Rope Pull Emergency Stop Switch
ER6022
• Long rope spansup to 80 m meansfewer number
of switchesrequired per application
•Tension indicator—the tension indicator makesthe
system easy to set up and to maintain the proper
rope tension
• Contact arrangementsof 2 N/C + 1 N/O or 3 N/C
• IP67 (NEMA 6) enclosure enablesthe ER6022
switch to withstand water washdown cleaning
•Heavy-duty housing—the die-cast housing and
stainless steel eye nut makesthe ER6022 suitable
for demanding industrial applications
•Reset button—the blue reset button must be
pushed in order to return to “machine run” condition
following switch actuation by apulled or slacked
rope
• Long life—the ER6022 switch isdesigned for amin-
imum of one million actuations
•Vibration tolerant—the snap-acting switch contacts
protect against nuisance tripping due to vibration
•Indicator beacon—the optional dual indicator bea-
con, available in 24 VDC, can be wired to flash red
to indicate atripped switch or glow aconstant green
to indicate aproperly reset switch
•E-stop button—the ER6022 has two mounting posi-
tionswhere the optional E-stop button may be in-
stalled; the E-stop button may be added or replaced
in the field
Operation
Blue Reset Button
A blue reset button isprovided to easily return
the unit back to itsmachine-run position after
actuation.
Emergency Push Button
The emergency push button may
be installed or repositioned in the
field. The ER6022 has two possi-
ble mounting positionsfor the
emergency stop button.
Installation Hardware Available
RK Rope Tension Kit
The RK Rope Tension Kit comes
with all of the required hardware
for most installations. A spring is
required as shown in the installa-
tion example below.
Installation Hardware
Individual hard-
ware itemsmay
be purchased for
specific installa-
tion requirements.
Te n sion/Gripper
Spring
Turnbuckle
Eyebolt
Thimble
Double Loop Clip
Ro
p
e Pulle
y
E54E-EN-01+ER6022+Datasheet.fm Seite 1 Freitag, 12. Oktober 2007 12:57 12

2 Rope Pull Emergency Stop Switch
For the Latest Information
On the Internet: www.omron-industrial.com or www.sti.com
Contact Arrangements
Mounting Specification
Note: Some installationsmay require aER6022 on each end.
Applications
Typical applicationsare on conveyor systemsand
across rotating machinery, and around hazardous
areas.
Ordering information
Rope Pull Emergency Stop Switch
Accessories
E-Stop Indicator Beacon ContactsWiring Entry Model
Not included Not included 2 N/C + 1 N/O 3 x M20 ER6022-021M
Not included Not included 3 N/C 3 x M20 ER6022-030M
Not included Included (24 VDC) 2 N/C + 1 N/O 3 x M20 ER6022-021ML
Not included Included (24 VDC) 3 N/C 3 x M20 ER6022-030ML
Included Not included 2 N/C + 1 N/O 3 x M20 ER6022-021ME
Included Not included 3 N/C 3 x M20 ER6022-030ME
Included Included (24 VDC) 2 N/C + 1 N/O 3 x M20 ER6022-021MEL
Included Included (24 VDC) 3 N/C 3 x M20 ER6022-030MEL
Item Model
Replacement Lid SM06-SL500
Replacement Lid/LED SM06-SL510
Rope Kit, 5 m, Stainless Steel RK5
Rope Kit, 10 m, Stainless Steel RK10
Rope Kit, 20 m, Stainless Steel RK20
Rope Kit, 50 m, Stainless Steel RK50
Rope Kit, 80 m, Stainless Steel RK80
Rope Only, 5 m R5M
Rope Only, 10 m R10M
0 mm
11/12
21/22
33/34
2NC + 1NO VersionsRope Slack Tension Range Rope Pulled
Contact Open Contact Closed
11/12
21/22
31/32
3NC VersionsRope Slack Tension Range Rope Pulled
14.5 mm 17.0 mm3.5 mm
ER6022
≤80 m
≤500 mm ≤500 mmEvery ≤3 m Every ≤3 m
Wall
Eyebolt Support Safety Spring
Tensioner Gripper
E54E-EN-01+ER6022+Datasheet.fm Seite 2 Freitag, 12. Oktober 2007 12:57 12

