller Lever Models
With rubber roller lever models, the rubber roller may turn white
with the passage of time, but this will not affect the quality of
operation.
OMRON ON-LINE
Global - http://www.omron.com
USA - http://www.omron.com/oei
Canada - http://www.omron.ca
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS. To convert millimeters into inches, divide by 25.4
Cat. No. GC SAFETY-2 Printed in USA
OMRON CANADA, INC.
885 Milner Avenue
Toronto, Ontario M1B 5V8
416-286-6465
OMRON ELECTRONICS LLC
One Commerce Drive
Schaumburg, IL 60173
847-843-7900
For US technical support or other inquiries:
800-556-6766
2/03 Specifications subject to change without notice