3ER6022
ER6022
For the Latest Information
On the Internet: www.omron-industrial.com or www.sti.com
Specifications
Note: The safety contactsof the Omron STI switchesare described as normally closed (N/C)—i.e., with the rope properly tensioned and the
machine able to be started.
Dimensions
Rope Only, 20 m R20M
Rope Only, 50 m R50M
Rope Only, 100 m R100M
Rope Only, 126 m R126M
Tensioner Gripper, Stainless Steel SM06-TG00
Eye Bolt Stainless Steel, 8 per pack SM06-EB10
Double Loop Clip, Stainless Steel, 4 per pack SM06-DL20
Thimble Stainless Steel, 4 per pack SM06-THSS
Turnbuckle, Stainless Steel SM06-TB30
Spring, Stainless Steel SM06-SP50
Rope Pulley, Stainless Steel SM06-RPSS
E-Stop MechanismSM06-ES60
Electrical
Contact Configurations2 N/C + 1 N/O, 3 N/C
Safety Contacts2 N/C, 3 N/C
Switching Ability AC: 240 V–3 A, 120 V–6 A, Inductive,
DC: 24 V–2.5 A, Inductive
Auxiliary Contacts1 N/O
Max Switching Current/Volt/Amp 240 V/720 VA
Minimum Current 5 V, 5 mA DC
Electrical Life 1,000,000 minimum
LED Indicator Beacon 24 VDC
Mechanical
Mounting Any position
Mounting Hardware 4 x M5 screws
Actuator Travel for Positive Opening See diagramson previouspage
Max Rope Span80m
Operation Force < 125 N
Tensioning Force to Run Position 130 N typical
Case Material Die-cast aluminum alloy
Eye Nut MaterialStainless steel
Wiring Entry 3 x M20
Weight 880 g
Color Yellow
Mechanical Life 1,000,000 minimum
Environmental
Protection IP67 (NEMA 6)
Operating Temperature -25 to 80°C
Cleaning Water washdown
Compliance StandardsIEC947-5-1, IEC947-5-5, EN418, UL508, BS5304
Approvals/ListingsCE marked for all applicable directives, UL and C-UL
Item Model
897
32 96
23
40
49
63
10
4 mtg holesclearance
for M5 screws
222 239
MIN - MAX
86
54 23
E54E-EN-01+ER6022+Datasheet.fm Seite 3 Freitag, 12. Oktober 2007 12:57 12

4 Rope Pull Emergency Stop Switch
For the Latest Information
On the Internet: www.omron-industrial.com or www.sti.com
Safety precautions
Operating instructions
Installation must be in accordance with the following steps and stated
specifications and should be carried out by suitably competent personnel.
Adherence to the recommended maintenance instructions forms part of
the warranty.
!WARNING Do not defeat, tamper, remove or bypass this unit.
Severe injury to personnel could result.
W
!WARNING
1.Installation of all Safety Rope Switch systems must be in accordance
with a risk assessment for the individual application. Installation must
only be carried out by competent personnel and in accordance with
these instructions.
2.Rope support eyebolts must be fitted at 2.5 m. min. to 3 m. max. inter-
vals along all rope lengths between switches. The rope must be
supported no more than 500 mm from the switch eyebolt or Safety
Spring (if used). It is important that this first 500 mm is not used as part
of the active protection coverage.
3. M5 mounting bolts must be used to fix the switches. Tightening torque
for mounting bolts to ensure reliable fixing is 4 Nm. Tightening torque for
the lid screws, conduit entry plugs and cable glands must be 1.5 Nm to
ensure IP seal. Only use correct sizing glands for conduit entry and
cable outside diameter.
4. Tensioning of rope is achieved by use of tensioner / gripper assemblies.
Upon installation, tension to mid-position as indicated by the red arrows
in the viewing window of each switch. Check operation for all switches
and the control circuits by puling the rope at various locations along the
active protection area and resetting each switch by depressing the Blue
Reset button. Ensure each time that the switches latch off and require
manual resetting by depressing the Blue Reset button. Increase the sys-
tem tension further, if required, depending upon the checks along the
active length of coverage. If fitted with a Mushroom type E-Stop button
(Red) then test and reset each switch to ensure function of control cir-
cuits. Typical operational conditions for successful operation of system
is less than 75 N. pulling force and less than 150 mm deflection of rope
between eyebolt supports. If the optional LED is fitted but is not used,
ensure that the conductors remain coiled and tied to the tie hole in the
LED flange.
5. Every week: Check correct operation of system at locations along all
coverage length. Check for nominal tension setting, re-tension rope if
necessary. Every 6 months: Isolate power and remove cover. Check
screw terminal tightness and check for signs of moisture ingress. Never
attempt to repair any switch.
(120VAC)
(120VAC) Green
Red (common ) Black
Red
Green
Black
(+24VDC)
(+24VDC)
Optional 24 VDC Indicator Beacon
When +24VDC is applied to the red wire, the beacon will illuminate red
and flash.
When +24 VDC is applied to the green wire, the beacon will illuminate
green.
Optional 120 VAC Indicator Beacon
When +120VAC is applied to the red wire, the beacon will illuminate red
and flash.
When +120 VAC is applied to the green wire, the beacon will illuminate
green.
(0 V)
Tension Indicator
Indicator shown with steel rope properly adjusted.
In the interest of product improvement, specificationsare subject to change without notice.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimetersinto inches, multiply by 0.03937. To convert gramsinto ounces, multiply by 0.03527.
Cat. No. E54E-EN-01
